Xvive P58 Manual

Guitar wireless system 5.8 ghz wireless frequency band
Hide thumbs

Advertisement

Table of Contents

P58
Guitar
Wireless System
5.8 GHz Wireless Frequency Band
English Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the P58 and is the answer not in the manual?

Questions and answers

Related Manuals for Xvive P58

Summary of Contents for Xvive P58

  • Page 1 Guitar Wireless System 5.8 GHz Wireless Frequency Band English Manual...
  • Page 2 Xvive has developed a wireless system that uses the 5.8 GHz (Europe), EN 301.489 (Europe) band: the P58 Guitar Wireless System. 5.8 GHz is a less crowded The Korean version has been KC certi ed frequency, so it’s less likely to encounter signal interference;...

  • Page 3: Fcc Certification

    FCC CERTIFICATION FCC Caution: Any changes or modi cations not expressly However, there is no guarantee that interference will not occur approved by the party responsible for compliance could void in a particular installation. the user's authority to operate this equipment. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the This device complies with Part 15 of the FCC Rules.
  • Page 4 In extreme cases, they may even present a risk of explosion, obviously defective products. re, heat, smoke or gas. Xvive does not accept any liability • Do not continue to use defective rechargeable batteries. for damage arising from abuse or misuse.
  • Page 5 INFORMATION ABOUT COLLECTION AND DISPOSAL OF OLD ITEMS AND USED BATTERIES [For customers in the European Union] [Information on Disposal in Countries outside the European Union] If you want to discard electrical and electronic items, please contact your dealer or supplier for further information. To deal with these old products and batteries properly, These symbols on the products, packaging, or on any please help to save valuable resources and prevent any...

  • Page 6: One-Year Limited Warranty

    Xvive or an a liated Xvive service center warranty or non-warranty service. and deemed to be defective within the warranty period.
  • Page 7 • The purchaser will pay all freight charges to return the original item to Xvive USA or its a liated service centers. • If the unit is deemed to be covered by this warranty, Xvive will ship the repaired or replacement unit to the purchaser...
  • Page 8 WARNING: BEFORE USING YOUR XVIVE 5.8GHz GUITAR WIRELESS SYSTEM, CAREFULLY READ THE OPERATING INSTRUCTIONS. 1. Observe all instructions carefully in the P58 set manual. 3. Do not place near heat sources, such as radiators, heat 2. Do not to perform service operations beyond those registers, or appliances that produce heat.

  • Page 9: Features And Specifications

    FEATURES & SPECIFICATIONS CONTENTS P58 Guitar Wireless System • 5.8 GHz True Diversity wireless system • High-resolution 24-bit / 48 kHz audio Transmitter x1 1 PCS • Transmitter battery life: up to 5 hours Receiver x1 1 PCS • Receiver power: 9 - 12V DC (12V DC adapter included)
  • Page 10 TRANSMITTER USB charging port Power LED Channel LED 1/4” TS input Active/Passive Mode LED CH: Channel select button / Active/Passive Mode Battery Compartment Power on/o...
  • Page 11 RECEIVER Channel / Scan button 1/4” TS Output Tuner Screen with Tuner on/o Wireless RF LED and Channel LED True Bypass / 1/4” TS Guitar input DC 9 - 12V input Bu ered Bypass USB Type-C output for Transmitter charging...

  • Page 12: Quick Start

    QUICK START 2. Pair the Transmitter and Receiver by making sure that they 1. Plug the Transmitter into the output jack of your guitar/ are set to the same wireless channel. The A58 Transmitter bass/instrument. Using a ¼” instrument cable, connect has six channels;...
  • Page 13 QUICK START 4. Enjoy your wireless freedom! 3. Whenever the green RF LED on the Receiver is on, the Make sure the Transmitter is positioned at least 10 mm Transmitter and Receiver are successfully paired. (1 cm) from your body. Hello! RF LED Channel LED...
  • Page 14 QUICK START BUFFER TUNER ON P58 can be set to either True Bypass or Bu ered Bypass. Press the switch to turn the tuner ON: the screen will light Bu ered Bypass is a good choice if you use long cables up and the output will be muted.
  • Page 15 QUICK START PAIRING WITH ANOTHER A58: CONNECT WITH A GUITAR CABLE: If your transmitter runs out of power, you can pair your If necessary, you can connect your instrument to the receiver with another A58 transmitter set to the same Receiver/Tuner using a guitar cable.

  • Page 16: Batteries And Charging

    BATTERIES AND CHARGING RECEIVER POWER TRANSMITTER CHARGING FROM RECEIVER The Receiver must be powered by a 9V-12V adapter with a Your Transmitter can be charged by plugging it into the minimum current of 200 mA. back of the Receiver, using a USB Type-C cable. In order to charge the Transmitter, the Receiver must be connected to a power outlet using a 12V 400mA or 9V 500mA adapter.
  • Page 17 BATTERIES AND CHARGING BATTERIES AND CHARGING The P58 system comes with a USB-C charging cable, which POWER STATUS LED INDICATIONS POWER STATUS charges the transmitter when connected to any 5V / 2A BATTERY CHARGING Green (solid): 41-100% USB charger adapter or USB power source.
  • Page 18 TUNER FUNCTION INTRODUCTION TUNER WIRELESS RF LED MUTE When successfully connected When the footswitch is to the Transmitter, the RF LED turned o , the output will light will stay on. be muted and the MUTE LED will light up. - The note you are tuning to is displayed in the middle in white - Blue dots indicate that you are tuned at, and need to...
  • Page 19 SCAN FOR THE BEST CHANNEL ACTIVE AND PASSIVE MODES Press and hold the channel button on the Receiver for 3 The A58 Transmitter o ers both Active and Passive modes, seconds to enter Channel Scan mode. The Receiver’s channel making it compatible with all pickups—from passive to LED will ash during scanning and then will stay on the high-output active pickups! optimal wireless channel.
  • Page 20 1) Keep more than 3 metres of distance between the P58 receiver unit and Wi-Fi transmitters, such as routers. 2) If you experience interference from Wi-Fi devices in the vicinity, try changing to a di erent channel on the P58 transmitter and receiver.

  • Page 21: Specifications

    SPECIFICATIONS WIRELESS SYSTEM TRANSMITTER Globe: 5730 - 5844MHz, Up to 5 hours Wireless Frequency Battery Life Korea: 5729 - 5821MHz (3.8V rechargeable Li-ion, 780 mA) Passive mode input: 2.84Vp-p, Active Transmitter Input >100 feet line-of-sight outdoors. Actual Working Range mode input: 7.5Vp-p, volume -10 dB range depends on RF signal absorption, Maximum Level re ection and interference...

  • Page 22: Troubleshooting

    TROUBLESHOOTING NO SOUND LOW AUDIO OUTPUT • Check that the Transmitter and Receiver are connected • When using a passive instrument, make sure your properly, and that their power switches are turned on. Transmitter is set to Passive mode. • Check your instrument’s volume knob to make sure that SIGNAL INSTABILITY: RF LED FLICKERING signal is being sent to the Transmitter.
  • Page 23 APPLICATIONS Guitar or Bass Amp Guitar / Bass Amp Modeler, E ect Pedal or Pedalboard Piezo-electric TRANSMITTER RECEIVER Acoustic Guitar PA Mixer or Digital Recorder GUITAR WIRELESS SYSTEM 5.8 GHz Wireless Frequency Band...
  • Page 24 SHENZHEN FZONE TECHNOLOGY CO., LTD. 2nd oor, Building 12, Xicheng Industrial Area, Xixiang Town, Baoan District, Shenzhen Guangdong China. 518101 E-mail: support@xvive.com Tel: +86-755-2786 6639 www.xvive.com...

This manual is also suitable for:

P58r
