HPE Aruba Networking 6300F/M
Switch Series
Installation and Getting Started Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Aruba 6300F and is the answer not in the manual?

Questions and answers

Related Manuals for HP Aruba 6300F

Summary of Contents for HP Aruba 6300F

  • Page 1 HPE Aruba Networking 6300F/M Switch Series Installation and Getting Started Guide...
  • Page 2 Copyright Information © Copyright 2024 Hewlett Packard Enterprise Development LP. Open Source Code This product includes code licensed under certain open source licenses which require source compliance. The corresponding source for these components is available upon request. This offer is valid to anyone in receipt of this information and shall expire three years following the date of the final distribution of this product version by Hewlett Packard Enterprise Company.
  • Page 3 Notices The information contained herein is subject to change without notice. The only warranties for Hewlett Packard Enterprise products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. Hewlett Packard Enterprise shall not be liable for technical or editorial errors or omissions contained herein.

  • Page 5: Table Of Contents

    Chapter 2 Contents Contents Contents About this document Applicable products Related publications Introducing the switches Front of the switches Back of the switches Switch features Installing the switch Shipping the switch in a rack Included parts Installation procedures for 6300 switches SFP/SFP+/SFP28/SFP56 installation notes Sample network topologies Getting started with switch configuration...
  • Page 6 Warranty Information Regulatory Information Documentation Feedback Contents |...

  • Page 7: About This Document

    S0X44A HPE ANW 6300M 48SRX CL8 4C TAA Sw Fixed PoE Fixed Non-PoE JL665A Aruba 6300F 48G CL4 PoE 4SFP56 Switch JL667A Aruba 6300F 48G 4SFP56 Switch JL666A Aruba 6300F 24G CL4 PoE 4SFP56 Switch JL668A Aruba 6300F 24G 4SFP56 Switch...
  • Page 8 Start Here: Installation, Safety, and Regulatory Information for the HPE Aruba Networking 6300F/M Switches and Accessories Start Here: Installation, Safety, and Regulatory Information for the HPE Aruba Networking Modular Power Supplies Start Here: Installation, Safety, and Regulatory Information for the HPE Aruba Networking DC Modular Power Supplies AOS-CX software manuals AOS-CX Power Over Ethernet (PoE/PoE+) Planning and Implementation Guide...

  • Page 9: Introducing The Switches

    Chapter 2 Introducing the switches Introducing the switches HPE Aruba Networking multiport switches are store-and-forward devices offering low latency for high-speed networking. Certain switch models also support Power over Ethernet (PoE) technologies and full network management capabilities. This chapter describes these switches with the following information: Front of the switches: Network ports Management ports...
  • Page 10 Figure 1 Front of all the 6300 Switches Introducing the switches |...
  • Page 11 Table 1: Front of all the 6300 switches: Label and description Label Description JL658A HPE Aruba Networking 6300M 24G 24SFP+ 4SFP56 JL659A HPE Aruba Networking 6300M 48SR5 CL6 PoE 4SFP56 JL660A HPE Aruba Networking 6300M 24SR5 CL6 PoE 4SFP56 JL661A HPE Aruba Networking 6300M 48G CL4 PoE 4SFP56 JL662A HPE Aruba Networking 6300M 24G CL4 PoE 4SFP56 JL663A HPE Aruba Networking 6300M 48G 4SFP56 and JL762A Aruba 6300M 48G Pwr2Prt 2F 1PS Bdl...
  • Page 12 Figure 2 Example of 6300 Switch: JL658A, JL659A, JL660A, JL661A, JL662A, JL663A, JL664A, JL665A, JL666A, JL667A, JL668A Table 2: 6300 Switches: Labels and Description Label Description Switch Port LEDs Back Module status LED PoE LED Speed LED Stk LED Reset button Unit Identification LED Global Status LED SFP56 ports...

  • Page 13: Network Ports

    Table 3: 6300 Switches: Labels and Description Label Description Switch Port LEDs Back Module status LED PoE LED Speed LED Stk LED Reset button Unit Identification LED Global Status LED SFP56 ports USB-C Console LED Mode button RJ-45 console port USB/auxiliary port PoE Mode LED is present only on switch models that support PoE.

  • Page 14: Management Ports

    1/10/2 10/100- Smart Rate Smart Rate 1/10/2- 1/10/25/- 1/10/25/40/50*- Swi- 5GbE /1000 100M/1G/2- 100M/1/2.5/- 5GbE 50GbE /100GbE BaseT .5G/5G 5G/10G QSFP JL66 JL66 48 (CL4 PoE) JL66 24 (CL4 PoE) JL66 JL66 JL76 24 (CL6 PoE) (MACSe 48 (CL8 PoE) (MACSe 48 (CL8/CL6 PoE)

  • Page 15: Auxiliary Port

    There is a single serial console port on the switch, using a USB Type-C connector. This port is used to connect a console to the switch. Use a common USB to USB-C cable (must be data capable). A USB-A Bluetooth adapter (separately orderable, SKU# S1H23A) is available to provide an alternative way of managing and configuring your switch using a mobile app.
  • Page 16 Figure 4 Switch and port LEDs for JL658A, JL659A, JL660A, JL661A, JL662A, JL663A, JL664A, JL665A, JL666A, JL667A, JL668A, and JL762A Table 5: Switch and Port LEDs: Labels and Description Label Description Switch port LEDs Back Module status LED Speed mode selected LED Stk LED Reset button UID (Unit Identification)
  • Page 17 Label Description Speed mode selected LED Stk LED S Reset button UID (Unit Identification) Global Status LED Mode select button OOBM port LED Table 7: Front Panel LED Behavior Switch LEDs Function State Meaning Back LED Status of modular components On - Green Normal installed in the back of the...

  • Page 18: Led Mode Select Button And Indicator Leds

    Switch LEDs Function State Meaning UID LED Locator LED User configured the located LED : OFF On/Flash Blue (for User configured the locator 30 min) LED: On/Flash Global Status Overall status of the product Flash - Green Self-test in progress during Indicator LED UBOOT and SVOS On - Green...

  • Page 19: Reset Buttons

    The state of the switch port LEDs is controlled by the LED Mode select button. The current view mode is indicated by the mode LEDs next to the button. To step from one view mode to the next, press the button to cycle through the different modes.
  • Page 20 Fan requirements Switches Fan Tray 1 Fan Tray 2 JL658A Required Required JL659A Required Required JL663A Required Optional JL664A Required Optional JL660A Required Optional JL661A Required Optional JL662A Required Optional JL762A Required Required R8S89A Required Required R8S90A Required Required R8S91A Required Required R8S92A...

  • Page 21: Power Supplies

    Fan Condition Fan Speed Fan Redundancy Shutdown 2 fans fault Not supported Upon detection, system will be shut down in 3 minutes or component hits thermal limit System with no fan tray Missing both fan Not supported Upon detection, system will be tray/all fans faulted shut down in 3 minutes or component hits thermal limit.

  • Page 22: Power Connector

    HPE Aruba Networking X372 54VDC 1600W 110-240VAC Power Supply (JL670A): A 1600 watt (high-line only) power supply for applicable PoE switches. Offers up to 1440 watts of PoE power, and is keyed so that it will not fit into the power supply slots of non-PoE HPE Aruba Networking switches. HPE Aruba Networking 6300M 1050W 36-72VDC PSU (JL758A): A 1050 watt power supply used for 6300M PoE switches.

  • Page 23: Switch Features

    JL661A Aruba 6300M 24G Class 4 PoE and 4-port SFP56 Switch JL662A Up to 30W Aruba 6300F 48G Class 4 PoE and 4-port SFP56 Switch JL665A Aruba 6300F 24G Class 4 PoE and 4-port SFP56 Switch JL666A HPE Aruba Networking 6300F/M Switch Series | Installation and Getting Started Guide...
  • Page 24 HPE Aruba Networking 6300F/M switch PoE per port Standard Aruba 6300M 48 HPE Smart Rate Class 6 PoE Up to 60W IEEE 802.3bt 100M/1G/2.5G/5G Switch IEEE 802.3af/at** JL659A Aruba 6300M 24 HPE Smart Rate Class 6 PoE 100M/1G/2.5/G5G Switch JL660A HPE Aruba Networking 6300M 48SR10 Class 8 PoE IEEE 802.3bt 4p100G Switch IEEE 802.3af/at**...
  • Page 25 Aruba Activate: Cloud-based service that provides inventory control and facilitates Zero Touch Provisioning. Aruba ClearPass Policy Manager: Network policy management software for wired and wireless network devices that provide on-boarding and role-based control/security. Aruba Central: Network management software cloud platform. It offers IT organizations a simple, secure, and cost-effective way to manage and monitor HPE Aruba Networking switches and HPE Aruba Networking instant wireless APs.

  • Page 26: Installing The Switch

    Chapter 3 Installing the switch Installing the switch The following sections shows how to install the switch. The switches come with an accessory kit that includes the brackets for mounting the switch in a standard 19-inch telco rack or in an equipment cabinet. Also included are rubber feet that can be attached so the switch can be securely positioned on a horizontal surface.

  • Page 27: Installation Procedures For 6300 Switches

    HPE Aruba Networking 6300M PoE Switches (with AC power supplies) Switzerland 8120-5339 Chile 8120-8389 Danish 8120-5340 Thailand/Philippines 8121-0671 Japan high line 8120-5338 (JL086A, Taiwan 15A 8121-1511 (JL086A, JL087A) JL087A) Japan low line 8120-5342 (JL086A) Taiwan 10A 8121-0967 (JL086A) HPE Aruba Networking 6300M Non-PoE Switches (with AC power supplies) Argentina 8120-6869 Japan...

  • Page 28: Installation Precautions And Guidelines

    4. Connect power to the switch and wait for the health LED to turn green after the switch passes the self-test, then remove power from the switch. 5. Mount the switch. Mounting restrictions apply. See the "Warning" under "Installation precautions and guidelines". 6.

  • Page 29: Prepare The Installation Site

    If your installation requires a different power cord than the one supplied with the switch and power supply, be sure that the cord is adequately sized for the current switch requirements. In addition, be sure to use a power cord displaying the mark of the safety agency that defines the regulations for power cords in your country/region.
  • Page 30 Figure 9 Air Flow Direction of the 6300 Switches (except JL762A) Figure 10 Air flow Direction of the JL762A Switch Install a power supply or a second power supply for modular switches 1. Remove the power supply blank. HPE Aruba Networking 6300F/M Switch Series | Installation and Getting Started Guide...

  • Page 31: Ac Power Supply

    2. Insert the power supply. 3. Place the unit inside the rack, making sure the PSU is properly and fully inserted into the switch with the latch locked into place. AC power supply 1. Use the supplied AC cable for the power supply and the 6300M switch being installed. 2.
  • Page 32 When using a DC power supply, the unit should be installed in a restricted access location. Only trained and qualified personnel should be allowed to install, replace, or service this equipment. Ensure that the DC cable is disconnected from the DC power source before proceeding with the installation. 1.
  • Page 33 3. Remove the transparent protective cover from the DC input connector of the power supply and set it aside. 4. Install the Ground, +DC, and -DC wires, making sure there is a three-inch gap (1 in below illustration) below the unit for the DC cable. Fasten the Green wire to the Screw Terminal marked with on the power supply.

  • Page 34: Verify The Switch Boots Correctly

    6. Reinstall the transparent protective cover on the DC input connector of the power supply. 7. Connect the other end of the DC cable to a DC source following the correct polarity. Do not move the unit with the power supply after the DC cables are installed. Do not remove the DC power supply from the unit with the DC cable installed or the DC source turned on.

  • Page 35: Disconnect Power From The Switch

    Check the LEDs on the switch to make sure the switch is on and operating. When the switch is powered on, it performs its diagnostic self-test and initialization. This boot process, depending on switch model and configuration, takes approximately 1-2 minutes to complete.

  • Page 36: Mounting The Switch In A Two-Post Rack

    2. Position the switch with the top panel up on the selected horizontal surface. Ensure that the power cord and network cables at switch mounting location will not create a tripping hazard. Avoid blocking any ventilation openings on the sides, rear, or front of the switch. Mounting the switch in a two-post rack Before you begin, prepare your network data cables (not included) for connecting the switch to the network.

  • Page 37: Connect The Switch To A Power Source

    The four-post rack mount for the switches requires the optional J9583A HPE X410 Universal Rack Mounting Kit. To use this kit to mount a switch, see the installation instructions provided with the kit. Connect the switch to a power source For AC power supplies: Plug the included power cord into the power connector on the switch and into a nearby AC power source.

  • Page 38: Sfp/Sfp+/Sfp28/Sfp56 Installation Notes

    Connect network cables from network devices or your patch panels to the fixed RJ-45 ports and to any installed transceivers. Connect network cables to the RJ-45 data ports and to any optional transceivers installed on the switch front panel. SFP/SFP+/SFP28/SFP56 installation notes When selecting a fiber SFP/SFP+/SFP28/SFP56 device, make sure it can function at a maximum temperature that is not less than the recommended maximum operational temperature of the product.

  • Page 39: Sample Network Topologies

    See the Transceiver Guide. See the supported transceivers information in the Data Sheet for your switch model. Hot swapping SFP/SFP+/SFP28/SFP56 transceivers Supported SFP/SFP+/SFP28/SFP56 transceivers that you can install in your HPE Aruba Networking switch can be “hot swapped”– removed and installed while the switch is receiving power. However, disconnect the network cables from the SFP/SFP+/SFP28/SFP56 transceivers before hot-swapping them.
  • Page 40 The end node devices are connected to the switch by straight-through or crossover twisted-pair cables. Either cable type can be used because of the IEEE Auto MDI/MDI-X features on the switch. Figure 12 Example as a Segment Switch The switch also works well as a segment switch. That is, with its high performance, it can be used for interconnecting network segments.
  • Page 41 Figure 13 Example as a Segment Switch Implementing PoE Figure 14 Example of Connecting to a Backbone Switch For example, you can use an backbone switch to interconnect each of your smaller work group switches to form a larger network. All devices in this network can communicate with each other and also with the campus backbone. Depending on your bandwidth needs, the links between switches can run at 1G/10G/25G/50G, and use copper or fiber cabling with the appropriate SFP/SFP+/SFP28/SFP56 transceivers.

  • Page 42: Getting Started With Switch Configuration

    Chapter 4 Getting started with switch configuration Getting started with switch configuration This chapter is a guide for using the console Switch Setup screen to quickly assign an IP address and subnet mask to the switch. You can also set a Manager password and, optionally, configure other basic features. For more information on using the switch console, see the Fundamentals Guide for your switch model.

  • Page 43: Replacing Components

    Chapter 5 Replacing components Replacing components This chapter describes how to remove and install the following components in the HPE Aruba Networking 6300M Switch Series: Power supply Fan tray There are no user-replaceable parts on the HPE Aruba Networking 6300F Switch Series. The 6300M switches and their components are sensitive to static discharge.

  • Page 44: Replacing The Power Supply

    1. Loosen the T10 screws by turning counter clockwise. 2. Grasping the pull handle of the failed fan, remove the component. 3. Insert the new fan by sliding the component all the way. 4. Tighten the T10 screws by turning them clockwise. Replacing the power supply If the switch is configured with redundant power supplies, the switch will not suffer any loss of traffic or performance if one power supply fails.
  • Page 45 Unplugging the DC power supply when the PSU is powered on is not supported. AC power supply 1. Remove the AC power cable from the connector on the failed power supply. 2. Grasping the handle of the failed power supply, release the locking mechanism by squeezing the latch handle while removing the failed power supply.
  • Page 46 3. Insert the new power supply. Slide it in all the way in until the locking mechanism locks. DC power supply 1. Switch off the DC source and remove the DC cable from the DC source. 2. Remove the transparent protective cover from the DC input connector on the DC power supply. Unfasten the DC cable from the DC power supply.

  • Page 47: Troubleshooting

    Chapter 6 Troubleshooting Troubleshooting This chapter describes how to troubleshoot your switch, primarily from a hardware perspective. You can perform more in-depth troubleshooting on the switch using the software tools available with the switch. Included are the console interface and the built-in web browser interface. Basic troubleshooting tips Most problems are caused by the following situations.

  • Page 48: Diagnosing With The Leds

    tree, GVRP, LACP, and other features may put the port in a blocking state. Use the switch console to determine the port configuration and verify that there is not an improper or undesired configuration of any of the switch features that may be affecting the port. Diagnosing with the LEDs Table 13: Front Panel LED Behavior Switch LEDs...
  • Page 49 Switch LEDs Function State Meaning UID LED User-configurable LED User defined the located LED : OFF On/Flash Blue (for User defined the 30 min) locator LED: On/Flash Global Status Overall status of the product Flash - Green Self-test in progress Indicator LED during UBOOT and SVOS...

  • Page 50: Diagnostic Tips

    Switch LEDs Function State/Mode Meaning PSU Status Status of power supply On Green Normal Indicator LED No power, PSU has invalid AC or DC input or invalid DC output Slow Flash - Green Power supply has faulted or warning Diagnostic Tips Problem Solution The switch is not plugged into...
  • Page 51 Problem Solution One or more of the switch Try disconnecting power from the switch and wait a cooling fans may have failed. few moments. Then reconnect the power to the switch and check the LEDs again. If the error indication reoccurs, one or more of the fans has failed.
  • Page 52 Problem Solution cabling complies with the IEEE 802.3ab standard. Install the cable according to the ANSI/TIA/EIA- 568-A-5 specifications. Ensure that cable testing complies with the stated limitations for Attenuation, Near-End Crosstalk, Far-End Crosstalk, Equal-Level Far-End Crosstalk (ELFEXT), Multiple Disturber ELFEXT, and Return Loss.

  • Page 53: Proactive Networking

    Problem Solution whether the port is put into a “blocking” state. For software troubleshooting tips, see the chapter “Troubleshooting” in the Management and Configuration Guide for your switch at https://www.hpe.com/networking/support. A redundant power supply has At least one power supply must be operating properly. experienced a fault.

  • Page 54: Testing Twisted-Pair Cabling

    Unplug and plug in the power cord (power cycling). Press the Reset button on the front of the switch. Reboot the switch via the management console’s boot system command. Power cycling the switch and pressing the Reset button both cause the switch to perform its power-on self test, which almost always will resolve any temporary operational problems.

  • Page 55: Downloading New Switch Software

    As part of your troubleshooting process on the switch, it may become necessary to return the switch configuration to the factory default settings. This process momentarily interrupts the switch operation, clears any passwords, clears the console event log, resets the network counters to zero, performs a complete self-test, and reboots the switch into its factory default configuration, including deleting the IP address, if one is configured.

  • Page 56: Specifications

    Specifications Physical and environmental Switch Dimensions (W x D x H) Weight Aruba 6300F 48-port 1GbE PoE+ and 4-port 17.4" x 12.9" x 1.73" 11.24 lb (5.1 kg) SFP56 Switch (JL665A) (44.2 x 32.7 x 4.4 cm) Aruba 6300F 24-port 1GbE PoE+ and 4-port 10.91 lb (4.95 kg)
  • Page 57 Switch Dimensions (W x D x H) Weight HPE ANW 6300M 24SR10 CL6 PoE 2p50G 17.4" x 15.2" x 1.73" 11.60 lb (5.26 kg) 2p25G SW (R8S89A) (44.2 x 38.5 x 4.4 cm) HPE ANW 6300M 48SR5 CL8 PoE 2p50G 12.08 lb (5.48 kg) 2p25G SW (R8S90A) HPE ANW 6300M 48SR5 CL8/CL6 2p50G...

  • Page 58: Electrical

    6300M (JL658A, JL659A, JL660A, 6300F (JL665A, JL666A, JL667A, JL661A, JL662A, JL663A, JL664A, JL668A) JL762A,S0G03A, S0E91A, S0X44A) Operating relative 5% to 95% @ 104°F (40°C) non-condensing 5% to 95% @ 104°F (40°C) non-condensing humidity Non-operating -40°F to 158°F (-40°C to 70°C) up to 15000 -40°F to 158°F (-40°C to 70°C) up to 15000 temperature Non-operating...

  • Page 59: Acoustics

    JL661A Aruba 6300M 48G CL4 PoE 4SFP56 Swch Sound Power (LWAd) 4.7 Bel Sound Pressure (LpAm) (Bystander) 29.8 dB JL662A Aruba 6300F 24G CL4 PoE 4SFP56 Swch Sound Power (LWAd) 4.7 Bel Sound Pressure (LpAm) (Bystander) 29.4 dB JL663A Aruba 6300M 48G /4SFP56 Swch Sound Power (LWAd) 4.6 Bel...

  • Page 60: Safety

    Product* Acoustics Sound Pressure (LpAm) (Bystander) 34.9 dB JL666A Aruba 6300F 24G CL4 PoE 4SFP56 Swch Sound Power (LWAd) 5.0 Bel Sound Pressure (LpAm) (Bystander) 32.3 dB JL667A Aruba 6300F 48G 4SFP56 Swch Sound Power (LWAd) 4.9 Bel Sound Pressure (LpAm) (Bystander) 31.5 dB JL668A Aruba 6300F 24G 4SFP56 Swch Sound Power (LWAd) 4.9 Bel...

  • Page 61: Connectivity Standards

    Table 17: Safety and Regulatory Information for all 6300F/M Switch Models JL658A, JL659A, JL660A, JL661A, JL662A, JL663A, R8S89A, R8S90A, R8S91A, R8S92A, S0E91A, S0X44A JL664A, JL665A, JL666A, JL667A, JL668A Safety-EU EN 60950-1:2006 +A11:2009 EN 62368-1:2014 +A11:2017 +A1:2010 +A12:2011 +A2:2013 EN 62368-1:2020 +A11:2020 EN 62368-1:2014 +A11:2017 EN 62368-1:2020 +A11:2020 Safety-Worldwide...
  • Page 62 Laser Safety Information EN/IEC Compatible with these SFP ("mini- Technology Standard SFP+Lasers IEEE standards GBIC") Lasers Compliance IEEE 802.3an 10GBASE-T (with transceiver) 2.5G and 5G HPE Smart Rate IEEE Twisted-Pair 802.3bz Copper 100-FX IEEE 802.3u 100BASE-FX EN/IEC Class 1 Laser 60825 Product Laser Klasse 1...
  • Page 63 Laser Safety Information EN/IEC Compatible with these SFP ("mini- Technology Standard SFP+Lasers IEEE standards GBIC") Lasers Compliance Laser Klasse 40-Gig LR4 IEEE 802.3ae 40GBASE-LR4 EN/IC 60825 Class 1 Laser Product Laser Klasse Specifications |...

  • Page 64: Cabling And Technology Information

    Chapter 8 Cabling and technology information Cabling and technology information This section includes switch connector information and network cable information for cables used with the HPE Aruba Networking switches. Incorrectly wired cabling is a common cause of problems for LAN communications. HPE Aruba Networking recommends that you work with a qualified LAN cable installer for assistance with your cabling requirements.
  • Page 65 Table 21: Cabling Specifications Twisted-pair copper 10 Mbps Operation Category 3, 4 or 5, 100-ohm unshielded twisted-pair (UTP) or shielded twisted-pair (STP) cable, complying with IEEE 802.3 10BASE-T specifications. 100 Mbps Category 5, 100-ohm UTP, or STP cable, complying Operation with IEEE 802.3u 100BASE-TX specifications.

  • Page 66: Mode Conditioning Patch Cord

    The 2.5 Gb/s Smart Rate operates on cable installations that are designed to support 1000BASE-T operation. The cabling installation must meet the 1000BASE-T link segment characteristics described in IEEE 802.3-2012. The installation must also meet the Category 5e or Class D limits described in the ANSI/TIA/EIA 568-C.2 and ISO/IEC 11801 standards, respectively.

  • Page 67: Twisted-Pair Cable/Connector Pin-Outs

    between the fiber-optic port in your switch and your multimode fiber-optic network cabling, at both ends of the network link. The patch cord consists of a short length of single mode fiber cable coupled to graded-index multimode fiber cable on the transmit side, and only multimode cable on the receive side. The section of single mode fiber is connected in such a way that it minimizes the effects of the differential mode delay in the multimode cable.

  • Page 68: Crossover Twisted-Pair Cable For 10 Mbps Or 100 Mbps Network Connection

    Figure 16 Cable Diagram Pins 1 and 2 on connector “A” must be wired as a twisted pair to pins 1 and 2 on connector “B”. Pins 3 and 6 on connector “A” must be wired as a twisted pair to pins 3 and 6 on connector “B”. Pins 4, 5, 7, and 8 are not used in this application, although they may be wired in the cable.

  • Page 69: Straight-Through Twisted-Pair Cable For 1000 Mbps Network Connections

    Figure 17 Cable Diagram Pins 1 and 2 on connector “A” must be wired as a twisted pair to pins 1 and 2 on connector “B”. Pins 3 and 6 on connector “A” must be wired as a twisted pair to pins 3 and 6 on connector “B”. Pins 4, 5, 7, and 8 are not used in this application, although they may be wired in the cable.
  • Page 70 Figure 18 Cable Diagram Pins 1 and 2 on connector “A” must be wired as a twisted pair to pins 1 and 2 on connector “B”. Pins 3 and 6 on connector “A” must be wired as a twisted pair to pins 3 and 6 on connector “B”. Pins 4 and 5 on connector “A”...

  • Page 71: Support And Other Resources

    Chapter 9 Support and Other Resources Support and Other Resources Access HPE Aruba Networking support and updates, and view warranty and regulatory information Accessing HPE Networking Support HPE Aruba Networking Support Services https://www.arubanetworks.com/support-services/ HPE Networking Support Portal https://asp.arubanetworks.com/ North America telephone 1-800-943-4526 (US & Canada Toll-Free Number) +1-408-754-1200 (Primary - Toll Number) +1-650-385-6582 (Backup - Toll Number - Use only when all other numbers are not working)

  • Page 72: Warranty Information

    Access to some updates might require product entitlement when accessed through the Hewlett Packard Enterprise Support Center. You must have an HP Passport set up with relevant entitlements. Some software products provide a mechanism for accessing software updates through the product interface.
