Amazfit A1602 Manual

Table of Contents

Contents

1 Installing the APP
2 Pair with phone
3 Turn on/off the unit
4 Charging the unit
5 Precautionary measures
6 Main parameters
7 List of faults
8 Documents / Resources
- 8.1 Download manual

Installing the APP

Download the app «Amazfit Smart Watch» or scan the QR-code, to install the application.

Pair with phone

Pairing with phone
Open APP «Amazfit Smart Watch», to register, and then, following guidance, scan the QR-code to link Amazfit Smart Watch.

Turn on/off the unit

Turning on/off the unit
Click on the watch button, which is located on the right side, to turn on the display.
If in the on mode, press and hold this button, you'll turn off your watch.
While first using, the watch display may appear QR-code to link Amazfit Smart Watch with your phone.

Charging the unit

Charging the unit
Place the watch on the proper docking station to recharge the device.
Please use the hours to recharge the battery charger with a nominal output voltage of 5V and 500mA output current and higher

Precautionary measures

The watch has a IP67 level of dust and water resistance, can be in water with room temperature at a depth of 1 meter for 30 minutes. But do not use the device in the shower and during the voyage.
Do not use watch under the water. If watch becomes wet, it is necessary to wipe the touch screen with a dry cloth, and then you can charge your device and start using them.
The watch is not protected from sea water, acid and alkaline solutions, chemicals and other substances. In case of breakage or damage of device as a result of improper use, you can not use the warranty service.

Main parameters

Title: Amazfit Smart Watch
Model: A1602
Battery Capacity: 280mAh
Type of wireless connection: Bluetooth 4.0 / Wi-Fi
Input voltage: 5V DC
Input Current: 500 mA (MAX)
Operating temperature: 0°C - 40°C
The level of water resistance: IR67
Requirements: support for Bluetooth 4.0 on Android 4.4 or 7.0 or above iSO
Select «More and more devices» to check the number of CMIIT ID

List of faults

Product Name	List of faults
Amazfit Smart Watch	Improper operation of the apparatus features described in the user manual Problems with display / text Problems with vibration feedback Problems with timing devices The occurrence of cracks / damage due ta construction material or devices
Dock station	Problems with the charging device

Manufacturer: OOO «Anwei Huami Xinxi Technology» (Mi eco-system)
Location: Hefei city, Gaoxin District, Wangjiangxi Road 800, Guojia Dongman Main Center, Building A4, Office 1201

Xiaomi-Mi.com
