- Page 1 999-00451 Connected Door Lock Installation Instructions Secure Control from Anywhere ™...
-
Page 2: Installation Instructions
Installation Instructions 999-00451 Box Contents Screw Cover Key (2) Exterior Gasket Interior Rechargeable InteriorMounting Assembly Assembly Battery (2) Plate Drive-in Latch Collar Square Corner Strike Reinforcement Dust Box (Optional) Face Plate Plate Plate Mounting Screws (2) --------- Mounting Plate Screw (1) ------------------ USB Cable Interior Housing Screw (1) ------------------------- Battery CompartmentScrews(2)----------------------... -
Page 3: Tools You Will Need
Tools you will need: Tools you may need: IMPORTANT INSTALLATION NOTES. PLEASEREAD: • Remove the battery from the battery compartment and charge it in the Charging Cradle until the LED turns green. • The Array By Hampton ™ connected door lock has a built-in solar panelthat will charge the battery if positioned in direct sunlight. -
Page 4: Installation Overview
Installation Overview Part Description BATTERY COVER (L) Exterior Assembly Cylinder RECHARGEABLE Tailpiece BATTERY (J) Power Cable Gasket BATTERY COMPARTMENT Latch SCREWS (DD) Interior Mounting Plate Interior Assembly Rechargeable Battery Antenna Cover INTERIOR ASSEMBLY (I) Battery Cover Tailpiece Receiver Strike Plate ANTENNA Reinforcement Plate COVER (K) -
Page 5: Pre-Installation Instructions
Pre-Installation Instructions 1. Charge Battery a. Remove the Battery Cover (L), Rechargeable b. Carefully remove the Antenna Battery (J), Battery Charging Cradle, USB Cable Cover (K) by gently pulling the and Wall Adapter. Remove the plastic tab on the edges outward slightly and lifting. Battery (J). - Page 6 4. Install Latch and Strike Plate (Continued) Determine the Proper Faceplate Mortise on door edge chiseled: a. Square corner faceplate b. Round corner faceplate Door edge not chiseled: c. Drive-in collar option Drive-in collar Set the Latch Backset The distance from the center of the bore hole to the edge of the door is called the backset. If the backset of your door is 2-3/8", you don’t need to adjust the latch.
- Page 7 Deadbolt Installation Instructions 5. Install Lock Assemblies A. Door Bore Hole Options Option 1 Option 2 For door with bore hole 2-1/8" diameter For door with bore hole 1-1/2" diameter follow Steps B proceed to STEP D. and C for Mounting Plate Screw (BB) and Mounting Plate removal.
- Page 8 5. Install Lock Assemblies (Continued) E. Power Cable (E) goes underneath the latch. Insert F. Bulged part of the Interior Mounting Plate (H) Tailpiece (D) horizontally. must be toward the door. EXTERIOR VIEW Door Power Cable (E) Tailpiece Tailpiece (D) Power Cable (E) Exterior...
- Page 9 5. Install Lock Assemblies (Continued) J. Align the Tailpiece Receiver (M) of the Interior Assembly (I) onto the Tailpiece (D). INTERIOR VIEW Interior Assembly (I) Interior Assembly (I) Power Cable (E) Tailpiece Receiver (M) Tailpiece (D) K. Insert the two Battery Compartment Screws (DD) and tighten.
- Page 10 Door Preparation Instructions for New Doors If installing the Array By Hampton ™ connected door lock on a new door, follow the door preparation instructions and use the template on Page 10. Mark Door with Template a. Mark the centerline for the deadbolt about 44" 5½"...
- Page 11 This line should be 3 inches. Measureit 3" before using this template. If the line is not 3 inches when measured, print this instruction out,fullscaleonpaperthatis8.5"x11"and measure again. Forbackset 2-3/4" (70mm) Foldondottedlineandfit on dooredge For backset 2-3/8" (60mm) Make a 1" (25.4mm) hole at center Fits 2-1/8"...
- Page 12 ARRAY BY HAMPTON BATTERY MANUFACTURER’S INSTRUCTIONS ™ WARNING: • Misusing the battery may cause it to get hot, explode, or ignite and cause injury. Follow the safety rules listed below: Do not place battery in fire or heat the battery. Do not penetrate the battery with nails, strike the battery with a hammer, step on the battery, or otherwise subject it to strong impacts or shocks.
- Page 13 Radiation Exposure Statement This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20 cm between the radiator your body. Product specification Product name Smart Lock Array By Hampton Product model 2354X Operating temperature...
