FALCON EYE OMEGA 3K Manual

OMEGA 3K
FHH0143
EN SPECIFICATION
OPERATION LIGHT
MODE OUTPUT
TURBO
3000 lm
HIGH 1800 lm
MEDIUM
1200 lm
LOW
600 lm
ULTRA LOW
350 lm
STROBE
-
S.O.S. -
RED FLASHING -
BATTERY 20650 Li-Ion 3,7V 2600 mAh
CHARGING TIME 3 h
WEIGHT 185 g
DIMENSIONS 118 x 41 x 35 mm
IP RATING IPX4
IMPACT RESISTANCE 1 m
Thank you for choosing a Mactronic
and maintenance guarantee the product's high durability and
reliability. Please read the operating manual and keep it for refe-
rence, because it contains important information about safety and
operation of the product.
NOTICE
It is not recommended to use the flashlight for purposes other
than intended. The manufacturer explicitly voids the warranty if
the flashlight has been used for other than its intended purpose.
FLASHLIGHT OPERATION
Attention! The flashlight comes with a factory-installed battery
contact separator, which must be removed from the battery com-
partment. To remove the separator, unscrew the tail cap, take out
the battery contact separator inside, and then screw the tail cap
back into place.
To turn on the flashlight, press the button located on the body. The
flashlight will start in HIGH mode. Subsequent presses will switch
modes in the following order: HIGH → MEDIUM → LOW → ULTRA
LOW → OFF. If the interval between button presses exceeds 10
seconds, the flashlight will turn off after the next press. To activate
or switch to TURBO mode at any time, quickly press the button
twice—double-click. After the next press or after 30 seconds,
the flashlight will return to the previous mode. If the flashlight
is turned on from OFF directly to TURBO mode (double-click), it
will switch to HIGH mode after 30 seconds. To turn on the flashli-
ght in STROBE mode, press and hold the button for 3 seconds.
Subsequent single presses will now switch modes in the following
order: STROBE → S.O.S. → RED FLASHING → OFF. The flashlight
signals battery depletion using an LED hidden in the button: Blue
– fully charged, Red – low battery.
REPLACING THE BATTERY
To charge the flashlight, connect the included USB cable to a po-
wer source: USB-5V/1A. Plug the other end of the cable with the
USB-C connector into the flashlight's charging port, hidden behind
the rubber charging port cover. The active charging process will
be indicated by the red LED lighting up on the switch. The chan-
ge in LED color from red to blue signifies the completion of the
charging process.
CAUTION!
Make sure you use only genuine parts designed for Falcon Eye
flashlight. Using spare parts from other manufacturers may af-
fect the quality and parameters of the product. The rechargeable
batteries used in this product may be subject to re-processing.
Pursuant to the EU's WEEE regulation, storage batteries must
BEAM RUN
DISTANCE TIME
215 m 30 sec
165 m 2 h
140 m 3 h
95 m 5 h
85 m 8 h
- -
- -
- -
product. Proper operation
®
not be disposed of with normal household waste. Instead, they
must be disposed of at designated battery collection points. Con-
tact the management of your local waste collection company for
advice on the required ways and types of re-processing, or other
instructions.
GENERAL INFORMATION
Modifications and repairs:
Modifications and repairs, other than those authorized by Mactro-
nic , are prohibited.
®
Mactronic's warranty:
®
Flashlight has a 2-year warranty on defects in material and
workmanship. Warranty does not cover: products bearing the cha-
racteristics of normal wear and tear, rust, altered and modified,
improperly stored, damaged as a result of falls, negligence, le-
aking batteries and by use for which it was not intended.
WARRANTY CARD
The warranty card can be downloaded at www.falconeye.pl
USING AND HANDLING THE BATTERY
To reduce the risk of fire, electrocution or other bodily harm, care-
fully read the flashlight's operating manual.
- Always make sure the battery's polarity is correct.
- Remove the batteries if the flashlight is stored for extended time.
- Do not recharge alkaline batteries.
- Do not dispose of the batteries in fire.
- Keep the batteries out of reach of the children.
- Do not force the batteries open.
- Keep the flashlight away from UV radiation, humidity and che-
mical products.
DE SPEZIFIKATION
LEUCHTMODI
TURBO
HIGH
MEDIUM
LOW
ULTRA LOW
STROBE
S.O.S.
RED FLASHING -
HAUPTEINSPEISUNG 20650 Li-Ion 3,7V 2600 mAh
LADEZEIT 3 h
GEWICHT 185 g
GRÖSSE 118 x 41 x 35 mm
IP-SCHUTZART IPX4
STOSSCHUTZ 1 m
Vielen Dank, dass Sie sich für ein Mactronic
haben. Eine ordnungsgemäße Bedienung und Wartung gewährleistet
eine hohe Lebensdauer und Zuverlässigkeit. Bitte lesen und befolgen
Sie dieses Handbuch zum späteren Gebrauch, da es wichtige Informa-
tionen zum sicheren Betrieb und Nutzung enthält.
HINWEIS
Bestimmungswidrige Nutzung der Taschenlampe wird nicht empfoh-
len. Der Hersteller nimmt die Garantie ausdrücklich zurück, wenn die
Taschenlampe bestimmungswidrig benutzt wird.
BEDIENUNG DER TASCHENLAMPE
Achtung! Die Taschenlampe ist mit einem werkseitig installierten
Batteriekontaktseparator ausgestattet, der aus dem Batteriefach
entfernt werden muss. Um den Separator zu entfernen, schrauben
Sie die Endkappe ab, entnehmen Sie den Batteriekontaktseparator
aus dem Inneren und schrauben Sie die Endkappe wieder an ihren
Platz.
Um die Taschenlampe einzuschalten, drücken Sie den Knopf am
Gehäuse. Die Taschenlampe startet im HIGH-Modus. Weitere Tasten-
drücke schalten die Modi in folgender Reihenfolge um: HIGH → ME-
DIUM → LOW → ULTRA LOW → OFF. Wenn der Abstand zwischen den
Tastendrücken 10 Sekunden überschreitet, schaltet sich die Taschen-
lampe nach dem nächsten Tastendruck aus. Um die Taschenlampe
®
jederzeit in den TURBO-Modus zu schalten, drücken Sie den Schalter
zweimal schnell – Doppelklick. Die Lampe kehrt nach dem nächsten
Tastendruck oder nach 30 Sekunden in den vorherigen Modus zurück.
Wenn die Taschenlampe aus dem OFF-Modus direkt in den TURBO-
LUMEN LEUCHTWEITE
3000 lm 215 m
1800 lm 165 m
1200 lm 140 m
600 lm 95 m
350 lm 85 m
- -
- -
-
-Produkt entschieden
®
LEUCHTDAUER
30 sec
2 h
3 h
5 h
8 h
-
-
-
