- Page 1 User Manual for RB10-2404M-PSE 10 Gigabit Uplink Management Switch January 2025...
-
Page 2: Management And Maintenance
Introduction Product overview RB10-2404M-PSE is a 10G uplink Layer 3 enterprise level network managed PoE switch optimized for enterprise level customers. Switch implements a new generation high-performance platform and new self-developed switch OS. Supports flexible 802.1Q VLAN, IGMP, port monitoring, port aggregation, bandwidth control, ring network applications and other network management functions. -
Page 3: Installation
Switch diagram Back Front 10G Managed PoE Switch AC-110-24 0V 1000M L3 24G PoE+4*10G Link/Act 1000M Console LED indicator 24*10/100/1000M port 4*10G SFP 1*console port Grounding screw AC power connector LED definition: Indicator State Description Normal power on Green light ON Power indicator：... -
Page 4: Desktop Installation
Desktop installation Attach the four non slip rubber pads that came with Place the switch on a horizontal desktop in a the device to the bottom corners of the switch. ventilated area. Gigabit Managed PoE Switch Gigabit Managed PoE Switch 1000M 1000M L3 24G PoE+4*10G... - Page 5 WARNING 1.Do not stack heavy objects on top of switch. 2.To avoid risk of electric shock, do not open unit under operation or with the power still active. 3.Clean switch with dry soft cloth, do not use any liquid. 4.lf the power cable is damaged please replace cable or contact us for a replacement cable. Applications VLAN application Fiber media converter...
-
Page 6: 06 Troubleshooting
Troubleshooting Check for AC power cord plug to be fully plugged. The PWR indicator is not on after the power is connected Check AC power cord for damage and replace. Check for proper RJ45 link indicators. No link means Switch cannot communicate after power up network cable is not connected. - Page 7 Technical Specifications RB10-2404M-PSE Product model 4x 10G SFP+ and 24x 10/100/100Base-Tx PoE+ managed switch Product description 24*10/100/1000Base-TX PoE Port (Data) Fixed ports 4*1G/10G SFP/SFP+ 1-2 ports support Poe IEEE 802.3af/at/poe + + / BT PoE ports 3-24 ports support Poe IEEE 802.3af/at IEEE802.3af/at/PoE++/BT...
- Page 8 Product size/ 440mm*290mm*45mm package size（L*W*H） 515mm*375mm*95mm N.W/G.W（kg） 2.5kg/2.8kg Installation Rack type (19" rack mounting brackets included) Lightning protection / 8/20us；IP30 protection level 3C； Certificate CE mark, commercial； CE/LVD EN60950；FCC Part 15 Class B； RoHS； Warranty 1 year (Accessories not included)
