- Page 1 OWNER’S MANUAL LG Digital Signage (MONITOR SIGNAGE) Please read the user manual before using this product to ensure safe and convenient use. 55VH7J 55VM5J www.lg.com Copyright © 2021 LG Electronics Inc. All Rights Reserved.
-
Page 2: Table Of Contents
TABLE OF CONTENTS BASIC ..........3 - Checking the Accessories ..........3 - Checking the Optional Accessories ......4 - Learning the Buttons ............5 GETTING READY ......6 - Storage Method for Panel Protection ....6 - Connecting the IR Sensors ..........8 - Kensington Lock Device ..........9 CHECKING BEFORE INSTALLATION ...... -
Page 3: Basic
This product is not intended for household use. BASIC NOTE • The accessories provided with your product may vary depending on the model or region. • Product specifications or contents in this manual may be changed without prior notice due to upgrade of product functions. -
Page 4: Checking The Optional Accessories
How to use the ferrite core Use the ferrite core to reduce the electromagnetic interference in the power cable. Wind the power cable on the ferrite core once. Place the ferrite core close to the monitor. Checking the Optional Accessories In order to improve product performance, optional accessories are subject to change without prior notice. -
Page 5: Learning The Buttons
Learning the Buttons The illustrations may differ depending on the model. • : Change the input signal. • : Accesses the main menus, or saves your input and exits the menus. • : Adjust the up and down. • : Moves left and right. •... -
Page 6: Getting Ready
GETTING READY Storage Method for Panel Protection Correct Method If the product needs to be set upright, hold both sides of the product, and tilt backward carefully for. Do not let the panel to touch the floor. Panel When laying down the product, lay a cushion on a flat floor. Put the product on it with the panel of the product facing down. - Page 7 Incorrect Method If the product is tilted onto the bezel, the bottom of the panel may be damaged. Panel If the product is tilted toward the corner of the panel, the bottom of the panel may be damaged. Panel...
-
Page 8: Connecting The Ir Sensors
Connecting the IR Sensors This allows a remote control sensor to be placed in a custom location. Then that display can control other displays via an RS-232C cable. -
Page 9: Kensington Lock Device
Kensington Lock Device (This feature applies only to some models.) The Kensington lock device connector is located on the back of the monitor. For more information on installation and use, refer to the user manual provided with the locking device. Connect the Kensington security system cable between the monitor and a table. -
Page 10: Checking Before Installation
CHECKING BEFORE INSTALLATION We are not responsible for product damage caused by failure to follow the guide. Installation Orientation Using Vertically When installing vertically, rotate the monitor 90 degrees clockwise while facing the front of the screen. Tilt Angle 15˚ 40 mm Ceiling, Floor Orientation... -
Page 11: Installation Location
Installation Location We are not responsible for product damage caused by failure to follow the guide. Indoor Installing on a Wall A : 200 mm (7.8 inches) or more B : 100 mm (3.9 inches) or more • The warranty will not cover any damage caused by using the product in direct sunlight on the front panel. -
Page 12: Wall Mount Holder
Wall Mount Holder To install the monitor on a wall, attach a wall mount holder (optional) to the back of the monitor. Take caution, and ensure that the wall mount holder (optional) is securely fixed to the monitor and to the wall. The VESA dimensions of the wall mount by model are as follows. - Page 13 Securing the monitor to a wall (optional) (Depending on model) Insert and tighten the eyebolts, or brackets and bolts on the back of the monitor. - If there are already bolts inserted in the eyebolts’ position, remove the other bolts first. Mount the wall brackets with the bolts to the wall.
-
Page 14: Safety And Precaution Guide For Installation
Safety and Precaution Guide for Installation During installation, ensure any conductive materials (metals, etc.) do not enter through the gaps or vent holes between the panel and the back cover. - Covering the back of the product with a cloth may prevent foreign substances from entering the product and causing malfunction. -
Page 15: Tiling Displays
Tiling Displays How to Mount the Set Example of 2 x 2 Tiling Using the screws for attaching the VESA wall mount, mount the set to the wall mount plate or the wall. Screws for attaching the VESA wall mount (M6) (Unit: mm (inches)) 600 (23.6) - Page 16 How to Join Sets Install the additional sets using the VESA wall mounting screws by using the same method mentioned before. (M4 x L6) Complete the 2 x 2 tiling. You can use various options of tiling including 3 x 3 by using the same method. Completeness of the Set (2 x 2 tiling complete) CAUTION •...
- Page 17 NOTE • The load applied to each set should be supported by the wall mount plate or the wall using a VESA wall mount (600 x 400). • The load applied to each set should be supported by the wall mount plate using a VESA wall mount. (Each set must be firmly mounted to the wall mount plate or the wall.) •...
-
Page 18: Precautions For Use
PRECAUTIONS FOR USE Dust The warranty will not cover any damage caused by using the product in an excessively dusty environment. Afterimage • After-image appears when the product is turned off. - Pixels may be damaged rapidly if a still image is displayed on the screen for a long period of time. Use the screen- saver function. - Page 19 • Recommended Usage Condition Change the background color and text color at equal intervals. - Afterimages occur less when the colors to be changed are complementary to one another. ITO or MoTi Pixel Layer Switch the screen at equal time intervals. - Take caution, and ensure that text or images from before the screen change are not left in the same location after the screen change.
-
Page 20: Product Specifications
PRODUCT SPECIFICATIONS Without prior notice, all product information and specifications contained in this manual are subject to change to improve the performance of the product. 55VH7J IR IN, RS-232C IN, RS-232C OUT, HDMI IN 1, HDMI IN 2, DVI-D IN, DP IN, DP OUT, USB 2.0 IN, Input/Output Ports AUDIO IN, AUDIO OUT, LAN IN, LAN OUT, OPS IN Recommended Resolution... - Page 21 Model Name Size (Width x Height x Thickness) (mm) Weight (kg) 1,212.2 x 683.0 x 86.9 18.8 55VH7J Size (Width x Height x Thickness) (inches) Weight (lbs) 55VM5J 47.7 x 26.8 x 3.4 41.4 DVI-D / HDMI / DisplayPort / OPS (PC) Support Mode Resolution Horizontal frequency (kHz) Vertical frequency (Hz)
- Page 22 NOTE • When the cable is connected to the DVI-D, HDMI or the DisplayPort, you can select the PC/DTV mode optionally. It is recommended that you select PC mode when connecting to a PC and select DTV mode when connecting to other devices.
-
Page 23: Licence
LICENCE Supported licenses may differ by model. For more information of the licenses, visit www.lg.com. The terms HDMI, HDMI High-Definition Multimedia Interface, HDMI trade dress and the HDMI Logos are trademarks or registered trademarks of HDMI Licensing Administrator, Inc. Manufactured under license from Dolby Laboratories. Dolby, Dolby Vision, Dolby Vision IQ, Dolby Audio, Dolby Atmos, and the double-D symbol are trademarks of Dolby Laboratories Licensing Corporation. - Page 24 Refer to ENERGYSTAR.gov for more information on the ENERGY STAR® program. Supplier’s Declaration of Conformity Trade Name Responsible Party LG Electronics USA, Inc. Address 111 Sylvan Avenue, North Building, Englewood Cliffs, NJ The model and serial number of the product are 07632 located on the back and on one side of the product.
