Seagate ST905004CEA2E1-RK - FreeAgent Theater+ - Digital Multimedia Receiver Specifications page 2

Minimum System
Requirements
Supported Formats
Supported File Systems
Output
Input
TV Systems
Product Dimensions
Inside the Box
Product Retail
Packaging Specs
(Length x Width x Height)
Region Product
US Media Player Only
US Media Player Solution
• PC : Windows XP or Vista, 256MB RAM and an available USB port
• Mac: OS X 10.4.11 or 10.5.6 or later and an available USB port
• TV: Composite video, component video or HDMI connection and stereo, optical S/PDIF or HDMI audio connection
• Internet Services: Broadband internet – 10/100 Mbps wired network connection or Seagate optional wireless
accessory
Video Formats: MPEG-1, MPEG-2 (VOB/ISO), MPEG-4 (DivX /Xvid), DivX HD, Xvid HD, AVI, MOV, MKV, RMVB,
AVC HD, H.264, WMV9, VC-1, M2TS, TS/TP/M2T
Subtitles: SAMI(smi), SRT and SUB
Video resolutions: NTSC 480i/480p, PAL 576i/576p, 720p, 1080i, 1080p
Audio AAC, MP3, Dolby® Digital, DTS, ASF, FLAC, WMA, LPCM, ADPCM, WAV, OGG
Playlist: M3U, PLS
Photo JPEG files up to 20 megapixels, BMP, GIF, PNG, TIFF
NTFS, FAT, FAT32, HFS+
Video: Composite, Component, HDMI 1.3
Audio: Stereo, Optical S/PDIF, HDMI 1.3
Network: Ethernet 10/100 mbps
Power Adapter
PAL/NTSC
1.18 in H x 7.20 in W x 6.89 in L
Media Player
AV Cable
Component Cable
Ethernet Cable
EnergyStar compliant power supply
Media Player Only
Box dimensions: 9.57 x 8.35 x 3.62 in
Box weight: 2.99 lbs
Master carton dim: 14.80 x 8.70 x 10.39 in
Master carton weight: 12.79 lbs
Master carton quantity: 4
Master cartons per pallet: 48
Pallet dim: 48.00 x 40.00 x 46.57 in
Pallet weight: 665.80 lbs
Pallet layers: 4
Capacity
N/A
500GB
© 2009 Seagate Technology LLC. All rights reserved. Seagate, Seagate Technology, the Wave logo, FreeAgent Go, and FreeAgent Theater+ are
trademarks or registered trademarks of Seagate Technology LLC or one of its affiliated companies in the United States and/or other countries. All
other trademarks or registered trademarks are the property of their respective owners. When referring to hard drive capacity, one gigabyte, or GB,
equals one billion bytes and one terabyte, or TB, equals one thousand billion bytes. Your computer's operating system may use a different standard of
measurement and report a lower capacity. In addition, some of the listed capacity is used for formatting and other functions and will not be available
for data storage. Seagate reserves the right to change, without notice, product offerings or specifications. Seagate Technology LLC, 920 Disc Drive,
Scotts Valley CA 95066 U.S.A. DS1692.1-0908US
Interface: 1x USB 2.0 at front
Note: Optional Wireless 802.11b/g/n adapter can be
FreeAgent Theater+ Software and User Guide (PDF)
Set-Up Guide
FreeAgent Go™ Portable Hard Drive (Solution Only)
USB 2.0 Cable (Solution Only)
1-Year Limited Warranty
Media Player Solution
Box dimensions: 9.57 x 8.35 x 4.65 in
Box weight: 3.67 lbs
Master carton dim: 18.74 x 8.70 x 10.39 in
Master carton weight: 15.67 lbs
Master carton quantity: 4
Master cartons per pallet: 40
Pallet dim: 48.00 x 40.00 x 46.57 in
Pallet weight: 670.20 lbs
Pallet layers: 4
Model Number
STCEA201-RK
ST905004CEA2E1-RK
1x USB 2.0 at back
connected to front or rear USB host ports.
Weight: 1.11 lbs
UPC Code Multi-pack UPC
763649018071 10763649018078
763649018064 10763649018061
