Havit H2002G Instruction Manual

H2002G Instruction manual
Earplugs Specification
Speaker: Φ53 mm
Impedance: 64±15%Ω
Sensitivity: 113±3dB
Frequency response: 20hz to 20khz
Microphone: Ø6.0×2.7mm
Microphone sensitivity: -42±3dB
Wireless distance: 10m
Wireless technology: 2.4GHz
lithium battery: 1200mAh
Continuity Play: 30H(No backlight),20H(brightest backlight)
Function Show Image
灯光键：Light key 音量+：Volume + 音量-：Volume - 音频线接口：Audio cable interface
7.1 开关：7.1 Switch 电源开关：Power Switch 状态指示灯：Status Indicator TYPE-C 接口：
TYPE-C interface 麦 克 风 开 关 ： Microphone switch 2.4G 接 收 器 指 示 灯 ： 2.4G transmitter
indicator
Operation Guide
1. Headset on pairing use
Insert the 2.4G transmitter (hereinafter referred to as the transmitter) into the device USB

data port, and the transmitter enters the search pairing state after insertion (the transmitter
indicator light flashes continuously).
 Long press the power switch button on the headset for about 5 seconds, then the headset
will have a "drop" sound, the headset can be turned on normal use (headset on the LOGO
light is on by default).
 The headset and the transmitter have been paired at the factory, and the two devices can be
automatically connected and used normally after opening the headset. (Note: When the
transmitter and headset did not pair, the transmitter into the computer, the transmitter light
will continue to flash, then turn on the headset, while long press the microphone on key for
5 seconds, then the headset into the pairing state, the headset blue light flashes rapidly, the
headset and the transmitter pairing, the transmitter light will always be on.)
After the headset and transmitter pairing successfully, the transmitter's indicator light is

always on.
