Inbay 241050-01 User Manual

Wireless charging subsystem qi 1.3 gen.4 1-coil

Download this manual

Wireless Charging Application

241050-01

Subsystem item no.:

240000-01-11

Wireless Charging Subsystem Qi 1.3 Gen.4 1-Coil

Item number

Specification:

PCBA

Product Mode

Ref.-Design/Coil Array

WPC Qi Standard

illustration

sample

www.inbay.systems

User Manual

240000-01-11

- PCBA 1 Coil

- Micro-Fit 3.0 Connector

- Multicolor LED

- On Board Fuse 4A

IF 240000-01-11-1

EPP 15W Fixed Frequency 127,75 kHz ± 1.2 kHz

MP-A11

1.3.2 (under testing)

Wireless Charging Subsystem Qi 1.3 Gen.4 1-Coil

Features:

• Overvoltage Protection

• Over Current Protection

• Over Temperatur Protection

• Foreign Object Detection (FOD)

power supply

Need help?

Do you have a question about the 241050-01 and is the answer not in the manual?

Page 1 • Over Current Protection • Over Temperatur Protection • Foreign Object Detection (FOD) power supply © 2019 · acv GmbH · Straßburger Allee 10-12 · 41812 Erkelenz © 2022 · acv GmbH · Straßburger Allee 10-12 · 41812 Erkelenz · www.inbay.systems www.inbay.systems...
Page 2 User Manual...
Page 3 DETECTION (FOD) CARD xxxx xxxx xxx IMPORTANT INFORMATION: Please don‘t place any other objects such as coins, credit cards etc. onto the INBAY surface. Especially smartphones with attached ring stand holder must not be used! - otherwise the integrated Foreign Object Detection (FOD) will interrupt wireless charging for safety reasons.
Page 4 User Manual MANUAL IMPORTANT! AFTER INSTALLATION THE MANUAL HAS TO BE PLACED INTO THE DASH BOARD OF THE CUSTOMER‘S CAR.
Page 5: Federal Communications Commission Interference Statement
FCC: FEDERAL COMMUNICATIONS COMMISSION INTERFERENCE STATEMENT This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
Page 6 User Manual human exposure installation area (sample) Driver Seat Passenger Seat Knee 26,0 cm Knee 34,0 cm 42,5 cm 43,0 cm Body 50,0 cm Body 57,0 cm Hand 20,0 cm Hand 34,0 cm 46,5 cm 56,0 cm Head 66,0 cm Head 75,5 cm Passenger...
