  • Page 1 Power Systems Installing the IBM PowerLinux 7R1 (8246-L1C or 8246-L1S) GI11-9878-01...
  • Page 3 Power Systems Installing the IBM PowerLinux 7R1 (8246-L1C or 8246-L1S) GI11-9878-01...
  • Page 4 Before using this information and the product it supports, read the information in “Safety notices” on page v, “Notices” on page 35 the IBM Systems Safety Notices manual, G229-9054, and the IBM Environmental Notices and User Guide, Z125–5823. This edition applies to IBM Power Systems servers that contain the POWER7 processor and to all associated models.

  • Page 5: Table Of Contents

    Safety notices ....... . . v Installing the IBM PowerLinux 7R1 (8246-L1C or 8246-L1S)....1 Prerequisites for installing the 8246-L1C or 8246-L1S .
  • Page 6 Power Systems: Installing the IBM PowerLinux 7R1 (8246-L1C or 8246-L1S)

  • Page 7: Safety Notices

    You should also refer to the safety information documentation any time you do not clearly understand any safety information in the U.S. English publications. Replacement or additional copies of safety information documentation can be obtained by calling the IBM Hotline at 1-800-300-8751.
  • Page 8 Electrical voltage and current from power, telephone, and communication cables are hazardous. To avoid a shock hazard: v Connect power to this unit only with the IBM provided power cord. Do not use the IBM provided power cord for any other product.
  • Page 9 Observe the following precautions when working on or around your IT rack system: v Heavy equipment–personal injury or equipment damage might result if mishandled. v Always lower the leveling pads on the rack cabinet. v Always install stabilizer brackets on the rack cabinet. v To avoid hazardous conditions due to uneven mechanical loading, always install the heaviest devices in the bottom of the rack cabinet.
  • Page 10 Pack the rack cabinet in the original packaging material, or equivalent. Also lower the leveling pads to raise the casters off of the pallet and bolt the rack cabinet to the pallet. (R002) (L001) (L002) viii Power Systems: Installing the IBM PowerLinux 7R1 (8246-L1C or 8246-L1S)
  • Page 11 (L003) All lasers are certified in the U.S. to conform to the requirements of DHHS 21 CFR Subchapter J for class 1 laser products. Outside the U.S., they are certified to be in compliance with IEC 60825 as a class 1 laser product.
  • Page 12 Exchange only with the IBM-approved part. Recycle or discard the battery as instructed by local regulations. In the United States, IBM has a process for the collection of this battery. For information, call 1-800-426-4333. Have the IBM part number for the battery unit available when you call. (C003)

  • Page 13: Installing The Ibm Powerlinux 7R1 (8246-L1C Or 8246-L1S)

    Installing the IBM PowerLinux 7R1 (8246-L1C or 8246-L1S) ™ Follow the steps outlined in this topic collection for installing the IBM PowerLinux 7R1 (8246-L1C or 8246-L1S) system. You might need to read the following documents before you begin to install the server: v The latest version of this document is maintained online.

  • Page 14: Installation Overview

    1. “Installing the server into a rack” on page 3 2. “Cabling the server and setting up the console” on page 15 3. “Completing the server setup” on page 21 Power Systems: Installing the IBM PowerLinux 7R1 (8246-L1C or 8246-L1S)

  • Page 15: Installing The Server Into A Rack

    Before installing the system unit into a rack, complete the following steps: 1. Read the Rack safety notices (http://publib.boulder.ibm.com/infocenter/systems/scope/hw/topic/ p7hbf/racksafety.htm). 2. Plan where to place the system units. Place the larger and heavier system units in the lower part of the rack.

  • Page 16: Marking The Location

    EIA unit as A, as shown in Figure 2 on page 5. Mark the rack so that the mark can also be seen from the rear of the rack. Power Systems: Installing the IBM PowerLinux 7R1 (8246-L1C or 8246-L1S)

  • Page 17: Attaching The 8246-L1C Or 8246-L1S Mounting Hardware To The Rack

    Mark the bottom hole of this EIA unit as A. 9. Repeat step 7 on the left side of the rack. Attaching the 8246-L1C or 8246-L1S mounting hardware to the rack You might need to attach the mounting hardware to the rack. Use the procedure in this section to perform this task.
  • Page 18 Figure 4. Aligning and engaging the pins into the holes in the rear of the rack 4. Reinstall the screw that was removed in step 2 on page 5, as shown in Figure 5 on page 7. Power Systems: Installing the IBM PowerLinux 7R1 (8246-L1C or 8246-L1S)
  • Page 19 Figure 5. Reinstalling the screw Attention: You must install the screw to secure the device. 5. Return to the front of the rack. Ensure the latch is still open on the front of the slide rail. Refer, step 1 on page 5. 6.

  • Page 20: Installing The 8246-L1C Or 8246-L1S System Into The Rack

    9. Continue with “Installing the 8246-L1C or 8246-L1S system into the rack.” Installing the 8246-L1C or 8246-L1S system into the rack Use the procedure in this section to install an 8246-L1C or 8246-L1S system into the rack. The information provided is intended to promote safety and reliable operation.

  • Page 21: Installing The Cable-Management Arm

    Figure 9. Release latches and server 4. Remove the shipping bracket that is on the left side of the rear of the system before you cable it. To remove the shipping bracket, complete the following steps: a. Remove the two screws (A), as shown in Figure 10. Figure 10.
  • Page 22 Position the unattached end of the support arm so that the locking tab on the underside of its tip aligns with the bracket hole. Insert the tab into the hole (1) and turn the bracket (2) to secure it to the Power Systems: Installing the IBM PowerLinux 7R1 (8246-L1C or 8246-L1S)
  • Page 23 support arm, as shown in Figure 13. Figure 13. Securing the cable-management stop bracket to the support arm 3. To attach the other side of the support arm to the backside of the slide rail, slide the bracket (B) into the left slide rail until the spring-loaded latch snaps into place, as shown in Figure 14.
  • Page 24 Slide the other cable-management arm tab into the extension bracket (E) on the outside of the right slide rail (2). Push the tab until the spring-loaded latch snaps into place, as shown in Figure 17 on page 13. Power Systems: Installing the IBM PowerLinux 7R1 (8246-L1C or 8246-L1S)

  • Page 25: Connecting The Expansion Units, Disk Drives, And Pci Adapters

    1. For information about connecting expansion units, see Enclosures and expansion units 2. For information about connecting the disk drive unit, see Disk drives 3. For information about connecting the PCI adapters, see PCI adapters (http://publib.boulder.ibm.com/ infocenter/systems/scope/hw/topic/p7hakl/p7hak_pciadapters_front_71x_73xl.htm). Installing the server into a rack...
  • Page 26 Power Systems: Installing the IBM PowerLinux 7R1 (8246-L1C or 8246-L1S)

  • Page 27: Cabling The Server And Setting Up The Console

    (part number 46K5108) is used to convert the ASCII terminal nine–pin Dshell connector to an RJ45 serial port connector on the system. For more information about the locations of the connectors on the system, see 8246-L1C and 8246-L1S locations (http://publib.boulder.ibm.com/infocenter/systems/scope/ hw/topic/p7ecsl/p7ecsloccodes_71x_73x.htm).

  • Page 28: Cabling The Server To The Hardware Management Console

    Using service applications, the HMC communicates with managed systems to detect, consolidate, and forward information to IBM service for analysis. If you have not already done so, install and configure your HMC. For instructions, see Installation and configuration scenarios (http://publib.boulder.ibm.com/infocenter/systems/scope/hw/topic/p7hail/...

  • Page 29: Cabling The Server And Accessing The Integrated Virtualization Manager

    To learn more about connecting an HMC to a private network so that it can manage more than one managed system, see HMC network connections (http://publib.boulder.ibm.com/infocenter/systems/ scope/hw/topic/p7hail/netconhmc.htm). Note: v You can also have multiple systems attached to a switch that is then connected to the HMC. For more information, see HMC network connections.

  • Page 30: Cabling The Server With Keyboard, Video, And Mouse

    5. Connect the power cables for the server and wait for the green light on the operator panel to start flashing. For more information, see “Connecting the power cables to the system” on page 19. 6. Install an operating system and update the operating system, if required. Power Systems: Installing the IBM PowerLinux 7R1 (8246-L1C or 8246-L1S)

  • Page 31: Connecting The Power Cables To The System

    Connecting the power cables to the system Use this procedure to connect power cables to the system. Note: You must have completed cabling the system and setting up a console, before connecting the power cables to the system. To connect power cables to the system, complete the following steps: 1.
  • Page 32 Connect the system power cords from the server and I/O drawers to the PDU with an IEC 320 type receptacle. b. Attach the PDU input power cord and plug it into the alternating current (ac) power source. Power Systems: Installing the IBM PowerLinux 7R1 (8246-L1C or 8246-L1S)

  • Page 33: Completing The Server Setup

    3. Change the managed system passwords. To change the managed system passwords, complete the following steps: a. In the navigation area, expand Systems Management > Servers. b. In the contents area, select the managed system. c. In the operations area, click Update passwords. © Copyright IBM Corp. 2012, 2013...
  • Page 34 For instructions about creating partitions, see Partitioning with the HMC (http:// publib.boulder.ibm.com/infocenter/systems/scope/hw/topic/p7hatl/iphbllparwithhmcp6.htm). For instructions about deploying system plans, see Deploying a system plan by using an HMC (http://publib.boulder.ibm.com/infocenter/systems/scope/hw/topic/p7hc6l/ iphc6deploysysplanp6.htm). 9. Install an operating system and update the operating system. Power Systems: Installing the IBM PowerLinux 7R1 (8246-L1C or 8246-L1S)

  • Page 35: Completing Server Setup If You Do Not Have A Management Console

    5. To start a system that is not managed by an HMC or ASMI, complete the following steps: a. Open the front door of the managed system. b. Press the power button on the control panel. See Power on (http://publib.boulder.ibm.com/ infocenter/systems/scope/hw/topic/p7hbyl/poweronoff.htm).
  • Page 36 Power Systems: Installing the IBM PowerLinux 7R1 (8246-L1C or 8246-L1S)

  • Page 37: Reference Information

    Attach the mounting hardware to the rack and install the To install the mounting hardware to the rack, see cable management arm. “Attaching the 8246-L1C or 8246-L1S mounting hardware to the rack” on page 5 To install the cable management arm, see “Installing the cable-management arm”...

  • Page 38: Installing The Factory-Racked Server

    You might need to install the factory-racked server. Use this procedure to perform this task. To install a server that is already in a factory-installed rack, complete the following high-level tasks: Power Systems: Installing the IBM PowerLinux 7R1 (8246-L1C or 8246-L1S)
  • Page 39 Task Where to find associated information Check the prerequisites. For instructions, see “Prerequisites for installing the 8246-L1C or 8246-L1S” on page 1. Perform the inventory. For instructions, see “Before you begin” on page 1. Verify the rack position. You must first install the rack. If you do not have a rack installed, see Installing the rack (http:// publib.boulder.ibm.com/infocenter/systems/scope/hw/...

  • Page 40: Supporting Information For Setting Up Consoles

    For example, if you connected your PC or notebook to HMC1, the IP address for Power Systems: Installing the IBM PowerLinux 7R1 (8246-L1C or 8246-L1S)

  • Page 41: Setting The Ip Address On Your Pc Or Notebook

    If you plan to connect your PC or notebook to your network, see Accessing the ASMI without an HMC (http://publib.boulder.ibm.com/infocenter/systems/scope/hw/topic/p7hbyl/ connect_asmi.htm). Setting the IP address on your PC or notebook To access the ASMI through a web browser, you first need to set the IP address on a PC or notebook.

  • Page 42: Windows Xp And Windows 2000

    Attention: Record the current settings before making any changes. Use this information to restore these settings if you disconnect the PC or notebook after setting up the ASMI web interface. 5. Select Use the Following IP Address. Power Systems: Installing the IBM PowerLinux 7R1 (8246-L1C or 8246-L1S)

  • Page 43: Correcting An Ip Address

    ASCII terminal” on page 15. v Determine the current IP address. For instructions, see Function 30: Service processor IP address and port location(http://publib.boulder.ibm.com/infocenter/systems/scope/hw/topic/p7hb5l/ func30.htm). v Move the reset toggle switches on the service processor from their current position to the opposite position.

  • Page 44: Best Practices For Integrating Cable And System Placement

    This applies to installing them into the cable management arm and retaining them to the rack, brackets, and other features that may be provided for cable management. Power Systems: Installing the IBM PowerLinux 7R1 (8246-L1C or 8246-L1S)
  • Page 45 v Install and route the communications cables, starting with smallest diameter first and then progressing to the largest diameter. v Use the innermost cable-management bridge lances for SPCN cables. v Use the middle cable-management bridge lances for power and communications cables. v The outermost row of cable-management bridge lances are available for use when routing cables.
  • Page 46 Figure 22. Cable bend radius Related information: POWER7 770/780 Cabling guide Power Systems: Installing the IBM PowerLinux 7R1 (8246-L1C or 8246-L1S)

  • Page 47: Notices

    All statements regarding the manufacturer's future direction or intent are subject to change or withdrawal without notice, and represent goals and objectives only. The manufacturer's prices shown are the manufacturer's suggested retail prices, are current and are subject to change without notice. Dealer prices may vary. © Copyright IBM Corp. 2012, 2013...

  • Page 48: Homologation Statement

    IBM, the IBM logo, and ibm.com are trademarks or registered trademarks of International Business Machines Corp., registered in many jurisdictions worldwide. Other product and service names might be trademarks of IBM or other companies. A current list of IBM trademarks is available on the web at Copyright and trademark information at www.ibm.com/legal/copytrade.shtml.
  • Page 49 Properly shielded and grounded cables and connectors must be used in order to meet FCC emission limits. IBM is not responsible for any radio or television interference caused by using other than recommended cables and connectors or by unauthorized changes or modifications to this equipment.

  • Page 50: Vcci Statement (Japan)

    Electromagnetic Interference (EMI) Statement - People's Republic of China Declaration: This is a Class A product. In a domestic environment this product may cause radio interference in which case the user may need to perform practical action. Power Systems: Installing the IBM PowerLinux 7R1 (8246-L1C or 8246-L1S)

  • Page 51: Electromagnetic Interference (Emi) Statement - Taiwan

    Um dieses sicherzustellen, sind die Geräte wie in den Handbüchern beschrieben zu installieren und zu betreiben. Des Weiteren dürfen auch nur von der IBM empfohlene Kabel angeschlossen werden. IBM übernimmt keine Verantwortung für die Einhaltung der Schutzanforderungen, wenn das Produkt ohne Zustimmung von IBM verändert bzw.

  • Page 52: Class B Notices

    This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. Power Systems: Installing the IBM PowerLinux 7R1 (8246-L1C or 8246-L1S)
  • Page 53 Properly shielded and grounded cables and connectors must be used in order to meet FCC emission limits. Proper cables and connectors are available from IBM-authorized dealers. IBM is not responsible for any radio or television interference caused by unauthorized changes or modifications to this equipment.
  • Page 54 Confirmed Harmonics Guideline with Modifications (products greater than 20 A per phase) IBM Taiwan Contact Information Electromagnetic Interference (EMI) Statement - Korea Germany Compliance Statement Deutschsprachiger EU Hinweis: Hinweis für Geräte der Klasse B EU-Richtlinie zur Elektromagnetischen Verträglichkeit Power Systems: Installing the IBM PowerLinux 7R1 (8246-L1C or 8246-L1S)

  • Page 55: Terms And Conditions

    Permissions for the use of these publications are granted subject to the following terms and conditions. Applicability: These terms and conditions are in addition to any terms of use for the IBM website. Personal Use: You may reproduce these publications for your personal, noncommercial use provided that all proprietary notices are preserved.
  • Page 56 IBM reserves the right to withdraw the permissions granted herein whenever, in its discretion, the use of the publications is detrimental to its interest or, as determined by IBM, the above instructions are not being properly followed. You may not download, export or re-export this information except in full compliance with all applicable laws and regulations, including all United States export laws and regulations.
