Sauna and Steam control
Series FCU2x00/FCU3x00/FCU4x00
Instruction for the service menu
Instruction for the configuration menu
Only for trained service technicians not for end customer!
Doc-ID: SuK_FCUxxxx_EN
Version: V 2.08
Read the safety warnings in the operating manual and Installation
instructions!
Stand: 18.06.2019
Advertisement
Related Manuals for Fasel Elektronik FCU2 00 Series
Summary of Contents for Fasel Elektronik FCU2 00 Series
- Page 1 Stand: 18.06.2019 Sauna and Steam control Series FCU2x00/FCU3x00/FCU4x00 Instruction for the service menu Instruction for the configuration menu Only for trained service technicians not for end customer! Read the safety warnings in the operating manual and Installation instructions! Doc-ID: SuK_FCUxxxx_EN Version: V 2.08...
- Page 2 Stand: 18.06.2019 Instruction for service menu Only for trained service technicians not for end customer! Read the safety warnings in the operating manual Some menus are available only if the corresponding bathing options or other options are available. Display FCU2x00 keys FCU4x00 Info...
- Page 3 Stand: 18.06.2019 Selection of the settings required for the evaporator. You can select if, in case of error, the connected steam generator turns (at water ...
- Page 4 Stand: 18.06.2019 If during the sensor correction positive values are entered, then the control will perceive a higher temperature or humidity of the sensor, i.e. in spite of identical settings it will become colder (or ...
- Page 5 Stand: 18.06.2019 inside then the brightness is automatically reduced. Here you can match the control device to the colour of the light. ...
- Page 6 Stand: 18.06.2019 analog outputs A1+ … A4+. For temperature control: If the temperature in the sauna cabin becomes too high then a smaller xp-value should be set. If on the contrary the set temperature is not ...
- Page 7 Stand: 18.06.2019 Instruction for the configuration menu for the customer configuration Brief instruction for configuration menu. Only for trained service technicians not for end customers Read the safety warnings in the operating manual Some menus are available only if the corresponding bathing options or other options are available. ...
- Page 8 Stand: 18.06.2019 NO: standard d/T Delta-T- Control (Value can be set, see below) YES: if the oven temperature is higher by the set delta-T - temperature then the oven is switched ...
- Page 9 Stand: 18.06.2019 IRO: (From V6.10) Lock the oven in IR mode YES: oven never turns on NO: oven controls to basic temperature FAN: Analog output 0-10V for "Pro"-vaporizer, in order to control the vaporizer in its performance. ...
- Page 10 Stand: 18.06.2019 Only if released in the configuration 'D/T’: Here you can set the delta temperature. Only if released in the configuration 'MST': ...
- Page 11 Stand: 18.06.2019 Technical changes and errors excepted, illustration similar...
- Page 12 Stand: 18.06.2019 Notes: Technical changes and errors excepted, illustration similar...
