CEG SERIES THERMOSTATIC GRIDDLES
For Your Safety
Do NOT store or use gasoline or other
flammable vapors and liquids in the
vicinity of this, or any other equipment.
Telephone:(714) 547-9218
Improper installation, adjustment, alteration, service or
maintenance can cause property damage, injury or death.
Read the installation, operation and maintenance instructions
thoroughly before installing or servicing this equipment.
11990 Rivera Rd. Santa Fe Springs, CA 90670
www.connertoncooking.com
Installation,
Operation &
Maintenance
Instructions
Warning!
(562) 464 - 9901
1
Advertisement
Related Manuals for Connerton CEG Series
Summary of Contents for Connerton CEG Series
- Page 1 Installation, Operation & Maintenance Instructions CEG SERIES THERMOSTATIC GRIDDLES For Your Safety Warning! Do NOT store or use gasoline or other Improper installation, adjustment, alteration, service or flammable vapors and liquids in the maintenance can cause property damage, injury or death.
- Page 2 To Purchaser After installation of your griddle, immediately contact your local gas supplier to obtain information in the event the user of your equipment smells gas. This information must be posted in a prominent location To User RETAIN THIS MANUAL FOR FUTURE USE Upon receipt of this griddle, inspect it thoroughly for any damage which may have occurred during shipment.
- Page 3 Gas Piping: Make sure the gas pressure regulator supplied with the griddle is installed correctly. Connect the outlet side of regulator to griddle. The regulator is set at 4 inches w.c. on natural gas and 11 inches w.c. on propane gas. A 1/8” pressure tap is provided on the gas manifold at the front of the griddle for checking the gas pressure.
- Page 4 CEG THERMOSTATIC GRIDDLES 05-476-DS griddle plate 00-225-00 pilot valve (straight) 05-400-DS body 15-251-00 New style t-stat for CG * CEG 05-426-DS front panel 00-525-00 bezel for old style thermostat 05-450-00 grease drawer 05-550-00 dial for old style thermostat 05-301-DS gas manifold pipe 15-251-02 **knob for new style thermostat 05-200-01...
-
Page 5: Troubleshooting Guide
Effective January 2020 CONNERTON (Company) warrants to the original owner that the product be free from defects in materials and/or workmanship. This warranty shall apply to units properly installed in a static location only and be in effect for two (2) years from the date of purchase but shall not exceed 30 months from the date of shipment from the Company. - Page 6 Damage incurred during transit and/or handling. Damage resulting from the use of other than genuine CONNERTON parts. Damage resulting from the use of or exposure to harsh chemicals or improper cleaning procedures. Damages caused by flood, fire or other acts of nature.
