Material Handling Precautions and Storage precautions that must be followed. ADB SAFEGATE reserves the right to examine goods upon which a claim is made. Said goods must be presented in the same condition as when the defect therein was discovered. ADB SAFEGATE furthers reserves the right to require the return of such goods to establish any claim.
A mounting collar on the base of the vane body fits onto the Model 20231 Mast Adapter or the Model 2023 Crossarm. The 20231 Mast Adapter is used to install a single vane, while the 2023 Crossarm allows the Model 2020 Vane to be installed in combination with an anemometer, such as the Model 2030.
2020 housing’s packing carton. The tail is packed inside a folded cardboard container taped to the side of the 2020 carton. Install the tail and counterweight as explained in the steps below.
2.5 Orientation The Model 2020 Micro Response Vane must be oriented correctly as to direction. The axis of the vane should be as close to vertical as possible. Orient the vane to direction (azimuth) as described in the steps below.
The connector is a quick release type and requires only a quarter turn of the nut to lock it in place. Do not tighten with a wrench. Connections are as shown in drawing 2020-004 at the back of this manual. If cable is ordered with the vane, the connector will be attached at the factory.
Model 2020 Micro Response Vane 4. Calibration Refer to the appropriate signal conditioning manual for system calibration instructions. Check the Model 2020 Micro Response Vane for correct operation prior to making any adjustments to the system electronics. 4.1 Checking Vane Operation To check vane operation, follow the steps below.
Page 9
Model 2020 Micro Response Vane CALIBRATION CERTIFICATE Instrument Micro Response Vane Model Number 2020 Serial Number Range Calibration Points Output (typical) Output (actual) 1–360° Azimuth 180° AZ 1.665 V DC* * with excitation voltage of 3.333 V DC Cable T600503...
Use great care in disassembly and reassembly of the vane and vane body. Never use excessive force to make parts fit together. Overtightening of fasteners will either break the fastener or damage the machined threads. Any difficulties encountered during servicing that are not correctable by the user should be referred to the ADB Safegate. Customer Service Department.
5.5 Maintenance Kit A maintenance kit (P/N M488140) is available for the Model 2020 that provides the parts necessary for basic upkeep of the instrument. The kit includes those parts that are the most susceptible to wear, such as bearings and set screws. To order this kit, contact ADB Safegate.
The top piece has four shafts, which should set in the four holes on the lower piece. Raise the calibrator on the Model 2020 vane shaft so that the top piece does not have any weight on the calibration shaft, but the shaft is still in the groove.
Model 2020 Micro Response Vane 6. Warranty Unless specified otherwise, ADB Safegate. (the Company) warrants its products to be free from defects in material and workmanship under normal use and service for one year from date of shipment, subject to the following conditions: The obligation of the Company under this warranty is limited to repairing or replacing items or parts which have been returned to the Company and which upon examination are disclosed, to the Company’s satisfaction, to have been...
The following pages include reference drawings to assist in installation and maintenance of this instrument. M403256-01-003 (2 sheets) 2020/2030 Crossarm Assembly Mounting Drawing 2020-003 (2 sheets) Assembly Drawing, 2020 Vane Sensor Body 2020-004 2020 Schematic CODE& Edition UM-5055, Rev. 1.1.26, 2024/11/13 125...
