hivolt HS Series Manual

HS/HB Series
SINGLE POLE HIGH VOLTAGE CONNECTORS
10 / 20 / 30 / 40kV
FEATURES

− Up to 40kV / 30A
DC
− 100,000 Mating Cycles
− UL94 V-0 Flammability Rating
− Extended Temperature Range
− Central Attachment
− Low Cost
− Made in Germany
− Completed cable assemblies available
− RoHS compliant
APPLICATIONS

− Instrument High Voltage Connections
− Test Stations
DESCRIPTION

The single pole high voltage connector pairs HSxx (cable mounting connector) and HBxx (instrument mounting socket) are
available for operating voltages of 10kV
shielded / screened high voltage cable.
The silver-plated central contact, the strong nickel-plated housing and the screw interlock warrant a safe and reliable
connection. Extended operating temperature range due to PTFE insulation. The 20kV models also with POM insulation.
Model
Plug Receptacle
HS11-T HB11-T
HS21 HB21
HS21-T HB21-T
HS31-T HB31-T
HS40-T HB40-T
SPECIFICATIONS

Termination inner contact:
Shield connection:
Contact surface:
Insulation material:
Temperature range:
Insulation resistance:
Contact resistance:
Wire gauge:
Mating / unmating force:
Mating cycles:
Max. outer diameter - shielded:
Max. inner insulation diameter:
Suitable cable type:
Bespoke ready-to-use high voltage cable assemblies based on several high voltage cable types are available. The cable
assemblies are fully tested. Please contact hivolt.de for details
Ratings listed above apply to clean connector pairs in standard atmospheric conditions. When connectors are used in an
adverse environment (such as high temperature, humidity, pollution content, extreme mechanical exposure etc.) the
connector should be derated. The fitness for use must be proved by extended operational tests.
© 2018 hivolt.de - Subject to change without notice, errors expected.
hivolt.de GmbH & Co. KG
Oehleckerring 40 D-22419 Hamburg
∙
, 20kV ,30kV and 40kV
DC DC DC
Operating Test
Voltage Voltage
10kV 15kV
DC DC
20kV 30kV
DC DC
20kV 30kV
DC DC
30kV 45kV
DC DC
40kV 60kV
DC DC
soldering
screw joint / cable gland
Ag
PTFE (Teflon®) white (POM (Delrin®) white on request for 20kV models)
-50°C to +200°C (PTFE) (-30°C to +120°C (POM))
10 Ω (contact / housing)
16
max. 300 μΩ
max. 2.5mm² / bore hole: ø2.4mm
5.5N / 4.0N
100 000
6.5mm
5.0mm
shielded high voltage cable; e.g:
HPW-40S-0.5-A-2
130660
HTV-30S-22-2
HRG58-20-2
HSL-8S-0.75-B-2
Germany  +49 40 537122-0
∙ ∙
. The connectors are suitable for use with
DC
Rated Insulation
Current material
30A PTFE
30A POM
30A PTFE
30A PTFE
30A PTFE
up to 40kV , PE / PUR, LSZH, universal
DC
up to 30kV , PE / PVC, universal
DC
up to 30kV , PE / PVC, UL (internal wiring)
DC
up to 20kV , PE / PUR, LSZH
DC
up to 8kV , Silicone (high temperature)
DC
 +49 40 537122-99
∙
Mounting type
(panel mount connector
HBxx)
round flange
round flange
round flange
round flange
4-hole flange
HS_HB_e 01/2018 Page 1 of 5
