Electronic Aquastat® Controller
APPLICATION
The L7148F Electronic Aquastat® Controller replaces
the function of the bulb and capillary electromechanical
Aquastat® with electronic temperature sensing and
microprocessor controlled relays.
The L7148F Electronic Aquastat® Controller has an
internal high limit controller and is intended for use in
gas-fired boilers using a 24 Vac burner circuit with
vestibules for a wiring enclosure. The L7148F can
replace a Honeywell L4080 High-Limit and R8225
Transformer Relay.
The L7148F has a 24 Vac burner output and is used in
gas boilers where ignition controls such as the Honeywell
S8600 Spark Ignition or SV9500/SV9501 SmartValve™
controls or standing pilot gas controls such as the
Honeywell VR8300 are powered from 24 Vac.
An external 120 Vac to 24 Vac transformer with 10 VA
minimum is required to power the L7148F. For total
external transformer VA requirements, add the 10 VA
requirement for the control, gas valve load requirement
(connections B1, B2), zone valve connection
requirement (see zone valve specifications), vent
damper requirement and VA requirement for any other
equipment. Total low voltage load must not exceed 4A.
The L7148F Electronic Aquastat® is available with quick
connect or AMP© plug connections. The 3/16 in. (5 mm)
B1 quick connect and AMP© plug connections meet
ANSI miswiring requirements. C(Z), W(T) and R(TV)
terminals are provided in a terminal block with screw
connections.
The complete L7148F system requires a sensor,
immersion well and transformer, all of which must be
ordered separately. See Table 1 for sensor
specifications.
® U.S. Registered Trademark
Copyright © 2002 Honeywell • All Rights Reserved
INSTALLATION INSTRUCTIONS
SPECIFICATIONS
High Limit Setpoint Range: 130°F to 240°F (54°C to
116°C). (Select models may differ.)
Differential: Fixed 10°F (6°C). (Select models may
differ.)
Operating Voltage Range:
L1-L2 Line Voltage Power: Nominal, 120 Vac.
R-C 24V Transformer Output: Nominal, 24 Vac.
Minimum/Maximum Ambient Temperature:
Minimum: -30°F (-9°C) with 2.0A 24V load.
Maximum: 150°F (66°C) with 2.0A 24V load.
Operating Relative Humidity: 0 to 95% RH
non-condensing.
Electrical Ratings (60 Hz only):
B1-B2: 2.0A at 24 Vac.
C1-C2: Full Load 7.4A at 120 Vac; Locked Rotor, 44.4A
at 120 Vac.
NOTE: Total low voltage load must not exceed 4.0A.
Case Dimensions: See Fig. 1.
Mounting: Vestibule mount.
Accessories:
Sensor: Thermistor sensor available separately. For
leadwire lengths available, see Table 1.
Immersion Well: Available separately. Contact your dis-
tributor or Honeywell sales representative to order, or
refer to Accessories for Immersion Wells, Compres-
sion Fittings, and Element Holders, form
68-0040.
Transformer: Available separately with either quick con-
nect terminals or AMP® plug connections. Contact
your distributor or Honeywell sales representative to
order.
121371AA Sensor Retaining Clip.
32002656-001 Sensor Retaining Spring.
L7148F
69-1065B-2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Aquastat L7148F and is the answer not in the manual?

Questions and answers

Summary of Contents for Honeywell Aquastat L7148F

  • Page 1 The L7148F has a 24 Vac burner output and is used in Minimum: -30°F (-9°C) with 2.0A 24V load. gas boilers where ignition controls such as the Honeywell Maximum: 150°F (66°C) with 2.0A 24V load. S8600 Spark Ignition or SV9500/SV9501 SmartValve™...
  • Page 2: Installation

    Electrical Shock Hazard. a shell I.D. of 3/8 in. (10 mm). To order an immersion Can cause severe injury, death or equipment well, contact your distributor or Honeywell sales damage. representative, or refer to Accessories for Immersion Disconnect power supply before beginning Wells, Compression Fittings, and Element Holders, form wiring.
  • Page 3 Connect the AMP© plugs to the receptacles on the control. An AMP© plug connection is shown in Fig. 8. The L7148F and appropriately sized external transformer can power up to three Honeywell V8043 Zone Valves. SENSOR Additional valves, in groups of three or less, require an additional transformer, or use Honeywell R8889 Zone Valve Panel.
  • Page 4: High Limit

    A system containing an L7148F Electronic Aquastat® Normal Controller does not require a separate high limit High Limit controller. The L7148F can replace a Honeywell L4080 High-Limit Controller and an R8225 Transformer Relay. Either Reset The L7148F does not provide a low limit function. An external transformer, appropriately sized for the specific application;...
  • Page 5: Checkout And Troubleshooting

    L7148F ELECTRONIC AQUASTAT® CONTROLLER CHECKOUT AND device through several cycles to make certain that it provides proper control of the system as described in the TROUBLESHOOTING Operation section. Troubleshooting Checkout Use Fig. 12 as a guide for troubleshooting. Check to make certain that the Electronic Aquastat® Controller has been properly installed and adjusted.
  • Page 6 L7148F ELECTRONIC AQUASTAT® CONTROLLER L7148F TO ADDITIONAL R845A RELAYS FOR OTHER ZONES T87F T87F T87F R845A RELAY ZONE 1 R845 RELAY R845 R845 PUMP PUMP PUMP DISCONNECT SWITCH OPTIONAL VENT DAMPER PLUG THTR L7148F VOLTAGE LOW VOLTAGE GAS VALVE GAS VALVE (VR8300) (VR8300) THTR...
  • Page 7 R IS A CONVENIENCE TERMINAL FOR 24V HOT CONNECTION FOR USE WITH IGNITION CONTROLS. THERMOSTAT M11478B Fig. 8. Wiring L7148F with S8610 Intermittent Pilot Ignition Module with automatic vent damper plug and Honeywell D892/D896/M892/M896 Vent Damper. DISCONNECT OPTIONAL VENT DAMPER PLUG SWITCH...
  • Page 8 L7148F ELECTRONIC AQUASTAT® CONTROLLER S8600 DISCONNECT CIRCULATOR SWITCH L7148F CABLE D892/D896/M892/M896 L1 C2 L2 FUSE HIGH LIMIT DIAL HIGH LIMIT CONTACTS 6-PRONG FEMALE MOLEX POLARIZED 4-PRONG DATA RECEPTACLE IN L7148F MALE MOLEX PLUG AND PORT AND 5-PRONG MALE 4-PRONG FEMALE MOLEX PLUG ON CABLE MATING PLUG ON CABLE S1 S2...
  • Page 9 L7148F ELECTRONIC AQUASTAT® CONTROLLER L7148F T87F T87F T87F ZONE 1 ZONE 2 ZONE 3 R882C R882C R882C N.O. N.O. N.O. N.C. N.C. N.C. COM. COM. COM. VALVE OR N.O. N.O. N.O. IGNITION N.C. N.C. N.C. CONTROL COM. COM. COM. CIRCULATOR CIRCULATOR CIRCULATOR ZONE 1...
  • Page 10 THERMO WELL LOCATED PER BOILER OEM INSTRUCTIONS. M20069 Fig. 12. L7148F Troubleshooting Guide. Automation and Control Solutions Honeywell Honeywell Limited-Honeywell Limitée 1985 Douglas Drive North 35 Dynamic Drive Golden Valley, MN 55422 Scarborough, Ontario M1V 4Z9 Printed in U.S.A. on recycled 69-1065B–2...
