QEI MicroPAQ-940S User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
DIO-9100 USER'S GUIDE
UG-1062
UG-1089
MicroPAQ-940S
User's Guide
December 2018

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MicroPAQ-940S and is the answer not in the manual?

Questions and answers

Related Manuals for QEI MicroPAQ-940S

Summary of Contents for QEI MicroPAQ-940S

  • Page 1 DIO-9100 USER’S GUIDE UG-1062 UG-1089 MicroPAQ-940S User’s Guide December 2018...
  • Page 2 The information in this document has been carefully checked and is believed to be accurate. However, no responsibility is assumed or implied for inaccuracies. Furthermore, QEI, LLC reserves the right to make changes to any products herein described to improve reliability, function or design. QEI, LLC does not assume liability arising out of the application or use of any product or circuit described herein;...
  • Page 3 MicroPAQ-940S User’s Guide UG-1089 Revisions Revision Description Date Released Aug 23, 2018 Updated QEI Address Dec. 6, 2018 • MicroPAQ-940S User’s Guide Revisions...

  • Page 4: Table Of Contents

    UG-1089 Contents 1 Description ................1 2 Specifications ................2 3 Input Power Connections ............3 Powering a Single MicroPAQ-940S Module ......3 Powering Multiple MicroPAQ-940S Modules ......3 4 Status Point Inputs ..............6 General ................6 Status Terminal Block Pinout ..........7 Typical Status Connections ..........

  • Page 5: Description

    All status points are optically isolated, and transient protected. Each MicroPAQ-940S module includes an RS-422 port for communications with the MicroPAQ-940P Main Processor Module. The RS-422 port uses two RJ45 connectors, allowing multiple -940S modules to be daisy chained together.

  • Page 6: Specifications

    MicroPAQ-940S User’s Guide UG-1089 2 Specifications General Description Microprocessor Type ARM Cortex M4 Microcontroller Module Addressability 8 Address DIP switches (up to 4096 Status points per system). Communications Ports Port 1: Purpose Main Communications Port Interface RS-422 Protocol ASCII Asynchronous Bit Rate 115.2Kbps...

  • Page 7: Input Power Connections

    3.1 Powering a Single MicroPAQ-940S Module Note: Be sure MicroPAQ-940P plug-in jumper J11 (near the expansion port 4, J10) is set to pins 1-2 (Internal Power) or the MicroPAQ-940S will not function. The MicroPAQ-940P can power a single MicroPAQ-940S Module without the need...
  • Page 8 1 and 2 Common Power supply common connection. The following illustration shows multiple MicroPAQ-940S modules connected to a MicroPAQ-940P. Note that an external power supply is used to power the -940S modules: • Input Power Connections Copyright © 2018 QEI...
  • Page 9 MicroPAQ-940S User’s Guide UG-1089 • Copyright © 2018 QEI Input Power Connections...

  • Page 10: Status Point Inputs

    UG-1089 4 Status Point Inputs General The MicroPAQ-940S includes 16 status connections. The first 8 status input connections (points 1-8) appear at terminal block TB1. The second 8 status input connections (points 9-16) appear at terminal block TB2. Each group of 8 status connections are separated into two sub-groups of four status inputs each.

  • Page 11: Status Terminal Block Pinout

    MicroPAQ-940S User’s Guide UG-1089 Status Terminal Block Pinout TB1 PIN# Name Description STAT #1 Status Point 1 connection. STAT #2 Status Point 2 connection. STAT #3 Status Point 3 connection. STAT #4 Status Point 4 connection. COMMON 1 Status Point 1 thru 4 common.
  • Page 12 MicroPAQ-940S User’s Guide UG-1089 GROUP OF FOUR GROUP OF FOUR NEGATIVE KEYED POSITIVE KEYED ISOL. DC P/S +12Vdc or +24Vdc CONTACTS STATUS USER STATUS 13-16 STATUS 9-12 ISOL LEDs 12 11 LEDs ISOL STATUS 1-4 STATUS 5-8 USER STATUS CONTACTS ISOL.
  • Page 13 MicroPAQ-940S User’s Guide UG-1089 (INTERNALLY JUMPERED COMMONS J1,J2) GROUP OF EIGHT NEGATIVE KEYED ISOL. DC P/S +12Vdc or +24Vdc CONTACTS STATUS USER STATUS 13-16 STATUS 9-12 ISOL LEDs 12 11 LEDs ISOL STATUS 1-4 STATUS 5-8 USER STATUS CONTACTS ISOL.
  • Page 14 MicroPAQ-940S User’s Guide UG-1089 (EXTERNALLY JUMPERED COMMONS) GROUP OF EIGHT NEGATIVE KEYED ISOL. DC P/S +12Vdc or +24Vdc CONTACTS STATUS USER STATUS 13-16 STATUS 9-12 ISOL LEDs 12 11 LEDs ISOL STATUS 5-8 STATUS 1-4 USER STATUS CONTACTS ISOL. DC P/S...
  • Page 15 MicroPAQ-940S User’s Guide UG-1089 (EXTERNALLY JUMPERED COMMONS) GROUP OF EIGHT POSITIVE KEYED ISOL. DC P/S +12Vdc or +24Vdc CONTACTS STATUS USER STATUS 13-16 STATUS 9-12 ISOL LEDs 12 11 LEDs ISOL STATUS 1-4 STATUS 5-8 USER STATUS CONTACTS ISOL. DC P/S...

  • Page 16: Led Indicators

    5 LED Indicators 5.1 General The MicroPAQ-940S includes various LED indications. Almost all of the LEDs are high brightness red, except for the Comm Port TXD Leds (Green). The Status LEDs are visible through the front panel. Some other LEDs are visible are located on the PCB, behind the front panel or at the edges, and cannot easily be viewed without removing the front panel.

  • Page 17: Led Locations

    6 Dip Switches 6.1 Address DIP Switches Each MicroPAQ-940S is addressable (from the MicroPAQ-940P) via eight DIP switches located in the upper left hand corner. Address is in Binary, with Bit 0 on the left, and Bit 8 on the right. A switch in the UP position is a logic “1” and DOWN is a logic “0”.

  • Page 18: Address Examples

    MicroPAQ-940S User’s Guide UG-1089 6.1.1 Address Examples Address 10100000 1+4 = 5 Address 00001110 16+32+64 = 112 6.2 Watchdog DIP Switch The watchdog circuit monitors the processor health, and should always be enabled. This DIP switch (SW4, bottom edge of PCB) is a factory setting. When the SW4 switch is OFF (down), the watchdog circuit is enabled (factory setting).

  • Page 19: Rs-232 Port 2 (J8)

    MicroPAQ-940S User’s Guide UG-1089 ADDR STATUS 9-16 STATUS MODULE STATUS 1-8 J3, J6 PIN# Name Description Common P/S Common Common P/S Common Data Receive In + Data Transmit Out + Data Transmit Out - Data Receive In - +24V +24Vdc P/S In...

  • Page 20: Jumpers

    MicroPAQ-940S User’s Guide UG-1089 8 Jumpers General The MicroPAQ=940S includes four plug-in jumpers. The function of each plug-in jumper is shown in the table below. Refer to the drawing below for jumper location on the PCB. Jumper Name Description ISO/COM Status Groups 1-4 and 5-8 Commons Jumper.

  • Page 21: Earth Grounding

    Connect earth ground to 0.250” quick disconnect tab J19 in the upper right corner of the PCB (to the right of terminal block TB2). After installation of the MicroPAQ-940S, check with a DVM for continuity between the quick disconnect tab J19, and earth ground of the system installation.

  • Page 22: Mechanical

    10 Mechanical Mechanical dimensions are shown below. Dimensions are 4.13” L x 5.60” W x 2.5” H. The MicroPAQ-940S is designed for standard 35mm DIN Rail Mounting. DIN Rail Mount : (Note: Add DIN rail height to listed height dimension.)
  • Page 23 UG-1089 Panel Mount: The MicroPAQ-940S can be ordered with Panel Mounting Brackets, which adapt the MicroPAQ Panel Mount applications (rather than DIN rail) if desired. Dimensions are 4.13” L x 5.60” W x 2.5” H (identical to the DIN rail mount dimensions).

  • Page 24: Relevant Cabling

    12 Ordering Information MicroPAQ-940S Status Module 40-058244-XXX The MicroPAQ-940S is an I/O Expansion Module that is part of the QEI family of Distribution Automation Products. The -940S provides 16 isolated Status inputs, arranged as four groups of four status points.
