TKO 9050 Owner's Manual

Functional trainer
Hide thumbs Also See for 9050:

Advertisement

Quick Links

Functional Trainer
Model 9050
Owner's Manual
www.tko.com
2

Advertisement

loading
Need help?

Need help?

Do you have a question about the 9050 and is the answer not in the manual?

Questions and answers

Summary of Contents for TKO 9050

  • Page 1 Functional Trainer Model 9050 Owner’s Manual www.tko.com...
  • Page 2 Product Diagram...
  • Page 3 Exploded Diagram...
  • Page 4 Parts List...
  • Page 5 Parts List Description QTY No. Description Left Upright Frame Bearing 61800ZZ Right Upright Frame Bearing 61804ZZ Pulley Φ95*24 Rear Lower Support Frame Top Support Frame End Cap PT 50*100*3 Foam Grip Ø24*3*345mm Left Slide Frame Foam Grip Ø24*3*160mm Right Slide Frame Foam Grip Ø24*3*290mm Front Wheel Bracket Pulley Frame...
  • Page 6 Parts List Long Bar Short Handle Tricep Rope Ankle Strap Chains Hand Grips Safety Hooks...
  • Page 7 Assembly Note: Before starting assembly remove all parts and hardware from the carton, ensure you have everything according to the list. Step 1 Install Rear Lower Support Frame (3), Rear Top Support Frame (33) and Rear Top Support Frame (4) onto Left Frame (2) and Right Frame (1), using Hex Bolt M10*25 (46) and Flat Washer Φ11*Φ20*2 (52).
  • Page 8 Assembly Step 2 Loosen and remove 2 Guide Rod Bush (12) from the Guide Rod (10); Then remove the Top Weight Plate (15) and The Selector Rod assembly from the Guide Rods.
  • Page 9 Assembly Step 3 Re-Insert both Guide Rod (10) into the holes on the bottom of the Main Frame; Make sure the Rubber Bumpers are at the bottom of the Guide Rods.
  • Page 10 Assembly Step 4 Install 20 Weight Stack (14) onto the Guide Rod (10); Re-install the Top Weight Plate (15) and Selector Rod assembly onto the top of the Weight Stack; Make Sure the holes of the Weight Stack for the Magnetic Lock Pin are the same direction.
  • Page 11 Assembly Step 5 First Re-install the Guide Rod Bush (12) that was removed in STEP 2; Then tighten both Hex Screw M 6*4 (62) with a wrench; Repeat the same procedure for the other side.
