Summary of Contents for Good Display DMPH315E62
- Page 1 31.5 inch Color E-paper Display Signage DMPH315E62 Dalian Good Display Co., Ltd.
-
Page 2: Product Specifications
31.5 inch Epaper Signage Product Specifications Customer Standard Description ePaper Display Signage DMPH315E62 Model Name Date 2024/08/23 Revision Design Engineering Approval Check Design No.18, Zhonghua West ST,Ganjingzi DST,Dalian,CHINA Tel: +86-411-84619565 Email: info@good-display.com Website: www.good-display.com www.good-display.com 2/12 DMPH315E62... -
Page 3: Table Of Contents
31.5 inch Epaper Signage Contents Overview ...............4 2. Description of I/O Ports on the Bottom Structure..5 3. LED Status Indicator Explanation ......8 4. Product Parameters..........9 5. Updating Images via USB Drive....... 11 6. Important Notices..........12 www.good-display.com 3/12 DMPH315E62... -
Page 4: Overview
31.5 inch Epaper Signage 1. Overview 1.1. Product Overview 1.2. Product Appearance and Port Function Description 1.2.1. Front View Black Housing Display Area www.good-display.com 4/12 DMPH315E62... -
Page 5: Back View
7. Type-C (PD) Charging Port: Used to connect an external Type-C charger. 2.2. Button Function Description 2.2.1. DOWN Button (1) During the image update process, press briefly to switch to the next image. This function only works when there are two or more images in the system. www.good-display.com 5/12 DMPH315E62... - Page 6 (xtacepSetup.exe installer). (2) Open the software and select 31.5E6 for the EPD type. (3) Click the top-left corner to select files. You can either choose an entire folder or add images by selecting additional files. www.good-display.com 6/12 DMPH315E62...
- Page 7 - Operated: Select Update. Insert the USB drive into your computer, click the "Please select save path" button, and then choose to save on the USB drive, as shown below: www.good-display.com 7/12 DMPH315E62...
-
Page 8: Led Status Indicator Description
6) Press the POWER button briefly to turn on the device. The red indicator light will flash, indicating that the device is powering on. 7) Insert the USB drive into the main unit; after about 15 seconds, the image update will begin automatically. 3. LED Status Indicator Description www.good-display.com 8/12 DMPH315E62... -
Page 9: Product Parameters
(6) When the charger is unplugged while the device is powered off, the indicator light will turn off. 4. Product Parameters Model Name DMPH315E62 Size: 31.5 inch Type: E Ink Spectra6 Color: Red, Yellow, Blue, White, Green, Black View Angle(H/V): 178°(H)/178°(V) - Page 10 Languages Supported: English and Chinese (default is English) Overall Dimensions: Metal Casing: 723x418x30.5mm Wood Grain Plastic Casing: 747x442x34.5mm Packaging Dimensions: 843x151mmx590mm Net Weight: Sheet Metal: 7.65kg Machine Dimensions and Weight Water Transfer Printing: 8.35kg Gross Weight: Sheet Metal: 9kg www.good-display.com 10/12 DMPH315E62...
-
Page 11: Updating Images Via Usb Drive
5. Updating Images via USB Drive Press the Power button to turn on the device. After the device is powered on, insert the USB drive containing the configured "XT_Resources" folder into the USB 2.0 port on the device. www.good-display.com 11/12 DMPH315E62... -
Page 12: Important Notices
1. The storage environment must be fireproof, moisture-proof (humidity not exceeding 90%), heat-resistant (temperature not exceeding 50°C), free from pressure, dirt, heavy objects, and damage. 2. The storage temperature should not fall below 0°C, as this may cause the device to malfunction. www.good-display.com 12/12 DMPH315E62...
