Best Choice Products SKY9403 Instruction Manual

Arched storage cabinet
Hide thumbs

Advertisement

Table of Contents

INSTRUCTION
MANUAL
Arched Storage Cabinet
SKY9403 + SKY9405 + SKY9406
Ver. 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SKY9403 and is the answer not in the manual?

Questions and answers

Related Manuals for Best Choice Products SKY9403

Summary of Contents for Best Choice Products SKY9403

  • Page 1 INSTRUCTION MANUAL Arched Storage Cabinet SKY9403 + SKY9405 + SKY9406 Ver. 1...

  • Page 2: Tools Required

    134.2 LBS 28.6 LBS 24.2 LBS 28.6 LBS 24.2 LBS 28.6 LBS 2 PERSON UP TO 60 MIN. TOTAL TOP SHELF UPPER SHELF MIDDLE SHELF LOWER SHELF CABINET BOTTOM ASSEMBLY ASSEMBLY CAPACITY CAPACITY CAPACITY CAPACITY CAPACITY CAPACITY NOTICE Please retain these instructions for future reference. •...
  • Page 3 MOUNTING CAM LOCK FOOT SLIDER ARCH RUBBER STRAP COVER STRAP 2 PCS 10 PCS 6 PCS 2 PCS (SKY9403 ONLY) SHELF RUBBER STRAP 2 PCS (SKY9403 ONLY) PARTS ARCH BACKING ARCH FRONT LINING ARCH CENTRAL BRACE 1 PC 1 PC...
  • Page 4 PARTS ARCH TOP BRACE ARCH SIDE BRACE TOP SHELF 1 PC 2 PCS 1 PC CABINET LEFT SIDE CABINET RIGHT SIDE SHELF FRONT 1 PC 1 PC 2 PCS UPPER SHELF MIDDLE SHELF BOTTOM SHELF 1 PC 1 PC 1 PC CABINET BOTTOM TOP DIVIDER RIGHT FRONT FRAME...
  • Page 5 PARTS LEFT FRONT FRAME DOOR MOUNTING BLOCK SIDE 1 PC 2 PCS 4 PCS BOTTOM BACK BOARD UPPER BACK BOARD ARCH COVER BOARD 2 PCS 2 PCS 2 PCS BACK BOARD DIVIDER 2 PCS...
  • Page 6 PRODUCT ASSEMBLY Locate the part B arch front lining and insert five part 1 cam bolts. Locate two part I shelf front and insert six part 1 cam bolts, three bolts per base frame. Locate the part A arch backing and attach the part C arch central brace with one part 4 wood screw and one part 3 dowel.
  • Page 7 PRODUCT ASSEMBLY Insert two part 3 dowels into the bottom of the part A arch backing. Attach the part F top shelf to the part A arch backing with three part 4 screws. Insert two part 2 cam locks into the bottom of the part F top shelf. Insert one part 2 cam lock into the part C arch central brace and part E arch side braces, three locks total.
  • Page 8 PRODUCT ASSEMBLY Slide two part U arch cover boards into their designated grooves between the part A & B arch front/backing, taking care to insert cover boards so the fastener hole notches sit at the top of the arch. Attach the part D arch top brace to the part C arch central brace through the part U arch cover boards with two part 9 bolts.
  • Page 9 PRODUCT ASSEMBLY Insert six part 1 cam bolts each into the part G and H cabinet sides, twelve cam bolts total. Locate the part N top divider and insert two part 2 cam locks. Attach it to the part H cabinet right side. Turn the cam locks to secure.
  • Page 10 PRODUCT ASSEMBLY Slide one part S bottom back board into the grooves on the part M cabinet bottom and the part H cabinet right side. Slide one part V back board divider on the top edge of the part S bottom back board. Slide one part S bottom back board between the part V back board divider and the part K middle shelf.
  • Page 11 PRODUCT ASSEMBLY Insert two part 2 cam locks into the part N top divider. Insert two part 2 cam locks and two part 3 dowels each into the part K middle shelf and part M cabinet bottom. Attach the part G cabinet left side to the part N top divider, part K middle shelf, and part M cabinet bottom.
  • Page 12 PRODUCT ASSEMBLY Stand the cabinet assembly upright then insert one part T upper back board between the part H & G cabinet sides. Slide the one part V back board divider onto the top edge of the upper back board, then slide a second part T upper back board between the part H &...
  • Page 13 PRODUCT ASSEMBLY Locate the part O and part P front frames and insert eight part 1 cam bolts, four bolts per frame. Insert four part 2 cam locks and three part C dowels each into the part H and part G cabinet sides, eight cam locks and six dowels total.
  • Page 14 PRODUCT ASSEMBLY Place one part 14 cam lock cover over the top three cam locks on each side of the cabinet assembly, six covers total. Place four part 15 foot sliders onto the bottom of the part H and part G cabinet sides, then place two foot sliders on the bottom of each part O and part P front frame, six foot sliders total.
  • Page 15 PRODUCT ASSEMBLY Insert two part 2 cam locks and two part 3 dowels each into the top of the part H and part G cabinet sides, four cam locks and four dowels total. Attach the part F top shelf to the part H and part G cabinet sides. Turn the cam locks to secure, then cover each cam lock with one part 14 cam lock cover, four covers total.
  • Page 16 PRODUCT ASSEMBLY Locate the part J upper shelf and insert three part 2 cam locks and two part 3 dowels. Attach one part I shelf front to the part J upper shelf. Insert eight part 6 shelf supports into the part H and part G cabinet sides as desired. NOTE: To ensure the shelves sit level, be sure the shelf supports in either cabinet side are mounted parallel to each other.
  • Page 17 PRODUCT ASSEMBLY Slide the part J upper shelf and part L bottom shelf onto the part 6 shelf supports. Locate one part Q door and attach two part 7 hinges with four part 5 screws, two screws per hinge. Repeat to assemble a second door.
  • Page 18 PRODUCT ASSEMBLY Locate four part R mounting blocks and insert two part 3 dowels into each, eight dowels total. Attach the two part R mounting blocks each to the part H and part G cabinet sides with sixteen part 4 screws, four screws per mounting block.
  • Page 19 PRODUCT ASSEMBLY Attach the doors by securing the part 7 hinges to the part R mounting blocks with sixteen part 5 screws, four screws per hinge. Attach one part 8 cabinet door handle to one part Q door with the two included screws, repeat to attach the second handle to the other door.
  • Page 20 PRODUCT ASSEMBLY Attach two part 13 mounting straps to the back of the part A arch backing with two part 11 screws. Attach sixteen part 10 back screw & guides to the back of cabinet assembly as shown.
  • Page 21 PRODUCT ASSEMBLY SKY9403 ONLY: Place two part 16 rubber straps onto part A arch backing. Place two part 17 rubber straps onto part F top shelf.

  • Page 22: Wall Mounting

    WALL MOUNTING Select an appropriate location, then mark two spaces on the wall using the part 13 mounting straps as guides. Use a drill on the marked spaces. Insert two part 12 wall anchors into the new holes in the wall. Overlap the holes with the mounting straps, then attach the cabinet to the wall by drilling two part 4 wood screws through the part 13 mounting straps and into the wall anchors.

  • Page 23: Door Alignment

    DOOR ALIGNMENT If your door is too low or too high... door Loosen the height screws, then move the door up or down to make it level. If you need to adjust the depth of the doors... door Adjust the in-and-out screws until the door is aligned with the side of cabinet. If the space between your doors is o ...

  • Page 24: Help Center

    All returns must be shipped back to the Best Choice Products Return Center at the customer’s expense. If the reason for return is a result of an error by Best Choice Products then Best Choice Products will provide a pre-paid shipping label via email. Boxes for return shipping will not be provided by Best Choice Products, and is the customer’s responsibility to either use the original shipping boxes or purchase new boxes.
