ASSEMBLY INSTRUCTIONS
ITEM#: AK3491
Important Safety Instructions:
● Please read all instructions before beginning assembly
● Please make sure receive all the parcels to start the assembly
● For your safety and convenience,assembly by two people is recommended
● Use the parts and hardware lists to identify and separate each of the components included
● Save all packing materials until assembly is completed to avoid the accidental discarding
of smaller parts or hardware
THANK YOU FOR PURCHASING
