Delta Electronics Igniter IGT005 Specification Sheet

Igniter
IGT005 Type

Features

Via 3 Vdc externally supplied from battery and the functioning of the trigger board, the
high voltage coil is stimulated and results into 37 KVo-p to start up the ignition.

Applications

Gas Igniter

Mechanical Dimension:

Electrical Characteristics:

o
AT 25 C, 65%RH, INDUCTANCE TESTED@1KHz/1V
PART NO.
IGT-005
Input voltage: 3 Vdc
Switching frequency: 5Hz Min.
o
Operation temperature: -10C to +55C
o
Storage temperature: -20C to +70C
Insulated with epoxy resin

Recommended Circuit:

DELTA ELECTRONICS, INC.
(TAOYUAN PLANT CPBG)
Unit: mm
A B C D
+ -
30.0 Max.
70.0 Max.
PRIMARY
INDUCTANCE (uH) INDUCTANCE (mH)
57.0 20%
o
o
+
TRIGGER
DC 3V
- CIRCUIT
252, SAN YING ROAD, KUEISAN INDUSTRIAL ZONE, TAOYUAN SHIEN, 333, TAIWAN, R.O.C.
TEL: 886-3-3591968; FAX: 886-3-3591991
http://www.deltaww.com
4.5
60.0 Max.
SECONDARY OUTPUT VOLTAGE
(KVo-p)
360.0 20% 37.0 3.0
IGNITER
T1
1
2
5
6
3
4
73
WEIGHT
72g
A
B
C
D
