- Page 1 SAPPHIRE-680FSG SAPPHIRE-681FSG TOSHIBA Bluetooth® IC Evaluation Board User’s Manual SENSYST Rev 1.0...
-
Page 2: Regulatory Compliance Information
Regulatory Compliance Information This evaluation board contains the device that transmit and receive radio signals for the 2.4-GHz unlicensed frequency range and is gained regulatory approvals to be used in Japan and United States. FEDERAL COMMUNICATIONS COMMISSION Part 15 Compliant Caution This device complies with part 15 of the FCC Rules. - Page 3 SAPPHIRE Evaluation Board KIT <Contents > Evaluation board …1 The coaxial RF adapters suitable for Hirose MS-156C, and the debug emulator with half pitch 10 pin cable USB Type A Male to Mini B Male Cable …1 aren’t included in this KIT. If need for your evaluation or development, please prepare yourself. Jumper socket …17 IDE is required for developing user applications.
- Page 4 1 Features The SAPPHIRE evaluation board includes Toshiba Bluetooth LE IC complies with Bluetooth 5, low energy single-mode radio and has the following features. [Radio] Complies with Bluetooth 5, low energy single-mode radio operates at 2402 MHz to 2480 MHz. (ISB Band 2400~2483.5MHz) Toshiba Qualified Bluetooth protocol stacks such as GATT, SMP and HCI are stored in the Bluetooth LE IC.
- Page 5 2 Overview SAPPHIRE-680FSG/681FSG evaluation board, its dimension is about 10cm x 7 cm, contains the following components as shown in the below figure. ANT Pattern Antenna CN11 SLD Metal Case IC1 Toshiba Bluetooth IC IC3 EEPROM CN10 IC5 USB-UART Bridge IC6 USB-SWD Bridge IC7 3.3V LDO...
- Page 6 Figure below is for HCI mode operation setting. Check the jumper position on this board so that it can be communicated with a Windows PC via virtual COM port. (The picture below is a SAPPHIRE-680FSG) Bluetooth LE IC starts HCI mode operation. Using host application software such as HCIScript, you can command to the Bluetooth LE IC on this board and download user applications to the non-volitile memory.
- Page 7 4 Getting Started for user-app mode operation Figure below is for user-app mode operation setting. Check the jumper position to run a user application program. Jumper sockets among SDA and GPIO(8) and among SCL and GPIO(7) are not required for SAPPHIRE-680FSG.
