Siemens 5SD7 483 Series Installation Instruction

Montageanleitung
Installation Instruction
RSC (0,25 Nm)
DE – Kodierung
EN – Coding
Fernmeldekontakt / Remote Signalling Contact
5SD7 483-1
RSC
12 11 14
7mm
0.14 mm
Safety
instructions
see back view
5SD7 483-X
5SD7 498-1
4,5 Nm
U /I
max max
AC: 250 V/ 1 A
U /I
max max
DC: 125 V/ 0.2 A
7mm
2 2
- 1.5 mm
MLFB
Anforderungsklasse / Requirement class
Max. Stringspannung U /
OC STC
Max. string voltage U
OC STC
Max. Kurzschlussstrom I /
SC STC
Short circuit current I
SC STC
Nennstoßstrom I (8/20)μs /
n
Nominal discharge current I (8/20)μs
n
Max. Ableitstoßstrom I (8/20)μs /
max
Max. discharge current I (8/20)μs
max
Schutzpegel U / Protection level U
p p
Temperaturbereich /
Operating temperature range
Schutzart / Degree of protection
∅ min. L, N, PE
∅ max. L, N, PE
Ersatzstecker / Replacement
Installation
!
Photovoltaic Application
6
L+ L-
L-
L+
L-
L+
L
N PE
5SD7 483-0 / 5SD7 483-1
C acc. to E DIN VDE 0675-6;
SPD class II acc. to IEC 61643-1;
SPD Type 2 acc. to EN 61643-11
1000 V DC
80 A DC
15 kA
30 kA
≤ 5 kV
-40 ... +80 °C
IP20
2
14.5 mm 14.5 mm
2.5 mm
2
35 mm
5SD7 498-1
transparent ⇒ ok
red ⇒ defect
⇒
Recycling
Photovoltaic
Generator
≤ −>
I max. 80 A
DC (SC STC)
U ocstc
1000V
DC max
L+
L-
To converter
1000 V
Switch
Converter
Z-NR: 9661080_02/03.02.09 Printed in Germany
253676.41.96 "03"
2
2.5 mm
2
25 mm
