WCB731M, WCB730M, WCB736M, WCB737M
1. Introduction
WCB731M is a Wi-Fi / Bluetooth Combo module compliant with IEEE802.11 a.b.g.n.ac MAC/baseband/radio and
Bluetooth 5.0 optimized for low-power applications.
The core chipset is from MediaTek part number MT7668AUN.
2. Hardware Architecture:
2.1 Main Chipset Information
Item
IEEE802.11 a.b.g.n.ac mac/baseband/radio
Bluetooth 5.0
Version 1.0
Vendor
MediaTek
XuGuang Tech
Part Number
MT7668AUN
page 1 of 21
Advertisement
Table of Contents
Related Manuals for Samsung WCB731M
Summary of Contents for Samsung WCB731M
- Page 1 WCB731M, WCB730M, WCB736M, WCB737M 1. Introduction WCB731M is a Wi-Fi / Bluetooth Combo module compliant with IEEE802.11 a.b.g.n.ac MAC/baseband/radio and Bluetooth 5.0 optimized for low-power applications. The core chipset is from MediaTek part number MT7668AUN. 2. Hardware Architecture: 2.1 Main Chipset Information...
-
Page 2: Operational Description
3. Operational Description WCB731M is the 802.11a/b/g/n /ac +Bluetooth 5.0 Combo Module that acts as a communication controller for users of a wireless device to connect to SMART TV - Features >IEEE 802.11ac Draft compliant. >Dual-band 2.4GHz /5 GHz >Dual-stream spatial multiplexing up to 600Mbps data rate >Support 20, 40, 80MHz channel with optional SGI(256QAM modulation) -
Page 3: Product Details
16kHz(256kbps rate) transferred over USB interface. - Adaptive Frequency Hopping The WCB731M Mgathers link quality statistics on a channel by basis to facilitate channel assessment and Channel map selection. The link quality is determined using both RF and baseband signal processing to Provide a more accurate frequency-hop map. - Page 4 - IEEE 802.11n HT20 - IEEE 802.11n HT40 Version 1.0 XuGuang Tech page 4 of 21...
-
Page 5: Recommended Operating Conditions
-IEEE 802.11ac -Output Power tolerance Output power ± 1 dBm -Simultaneous transmission BT LE 2.4GHz Wi-Fi 5GHz Wi-Fi BT LE 2.4GHz Wi-Fi 5GHz Wi-Fi -Recommended Operating conditions Typ. Unit Operating voltage Operating temperature(ambient) °C Version 1.0 XuGuang Tech page 5 of 21... - Page 6 -AS Information Company Name: CHENGDU XUGUANG TECHNOLOGY CO.,LTD. Fax: +86-28-84841628 Tel: +86-28-84841628 Add: 2 section of park road Longquanyi Chengdu China -Certification Information Name(Model name): Certification ID: Company Name: Production date Vendor: Version 1.0 XuGuang Tech page 6 of 21...
-
Page 7: Operating Frequency
Declaration of conformity We, Samsung Electronics Co., Ltd. of 129, Samsung-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do 16677, Korea declare under our sole responsibility that our product Manufacturer: Samsung Electronics Co., Ltd. Address: 129, Samsung-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do 16677, Korea Contact Person: Hansung You / Staff Engineer E-mail: digitalyou@samsung.com... -
Page 8: Output Power
OUTPUT POWER: 15.64 dBm(802.11a) 16.12 dBm(802.11n_HT20) Lower-sub band 15.19 dBm(802.11n_HT40) 14.64 dBm(802.11ac_VHT80) Antenna 0 14.63 dBm(802.11a) 15.11 dBm(802.11n_HT20) Higher-sub band 13.49 dBm(802.11n_HT40) 13.92 dBm(802.11ac_VHT80) 15.05 dBm(802.11a) 15.31 dBm(802.11n_HT20) Lower-sub band 14.55 dBm(802.11n_HT40) WLAN 5 GHz 13.52 dBm(802.11ac_VHT80) (5 150 MHz Antenna 1 17.08 dBm(802.11a) ~ 5 725 MHz) - Page 9 19.02 dBm(802.11b) 13.02 dBm(802.11g) Antenna 0 12.50 dBm(802.11n_HT20) 12.43 dBm(802.11n_HT40) 19.28 dBm(802.11b) WLAN 2.4 GHz 15.12 dBm(802.11g) Antenna 1 15.39 dBm(802.11n_HT20) 15.92 dBm(802.11n_HT40) 17.32 dBm(802.11g) Multiple Antenna 17.32 dBm(802.11n_HT20) 17.65 dBm(802.11n_HT40) 1 Mbps 11.00 dBm Bluetooth 2 Mbps 8.90 dBm 3 Mbps 8.88 dBm 1 Mbps...
-
Page 10: Device Type
FCC/IC Product description DEVICE TYPE Wi-Fi/BT Transceiver Temperature Range -20 °C ~ 50 °C Bluetooth LE 2 402 MHz ~ 2 480 MHz Bluetooth 2 402 MHz ~ 2 480 MHz 2 412 MHz ~ 2 472 MHz (802.11b/g/n(HT20)) WLAN 2.4 GHz 2 422 MHz ~ 2 462 MHz (802.11n(HT40)) 5 180 MHz ~ 5 240 MHz (802.11a/n(HT20)/ac(VHT20)) WLAN... - Page 11 1 Mbps 11.26 dBm Bluetooth LE 2 Mbps 11.25 dBm 1 Mbps 11.26 dBm Bluetooth 2 Mbps 10.89 dBm 3 Mbps 11.19 dBm 17.30 dBm(802.11b) 11.15 dBm(802.11g) Antenna 0 10.75 dBm(802.11n_HT20) 9.49 dBm(802.11n_HT40) 17.32 dBm(802.11b) WLAN 2.4 GHz 14.60 dBm(802.11g) Antenna 1 14.31 dBm(802.11n_HT20) 13.54 dBm(802.11n_HT40)
- Page 12 9.82 dBm(802.11a) 9.67 dBm(802.11n_HT20) Antenna 0 9.69 dBm(802.11n_HT40) 10.53 dBm(802.11ac_VHT80) 9.12 dBm(802.11a) WLAN 9.05 dBm(802.11n_HT20) 5 250 MHz ~ Antenna 1 8.95 dBm(802.11n_HT40) 5 350 MHz Band 10.35 dBm(802.11ac_VHT80) 12.40 dBm(802.11a) 12.27 dBm(802.11n_HT20) Multiple Antenna 12.35 dBm(802.11n_HT40) 13.45 dBm(802.11ac_VHT80) 9.83 dBm(802.11a) RF OUTPUT 9.80 dBm(802.11n_HT20) Antenna 0...
- Page 13 13.00 dBm(802.11a) 13.47 dBm(802.11n_HT20) Multiple Antenna 13.89 dBm(802.11n_HT40) WLAN 13.40 dBm(802.11ac_VHT80) 5 470 MHz ~ 13.08 dBm(802.11a) 5 725 MHz Band Multiple Antenna 12.89 dBm(802.11n_HT20) _Straddle 14.18 dBm(802.11n_HT40) 15.90 dBm(802.11ac_VHT80) 8.85 dBm(802.11a) 8.93 dBm(802.11n_HT20) Antenna 0 7.67 dBm(802.11n_HT40) 7.83 dBm(802.11ac_VHT80) 0.54 dBm(802.11a) 0.90 dBm(802.11n_HT20) Antenna 0_Straddle...
-
Page 14: Antenna Type
ANTENNA TYPE Chip Antenna Bluetooth LE -0.44 dBi Bluetooth -0.44 dBi Antenna 0 1.54 dBi WLAN 2.4 GHz Antenna 1 1.35 dBi Multiple Antenna 4.46 dBi Antenna 0 1.00 dBi 5 150 MHz ~ Antenna 1 1.25 dBi 5 250 MHz Band Multiple Antenna 4.14 dBi ANTENNA GAIN... -
Page 15: Fcc Radiation Exposure Statement
FCC MODULAR APPROVAL INFORMATION EXAMPLES for Manual This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device must accept any interference received, including interference that may cause undesired operation. -
Page 16: Upgrade Firmware
Validity of using the module certification: In the event that these conditions cannot be met (for example certain laptop configurations or co-location with another transmitter), then the FCC authorization for this module in combination with the host equipment is no longer considered valid and the FCC ID of the module cannot be used on the final product. In these circumstances, the OEM integrator will be responsible for re-evaluating the end product (including the transmitter) and obtaining a separate FCC authorization. - Page 17 FCC MODULAR APPROVAL INFORMATION EXAMPLES for Manual This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device must accept any interference received, including interference that may cause undesired operation. CAUTION: Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.
- Page 18 End product labelling The label for end product must include “Contains FCC ID: A3LWCB731M, Contains IC: 649E-WCB731M”. “ CAUTION: Exposure to Radio Frequency Radiation. This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance of 20cm between the radiator and your body.
- Page 19 Requirement per KDB996369 D03 2.2 List of applicable FCC rules List the FCC rules that are applicable to the modular transmitter. These are the rules that specifically establish the bands of operation, the power, spurious emissions, and operating fundamental frequencies. DO NOT list compliance to unintentional- radiator rules (Part 15 Subpart B) since that is not a condition of a module grant that is extended to a host manufacturer.
-
Page 20: Rf Exposure Considerations
2.5 Trace antenna designs For a modular transmitter with trace antenna designs, see the guidance in Question 11 of KDB Publication 996369 D02 FAQ – Modules for Micro-Strip Antennas and traces. The integration information shall include for the TCB review the integration instructions for the following aspects: layout of trace design, parts list (BOM), antenna, connectors, and isolation requirements. - Page 21 See Guidelines for Labeling and User Information for RF Devices – KDB Publication 784748. Explanation:The host system using this module, should have label in a visible area indicated the following texts: "Contains FCC ID: A3LWCB731M."Contains IC: 649E-WCB731M 2.9 Information on test modes and additional testing requirements5 Additional guidance for testing host products is given in KDB Publication 996369 D04 Module Integration Guide.
