ASHAPOWER LANDER-3000-36V User Manual

Dsp sine wave home ups
Hide thumbs

Advertisement

Quick Links

Download this manual
DSP SINE WAVE HOME UPS
HIGH PERFORMANCE WITH LOW ENERGY CONSUMPTION
INNOVAT I NG TOMORROW
MODEL: LANDER-3000-36V
Pure Copper transformer
with high grade lamination
No load DC current
70
Micron High grade PCB
0.8
Constant output power factor
( 3000VA = 2400W max. O/P load)
Grid charging ON/OFF Facility
to use with off grid power plants
Zero grid consumption at idle charging stage
Constant output Voltage
(222V) even on heavy loads
Pick & Place type circuit
Design for quick service
User configurable
Function settings
ISO
9001:201 5
R
HS
O
CERTIFIED
COMPLIANT
USER MANUAL
- +
0.7A 0.3A
1
Vers.5.5

Advertisement

loading
Need help?

Need help?

Do you have a question about the LANDER-3000-36V and is the answer not in the manual?

Questions and answers

Related Manuals for ASHAPOWER LANDER-3000-36V

Summary of Contents for ASHAPOWER LANDER-3000-36V

  • Page 1 INNOVAT I NG TOMORROW DSP SINE WAVE HOME UPS HIGH PERFORMANCE WITH LOW ENERGY CONSUMPTION MODEL: LANDER-3000-36V Pure Copper transformer with high grade lamination 0.7A 0.3A No load DC current Micron High grade PCB Constant output power factor ( 3000VA = 2400W max. O/P load)
  • Page 2 DSP SINE WAVE HOME UPS MODEL: LANDER 3000-36V Thank you for purchasing It is a high power ASHAPOWER HOME UPS-3KVA-36V. INVERTER/UPS for home/office having connected load of,inverter AC,induction cooker,rice coocker,fans washing machine,refrigerator,TV,computer,laser printer, induction motor pump and LED lights when used with 36VX200Ah batteries.

  • Page 3: Know Your Device

    KNOW YOUR DEVICE 36V/3KVA HOME UPS 4x16 LCD DISPLAY GRID INPUT MCB LED INDICATORS INNOVATING TOMORROW FUNCTION KEYS BATTERY INPUT DSP SINE WAVE COOLING FAN GRID GRID INVERTER EARTH HOME UPS PHASE NEUTRAL OUTPUT TO LOAD INVERTER ON GRID CHARGING ON FAULT BATTERY DC INPUT GRID POWER ON...
  • Page 4 BACK PANEL CONNECTORS COOLING FAN GRID IN MCB BATTERY INPUT (36V) GRID GRID INVERTER EARTH PHASE NEUTRAL OUTPUT TO LOAD GRID CONNECTION TERMINAL BLOCK FRONT PANEL INDICATIONS INNOVATING TOMORROW DSP SINE WAVE HOME UPS INVERTER ON GRID CHARGING ON FAULT GRID POWER ON BATTERY LOW OVER LOAD...

  • Page 5: Battery Bank

    2400W/36V HOME UPS CONNECTION DIAGRAM ASHAPOWER HOME UPS GRID IN MCB GRID LOAD POWER IN BATTERY INPUT GRID GRID INVERTER EARTH PHASE NEUTRAL OUTPUT TO LOAD BATTERY BANK (3 X 12V BATTERY / 200 AH)
  • Page 6 INVERTER (BATTERY) MODE PARAMETERS Inverter Output Volage 222 Volt Inverter Output Wave form DSP pure sine wave Inverter power factor Inv Output Frequency 50 Hz Inverter Surge Rating for 2 Second 250 % Battery high voltage trip 49.5 Volt Battery Low Warning Level 33 Volt Battery Low Trip Level 32.4 Volt...

  • Page 7: Led Indications

    LED INDICATIONS Grid power presence Red Grid power LED ON Battery grid charging Yellow Grid Charger LED ON INV Std by on Mains Green Inverter ON LED Blink INV load on Battery Green Inverter ON LED steady Overload Warning Red Overload LED ON Overload Trip Red Battery low LED ON Battery Low Warning...
  • Page 8 ASHAPOWER HOME UPS INSTALLATION & OPERATION GUIDE LINES 36V/3KVA INVERTER/20AMPS GRID POWER CHARGER 1) Battery bank setup : Check each battery separately for specific gravity, same terminal volt backup. not use old and new batteries together, either in parallel or in series.
  • Page 9 What is UPS mode in Quick settings menu. UPS mode is to shift the connected load on inverter from grid power to battery power when grid power drops below 190V. Fluctuations on grid power badly affect digital equipments as computers. When the device is used for digital equipments as computers select UPS mode in ON position.
  • Page 10 ASHAPOWER HOME UPS MAIN FUNCTION SETTINGS RANGE TYPE OF DESCRIPTION MENU SETTINGS DEFAULT Limit the float charging voltage recommended for the batteries. This INV-FLOAT-V value varies in di erent types of batteries. Default value given is for C10 CUSTOMER 39.0V 48.0V...
  • Page 11 ASHAPOWER HOME UPS LANDER- 3000-36V Vers.5.3 MAIN FUNCTION SETTINGS RANGE TYPE OF DESCRIPTION MENU SETTINGS DEFAULT INV-M--LOW V CUSTOMER Minimum AC mains voltage limit for inverter operation 100V 180V INV. MAINS LOW VOLT SETTINGS Below this limit system goes to inverter mode...
  • Page 12 COMPARE THE UNIQUENESS OF ASHAPOWER HOME UPS-LANDER-3000-36V LANDER 3000-36V Pure Copper transformer with Low grade Aluminium / High grade Lamination ( 2500VA = 2000W max. O/P load) (2500VA = 1750 W max. O/P load) (222V) even on heavy loads Grid charging ON/OFF Facility...
