  • Page 1 EN User Manual | Washer Dryer EW7W3916DA...

  • Page 2: Table Of Contents

    Welcome to Electrolux! Thank you for choosing our appliance. Get usage advice, brochures, trouble shooter, service and repair information: www.electrolux.com/support Subject to change without notice. CONTENTS 1. SAFETY INFORMATION................2 2. SAFETY INSTRUCTIONS................5 3. PRODUCT DESCRIPTION................8 4. TECHNICAL DATA..................8 5.

  • Page 3: General Safety

    • This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning the use of the appliance in a safe way and understand the hazards involved.
  • Page 4 • The appliance shall be installed as a freestanding product or below the kitchen worktop if space margins permit. • Do not install the appliance behind a lockable door, a sliding door or a door with a hinge on the opposite side, that would prevent the appliance door from being fully open.

  • Page 5: Safety Instructions

    • Items that have been soiled with substances such as vegetable or mineral oil, acetone, alcohol, petrol, kerosene, spot removers, turpentine, waxes and wax removers should be washed separately with an extra amount of detergent before being dried in the washer dryer. •...

  • Page 6: Electrical Connection

    • Make sure that there is air circulation • Ensure that there are no visible water between the appliance and the floor. leaks during and after the first use of the • Remove all the packaging and the transit appliance. bolts.
  • Page 7 2.5 Service repairers, and that not all spare parts are relevant for all models. • To repair the appliance contact the • Concerning the lamp(s) inside this product Authorised Service Centre. Use original and spare part lamps sold separately: spare parts only. These lamps are intended to withstand •...

  • Page 8: Product Description

    D. Electrical ratings B C D E. Serial number Scan the QR code with the built-in camera app to download the My Electrolux Care application from the App store on your smart device and follow the required steps. 4. TECHNICAL DATA...

  • Page 9: Installation

    Electrical connection Voltage 230 V Overall power 2100 W Fuse 10 A Frequency 50 Hz Level of protection against ingress of solid particles and moisture IPX4 ensured by the protective cover, except where the low voltage equipment has no protection against moisture Cold water Water supply Water supply pressure...

  • Page 10: Information For Installation

    WARNING! It is possible to see water flowing Do not put cardboard, wood or equivalent from the drain hose. This is because materials below the appliance feet to the washing machine has been adjust the level. tested at the factory. The inlet hose 4.
  • Page 11 WARNING! The inlet water shall not exceed 25 °C. Water drainage 3/4” The drain hose should stay at a height of no less than 60 cm and not more than 100 cm. You can extend the drain hose to 3/4” maximum 400 cm.

  • Page 12: Accessories

    6. ACCESSORIES 6.1 Available in www.electrolux.com/shop or from authorised dealer Only appropriate accessories approved by ELECTROLUX ensure the safety standards of the appliance. If unapproved parts are used, any claims will be invalidated. 6.2 Fixing plate kit...

  • Page 13: Control Panel

    Use the delicate fragrance exclusively necessary. developed by ELECTROLUX to add a pleasant feeling of "just-washed" garment to the removing odours and wrinkles action. ENGLISH...

  • Page 14: Control Panel Description

    7.2 Control panel description Rinçage Départ différé touch button Mode - Séchage touch button and The permanent options are set by permanent Anti-crease option holding pressed the relative button for at Time Manager touch button and least 3 seconds. permanent Child Lock option Programme dial Taches touch button and permanent Essorage touch button...
  • Page 15 The Temperature area: Temperature indicator . Cold water indicator. Door locked indicator. Child safety lock indicator. The digital indicator can show: • Programme duration (e. g. , washing and/or drying phase). • Delay time (e. g. • Cycle end ( •...

  • Page 16: Dial And Buttons

    Add garments indicator. It lights at the beginning of the washing phase, when it is still possible to pause the appliance and add more laundry. 8. DIAL AND BUTTONS 8.1 Introduction • Set the No Spin option Set this option to deactivate all spin phases.

  • Page 17: Permanent Extra Rinse

    When it is activated, the appliance will default to this option after you switch it off or change/ reset the programme. The option can increase the programme duration. This option increases the programme 8.7 Permanent Extra Rinse duration. With this option you can permanently have an extra rinse when you set a new programme.

  • Page 18: Child Lock

    To activate/deactivate this option, hold the Mode - Séchage button pressed for 3 indicator seconds until the indicator comes on/ goes off on the display. When it is activated, the appliance will default to this option after you switch it off or change/ reset the programme.

  • Page 19: Départ Différé

    On the display the relevant dryness indicator Touch the button repeatedly to set the goes on: required delay. The time increases in steps of 1 hour up to 20 hours. • Iron dry: laundry to be ironed. The display shows the selected delay time. •...
  • Page 20 Items with label "Dry clean only". FreshScent System ELECTROLUX fragrance. If you use this special gentle fragrance, your laundry will scent as just washed. Read carefully the instructions supplied with the fragrance. Reduce the fragrance dosage when treating smaller load.
  • Page 21 Programme Reference Maxi‐ Programme description Default tempera‐ spin speed (Type of load and level of soiling) ture Spin speed load Temperature range range 1600 rpm 9 kg All fabrics, except woollens and very delicate fabrics. (1600- 400 Programme for rinsing and spinning the laundry. The default Rinçage rpm) spin speed is the one used for cotton programmes.
  • Page 22 Programme Reference Maxi‐ Programme description Default tempera‐ spin speed (Type of load and level of soiling) ture Spin speed load Temperature range range 1200 rpm 2 kg (1200- 400 Outdoor rpm) Do not use fabric softener and make sure that 30 °C 40 °C - Cold there is no softener residue in the detergent...
  • Page 23 Programme Reference Maxi‐ Programme description Default tempera‐ spin speed (Type of load and level of soiling) ture Spin speed load Temperature range range Reset position. The display shows dashes only. According to Commission Regulation EU 2019/2023. This programme at default temperature and spin speed, in washing only mode, with rated capacity 9 kg is able to clean normally soiled cotton laundry declared to be washable at 40 °C or 60 °C, together in the same cycle.
  • Page 24 Programme ■ ■ FreshScent ■ ■ ■ Essorage/Vidange ■ ■ ■ ■ ■ ■ Rinçage ■ ■ ■ Lavage tambour ■ ■ ■ ■ ■ ■ ■ ■ ■ Anti-allergie ■ ■ ■ ■ ■ ■ ■ SportWear ■ ■ ■...

  • Page 25: Automatic Drying

    Programme Universal Liquid Univer‐ Liquid for col‐ Delicates Special oureds woollens powder 1) Outdoor ▲ ▲ Denim ▲ ▲ ▲ Propre & sec ▲ ▲ 1h/1kg At temperature higher than 60 °C the use of powder detergent is recommended. ▲ = Recommended Company for the washing of wool garments labelled as “hand wash”...

  • Page 26: Timed Drying

    Dryness Level Type of fabric Load Delicate fabrics up to 2 kg (acrylics, viscose and delicate mixed fabrics) Wool items up to 1 kg (woollen jumpers) Outdoor sporting garments up to 2 kg (outdoor clothing, technical, sport fabrics, waterproof and breathable jackets, shell jackets) Denim garments up to 4 kg...

  • Page 27: Settings

    Dryness Level Type of fabric Load Spin Suggested du‐ (kg) speed ration (mins) (rpm) Outdoor sporting garments 1200 140 - 160 (outdoor clothing, technical, sport fabrics, water‐ proof and breathable jackets, shell jackets) 1200 70 - 80 Denim garments 1200 160 - 189 1200 105 - 115...

  • Page 28: Daily Use - Washing Only

    12. DAILY USE - WASHING ONLY 12.3 Filling the detergent and WARNING! additives Refer to Safety chapters. 12.1 Activating the appliance 1. Connect the mains plug to the mains socket. 2. Open the water tap. 3. Press the Marche/Arrêt button for a few seconds to activate the appliance.

  • Page 29: Setting A Programme

    2. Press the lever down to remove the Make sure that the flap does not cause a dispenser. blockage when you close the drawer. 3. To use powder detergent, turn the flap 12.5 Setting a programme 1. Turn the programme dial to select the desired washing programme.

  • Page 30: Starting A Programme With The Delay Start

    After touching the Départ/Pause button, the maximum declared load indicator goes The drain pump can operate shortly off, the SensiCare System starts the laundry before the appliance fills water. load detection: 1. The appliance detects the load in the first 12.7 Starting a programme with the 30 seconds.

  • Page 31: Interrupting A Programme And Changing The Options

    12.11 Opening the door - Adding garments The SensiCare System is not available If the icon is on, you can always open the with all programmes such as :Laine, door. Rinçage and programmes with short cycles. 12.9 Interrupting a programme and If the temperature and level of the water changing the options in the drum are too high and/or the drum...

  • Page 32: Draining Water Out After End Of Cycle

    12.13 Draining water out after end 4. Press the Marche/Arrêt button for a few of cycle seconds to deactivate the appliance. If you have chosen a programme or an option 12.14 Stand-by function that does not empty out the water of the last The Stand-by function automatically rinse, the programme is completed, but: deactivates the appliance to reduce the...

  • Page 33: Washing And Timed Drying

    2. Set the Propre & sec programme by The time value on the display is the means of the programme dial. The duration of both cycles washing and drying, calculated on a default load size. indicators appear on the display. 3.

  • Page 34: Daily Use - Drying Only

    You can remove the laundry before the 1. Remove the laundry from the appliance. anti-crease phase is completed. We 2. Make sure that the drum is empty. recommend, for better results, that you remove the laundry when the phase is almost completed or completed.

  • Page 35: Fluff In The Fabrics

    recommend, for better results, that you In the display the door locked indicator remove the laundry when the phase is comes on. almost completed or completed. The The display also shows the remaining programme time. indicator remains lit. • Press the Marche/Arrêt button for some 14.4 At the end of the drying seconds to deactivate the appliance.

  • Page 36: Hints And Tips

    16. HINTS AND TIPS WARNING! Refer to Safety chapters. 16.1 The laundry load • Divide the laundry into: white, coloured, synthetics, delicates and wool. • Follow the washing instructions on the laundry care labels. • Empty pockets and unfold the items. •...

  • Page 37: Ecological Hints

    • Use only detergents and other treatments • Loading the appliance to the maximum specially made for washing machines. capacity indicated for each First, follow these generic rules: programmes helps to reduce energy – powder detergents (also tablets and and water consumption. single-dose detergents) for all types of •...

  • Page 38: Drying Cycle Duration

    • Fabrics with residue of hair sprays, nail WARNING! solvents or similar. • Garments with foam-rubber or materials To avoid creasing and shrinkage do similar to foam-rubber. not overdry the laundry. 16.8 Garment labels 16.11 General Tips When you dry the laundry, obey the Refer to the «Drying programmes»...

  • Page 39: Removing Foreign Objects

    17.2 Removing foreign objects 17.5 Maintenance wash The repeated and prolonged use of low temperature programmes can cause detergent deposits, fluff residues, bacterial Make sure that pockets are empty and all growth inside the drum and the tub. This loose elements are tied up before could generate bad odours and mildew.

  • Page 40: Cleaning The Detergent Dispenser

    Rust deposits in the drum may occur due to rusting foreign body in the washing or tap water containing iron Clean the drum with special products for stainless steel. Always follow the instructions that you find on the packaging of the product. Do not clean the drum with acidic descaling products, scouring products containing chlorine or iron or steel wool.

  • Page 41: Cleaning The Drain Pump

    2. Place a suitable bowl below the drain 17.9 Cleaning the drain pump pump access to collect the water that flows out. 3. Open the chute downwards. Always keep WARNING! a rag nearby to dry up any water spillages Disconnect the mains plug from the when removing the filter.

  • Page 42: Cleaning The Inlet Hose And The Valve Filter

    7. Turn the filter anti-clockwise to remove it. 12. Close the pump cover. 8. If it is necessary, remove fluff and objects from the filter recess. 9. Make sure that the impeller of the pump can rotate. If it does not rotate, contact the Authorised Service Centre.

  • Page 43: Emergency Drain

    17.11 Emergency drain If the appliance cannot drain the water, carry out the same procedure, described in 'Cleaning the drain pump' paragraph. If necessary, clean the pump. When you drain the water with the emergency drain procedure, you must activate the drain system again: 1.
  • Page 44 18.1 Alarm Codes and Possible failures The appliance does not start or it stops during operation. First try to find a solution to the problem (refer to the tables). WARNING! Deactivate the appliance before carrying out any check. With some problems, the display shows an alarm code and the Départ/ Pause button may flash continuously: If the appliance is overloaded, remove some items from the drum...
  • Page 45 • The programme was not finished properly or the appliance stopped too early. Switch the appliance off and on again. Internal fail. No communica‐ • If the alarm code appears again, contact the Authorised Service Centre. tion between electronic ele‐ ments of the appliance.

  • Page 46: Emergency Door Opening

    Problem Possible solution • The SensiCare System is able to adjust the programme duration according to The programme duration in‐ creases or decreases during the type and the laundry load size. Refer to "The SensiCare System load de‐ programme execution. tection"...

  • Page 47: Consumption Values

    2. Disconnect the mains plug from the 5. Take out the laundry and then close the mains socket. appliance door. 3. Open the filter flap. 6. Close the filter flap. 4. Pull the emergency unlock trigger downward once. Pull it downward once again, keep it tensed and, in the meanwhile, open the appliance door.
  • Page 48 Litres Water consumption. Spin speed. Remaining moisture at the end of the cycle. The higher is the spin speed, the higher is the noise and the lower is the remaining moisture at the end of washing cycle. Values and programme duration may differ depending on different conditions (e.g. room temperature, water temperature and pressure, load size and type of laundry, supply voltage) and also if you change the default setting of a programme.

  • Page 49: Environmental Concerns

    Programme rpm 1) Litres hh:mm °C Coton 2.700 90.0 04:05 85.0 44.00 1600 90°C Coton 1.600 85.0 03:50 55.0 44.00 1600 60°C Coton 0.350 85.0 03:00 20.0 44.00 1600 20°C Synthétiques 0.800 55.0 02:15 40.0 35.00 1200 40°C Délicats 0.400 60.0 01:05 30.0...
