ASSEMBLY INSTRUCTIONS
Important Safety Instructions:
Please read all instructions before beginning assembly
Please make sure receive all the parcels to start the assembly
For your safety and convenience,assembly by two people is recommended
Use the parts and hardware lists to identify and separate each of the components included
Save all packing materials until assembly is completed to avoid the accidental discarding of
smaller parts or hardware
Assembly attention:
Please pay attention to the alignment of the holes during installation.
Please insert the screws in the right angle.
This product contains parts that can be damaged if incorrectly assembled.
Please follow instructions carefully.
ITEM#:
BAC001
THANK YOU FOR PURCHASING
1/9
