Summary of Contents for Korg X3
- Page 57 CONTENTS 1) Block Diagram: Page 2-4 2) Circuit Diagram: Page 5-10 3) Test Mode: Page 11 4) Parts List: Page 12-13 1st Edition Issued date: November 22nd, 2002 Issued by: KORG INC.
- Page 60 KLM 2382. sch‑ 1 ‑ M on Sep 30 15: 00: 17 2002...
- Page 67 microKORG Test Mode How to start the test mode: Auto Mode [1] + [3] & [POWER ON] : Full test except MIDI Loop Mode1 [WRITE] + [1] & [POWER ON] : Full test (Auto) = Auto Mode Mode2 [WRITE] + [2] & [POWER ON] : External Test (Auto) Mode3 [WRITE] + [3] &...
- Page 68 PART CODE PART NAME NOTE Q'TY 001233300 PCB ASSY KLM-2333 MICRO KORG M.PART 001238200 PCB ASSY KLM-2382 MICRO KORG M.PART 304000110 TR 2SA812 KLM-2333 304020230 TR 2SC3661-TA/TB KLM-2333 304060250 FET CPH6302-TL KLM-2333 312053000 LED MSGB39W (RED/GREEN) KLM-2333 314001400 DIODE RLS-73...
- Page 69 PART CODE PART NAME NOTE Q'TY 620018200 PSW KNOB KOC-E40224-1 M.PART *313X111000 3 DIGIT NUMERIC LED MT-AD563SR KLM-2333 *315X111008 LED MGB31D (GREEN) KLM-2333 *315X150003 LED MSB31DA-1 (RED) KLM-2333 *324X111011 IC XC61CN3102MR KLM-2333 *335X111001 X'TAL HC-49US 10.000MHZ KLM-2333 *362X111000 VR RV1103N1-25KQ-B10K (10KB) KLM-2333 *362X111001 VR R0902N1-20FA2-10KA (10KA) KLM-2333...
