- Page 1 12V ACCESSORY PANEL USER MANUAL AKEP-12VAP001 V1.6 PLEASE READ AND UNDERSTAND THIS MANUAL COMPLETELY BEFORE USING THIS PRODUCT.
-
Page 2: Table Of Contents
CONTENTS 1. INTRODUCTION..........3 2. SAFETY............3 3. INSTALLATION INSTRUCTIONS.....4 3.1 MOUNTING.........4 3.1 WIRING..........6 4. OPERATING INSTRUCTIONS......7 5. WARRANTY CARD.........8... -
Page 3: Introduction
1. INTRODUCTION This manual covers the safety precautions, operational procedures, installation & warranty terms of the Adventure Kings 12V Accessory Panel. The 12V panel is an electrical accessory panel designed to be soft wired or hard wired into a vehicle where it is permanently located. Fitted with a 12V voltmeter, 2x 12V CIG power sockets &... -
Page 4: Installation Instructions
3. INSTALLATION INSTRUCTIONS The following installation instructions focus on the mounting and wiring options suitable for the 12V Accessory Panel. If you are not comfortable with installing the 12V Accessory Panel yourself then it is recommended that you contact a qualified auto electrician to complete the installation. Always ensure that the power source (12V battery) has been disconnected before working on a 12V electrical system. - Page 5 STEP 4: Position the mounting plate where required and mark the hole centres for each socket. See Figure 1 to the right for hole dimensions. Use these hole dimensions to confirm you have accurately marked the holes centres. STEP 5: Drill out each socket hole using the 38mm hole saw.
-
Page 6: Wiring
3.1 WIRING Wiring the 12V Accessory Panel into a vehicle or canopy can be done a variety of different ways. The following shows a simple and safe wiring method for the 12V Accessory Panel. Remember to disconnect the power source (12V battery) before attempting any 12V electrical work. Contact a qualified auto-electrician if you unsure or not confident wiring the 12V Accessory Panel in yourself. -
Page 7: Operating Instructions
4. OPERATING INSTRUCTIONS After installation of the 12V Accessory Panel the voltmeter should indicate the voltage being supplied by the power source (12V car battery). If the voltmeter is not showing a reading or the sockets are not providing power, then complete the following checks or contact a qualified auto- electrician: •... -
Page 8: Warranty Card
12 MONTH LIMITED WARRANTY WARRANTY PERIOD: Full 12 month warranty from date of purchase against all manufacturing defects. WHAT DOES THE WARRANTY COVER? Under normal usage conditions, this warranty covers: a. Any defect in design or manufacture which results in the product failing to perform substantially as described in authorised advertising or literature.
