DSP SINE WAVE HOME UPS
HIGH PERFORMANCE WITH LOW ENERGY CONSUMPTION
INNOVAT I NG TOMORROW
MODEL: LANDER-6000-72V
Pure Copper transformer
with high grade lamination
No load DC current
70
Micron High grade PCB
0.8
Constant output power factor
( 6000VA = 4800W max. O/P load)
Grid charging ON/OFF Facility
to use with Off Grid power plants
Zero grid consumption at idle charging stage
Constant output Voltage
(222V) even on heavy loads
Pick & Place type circuit
Design for quick service
User configurable
Function settings
ISO
9001:201 5
R
HS
O
CERTIFIED
COMPLIANT
USER MANUAL
1
- +
0.7A 0.3A
Vers.5.5
Advertisement
Table of Contents
Related Manuals for ASHAPOWER LANDER-6000-72V
Summary of Contents for ASHAPOWER LANDER-6000-72V
- Page 1 INNOVAT I NG TOMORROW DSP SINE WAVE HOME UPS HIGH PERFORMANCE WITH LOW ENERGY CONSUMPTION MODEL: LANDER-6000-72V Pure Copper transformer with high grade lamination No load DC current 0.7A 0.3A Micron High grade PCB Constant output power factor ( 6000VA = 4800W max. O/P load)
-
Page 2: Unique Features
DSP SINE WAVE HOME UPS MODEL: LANDER-6000-72V Thank you for purchasing It is a high power ASHAPOWER HOME UPS 72V/6KVA. INVERTER/UPS for home/office having connected load of,inverter AC,induction cooker,rice coocker,fans washing machine,refrigerator,TV,computer,laser printer, induction motor pump and LED lights when used with 72VX200Ah batteries. - Page 3 KNOW YOUR DEVICE ASHAPOWER DSP SINE WAVE HOME UPS MODEL: LANDER-6000-72V 4x16 LCD DISPLAY GRID INPUT MCB LED INDICATORS INNOVATING TOMORROW FUNCTION KEYS BATTERY INPUT DSP SINE WAVE COOLING FAN GRID GRID INVERTER EARTH HOME UPS PHASE NEUTRAL OUTPUT TO LOAD...
-
Page 4: Front Panel Indications
ASHAPOWER DSP SINE WAVE HOME UPS MODEL: LANDER-6000 -72V FRONT PANEL INDICATIONS INNOVATING TOMORROW DSP SINE WAVE HOME UPS INVERTER ON GRID CHARGING ON FAULT GRID POWER ON BATTERY LOW OVER LOAD FORCED SHIFTING 4x16 LCD DISPLAY LED INDICATORS FUNCTION KEYS... -
Page 5: Battery Bank
ASHAPOWER DSP SINE WAVE HOME UPS MODEL: LANDER-6000 -72V HOME UPS CONNECTION DIAGRAM ASHAPOWER HOME UPS GRID IN MCB GRID LOAD POWER (72V) GRID GRID INVERTER EARTH PHASE NEUTRAL OUTPUT TO LOAD BATTERY BANK (6X 12V B ATTERY / 200 AH) - Page 6 ASHAPOWER DSP SINE WAVE HOME UPS MODEL: LANDER-6000 -72V INVERTER (BATTERY) MODE PARAMETERS Inverter Output Volage 222 Volt Inverter Output Wave form DSP pure sine wave Inverter power factor Inv Output Frequency 50 Hz Inverter Surge Rating for 2 Second...
-
Page 7: Led Indications
LED INDICATIONS Grid power presence Red Grid power LED ON Battery grid charging Yellow Grid Charger LED ON INV Std by on Mains Green Inverter ON LED Blink INV load on Battery Green Inverter ON LED steady Overload Warning Red Overload LED ON Overload Trip Red Battery low LED ON Battery Low Warning... - Page 8 ASHAPOWER HOME UPS INSTALLATION & OPERATION GUIDE LINES MODEL: LANDER-6000 -72V 1) Battery bank setup : Check each battery separately for specific gravity, same terminal volt backup. not use old and new batteries together, either in parallel or in series.
- Page 9 What is UPS mode in Quick settings menu. UPS mode is to shift the connected load on inverter from grid power to battery power when grid power drops below 190V. Fluctuations on grid power badly affect digital equipments as computers. When the device is used for digital equipments as computers select UPS mode in ON position.
-
Page 10: Main Function Settings
ASHAPOWER HOME UPS LANDER- 6000-72V MAIN FUNCTION SETTINGS Vers.5.5 RANGE TYPE OF DESCRIPTION MENU SETTINGS DEFAULT Limit the float charging voltage recommended for the batteries. This INV-FLOAT-V value varies in di erent types of batteries. Default value given is for C10 64.0V... - Page 11 ASHAPOWER HOME UPS LANDER- 6000-72V MAIN FUNCTION SETTINGS Vers.5.5 RANGE TYPE OF DESCRIPTION MENU SETTINGS DEFAULT INV-M--LOW V CUSTOMER Minimum AC mains voltage limit for inverter operation 100V 180V INV. MAINS LOW VOLT SETTINGS Below this limit system goes to inverter mode...
- Page 12 COMPARE THE UNIQUENESS OF ASHAPOWER HOME UPS-LANDER-6000-72V LANDER 6000-72V Pure Copper transformer with Low grade Aluminium / High grade Lamination ( 2500VA = 2000W max. O/P load) (2500VA = 1750 W max. O/P load) (222V) even on heavy loads Grid charging ON/OFF Facility...
