Paser PARKVIEW CF00062OFR31-ORA31 Installation Manual

Release date: 24.07.18
PARKVIEW is an electronic module, easy to install, that allows you to integrate professionally a ermarket parking sensors on vehicles compa bles
equipped with the OEM radio.
The device allows to display on the OEM radio display the signalling of the parking sensors as it happens for the OEM parking sensors.
The kit is composed by two special PARKVIEW module and the harnesses for the connec on. The installa on is simple.
Once installed the parking sensors kit, connect PARKVIEW modules as described in the following diagram.
BEFORE STARTING INSTALLATION, PLEASE ENABLE THE PARKING SENSOR FUNCTION OF THE CAR,
Fakra 40 ways
CAN L GND
CAN H 12 VDC
Wires exit view
The harness supplied with PARKVIEW is split in 2 sec ons: the first is composed by 4 wires to connect back the OEM radio of the vehicle.
In the QUADLOCK plug it must to connect:
YELLOW to the +12vdc posi ve wire
BLACK to the GND nega ve wire
GREEN to the CAN H
WHITE to the CAN L
PINK to the power of the parking sensor
The diagram above suggests the ho to manage the connec ons, the QUADLOCK plug is seen from the wire output side.
The second sec on of the harness is a kind of extension long 5 mts that must to lay down ll the boot, where is located the parking sensors device.
Then connect the 4 poles white MOLEX plug to the DISPLAY connector of the parking sensors as above described.
In the kit there are 2 module one for the rear one for the front, the connec on are both for Parkview modules;
For the both modules the buzzer used is the one in the cable so do not use the one of the kit.
Once the connec ons have been made, the system will be working immediately, the PARKVIEW LED will be GREEN when the car canbus is switched on, indi-
ca ng that the module is working correctly.
When reverse gear is engaged, the parking sensor control unit will be ac vated, automa cally PARKVIEW will ac vate the display on the original radio. On
some radio models, the MUTE radio is also managed on the display. When reverse gear is removed, the display will be interrupted.
RCD 310
Switching on the parking sensors, Parkview led will generate some red/green flashes, confirming the right working.
PARKVIEW CF00062OFR31-ORA31
Module to visualize the A ermarket Parking Sensors
FRONT REAR MED Parking E, Parking E Plus, Top Parking 18, Top Parking B,
Top Parking 3 e PASER ARLTOPPARK
INSTALLATION MANUAL
THROUGH THE VOLKWAGEN DIAGNOSIS TOLL ODIS
Fakra 52 ways
CAN L GND
CAN H 12 VDC
R 1 3 5
2 4
DESCRIPTION
VOLKSWAGEN
CONNECTIONS
R 1 3 5
2 4
1 / 4
BUZZER
REAR
BUZZER
FRONT
PINK wire power the PDC module
rev 1.0 18
45'
