CG SERIES THERMOSTATIC GRIDDLES
For Your Safety
Do NOT store or use gasoline or
other flammable vapors and liquids
in the vicinity of this, or any other
equipment.
Telephone:(714) 547-9218
Improper installation, adjustment, alteration, service or
maintenance can cause property damage, injury or death. Read
the installation, operation and maintenance instructions
thoroughly before installing or servicing this equipment.
11990 Rivera Rd. Santa Fe Springs, CA 90670
www.connertoncooking.com
Installation,
Operation &
Maintenance
Instructions
Warning!
(562) 464 - 9901
1
Advertisement
Related Manuals for Connerton CG Series
Summary of Contents for Connerton CG Series
- Page 1 Installation, Operation & Maintenance Instructions CG SERIES THERMOSTATIC GRIDDLES For Your Safety Warning! Do NOT store or use gasoline or Improper installation, adjustment, alteration, service or other flammable vapors and liquids maintenance can cause property damage, injury or death. Read...
- Page 2 To Purchaser After installation of your griddle, immediately contact your local gas supplier to obtain information in the event the user of your equipment smells gas. This information must be posted in a prominent location. To User RETAIN THIS MANUAL FOR FUTURE USE Upon receipt of this griddle, inspect it thoroughly for any damage which may have occurred during shipment.
- Page 3 Gas Piping: Make sure the gas pressure regulator supplied with the griddle is installed correctly. Connect the outlet side of regulator to griddle. The regulator is set at 4 inches w.c. on natural gas and 11 inches w.c. on propane gas. A 1/8” pressure tap is provided on the gas manifold at the front of the griddle for checking the gas pressure.
- Page 4 CG THERMOSTATIC GRIDDLES 00-225-00 pilot valve (straight) 10-476-DS griddle plate 10-251-00 thermostat valve (old style) 10-400-DS body 10-426-DS front panel 11a 15-251-00 **thermostat valve (new style) 10-450-00 grease drawer 00-525-00 bezel for old style thermostat 10-301-DS gas manifold pipe 00-525-00 dial for old style thermostat orifice hood (nat.
-
Page 5: Troubleshooting G
Damage incurred during transit and/or handling. Damage resulting from the use of other than genuine CONNERTON parts. Damage resulting from the use of or exposure to harsh chemicals or improper cleaning procedures. Damages caused by flood, fire or other acts of... -
Page 6: Limited Warranty
PROCEEDURES FOR REQUESTING WARRANTY SERVICE All services must be prearranged by the Company prior to works being performed. Contact CONNERTON service department at (714)-547-9218 furnish complete model and serial numbers and a copy of the purchase invoice and describe nature of the problem.
