ASROCK IMB-1714 Settings Manual

IMB-1714
IMB-X1714
and HDMI High-Definition
®
The terms HDMI
Multimedia Interface, and the HDMI logo are
trademarks or registered trademarks of HDMI
Licensing LLC in the United States and other
countries.
Revision History
Date Description
December 8, 2022 First Release
COM Port Pin9 PWR Setting Jumpers
1 : PWR_COM1 (For COM Port1)
PWR_COM2 (For COM Port2)
25 : PWR_COM3 (For COM Port3)
PWR_COM4 (For COM Port4)
PWR_COM5 (For COM Port5)
PWR_COM6 (For COM Port6)
1-2 : +5V
2-3 : +12V
2 : PS/2 Keyboard/Mouse Header
1
PIN Signal Name
1 KBCLK
2 +5V
3 KBDATA
4 +5V
5 MSDATA
6 GND
7 MSCLK
8 GND
LAN LED Headers
3 : I225_LED3 (For LAN3 Port)
38 : I225_LED2 (For LAN2 Port)
I225_LED1 (For LAN1 Port)
Signal Signal
PIN PIN Signal Name PIN
Name Name
LED_LNK#_
1 LILEDP 2 3 LED_1000#
ACT
4 : ATX 12V Power Connector
Chassis FAN Connectors (+12V)
5 : CHA_FAN1
GND
+12V
CHA_FAN_SPEED
FAN_SPEED_CONTROL
22 : CHA_FAN2
FAN_SPEED_CONTROL
CHA_FAN_SPEED
+12V
GND
GND
14 : CHA_FAN3
+12V
CHA_FAN_SPEED
FAN_SPEED_CONTROL
6 : CPU FAN Connector (+12V)
7 : USB 2.0 Port (USB2_13)
Jumpers and Headers Setting Guide
8 : PSU_SMB1
9 : 24-pin ATX Power Input Connector
Chassis Intrusion Headers
10 : CI1 :
Open : Normal
Short : Active Case Open
13 : CI2 :
Open : Active Case Open
Short : Normal
11 : USB 2.0 Port (USB2_12)
12 : PWR LOSS Jumper (PWR_LOSS1)
Open : No Power Loss
Short : Power Loss
15 : USB 3.2 Gen1 Header
Signal
PIN
Name
(USB3_5_6)
4 LED_2500#
SATA3 Connectors
8 5
17 : SATA3_4, SATA3_5
18 : SATA3_6, SATA3_7
4 1
23 : SATA3_0~3
19 : System Panel Header
24 : COM Port Headers (COM3~6) (RS232)
RRXD1
DDTR#1
DDSR#1
1
GND
TTXD1
DDCD#1
+12V
26 : ATX/AT Mode Jumper (SIO_AT1)
CPU_FAN_SPEED
GND
FAN_SPEED_CONTROL
Open : ATX Mode
Short : AT Mode
1
PIN Signal Name
1 SMB_CLK
2 SMB_DATA
3 SMBALERT#
4 GND
5 +3V
12
1
GND
Signal
Vbus Vbus
Vbus IntA_P1_SSRX-
IntA_P0_SSRX- IntA_P1_SSRX+
IntA_P0_SSRX+ GND
GND IntA_P1_SSTX-
IntA_P0_SSTX- IntA_P1_SSTX+
IntA_P0_SSTX+
GND
GND IntA_P1_D-
IntA_P0_D- IntA_P1_D+
IntA_P0_D+ ID
1
1
HDLED+ PLED+
HDLED- PLED-
PWRBTN#
GND
RESET# GND
DUMMY GND
CCTS#1
RRI#1
PWR
RRTS#1
27 : ESPI Header
24
28 : Printer Port / GPIO Header (LPT_GPIO1)
Printer Port:
13
PIN Signal Name PIN
26
24
22
1
20
18
16
14
12 JGPIOPWR
10 JGPIOPWR
8 SIO_GP73
6 SIO_GP74
4 SIO_GP75
2 SIO_GP76
* If you want to use the printer port function, please short pin4 and pin5 on
Digital Input / Output Power Select (JGPIO_PWR1).
29 : Digital Input / Output Default Value
Setting (JGPIO_SET1)
1-2 : Pull-High
2-3 : Pull-Low
30 : Digital Input / Output Power Select
(JGPIOPWR) (JGPIO_PWR1)
1-2 : +12V
2-3 : +5V
3-4 : +5V * If you want to use the printer port function, please
short pin4 and pin5 on Digital Input / Output Power
4-5 : GND
Select (JGPIO_PWR1).
31 : USB 2.0 Header
(USB2_10_11)
32 : SPDIF Header
+5V
33 : Front Panel Audio Header
GPIO:
Signal Name
NC 25 NA
GND 23 SIO_G70/GPP_E6
GND 21 SIO_G71/GPP_E5
GND 19 SIO_G72/GPP_I10
GND 17 SIO_GP87/GPP_H23
GND 15 SIO_GP86
GND 13 SIO_GP85
11 SIO_GP84
9 SIO_GP83
7 SIO_GP82
5 SIO_GP81
3 SIO_GP80
1 SIO_GP77
