Summary of Contents for ADENDORFF VLS12TS-1
- Page 1 Original Instructions Instruction Manual For Hydraulic Log Splitter VLS12TS-1 Read and understand the entire manual before operating machine. Save this manual for future referen Instruction manual 1. Read Carefully the instruction manual before operation.
-
Page 2: Safety Instructions
Do not allow person to operate until they have read the safe operating instruction contained this manual This warning sticker is to remind the operator to read the manual and make himself familiar with all safe instructions before starting to work on the machine. Keep your hands off all moving machine parts! Pinched hands danger. -
Page 3: Protect Your Eyes And Face
previsions on the workplace. Personal protection must be assured by wearing safely shoes and gloves ,tight-fitting apparels and goggles during splitting Make sure to select a suitable place with sufficient clearance for proper operation of the machine as well as or safe handling of the split logs and eventual ancillary tools and equipment. - Page 4 Warning label for releasing the air before operation Warning label for movable pressure plate Position: on movable pressure plate; on movable cylinder ends Crushing hazards General warning label WARNING! Before using the product, make sure the two hands controls function! ...
-
Page 5: Application Conditions
WARNING! NEVER using elbow to operate the lever! NEVER using any parts of body except hand to operate the lever. ALWAYS using TWO hands to operate the lever! 2.2 .APPLICATION CONDITIONS This log splitter is designed for operating under ambient temperatures between +5℃... - Page 6 low ambient temperature, let the motor run idle and cycle the unit several times till the oil in the hydraulic loop warms up. Setting of the main control valve is done at manufacturer before shipping. The unit comes to you ready for service so that no other adjustment/installation work is required other than assembly of the hand-guards on the control levers.
- Page 7 try to split such Across-the-Grain wood by continuously pressing operation handle or over 3 seconds!! Wood clamping before splitting: 3.7 Operation...
- Page 8 Firstly place the log on the working table and lean it against the log fixing device; Secondly press down the two operation handles to let the wedge run towards the log with wedge pressing on the top of the log. DO NOT RELEASE THE CONTROL LEVERS UNTIL THE CYCLE IS COMPLETELY OVER AND THE LOG IS SPLIT.
-
Page 9: Maintenance Instructions
(2)Unscrew the two bolts from the cylinder fixing part on both sides. Moving handle (2) Then start machine again to press down operation handles again to make the cylinder going down. After all above 2 steps are taken,operator can move the log splitter by the moving handle. - Page 10 detect eventual oil leaks -Lubrication of all moving parts 5.2 Hydraulic oil Periodically check the oil level inside the hydraulic oil tank. When doing so, accurately avoid contaminating the tank with dirt, wood chips, sow dust etc… Make sure that the splitter never runs without oil or with low oil level. When this happens, air is likely to reach inside the hydraulic loop.
- Page 11 safety and Protection up to max 0.03Anominal fault current. 6.3 Wiring Diagram...
-
Page 12: Risk Factors
6.4 HYDRAULIC DIAGRAMM 7.Risk factors 7.1Mecnanical dangers The special two –hands control mechanisms minimizes risks and dangers related to moving parts on the machine An additional safety provided on the machine in order to prevent working with only one handle while the other one is being engaged (held down) by some mechanical tool or system . -
Page 13: Troubleshooting Chart
WARNING: removing a fixed protection casing when the machine is running or without having priory cut the power 8.Trouble shooting chart Type of malfunction Possible origins of the problem Solutions When the control hands is -Oil level is too low -Fill oil in Pushed down. - Page 14 Move back wedge towards steel stud and fit the screws on the steel stud. Then tighten the two nuts M8. Protection guard Fix the protection guard with 2 screws M6x8, 2 spring washers ø6, 2 flat washers ø6. Control lever...
- Page 15 1.Rotate the control lever upwards and make it match the hole on the valve seat. 2.Fit the control lever into position using the bolt supplied as shown . The bolt should pass through the hole on the valve seat . 3.Then tighten the nut.
- Page 16 Put the chain on the hook. Technicai specifications Model number VLS12TS-1 Voltage 230V/50Hz Max Log splitting length 700mm Min log diameter 80mm Max log diameter 350mm Tank capacity 5.5L Splitting force Motor power...
- Page 18 Pos No. Description 1 work table 2 cylinder assembly 3 wedge 4 valve seat 5 brackt for valve seat 7 wood supporting frame 8 wood lifting frame 9 valve assembly 10 valve hinge 11 operation flat shaft 12 protecton guard 13 operation handle 14 plastic handles 15 guiding lienen...
- Page 19 screw for fixing wood lifting frameM12*50 41 clip pin 42 snap spring...
