- Page 1 42 inch E-paper Display Signage DMPH420EC1 Dalian Good Display Co., Ltd.
-
Page 2: Product Specifications
42 Inch Epaper Signage Product Specifications Customer Standard Description ePaper Display Signage Model Name DMPH420EC1 Date 2024/06/28 Revision Design Engineering Approval Check Design Zhongnan Building, No.18, Zhonghua West ST,Ganjingzi DST,Dalian,CHINA Tel: +86-411-84619565 Email: info@good-display.com Website: www.good-display.com www.good-display.com 2/15 DMPH420EC1... -
Page 3: Table Of Contents
2. Product Advantages ........4 3. Mechanical Specifications ......4 4. Product Structure ........6 5. Update Image via USB ....... 9 6. Update Image via WIFI ......12 7. Packaging and Installation ......14 8. Precautions ..........15 www.good-display.com 3/15 DMPH420EC1... -
Page 4: Overview
• Dual-state display (retains last image even after power loss) • Display can be updated via USB or WiFi (USB preferred) • Image formats supported: BMP, PNG, JPG 3. Structure Specification DMPH420EC1 Part Number Size: 42 inch Type: Black-and-White E Ink Display... - Page 5 Motherboard System: Android 7.1 CPU: Quad-core ARM Cortex A7 DDR: 1G EMMC: 8G Weight: about 11.5kg Specifications Overall dimensions: 896.2x682x35.5mm Operating Temperature: 0 °C~50°C Temperature and Storage Temperature: -25°C~70°C humidity Operating Humidity: 20%~90% www.good-display.com 5/15 DMPH420EC1...
-
Page 6: Product Structure
42 Inch Epaper Signage 4.Product Structure Figure 1: Front View of DMPH420EC1 mounting bracket Figure 2: Back View of DMPH420EC1 www.good-display.com 6/15 DMPH420EC1... - Page 7 42 Inch Epaper Signage Figure 3: Side View of DMPH420EC1 ① Power Button Turn the main power on or off. Pressing the power button briefly will start the sign, and the LED light will illuminate; pressing the power button again will turn off the sign, and the LED light will go off.
- Page 8 ⑤ DOWN Button • Press lightly to switch to the next displayed image. The system must have at least two images saved. • Press and hold for 3s to 10s, then release to view system status information. www.good-display.com 8/15 DMPH420EC1...
-
Page 9: Update Image Via Usb
1. Install the image conversion tool xtacepSetup-V2.5.3.exe. Typically installed on drive D of the computer. After installation, a folder named "XT Picture Processing Tool" will appear in drive D. Enter this folder to find the files below. www.good-display.com 9/15 DMPH420EC1... - Page 10 Ensure that there are no spaces in the image path or filenames. 3.Open the installed xtacep.exe software 4.Click on 'File' in the upper left corner, then load the folder containing the images that need to be updated according to the path. www.good-display.com 10/15 DMPH420EC1...
- Page 11 8. When all images have been converted, you can click the 'Open Folder' button in the software to view the processed images. The processed images will be automatically generated in a folder named XT_Resources, and the converted images will be saved in the image folder. www.good-display.com 11/15 DMPH420EC1...
-
Page 12: Copying Images
Scan the QR code on the left side with your phone to download the app. After downloading and installing the app, scan the QR code on the right side to configure the connection to the router. www.good-display.com 12/15 DMPH420EC1... -
Page 13: Uploading Images
After setting everything, click the Confirm button . The software will then display a message indicating a successful issue. Once issued successfully, the signboard will sequentially play the images according to the publishing list. www.good-display.com 13/15 DMPH420EC1... -
Page 14: Packaging And Installation
Avoid installing the product in kitchens, bathrooms, or areas exposed to high humidity as it may shorten the product's lifespan. • Do not install the product at altitudes above 3000 meters, as it may result in malfunction. www.good-display.com 14/15 DMPH420EC1... -
Page 15: Storage Precautions
5. Be cautious of collisions during usage. 8.3 Storage Precautions Store in a fireproof, moisture-resistant environment (humidity not exceeding 80%), away from high temperatures (not exceeding 7 0°C), avoiding stacking, dirt accumulation, heavy object pressure and damage. www.good-display.com 15/15 DMPH420EC1...
