- Page 1 INSTRUCTION MANUAL 4-Door Elevated Storage Cabinet SKY9544 + SKY9545 + SKY9546 Ver. 1...
-
Page 2: Tools Required
145.3 LBS 61.7 LBS 26.4 LBS 15.4 LBS 2 PERSON UP TO 60 MIN. TOTAL CABINET TOP BOTTOM BOARD SHELF (EACH) ASSEMBLY ASSEMBLY CAPACITY CAPACITY (EACH) CAPACITY CAPACITY NOTICE Please retain these instructions for future reference. • Please do not exceed the weight limitations of this item. •... - Page 3 HARDWARE M6 x 50mm MOUNTING M4 x 45mm M3.5 x 12mm BARREL BOLT HARDWARE SCREW SCREW & NUT SET 4 PCS 2 SETS 2 PCS 48 PCS CENTRAL LEG BACK SCREW DOOR FOOT SLIDER FOOT & GUIDE HANDLE 1 PC 16 PCS 4 PCS 4 PCS...
- Page 4 PARTS RIGHT DOOR I LEFT DOOR II RIGHT DOOR II 1 PC 1 PC 1 PC BASE SIDE BASE FRAME LEG I FRAME CONNECTOR 2 PCS 2 PCS 2 PCS LEG II BACK BOARD TOP FRAME CONNECTOR 2 PCS 4 PCS 2 PCS BACK DIVIDER CENTRAL LEG...
- Page 5 PRODUCT ASSEMBLY Locate the part A cabinet top and insert six part 1 cam bolts, set aside. Locate the part C and part D cabinet sides and insert three part 1 cam bolts into each, six cam bolts total. Locate the part E cabinet central panel and insert three part 1 cam bolts into each side of the panel, six cam bolts total.
- Page 6 PRODUCT ASSEMBLY Insert two part 2 cam locks into one part P back divider, then attach the divider to the part D cabinet left side. Turn the cam locks to secure. Insert one part 2 cam lock and one part 3 dowel into the part O top frame connector, then attach the frame connector to the part D cabinet left side.
- Page 7 PRODUCT ASSEMBLY Insert two part 2 cam locks into one part P back divider, then attach the divider to the part E cabinet central panel. Turn the cam locks to secure. Insert one part 2 cam lock into the part O top frame connector, then attach the frame connector to the part E cabinet central panel.
- Page 8 PRODUCT ASSEMBLY Slide two part N back boards into the designated slots between the part E cabinet central panel and the part D and part C cabinet sides. Insert two part 3 dowels each into the part D cabinet left side, part C cabinet right side, part E cabinet central panel, and both the part O top frame connectors, ten dowels total.
- Page 9 PRODUCT ASSEMBLY Insert six part 2 cam locks into the part D and part C cabinet sides and the part E cabinet central panel, two cam locks per side. Attach the part A cabinet top to the part D and part C cabinet sides, and part E cabinet central panel, then turn the cam locks to secure.
- Page 10 PRODUCT ASSEMBLY Locate the part L and part M legs and insert two part 1 cam bolts each, eight cam bolts total. Locate the part B cabinet bottom and insert twelve part 1 cam bolts. Locate the part Q central leg, then screw the part 13 central leg foot into the bottom. Attach the part Q central leg to the part B cabinet bottom with two part 11 screws.
- Page 11 PRODUCT ASSEMBLY Flip the assembly upside down, then insert two part 3 dowels each into the part D and part C cabinet sides, and the part E cabinet central panel, six dowels total. Attach the part B cabinet bottom to the part D and C cabinet sides and the part E cabinet central panel with six part 4 screws.
- Page 12 PRODUCT ASSEMBLY Locate the two part K base frame connectors then insert four part 9 barrel nuts, two nuts per connector, taking care to align the fastener hole with the predrilled holes in the sides of the frame connector. Attach the part L and part M legs to the part K base frame connectors with four part 9 barrel bolts.
- Page 13 PRODUCT ASSEMBLY Insert four part 2 cam locks each into the part K base frame connectors, eight cam locks total. Insert two part 2 cam locks each into the part J base side frames, four cam locks total. Attach the base frame assembly to the part B cabinet bottom, then turn the cam locks to secure. Place four part 16 foot sliders onto the bottom of the part L &...
- Page 14 PRODUCT ASSEMBLY Locate the part F & I doors, then attach two part 15 door handle with four part 6 screws, two screws per door handle. Attach two part 7 hinges to each door with eight part 12 screws, two screws per hinge. Locate the part G &...
- Page 15 PRODUCT ASSEMBLY Stand the cabinet assembly upright, then attach part F & I doors by securing the part 7 hinges to the cabinet side with sixteen part 12 screws, four screws per hinge. Repeat to attach the part G & H doors.
- Page 16 PRODUCT ASSEMBLY Insert eight part 5 shelf supports into the part D & part C cabinet sides and part E cabinet central panel at your desired height. NOTE: Be sure the shelf supports sit parallel to properly install the shelf. Slide two part R shelves onto the part 5 shelf supports.
- Page 17 PRODUCT ASSEMBLY Secure the part N back boards with sixteen part 14 back screws and guides. Attach the part 10 mounting straps to the part A cabinet top with the included mounting screw.
-
Page 18: Wall Mounting
WALL MOUNTING Select an appropriate location, then mark two spaces on the wall using the part 10 mounting straps as guides. Use a drill on the marked spaces. Insert two included wall anchors into the new holes in the wall. Overlap the holes with the mounting straps, then attach the cabinet to the wall by drilling two part 4 wood screws through the part 10 mounting straps and into the wall anchors. -
Page 19: Door Alignment
DOOR ALIGNMENT If your door is too low or too high... door Loosen the height screws, then move the door up or down to make it level. If you need to adjust the depth of the doors... door Adjust the in-and-out screws until the door is aligned with the side of cabinet. If the space between your doors is o ... -
Page 20: Help Center
All returns must be shipped back to the Best Choice Products Return Center at the customer’s expense. If the reason for return is a result of an error by Best Choice Products then Best Choice Products will provide a pre-paid shipping label via email. Boxes for return shipping will not be provided by Best Choice Products, and is the customer’s responsibility to either use the original shipping boxes or purchase new boxes.
