Release date: 24.07.18
PARKVIEW is an electronic module, easy to install, that allows you to integrate professionally a ermarket parking sensors on vehicles compa bles
equipped with the OEM radio.
The device allows to display on the OEM radio display the signalling of the parking sensors as it happens for the OEM parking sensors.
The kit is composed by two special PARKVIEW module and the harnesses for the connec on. The installa on is simple.
Once installed the parking sensors kit, connect PARKVIEW modules as described in the following diagram.
BEFORE STARTING INSTALLATION, PLEASE ENABLE THE PARKING SENSOR FUNCTION OF THE CAR,
A er making the connec ons, connect the
Parking Sensor KIT BUZZER and the PARK-
VIEW wiring connector B and calibrate the
Cobra system as usual.
B
BUZ
4
3
2
1
Once the calibra on has been performed,
disconnect the BUZZER and connect con-
nector A: the system is now ready to
operate.
A
BUZ
4
3
2
1
PARKVIEW CF00062OFR51-ORA51
Module to visualize the A ermarket Parking Sensors
FRONT REAR COBRA PS0158
INSTALLATION MANUAL
DESCRIPTION
VOLKSWAGEN
THROUGH THE VOLKWAGEN DIAGNOSIS TOLL ODIS
CONNECTIONS
Fakra 40 ways
CAN L
GND
CAN H
12 VDC
Wires exit view
BUZZER
BUZZER
A
Fakra 52 ways
CAN L
GND
CAN H
12 VDC
REAR
FRONT
1 / 5
rev 1.0 18
45'
A er making the connec ons, connect the
Parking Sensor KIT BUZZER and the PARK-
VIEW wiring connector B and calibrate the
Cobra system as usual.
B
BUZ
4
3
2
1
Once the calibra on has been performed,
disconnect the BUZZER and connect con-
nector A: the system is now ready to
operate.
A
BUZ
4
3
2
1
Advertisement
Table of Contents
Related Manuals for Paser PARKVIEW CF00062OFR51-ORA51
Summary of Contents for Paser PARKVIEW CF00062OFR51-ORA51
- Page 1 Release date: 24.07.18 rev 1.0 18 PARKVIEW CF00062OFR51-ORA51 Module to visualize the A ermarket Parking Sensors 45’ FRONT REAR COBRA PS0158 INSTALLATION MANUAL DESCRIPTION PARKVIEW is an electronic module, easy to install, that allows you to integrate professionally a ermarket parking sensors on vehicles compa bles equipped with the OEM radio.
- Page 2 Release date: 24.07.18 rev 1.0 18 PARKVIEW CF00062OFR51-ORA51 Module to visualize the A ermarket Parking Sensors 45’ FRONT REAR COBRA PS0158 INSTALLATION MANUAL The harness supplied with PARKVIEW is split in 2 sec ons: the first is composed by 4 wires to connect back the OEM radio of the vehicle.
- Page 3 Release date: 24.07.18 rev 1.0 18 PARKVIEW CF00062OFR51-ORA51 Module to visualize the A ermarket Parking Sensors 45’ FRONT REAR COBRA PS0158 INSTALLATION MANUAL AUDI A1 CONNECTION Connect: YELLOW to the +12vdc posi ve RED big size wire located down the dashboard...
- Page 4 Release date: 24.07.18 rev 1.0 18 PARKVIEW CF00062OFR51-ORA51 Module to visualize the A ermarket Parking Sensors 45’ FRONT REAR COBRA PS0158 INSTALLATION MANUAL PDC MANUAL ACTIVATION / DEACTIVATION If the car is equipped of steering wheel commands, by pressing for 3 seconds OK buFon, PDC is switched ON or OFF based on the last status.
- Page 5 The informa on in this guide are purely for informa on purposes, therefore, are subject to change without no ce. At the me of publica on the informa on is correct and reliable. However Paser can not be held responsible for any consequences resul ng from errors or omissions in this manual. Paser reserves the right to improve / change the product or manual without obliga on to no fy users.
