Summary of Contents for Bosch Security D9412G

  • Page 1 D9412G/D7412G Approved Applications Compliance Guide Control Panels...
  • Page 2 D9412G/D7412G | Approved Applications Compliance Guide | EN | 2 Bosch Security Systems | 9/03 | 43494E...
  • Page 3: Table Of Contents

    Household Fire Warning Equipment ..........................18 Figures Figure 1: D9412G System Wiring Diagram, 1 of 3 ........................9 Figure 2: D9412G System Wiring Diagram, 2 of 3 ......................... 10 Figure 3: D9412G System Wiring Diagram, 3 of 3 ......................... 11 Figure 4: D7412G System Wiring Diagram, 1 of 3 .........................
  • Page 4 D9412G/D7412G | Approved Applications Compliance Guide | Table of Contents EN | 4 Notes: Bosch Security Systems | 9/03 | 43494E...
  • Page 5: Overview

    D9412G/D7412G | Approved Applications Compliance Guide | 1.0 Overview EN | 5 1.3.2 Bank Safe and Vault Applications Overview The UL Listed Model 5110 Bell and Model 4001-42 Listings and Approvals External Line Balancer (both made by Rothenbuhler) 1. 1 . 1...
  • Page 6: Enclosures

    D9412G/D7412G | Approved Applications Compliance Guide | 1.0 Overview EN | 6 1.3.4 Enclosures Bosch Security Systems offers three optional enclosures for the control panel. • The D8103 Enclosure is suitable for residential fire and/or burglary installations and commercial burglary applications not requiring attack resistance or approval by Factory Mutual or NYC-MEA.
  • Page 7: System Chart

    D9412G/D7412G | Approved Applications Compliance Guide | 2.0 System Chart EN | 7 System Chart Table 1: UL System Chart 24 + 24 + 60 + 24 + 24 + 24 + 24 + 24 + 24 + 24 +...
  • Page 8 D9412G/D7412G | Approved Applications Compliance Guide | 2.0 System Chart EN | 8 Notes: Bosch Security Systems | 9/03 | 43494E...
  • Page 9: System Wiring Diagrams, Issue A

    In ALT ALARM RELAY C ZONEX IN 2 D9412G Control / Communicator is UL Listed For Central Station, Local, Remote Station and Household & SW AUX Fire Alarm, and Central Station, Local, Police Station Connect and Household Burglar Alarm. SUPV IN System is Intended To Be Checked By A Qualified Technician At Least Every 3 Years.
  • Page 10: D9412G Control Panel, 2 Of 3

    Model D136 Relay In ALT ALARM RELAY C D9412G Control / Communicator is UL Listed For Central Station, Local, Remote Station and Household ZONEX IN 2 & SW AUX Fire Alarm, and Central Station, Local, Police Station Connect and Household Burglar Alarm.
  • Page 11: D9412G Control Panel, 3 Of 3

    ZONEX IN 2 & SW AUX D9412G Control / Communicator is UL Listed For Central Station, Local, Remote Station and Household Fire Alarm, and Central Station, Local, Police Station Connect and Household Burglar Alarm. System is Intended To Be Checked By A Qualified Technician At Least Every 3 Years.
  • Page 12: D7412G Control Panel, 1 Of 3

    D9412G/D7412G | Approved Applications Compliance Guide | 3.0 System Wiring Diagrams EN | 12 D7412G Control Panel, 1 of 3 Figure 4: D7412G System Wiring Diagram, 1 of 3 D113 CHGR- BAT 2- BAT 2+ VAUX+ BAT 1- SUPV BAT 1+...
  • Page 13: D7412G Control Panel, 2 Of 3

    The Power Supply Provides a Maximum of 1.4 Amps For The Control POWER + 16.5 VAC 40 VA 60 Hz Panel and All Accessory Devices. For System Loading, See D9412G/D7412G Operation Model D1640 and Installation Guide (P/N:43488___). Internally Fused - Do Not short...
  • Page 14: D7412G Control Panel, 3 Of 3

    D9412G/D7412G | Approved Applications Compliance Guide | 3.0 System Wiring Diagrams EN | 14 D7412G Control Panel, 3 of 3 Figure 6: D7412G System Wiring Diagram, 3 of 3 46729G D1255 D1256 D1257 D1260 LEDs Off When Normal Charging Status Digital Alarm Communicator Transmitter Low Battery - 12.1 VDC...
  • Page 15: Current Rating Charts

    D9412G/D7412G | Approved Applications Compliance Guide | 4.0 Current Rating Charts EN | 15 Current Rating Charts Current Rating Chart for Standby Battery Calculations Table 2: Current Rating Chart for Standby Battery Calculations AC Power On AC Power Off In Alarm...
  • Page 16: Current Rating Chart For D8125Mux

    D9412G/D7412G | Approved Applications Compliance Guide | 4.0 Current Rating Charts EN | 16 Current Rating Chart for D8125MUX Fill in the following chart to determine the maximum currents for the D8125MUX and its accessories. Transfer the total figures to Table 2.
  • Page 17: Standby Battery

    D9412G/D7412G | Approved Applications Compliance Guide | 5.0 Standby Battery EN | 17 Standby Battery Calculation for NFPA 72 Fire Alarm Applications Requirements 5.2. 1 Current Chart First 5.1. 1 Household Burglary and Commercial See the Current Rating Chart for Standby Battery...
  • Page 18: Remote Station Or Auxiliary Systems

    D9412G/D7412G | Approved Applications Compliance Guide | 5.0 Standby Battery EN | 18 5.2.3 Remote Station or Auxiliary Systems 5.2.4 Household Fire Warning Equipment Remote Station or Auxiliary Systems require 60 hours The Household Fire Warning Equipment Standard of standby plus 5 minutes of alarm operation at the end requires 24 hours of standby plus 4 minutes of alarm of the 60 hour period.
  • Page 19 D9412G/D7412G | Approved Applications Compliance Guide | 5.0 Standby Battery EN | 19 Notes: Bosch Security Systems | 9/03 | 43494E...
  • Page 20 Bosch Security Systems 130 Perinton Parkway Fairport, NY 14450-9199 USA www.boschsecurity.us Customer Service: (800) 289-0096 Technical Support: (888) 886-6189 © 2003 Bosch Security Systems 43494E...
