- Page 1 User Manual Smart Residential Energy Storage System Model No.: PO1-AAW1 ICV1.0.0...
-
Page 2: Table Of Contents
Safety Instructions ....................... 3 Personal Safety ......................3 Working Area Safety ....................3 Cleaning and Maintenance ..................3 Warnings ........................4 About iCAN ..........................4 Overview ........................5 Features ........................5 Specification ......................6 Parts and Functions ....................7 Installation ..........................9 Connect Safety Connectors .................. -
Page 3: Preface
Thank you for purchasing POMCube iCAN, a smart residential energy storage system. In order to use your device safely, efficiently and effectively, please read the User Manual thoroughly and follow the instructions provided before using your iCAN. Please keep this User Manual for future reference. -
Page 4: Fcc Compliance Statement
Declaration of Conformity Model Number: PO1-AAW1 Trade Name: POMCube Responsible Party: POMCube Inc. Address: 19363 Brockton Ln Saratoga, CA 95070 USA General Contact: www.pomcube.com This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. -
Page 5: Safety Instructions
Do not handle the device and its components with wet hands. Failure to observe this may result in electric shocks. Always use genuine parts and accessories provided by POMCube Inc. Using parts and accessories other than the provided one may cause short circuits or overheating, and result in electric shock or fire. -
Page 6: Warnings
Installers must ensure that 20cm separation distance will be maintained between the device(excluding its handset) and users. POMCube disclaims all liability for any accidents or damage caused by using the product in the ways that are not described in this User Manual or using non-genuine parts or accessories. -
Page 7: Overview
Emergency Backup In the event of a power outage, iCAN can power your critical home devices with the stored electricity through its smart plugs. The maximum load is no more than 500W (AC 120v / 60Hz / Max 4.1 A). -
Page 8: Specification
4.3 Specification Model No. PO1-AAW1 Charge Input power supply AC 90 V - 130 V / 60 Hz / Max. 10.0 A Output power DC 90 V - 130 V supply Input power supply DC 90 V - 130 V/ Max. 5.0 A Discharge Output power AC 120 V/ 60 Hz / Max. -
Page 9: Parts And Functions
The real output power does not change when the device responds to a time schedule; The device has no reactive power output. The reactive power output will not change with the active power changes. 4.4 Parts and Functions Note: The images shown in this User Manual are for reference only and may slightly differ from the actual product. - Page 10 Indicator Sensors These sensors are not used for the time being. It is planned for the future versions of iCAN. The bottom plate is used for supporting the device. It is fixed to Bottom Plate the device with screws. Professional tool is needed to disassemble it from the device.
-
Page 11: Installation
5. Installation 5.1 Connect Safety Connectors Before use, you need connect the safety connector B on the back of the device with the safety connector A. To connect the two connectors: 1) Properly align the key in safety connector B and the slot in safety connector A. 2) Once they are aligned, finger-tighten the knurled knob to hold the connection firmly in place. -
Page 12: Reset The Fuse
Warnings: Never attempt to disassemble the safety connectors by yourself. Please hire a trained technician to disassemble the connectors. Do not disassemble safety connectors when the device is loaded. Please always press R/S button before disassembling the safety connectors, make sure ... -
Page 13: Reboot And Shut Down The Device
Wi-Fi setting, and need re-configure your network. 6.4 Wireless Charging The top cover of iCAN is a wireless charging pad compatible with WPC wireless charging standard, with the output of DC 5V/1A. To use the wireless charging function, please put your phone on the right position on the pad of the device and make sure that the wireless charging receiver is placed directly on top of the charging icon, as shown in the following image. -
Page 14: Getting Started With Peakshaver
The device is designed to be monitored and managed by the specified app PeakShaver. Please download PeakShaver first. For detailed operations of the app, please refer to the PeakShaver User Guide for iCAN available in About from the Left Menu of the app. 7.1 Download PeakShaver Scan the QR code below to download PeakShaver. -
Page 15: Monitor Real-Time Electricity Data
QR code or input the device code. You can find the QR code and the device code on the label pasted on the rear of the device. 1) Setup the Wi-Fi. iCAN only can be connected to 2.4 GHz Wi-Fi, make sure that your router supports 2.4GHz Wi-Fi signal. -
Page 16: Troubleshooting
Select 2.4GHz when you are setting your Wi-Fi. 2.4GHz Wi-Fi. router. Please consult your router supplier or POMCube Service Center for technical support. Unable to connect to Wi-Fi Your router may not work Check your router working status. If the... -
Page 17: Warranty And Service
Thank you for purchasing POMCube iCAN. POMCube values your business and always attempts to provide you the very best quality of service. POMCube warrants to the purchaser of the product in its original sealed packaging that the product is free from defects in material and workmanship, for the limited warranty period, which duration is seven years, beginning on the date the product was purchased in its original sealed packaging. -
Page 18: Service
Customer does not provide required proof of purchase POMCube reserves the right of final decision in all warranty cases. POMCube may interpret and revise the content of this warranty terms. 9.2 Service If you have any questions, please contact our Service Center line or your local distributor, or visit our website at www.pomcube.com. - Page 19 POMCube Inc. __________________________________________________________________________________ © 2016 POMCube Inc. All rights reserved. For more information, please visit www.pomcube.com...
