DS7200V2-UK User's Guide
Function
Turn the System All On:
Turn the System On Perimeter Only:
Turn the System Partial On:
Silence Alarms/Turn the System Off:
Bypass Zones:
System Reset:
View Faulted Zones:
Check System Faults:
View Alarm Memory:
System Test:
View System Faults:
Remote Program:
Walk Test:
Set System Date and Time:
View Zone Faults:
Keypad Adjust:
Move to Area:
Extend Auto-On Time:
Change Skeds (Timers):
Renew One-Time PINs:
Change Outputs:
Change PIN:
Change Another User's PIN:
Change Another User's Authority Level:
Add a User PIN:
Delete a User PIN:
Turn Chime On/Off:
Select Chime Tone:
Select Chime Zones:
Set Partial On (Part Set) Zones:
All Areas On:
All Areas Off:
Auto-Forward On/Off:
Auto-Forward On Setup:
Auto-Forward Off Setup:
View History Log:
Enable Installer PIN:
Keypad Sequence
[On] or [#][1]
[Perimeter Only] or [#][2]
[#][3]
Enter a valid User PIN
[Bypass]
[System Reset] or [#][4][7]
[*]
[#][4]
[#][4][0]
[#][4][1]
[#][4][2]
[#][4][3]
[#][4][4]
[#][4][5]
[#][4][8]
[#][4][9]
[#][5][0]
[#][5][1]
[#][5][2]
[#][5][3]
[#][5][4]
[#][5][5]
[#][5][6][1]
[#][5][6][2]
[#][5][6][3]
[#][5][8]
[#][6][1]
[#][6][2]
[#][6][3]
[#][6][5]
[#][8][0]
[#][8][1]
[#][8][2]
[#][8][3]
[#][8][4]
[#][8][5]
[#][9][2]
Table 1: Keypad Quick Reference
For more details see page:
Text Keypad
LED Keypad
12
33
12
33
12
33
10
32
15
36
24
45
15
44
20
42
21
43
22
44
21
43
28
48
23
45
16
37
22
N/A
11
32
29
N/A
26
47
26
N/A
20
42
27
N/A
16
37
17
38
17
39
18
40
19
41
24
45
25
46
25
46
13
34
28
47
28
47
29
47
29
N/A
30
N/A
31
N/A
31
48
Advertisement
Table of Contents
Related Manuals for Bosch Security DS7200V2-UK
Summary of Contents for Bosch Security DS7200V2-UK
- Page 1 DS7200V2-UK User’s Guide Function Keypad Sequence For more details see page: Text Keypad LED Keypad Turn the System All On: [On] or [#][1] Turn the System On Perimeter Only: [Perimeter Only] or [#][2] Turn the System Partial On: [#][3] Silence Alarms/Turn the System Off:...
-
Page 2: Table Of Contents
Auto Forward On Setup ..........29 3.38 Auto Forward Off Setup ..........30 3.39 Remote Arming with Telephone, Area 1 ....30 3.40 View History Log .............31 3.41 Enable Installer PIN ..........31 Copyright 2004 Bosch Security Systems Page 2 P/N: 4998152530B DS7200V2-UK User's Guide... -
Page 3: Introduction
Bypass Zones function (for text keypads, see intended to prevent an incident that might page 15; for LED keypads, see page 36). prohibit proper operation of the program/equipment, and/or cause personal injury. Copyright 2004 Bosch Security Systems DS7200V2-UK User's Guide P/N: 4998152530B Page 3 INTRODUCTION... - Page 4 Figure 2: Perimeter Only/Partial On Operation DINING KITCHEN ROOM ROOM ROOM LIVING BEDROOM ROOM = Controlled Zone is turned All On. Figure 1: All On Operation Copyright 2004 Bosch Security Systems Page 4 P/N: 4998152530B DS7200V2-UK User's Guide INTRODUCTION...
-
Page 5: Security System Limitations
Bedroom Room Rec Room Living Room Bedroom = Smoke Detector Locate smoke detectors between sleeping areas and family living Bedroom areas. Figure 3: Smoke Detector Locations Copyright 2004 Bosch Security Systems DS7200V2-UK User's Guide P/N: 4998152530B Page 5 INTRODUCTION... -
Page 6: Maintenance And Service
Make sure someone has not intentionally turned the breaker off. When all is clear, reset the breaker. Copyright 2004 Bosch Security Systems Page 6 P/N: 4998152530B DS7200V2-UK User's Guide... -
Page 7: Keypad Overview
[1]+[3] keys = _________________________ require displaying zones or users higher than 16 cannot be performed from this • [4]+[6] keys = _________________________ keypad. • [7]+[9] keys = _________________________ Copyright 2004 Bosch Security Systems DS7200V2-UK User's Guide P/N: 4998152530B Page 7 KEYPAD OVERVIEW... -
Page 8: Keypad Tones
Delay, the keypad sounds the Last _ _ _ _ _ _ _ _ _ _ Chance warning tone. You should (Fast) exit immediately. Table 3: Keypad Tone Descriptions Copyright 2004 Bosch Security Systems Page 8 P/N: 4998152530B DS7200V2-UK User's Guide KEYPAD OVERVIEW... -
Page 9: Check System Status (Text Keypad Only)
System is turned on Perimeter Only Steady with Entry Delay. Slow System is turned on Perimeter Only Flash with no Entry Delay. Table 5: LED Keypad System Status LEDs Copyright 2004 Bosch Security Systems DS7200V2-UK User's Guide P/N: 4998152530B Page 9 KEYPAD OVERVIEW... -
Page 10: Using The Text Keypad
An alarm report is sent to the ARC if the alarm is cleared. If the code is rejected, the keypad not silenced in time. sounds the error tone. Enter the code again. Copyright 2004 Bosch Security Systems Page 10 P/N: 4998152530B DS7200V2-UK User's Guide... -
Page 11: Keypad Adjust
(as set by your Installation Company) across the second line. Smiths Residence OK for All On Copyright 2004 Bosch Security Systems DS7200V2-UK User's Guide P/N: 4998152530B Page 11 USING THE TEXT KEYPAD... -
Page 12: Turn The System On
(for example, the front door is opened), the system immediately begins an alarm event. Turning the system on with no Exit Tone silences the Exit tone and doubles Exit Delay time. Copyright 2004 Bosch Security Systems Page 12 P/N: 4998152530B DS7200V2-UK User's Guide... -
Page 13: Set Partial On (Part Set) Zones
Check the system and restore any zones that are operation faulted, then re-arm the system. Press [#] to exit this function. The system does not arm if a Bad Set occurs. Copyright 2004 Bosch Security Systems DS7200V2-UK User's Guide P/N: 4998152530B Page 13 USING THE TEXT KEYPAD... -
Page 14: Force Arming The System
The display above uses an Exit Delay time of 60 seconds and only one zone is force armed. Exit Delay time and the number of zones force- armed might vary. Copyright 2004 Bosch Security Systems Page 14 P/N: 4998152530B DS7200V2-UK User's Guide... -
Page 15: View Faulted Zones
Zn 3, Hallway To unbypass 3 Press 3 + *. To unbypass a zone, repeat the steps above. Press [#] to exit this function. Copyright 2004 Bosch Security Systems DS7200V2-UK User's Guide P/N: 4998152530B Page 15 USING THE TEXT KEYPAD... -
Page 16: Set System Date And Time
* * * * The keypad displays the following to confirm that you have successfully changed your PIN: PIN changed The keypad automatically exits this function. Copyright 2004 Bosch Security Systems Page 16 P/N: 4998152530B DS7200V2-UK User's Guide USING THE TEXT KEYPAD... -
Page 17: Change Another User's Pin
Enter the new authority level (1 to 4) for the user that you want to change. Press [#] to exit this function. Press [#] again to return to the idle display. Copyright 2004 Bosch Security Systems DS7200V2-UK User's Guide P/N: 4998152530B Page 17... -
Page 18: Change Another User's Area
2 from User 4’s area assignment. Press [#] twice to return to the three selections shown in Step 2. Press [1] to create a PIN for the new user. Copyright 2004 Bosch Security Systems Page 18 P/N: 4998152530B DS7200V2-UK User's Guide... -
Page 19: Delete A User Pin
Press [#] to exit this function. If no keys are pressed, the keypad automatically returns to the idle display. Copyright 2004 Bosch Security Systems DS7200V2-UK User's Guide P/N: 4998152530B Page 19 USING THE TEXT KEYPAD... -
Page 20: Renew One-Time Pins
Press [#] to return the keypad to the idle display. The Fault tone continues until the situation is acknowledged. Contact your Installation Company if you still see fault messages. Copyright 2004 Bosch Security Systems Page 20 P/N: 4998152530B DS7200V2-UK User's Guide... -
Page 21: View Alarm Memory
− If there are no system faults, the keypad displays: There are no System troubles. Press [#] to return to the idle display. Copyright 2004 Bosch Security Systems DS7200V2-UK User's Guide P/N: 4998152530B Page 21 USING THE TEXT KEYPAD... -
Page 22: View Faulted Zones
May take 4 min. The keypad displays the results of the battery test: Battery Test Passed. Battery Test Failed! Please call for Service. Copyright 2004 Bosch Security Systems Page 22 P/N: 4998152530B DS7200V2-UK User's Guide USING THE TEXT KEYPAD... -
Page 23: Walk Test
If necessary, press [#] to stop the Walk Test. Test fire detection devices (smoke/heat detectors) weekly as instructed by your Installation Company and according to the devices’ instructions. Copyright 2004 Bosch Security Systems DS7200V2-UK User's Guide P/N: 4998152530B Page 23 USING THE TEXT KEYPAD... -
Page 24: Reset The System
This also resets the confirmed alarm. If your Installation Company does not allow you to clear a confirmed alarm, call for assistance. Copyright 2004 Bosch Security Systems Page 24 P/N: 4998152530B DS7200V2-UK User's Guide... -
Page 25: Select Chime Tone
Chime tone setting, press [#] to exit this function. After making your selection, the display confirms the choice you have made. Press [#] to exit this function. Copyright 2004 Bosch Security Systems DS7200V2-UK User's Guide P/N: 4998152530B Page 25 USING THE TEXT KEYPAD... -
Page 26: Extend Auto-On Time
Sk1 A1 Auto On Time 22:35 Entering 0000 for Sked time disables the Sked. The valid Sked time range is 0001 to 2400. Copyright 2004 Bosch Security Systems Page 26 P/N: 4998152530B DS7200V2-UK User's Guide USING THE TEXT KEYPAD... -
Page 27: Change Outputs
For example, if you do not want your Sked to operate on Mondays and Wednesdays, first press [8] to turn the All Days function off. Then press the appropriate keys to add or delete days. Copyright 2004 Bosch Security Systems DS7200V2-UK User's Guide P/N: 4998152530B Page 27... -
Page 28: Remote Program
Procedure Press [#][8][1]. The keypad prompts you to enter your PIN. The keypad indicates that all areas are off. Copyright 2004 Bosch Security Systems Page 28 P/N: 4998152530B DS7200V2-UK User's Guide USING THE TEXT KEYPAD... -
Page 29: Move To Area
Press [2] to turn it off. Forward On menu. Press [#] to exit this function. Press and hold [#] to exit this function. Copyright 2004 Bosch Security Systems DS7200V2-UK User's Guide P/N: 4998152530B Page 29 USING THE TEXT KEYPAD... -
Page 30: Auto Forward Off Setup
To delete a digit, press B key. To view and edit press Bypass. To stop edit press Bypass. To exit hold #. Copyright 2004 Bosch Security Systems Page 30 P/N: 4998152530B DS7200V2-UK User's Guide USING THE TEXT KEYPAD... -
Page 31: View History Log
The second line of the log display alternates between the time and date of the event and the area, zone (device), user and communication information for the event. Copyright 2004 Bosch Security Systems DS7200V2-UK User's Guide P/N: 4998152530B Page 31... -
Page 32: Using The Led Keypad
View Alarm Memory on page 43. To reset a fire alarm, press [System Reset] or [#][4][7] twice. Copyright 2004 Bosch Security Systems Page 32 P/N: 4998152530B DS7200V2-UK User's Guide USING THE LED KEYPAD... -
Page 33: Turn The System Off
(for example, the front door is opened), the system immediately begins an alarm event. Turning the system on with no Exit Tone silences the Exit tone and doubles Exit Delay time. Copyright 2004 Bosch Security Systems DS7200V2-UK User's Guide P/N: 4998152530B Page 33... -
Page 34: Set Partial On (Part Set) Zones
Repeat this step until all desired zones are selected for Partial On operation. Press [#] to save your selections and exit this function. Copyright 2004 Bosch Security Systems Page 34 P/N: 4998152530B DS7200V2-UK User's Guide USING THE LED KEYPAD... -
Page 35: Turn The System On With Tamper Or Fault (Trouble) Conditions
When the Exit Delay countdown ends, the Zone 1 LED turns off, but the Armed LED remains on. The Status LED turns on again. Enter a valid PIN to turn the system off. Copyright 2004 Bosch Security Systems DS7200V2-UK User's Guide P/N: 4998152530B Page 35... -
Page 36: Bypass/Unbypass Zones
To unbypass a zone, repeat the steps above. Status LED turns on again. Press [#] to exit this function. Enter your PIN to turn the system off. Copyright 2004 Bosch Security Systems Page 36 P/N: 4998152530B DS7200V2-UK User's Guide... -
Page 37: Set System Date And Time
After you enter the date and time, the keypad sounds a long beep and automatically exits the Date/Time function. Copyright 2004 Bosch Security Systems DS7200V2-UK User's Guide P/N: 4998152530B Page 37 USING THE LED KEYPAD... -
Page 38: Change Another User's Pin
Armed Perimeter Status Supervisory Power Bell Silenced Fire Trouble 9 10 11 12 13 14 15 16 Copyright 2004 Bosch Security Systems Page 38 P/N: 4998152530B DS7200V2-UK User's Guide USING THE LED KEYPAD... -
Page 39: Change Another User's Authority Level
− Zone 2 LED: Press [2] to change authority levels − Zone 3 LED: Press [3] to assign an area to a PIN Copyright 2004 Bosch Security Systems DS7200V2-UK User's Guide P/N: 4998152530B Page 39 USING THE LED KEYPAD... -
Page 40: Change Another User's Area
− Zone 2 LED: Press [2] to change authority levels − Zone 3 LED: Press [3] to assign an area to a PIN Copyright 2004 Bosch Security Systems Page 40 P/N: 4998152530B DS7200V2-UK User's Guide USING THE LED KEYPAD... -
Page 41: Delete A User Pin
14. Enter the user number, and then press [*]. For example, press [7][*] for User 7. 15. Enter the authority level (1 to 4). Press [#] to enter the assignment into the system. Copyright 2004 Bosch Security Systems DS7200V2-UK User's Guide P/N: 4998152530B Page 41... -
Page 42: Renew One-Time Pins
Table 11: Checking System Faults Press [#]to exit this function. If system faults persist, contact your Installation Company for assistance. Copyright 2004 Bosch Security Systems Page 42 P/N: 4998152530B DS7200V2-UK User's Guide USING THE LED KEYPAD... -
Page 43: View Alarm Memory
System Interval Flashing Fast Ground Fault Condition RF Keyfob Low Battery Condition Table 12: Viewing System Faults Press [#] twice to exit this function. Copyright 2004 Bosch Security Systems DS7200V2-UK User's Guide P/N: 4998152530B Page 43 USING THE LED KEYPAD... -
Page 44: View Faulted Zones
Testing Segment Failed Testing Segment Complete Table 15: System Test Status The keypad automatically exits this function when the system test is complete. Copyright 2004 Bosch Security Systems Page 44 P/N: 4998152530B DS7200V2-UK User's Guide USING THE LED KEYPAD... -
Page 45: Walk Test
PIN by quickly flashing the Status LED. The system now resets. After the system resets, the keypad automatically exits this function. Copyright 2004 Bosch Security Systems DS7200V2-UK User's Guide P/N: 4998152530B Page 45 USING THE LED KEYPAD... -
Page 46: Select Chime Tone
[#]. The keypad sounds the OK tone and exits this function. Press [#] to exit this function. Copyright 2004 Bosch Security Systems Page 46 P/N: 4998152530B DS7200V2-UK User's Guide USING THE LED KEYPAD... -
Page 47: Extend Auto-On Time
− If an area has faulted zones when you try to turn all areas All On, the appropriate Zone LEDs turn on (Zones 1 to 16). Copyright 2004 Bosch Security Systems DS7200V2-UK User's Guide P/N: 4998152530B Page 47 USING THE LED KEYPAD... -
Page 48: Remote Arming With Telephone, Area 1
The keypad sounds the OK tone, indicating that the remote programming session has begun. When the session is completed, the keypad automatically exits this function. Copyright 2004 Bosch Security Systems Page 48 P/N: 4998152530B DS7200V2-UK User's Guide USING THE LED KEYPAD... -
Page 49: Reference Materials
A pager display configured to show all four fields without separators using the sample information from above would look like this: 12340080221. Contact your Installation Company to modify pager display configuration. Copyright 2004 Bosch Security Systems DS7200V2-UK User's Guide P/N: 4998152530B... -
Page 50: System Event Descriptions
Alarm event within two minutes of CheckSum Fail Checksum on panel’s parameters failed. closing. Contact Alarm Reporting Company to verify panel program. Table 18: System Event Descriptions Copyright 2004 Bosch Security Systems Page 50 P/N: 4998152530B DS7200V2-UK User's Guide REFERENCE MATERIALS... - Page 51 Entry Delay by RPS. Frc, Prt, +Dly, Usr System forced Perimeter On with Open, RPS Opening by RPS. Entry Delay by user. Table 18: System Event Descriptions (continued) Copyright 2004 Bosch Security Systems DS7200V2-UK User's Guide P/N: 4998152530B Page 51 REFERENCE MATERIALS...
- Page 52 Rcvr Jam Jammed condition detected on RF Rstl, Flt, Panic Restoral from fault condition on Panic Receiver. detection device(s). Table 18: System Event Descriptions (continued) Copyright 2004 Bosch Security Systems Page 52 P/N: 4998152530B DS7200V2-UK User's Guide REFERENCE MATERIALS...
- Page 53 Output 2 configured as supervised siren output. Reserved. Siren Alarm Rstl Trouble condition on supervised siren output cleared. Reserved. Reserved. Table 18: System Event Descriptions (continued) Copyright 2004 Bosch Security Systems DS7200V2-UK User's Guide P/N: 4998152530B Page 53 REFERENCE MATERIALS...
-
Page 54: Glossary
Trouble Tone A tone that is on briefly, followed by a pause, on briefly (repeatedly). Zone A detection device or group of devices connected to your security system. Copyright 2004 Bosch Security Systems Page 54 P/N: 4998152530B DS7200V2-UK User's Guide... - Page 55 Outputs Change Another User’s PIN ..........17 Change Outputs..............27 Change Another User's PIN ..........38 Delete a User PIN............19, 41 Renew One-Time User PINs ..........42 Copyright 2004 Bosch Security Systems DS7200V2-UK User's Guide P/N: 4998152530B Page 55...
- Page 56 Set Partial On (Part Set) Zones........13, 34 Unbypass..............15, 36 View Faulted Zones..........15, 22, 44 Bosch Security Systems Ltd 7/04 Copyright 2004 Bosch Security Systems DS7200V2-UK User's Guide Copyright 2004 Bosch Security Systems P/N: 4998152530B Page 56 of 56 Page 56...
