- Page 1 USER MANUAL UNIVERSAL UTE TUB RACK SKU: AKRR-TUBRACK_01...
- Page 2 CONTENTS 1. WARNING 2. GENERAL INFORMATION 2.1 Package Contents 3. INSTALLATION 3.1 Tub Rack Installation 3.2 Adding a Roof Top Tent 4. WARRANTY PLEASE READ AND UNDERSTAND THIS MANUAL COMPLETELY BEFORE USING THIS PRODUCT. V1.4...
- Page 3 1. WARNING The Adventure Kings Ute Tub Rack is rated to a dynamic load rating of 100kg, we recommend users check the load rating capacity of their tubs with their vehicle manufacturer before use. Added weight can alter the braking and driving behavior of your vehicle. Adhere to payload limits of your vehicle and do not overload.
- Page 4 3. INSTALLATION It’s easiest to assemble the basic structure on the ground. This tub rack’s height is adjustable and can be altered once its on the vehicle. Installation can be easier done at a lower height and later altered to suit your requirements.
- Page 5 STEP Slot the headboard piece and tailgate piece into the upper legs, adjust the width to suit your vehicle. Add M8 bolts with washers and finger tighten with M8 Nylock nut. Add two support pieces to the top of the tub rack, connecting the two ends. Fit M8x20 bolts STEP washers and nuts and finger tighten.
- Page 6 3.2 ADDING A ROOF TOP TENT If you are adding a Kings Rooftop Tent, we advise that the “front to back” support beams are aligned with the mounting extrusion of the base of the tent (825mm apart). This provides a solid mounting base and an even distribution of weight.
- Page 7 4. WARRANTY 12 MONTH LIMITED WARRANTY WARRANTY PERIOD: Full 12 month warranty from date of purchase against all manufacturing defects. WHAT DOES THE WARRANTY COVER? Under normal usage conditions, this warranty covers: a. Any defect in design or manufacture which results in the product failing to perform substantially as described in authorised advertising or literature.
