  • Page 1 EN User Manual | Washer Dryer EW7W2294EG...

  • Page 2: Table Of Contents

    Welcome to Electrolux! Thank you for choosing our appliance. Get usage advice, brochures, trouble shooter, service and repair information: www.electrolux.com/support Subject to change without notice. CONTENTS 1. SAFETY INFORMATION................2 2. SAFETY INSTRUCTIONS................5 3. PRODUCT DESCRIPTION................7 4. TECHNICAL DATA..................8 5.

  • Page 3: General Safety

    • This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning the use of the appliance in a safe way and understand the hazards involved.
  • Page 4 • The appliance shall be installed as a freestanding product or below the kitchen worktop if space margins permit. • Do not install the appliance behind a lockable door, a sliding door or a door with a hinge on the opposite side, that would prevent the appliance door from being fully open.

  • Page 5: Safety Instructions

    • Items that have been soiled with substances such as vegetable or mineral oil, acetone, alcohol, petrol, kerosene, spot removers, turpentine, waxes and wax removers should be washed separately with an extra amount of detergent before being dried in the washer dryer. •...

  • Page 6: Electrical Connection

    • Make sure that there is air circulation • Ensure that there are no visible water between the appliance and the floor. leaks during and after the first use of the • Remove all the packaging and the transit appliance. bolts.

  • Page 7: Product Description

    2.5 Service professional repairers, and that not all spare parts are relevant for all models. • To repair the appliance contact the • Concerning the lamp(s) inside this product Authorised Service Centre. Use original and spare part lamps sold separately: spare parts only.

  • Page 8: Technical Data

    Worktop Drain hose Detergent dispenser Inlet hose connection Control panel Mains cable Door handle Transit bolts Rating plate Hose support Drain pump filter Feet for levelling the appliance The rating plate reports the model name (A) , product number (B), electrical ratings (C) and serial number (D).

  • Page 9: Information For Installation

    It is possible to see water flowing from the drain hose. This is because the washing machine has been tested at the factory. 4. Remove the three transit bolts and pull out the plastic spacers. Accessories delivered with the appliance may vary depending on the model.
  • Page 10 2. Position it toward left or right depending on WARNING! the positon of the water tap. Make sure that the inlet hose is not in vertical position. Do not put cardboard, wood or equivalent materials below the appliance feet to 3.
  • Page 11 It is possible to connect the drain hose in different ways: min.600 mm max.1000 mm Make sure that the drain hose makes a loop To a stand pipe with vent hole - Insert the to prevent particles going into the appliance drain hose directly into a drain pipe or stand from the sink.

  • Page 12: Accessories

    6. ACCESSORIES 6.1 Available in www.electrolux.com/shop or from authorised dealer Only appropriate accessories approved by ELECTROLUX ensure the safety standards of the appliance. If unapproved parts are used, any claims will be invalidated. 6.2 Fixing plate kit Read carefully the instructions supplied with the accessory.

  • Page 13: Control Panel Description

    7.2 Control panel description Time Manager touch button and permanent Child Lock option The permanent options are set by Prewash touch button and permanent holding pressed the relative button for at Extra Rinse option least 3 seconds. Spin touch button Programme dial Temperature touch button Display...
  • Page 14 The digital indicator can show: • Programme duration (e. g. , washing and/or drying phase). • Delay time (e. g. • Cycle end ( • Warning code (e.g. • Error indicator ( Time Manager indicator. Extra Rinse indicator. The spin area: Spin speed indicator No Spin indicator.

  • Page 15: Dial And Buttons

    8. DIAL AND BUTTONS 8.1 Introduction 8.5 Spin When you set a programme, the appliance automatically sets the default spin speed. The options/functions are not available Touch repeatedly this button to: with all washing programmes. Check the • Change the spin speed. The display compatibility between options/functions shows only the spin speeds available for and washing programmes in the...

  • Page 16: Permanent Extra Rinse

    indicator The option can increase the programme duration. 8.7 Permanent Extra Rinse With this option you can permanently have an extra rinse when you set a new programme. ■ ■ To activate/deactivate this option, hold the Prewash button pressed for 3 seconds until ■...

  • Page 17: Delay Start

    8.12 Delay Start With this option you can delay the start of a You cannot set all time values for programme to a more convenient time. different types of fabrics. Touch the button repeatedly to set the required delay. The time increases in steps of 8.11 Auto Dry 1 hour up to 20 hours.
  • Page 18 • Items with label "Dry clean only". ELECTROLUX fragrance. If you use this special gentle fragrance, your laundry will scent as just washed. Read carefully the instructions supplied with the fragrance. Reduce the fragrance dosage when treating smaller load. By means of the Time Manager button, you can reduce the programme duration when treating items labeled to be washed at low temperature.
  • Page 19 Programme Reference Maxi‐ Programme description Default temperature spin speed (Type of load and level of soiling) Temperature range Spin speed load range 1400 rpm 9.0 kg All fabrics, except woollens and very delicate fabrics. (1400- 400 Programme for rinsing and spinning the laundry. The de‐ Rinse rpm) fault spin speed is the one used for cotton programmes.
  • Page 20 Programme Reference Maxi‐ Programme description Default temperature spin speed (Type of load and level of soiling) Temperature range Spin speed load range 1200 rpm 3.0 kg Special programme for Denim clothing with delicate (1200 - 400 washing phase to minimize colour fading and marks. Denim rpm) For better care a reduced load size is recommended.
  • Page 21 Programme options compatibility Programme ■ ■ ■ Eco 40-60 ■ ■ ■ ■ ■ ■ ■ Cottons ■ ■ ■ ■ ■ ■ ■ Synthetics ■ ■ ■ ■ ■ Delicates ■ ■ ■ ■ Wool ■ ■ FreshScent ■ ■...

  • Page 22: Automatic Drying

    Suitable detergents for each programme Programme Universal Liquid Univer‐ Liquid for col‐ Delicates Special oureds woollens powder 1) Eco 40-60 ▲ ▲ ▲ Cottons ▲ ▲ ▲ Synthetics ▲ ▲ ▲ Delicates ▲ ▲ Wool ▲ ▲ Anti-Allergy ▲ ▲ ▲...

  • Page 23: Timed Drying

    Dryness Level Type of fabric Load Cottons and Linen up to 5.0 kg (bathrobes, bath towels, etc) Extra Dry For towelling materials Denim garments up to 3.0 kg Cottons and Linen up to 5.0 kg (bathrobes, bath towels, etc) Cupboard Dry For items to be stored Synthetics and mixed fabrics up to 3.0 kg...

  • Page 24: Settings

    Dryness Level Type of fabric Load Spin Suggested du‐ (kg) speed ration (mins) (rpm) Synthetics and mixed fabrics 1200 80 - 100 (jumpers, blouses, underwear, household and bed linen) 1200 45 - 55 Delicates 1200 100 - 120 (acrylics, viscose and delicate mixed fabrics) 1200 60 - 80 Wool...

  • Page 25: Before First Use

    11. BEFORE FIRST USE 1. Make sure that the electrical power is 4. Set and start a programme for cotton at available and the water tap is open. the highest temperature without any 2. Pour 2 litres of water into the detergent laundry in the drum.

  • Page 26: Setting A Programme

    4. To use liquid detergent, turn the flap down. - Maximum level for quantity of liquid additives. - Flap for powder or liquid detergent. Always follow the instructions that you find on the packaging of the detergent products, but we recommend that you do not exceed the maximum indicated level ).

  • Page 27: Starting A Programme With The Delay Start

    3. If desired, set one or more options by 3. Touch the Start/Pause button again to touching the related buttons. The related start the programme immediately. indicators will light up and the given information will change on the display Changing the delay start after the accordingly.

  • Page 28: Interrupting A Programme And Changing The Options

    anyway, despite the overload. In this case, it will be not possible to guarantee the best If the SensiCare System has completed washing results. and the water filling has already started, the new programme starts without repeating the SensiCare System. The About 20 minutes after the programme water and the detergent are not drained start, the programme duration could be...

  • Page 29: Stand-By Function

    The door unlocks and the indicator goes The option indicator Rinse Hold off. disappears. 1. Press button On/Off to deactivate the appliance. After five minutes from the end of the If you have selected No Spin , the programme, the energy saving function appliance will only drain the water.

  • Page 30: Washing And Timed Drying

    13.1 Complete wash&dry 2. Touch button Start/Pause to start the programme programme. The SensiCare estimation starts. Non-automatic wash&dry programmes In the display the door locked indicator In some washing programmes, you can comes on. combine Wash and Dry for running a The display also shows the remaining complete wash&dry programme.

  • Page 31: Daily Use - Drying Only

    14. DAILY USE - DRYING ONLY The display also shows the remaining WARNING! programme time. Refer to Safety chapters. 14.3 Timed Drying 1. Tap on the Time Dry button repeatedly to set the desired time value (see the This appliance is an automatic washer "Timed drying"...

  • Page 32: Fluff In The Fabrics

    15. FLUFF IN THE FABRICS During the washing and/or drying phase, To remove the fluff inside the drum, set a some types of fabric, (sponge, wool, special programme: sweatshirt) could release fluff. • Empty the drum. • Clean the drum, the gasket and the door The released fluff could stick to the fabrics with a wet cloth.

  • Page 33: Stubborn Stains

    – powder detergents (also tablets and single-dose detergents) for all types of fabric, excluding delicate. Prefer powder detergents containing bleach for whites and laundry sanitization, – liquid detergents (also single-dose detergents) , preferably for low temperature wash programmes (60 °C max) for all types of fabric, or special ones for woollens only.

  • Page 34: Drying Cycle Duration

    programmes helps to reduce energy • Fabrics with residue of hair sprays, nail and water consumption. solvents or similar. • With adequate pre-treatment, stains and • Garments with foam-rubber or materials limited soiling can be removed; the similar to foam-rubber. laundry can then be washed at a lower 16.8 Garment labels temperature.

  • Page 35: Care And Cleaning

    17. CARE AND CLEANING "Cleaning the inlet hose and the valve filter" WARNING! paragraphs. If necessary, please contact the Authorised Service Centre. Refer to Safety chapters. 17.3 External cleaning 17.1 Periodic cleaning schedule Clean the appliance with mild soap and warm Periodic cleaning helps to extend the life water only.

  • Page 36: Cleaning The Drum

    part of the appliance, run a maintenance wash regularly (at least once a month). Always follow the instructions that you find on the packaging of the product. Do not clean the drum with acidic Refer to "Cleaning the drum" paragraph. descaling products, scouring products containing chlorine or iron or steel wool.

  • Page 37: Cleaning The Drain Pump

    Regularly check the drain pump filter and make sure that it is clean. Clean the drain pump if: • The appliance does not drain the water. • The drum does not turn. • The appliance makes an unusual noise because of the blockage of the drain pump.
  • Page 38 4. Turn the filter 180 degrees in anti- 10. Clean the filter under the water tap. clockwise direction to open it, without removing. Let the water flow out. 11. Put the filter back into the special guides by turning it clockwise. Make sure that you tighten the filter correctly to prevent leakages.

  • Page 39: Cleaning The Inlet Hose And The Valve Filter

    17.10 Cleaning the inlet hose and the valve filter 45° 20° 17.11 Emergency drain If the appliance cannot drain the water, carry out the same procedure, described in 'Cleaning the drain pump' paragraph. If necessary, clean the pump. When you drain the water with the emergency drain procedure, you must activate the drain system again: 1.

  • Page 40: Troubleshooting

    18. TROUBLESHOOTING WARNING! Refer to Safety chapters. 18.1 Alarm Codes and Possible failures The appliance does not start or it stops during operation. First try to find a solution to the problem (refer to the tables). WARNING! Deactivate the appliance before carrying out any check. With some problems, the display shows an alarm code and the Start/ Pause button may flash continuously:...
  • Page 41 • Make sure that the sink spigot is not clogged. • Make sure that the drain hose has no kinks or bends. The appliance does not • Make sure that the drain filter is not clogged. Clean the filter, if necessary. Re‐ drain the water.
  • Page 42 Problem Possible solution • Make sure that a washing programme that ends with water in tub, has not been selected. • Make sure that the washing programme is finished. • Set the drain or the spin programme if there is water in the drum. You cannot open the appli‐...

  • Page 43: Emergency Door Opening

    18.2 Emergency door opening To open the door, proceed as follows: 1. Press the On/Off button to switch the In case of power failure or functioning failure appliance off. the appliance door remains locked. The 2. Disconnect the mains plug from the washing programme continues when the mains socket.
  • Page 44 19.2 Legend Laundry load. hh:mm Programme duration. Energy consumption. °C Temperature in the laundry. Litres Water consumption. Spin speed. Remaining moisture at the end of the cycle. The higher is the spin speed, the higher is the noise and the lower is the remaining moisture at the end of washing cycle. Values and programme duration may differ depending on different conditions (e.g.
  • Page 45 19.4 Common programmes - Washing only These values are indicative only. Programme rpm 1) Litres hh:mm °C Cottons 2.950 100.0 03:35 52.00 85.0 1400 90°C Cottons 2.000 95.0 03:20 52.00 55.0 1400 60°C Cottons 0.360 95.0 03:00 52.00 20.0 1400 20°C Synthetics 0.600...

  • Page 46: Environmental Concerns

    20. ENVIRONMENTAL CONCERNS appliances marked with the symbol with Recycle materials with the symbol . Put the the household waste. Return the product to packaging in relevant containers to recycle it. your local recycling facility or contact your Help protect the environment and human municipal office.
