LIMITED WARRANTY & DISCLAIMER ..................3 LIMITATION OF LIABILITY ....................... 5 Safety ........................... 6 2.1 After Sales Support ......................7 III. Aquilon Max Introduction ....................8 Overview..........................8 Technical Specifications ....................9 Proper Use ......................... 10 Inspection ........................10 VII.
User Manual I. Disclaimer • The intellectual property rights for this manual belongs to Holland Green Science Corporation (hereinafter referred to as “the Company”). • Products of the company are under the patent protection of China and other countries and regions (inclusive of obtained patents and patents currently under application).
Page 4
User Manual with all costs prepaid by Buyer. Replacement parts may be new or refurbished, at the election of the Company. All replaced parts shall become the property of the Company. Shipment to Buyer of repaired or replacement Products shall be made in accordance with the Delivery provisions of the Terms & Conditions agreed to by the purchase of this product.
User Manual company is not liable in cases of deliberate, negligent or accidental misuse of the products, use with inappropriate reagents or consumables, damage caused by disaster, repair or modifications done by anyone other than the company. The company does not warrant that the product will not infringe the intellectual property rights of a third party either alone or in combination with other products or in the operation of any process.
User Manual II. Safety IMPORTANT Safety Items to be Observed. Safety Warnings ! DANGER (may cause serious damage to property and or casualties) 1. Please carefully read this User Manual prior to operating the instrument and observe the instructions on safe operation. 2.
User Manual After Sales Support If problems are encountered or technical support is required when installing or using the instrument, please contact ServiceEurope@hollandgreenscience.com. The Company may provide technical assistance and information regarding the instrument or equipment or Service without charge at its sole discretion. Buyer assumes sole responsibility for any reliance on or use of such assistance and information, and the Company makes no warranty thereon.
User Manual III. Aquilon Max Introduction The Aquilon Max recirculating chillers feature PID temperature controllers to provide accurate and reliable temperature control and cooling. They are designed for continuous, reliable operation When the liquid is not in use, the liquid should be discharged.
User Manual IV. Technical Specifications Model 20303003 Product Name Aquilon Max Reservoir volume(L) Process temperature (℃) ﹣20℃~20℃ Ambient Temperature (℃) ≤30 Refrigeration Ambient relative humidity (%RH) ≤65 Performance Temperature stability (℃) ±2℃ Cooling capacity 2500 at 10℃ (W) Refrigerant R410A...
User Manual Proper Use The instrument is designed for non-residential use and to be used in conjunction only with accessories recommended within this manual and by the manufacturer. Inspection Unpack the equipment carefully and check for any damage which may have arisen during transport.
User Manual VII. Operating Instructions Preparation and precautions prior to use The instrument must be placed on a flat and level surface composed of non-combustible materials. b. 300mm (minimum) of clearance is required around the instrument to ensure the front and back ventilation grilles are well ventilated.
User Manual 7.1 User Interface • TEMP: Displays the measured temperature value. To set the desired temperature, press the SETTINGS key until the TEMP SET value flashes. Press the setting key again to confirm the parameter. • SET: Displays the desired temperature value set manually. •...
User Manual 7.2 Startup Connect the power according to the power outlet. Turn on the instrument at the main switch. The display shows the initialization sequence before the instrument is ready to use. NOTE: Every time you turn on the instrument it will beep intermittently, the icon of visual alarm and the word “end”...
User Manual 7.4 Start / Stop Cooling Operation Before the refrigeration is turned on, please press key to let the liquid circulate in the pipeline in advance. After setting the operating parameters, press button for 4 to 5 seconds to start the cooling process.
Page 15
User Manual Programs PROG 0 - Fixed Value and Time PROG 1 - Multi-step, Step 1 to Step 8 PROG 2 - Multi-step, Step 1 to Step 8 PROG 3 - Multi-step, Step 1 to Step 8 PROG 4 - Multi-step, Step 1 to Step 8 PROG 5 - Multi-step, Step 1 to Step 8 PROG 6 - Multi-step, Step 1 to Step 8 PROG 7 - Multi-step, Step 1 to Step 8...
Page 16
User Manual • Press the INCREASE or DECREASE key to change the first digit. • Mo=0000 Default value single-step program, Mo=0001 multi-step programs. STEP 4: Set the parameter and return to standard state. • Press the SETTING key 1 time to set parameter Mo and return to standard state. •...
Page 17
User Manual • Press the SETTING key for 3 seconds. “PROG 1” will initially blink. Then the number will blink. • Press the INCREASE key to select the program number to program. • Press the SETTING key to start the programming process. •...
Page 18
User Manual • Press the INCREASE or DECREASE key to enter the tenths temperature value. • Press the SHIFT key to move to the next parameter digits. Each move will cause parameter to blink. • Use INCREASE or DECREASE key to set each temperature value. •...
Page 19
User Manual • Press the SETTING key to accept the run time. • The next program step will appear. The tens temperature value will blink. STEP 4: Repeat Steps 2 and 3 for each program step. • Upon setting all the steps, the controller will return to multi-step program standard state. Note: Leave temperature and run time at zero for the steps not needed in the program.
Page 20
User Manual • Press the SETTING key to confirm the program to run. STEP 3: Press RUN key. • Press the RUN key for 2 seconds to start the program. STEP area, RUN, HEAT, and run time will illuminate. 7.5.4 Set up Program Cycling This function only applies to multi-step programs.
Page 21
User Manual STEP 4: Press SETTING key. • Press the SETTING key to enter Level 1 parameters. • Note: When entering the controller’s internal parameters, Level 1, LK= 0000 will always come up first. STEP 5: Scroll to parameter Cy. •...
Page 22
User Manual • Press the SETTING key 2 times to set parameter Cy and return to the multi-step program standard state. 7.5.5 Set up a RUN delay. The controller allows the user to delay the start of a program for up to 99 hours and 59 minutes. Once the delay times out, the program will start operation.
Page 23
User Manual • Press the INCREASE key to enter the first time value. Press the SHIFT key to move to the second time digit. Digit will blink. Press the INCREASE key to enter the second time value. • Press the SETTING key 1 time to set parameter dy and return to fixed value program standard state.
Page 24
User Manual STEP 5: Scroll to parameter dy • Press the SETTING key 2 times to scroll through parameters until the parameter dy appears. PROG 00 00 • Press the INCREASE key to enter the first time value. Press the SHIFT key to move to the second cycle digit.
Page 25
User Manual • Press the INCREASE key to enter the code digit. • Press the SETTING key to enter the Level 2 controller parameters. STEP 2: Scroll to parameter Po. • The tM parameter will appear. Press the SETTING key 1 time to scroll through parameters until the parameter Po appears.
User Manual • Press the SETTING key 4 times to set parameter Po and return to standard state. 7.6 Internal Parameter Settings Overview 7.6.1 The process of changing a parameter value STEP 1 • Press and hold the SETTING and shift keys for 3 seconds to view the controller’s internal parameters.
Page 27
User Manual STEP 4 • The first available function parameter within the level will appear. Press the increase key to change the first digit value. The value will blink as it is being set. • Press the shift key to move to the next parameter digits. Each move will cause the digit to blink. STEP 5 •...
Page 28
User Manual Level 2 LK = 0003 Level 4 LK = 8286 Version 1.0...
User Manual VIII Troubleshooting Problem Causes Solution The power cord is unplugged Reinsert or not plugged in correctly No power Reset once, if a further trip occurs, Tripped Breaker contact ServiceEurope@hollandgreenscience.com IX Maintenance and Cleaning Keep the instrument dry and clean in routine operations. Clean the outer surface with a non-abrasive cleanser and only connect the power supply when the entire instrument surface is dry.
Page 30
User Manual Holland Green Science Europe B.V. Mauritskazerne D41, Office D21 Nieuwe Kazernelaan 2 6711 JC EDE, The Netherlands Tel: +31643498156 E-mail: SalesEurope@hollandgreenscience.com E-mail: ServiceEurope@hollandgreenscience.com Chamber of Commerce number: 82526494 VAT number: NL862505744B01 Version 1.0...
