- Page 1 Your HTC 7 Trophy User guide...
-
Page 2: Conventions Used In This Guide
This is a safety precaution. Read these carefully to avoid any potential problems when using your phone. Want more info? For other helpful resources, go to www.htc.com/support. Please also read the Safety and regulatory guide that’s included in the box. For additional information about your phone, go to windowsphone.com. - Page 3 Basics Inside the box You’ll find the following inside the box: Phone Battery USB cable 3.5mm stereo headset Power adapter Micro SD card (installed) Quick Start Guide Product Safety & Warranty Statement...
-
Page 4: Your Phone
1 Basics Your phone Front panel Earpiece 2 Touch screen 3 BACK 4 Microphone 5 SEARCH 6 START 7 Notification LED Top panel POWER 2 3.5mm audio jack... -
Page 5: Left And Right Panels
Basics 13 Left and right panels VOLUME UP/DOWN 2 USB connector 3 CAMERA... -
Page 6: Back Panel
14 Basics Back panel 5 megapixel camera 2 LED flashlight 3 Back cover 4 Speaker... -
Page 7: Removing The Back Cover
Basics 15 Back cover Removing the back cover Remove the back cover to access the battery compartment and SIM card slot. With the phone turned off, hold your phone securely with the front facing down. With your thumb or finger, lift up the back cover from the small notch at the top of the phone. -
Page 8: Inserting The Battery
16 Basics Battery Your phone uses a rechargeable battery. Please use only original batteries and accessories that came with your phone or replacements that we recommend. How long the battery can last before it needs recharging depends on how you use your phone. Among these are the phone features and accessories you use (for example, leaving your Bluetooth connection always on uses more power). -
Page 9: Removing The Battery
Basics 17 Removing the battery Take the back cover off. See “Removing the back cover”. Lift the battery from the groove at the upper left side of the battery compartment to remove the battery. Charging the battery The battery is partially charged when shipped. Before you turn on and start using your phone, it is recommended that you charge the battery. - Page 10 18 Basics Connect the bigger end of the USB cable to the power adapter. Connect the smaller end of the USB cable to the phone. Plug in the power adapter to an electrical outlet to start charging the battery. Your phone may turn on when the battery is being charged. As the battery is being charged, the notification LED shows a solid red light when the battery is being charged.
-
Page 11: Switching Your Phone On Or Off
Basics 19 Switching your phone on or off Switching your phone on Press the POWER button. Easy. When you turn on the phone for the first time, you’ll need to set it up. Go to “Setting up your phone for the first time” and we’ll take you through it. Switching your phone off If the display is off, press the POWER button to turn it back on. -
Page 12: Finger Gestures
0 Basics Finger gestures When you want to type using the keyboard, select items onscreen such as apps and settings, or press onscreen buttons, simply tap them with your finger. Press and To open the available options for an item (e.g. contact or link hold in a web page), simply press and hold the item. - Page 13 Safety and regulatory guide...
-
Page 14: Please Read Before Proceeding
Without limiting the foregoing, it is further understood that HTC and its Affiliates are not responsible for any use or of the Accessed Information or the results arising from such use, and that you use such information at your own risk. - Page 15 Replace only with specified batteries. Recycle or dispose of used batteries according to the local regulations or reference guide supplied with your product. NOTE: This product should be operated only with the following designated Battery Pack(s). • HTC, Model BB96100 or BTR6300B Take extra precautions •...
- Page 16 Safety and regulatory guide • The phone should only be connected to products that bear the USB-IF logo or have completed the USB-IF compliance program. • Do not use a battery that appears damaged, deformed, or discolored, or the one that has any rust on its casing, overheats, or emits a foul odor.
- Page 17 Safety and regulatory guide Explosive atmospheres When in any area with a potentially explosive atmosphere or where flammable materials exist, the product should be turned off and the user should obey all signs and instructions. Sparks in such areas could cause an explosion or fire resulting in bodily injury or even death.
- Page 18 Safety and regulatory guide Use only the supplied integral antenna. Use of unauthorized or modified antennas may impair call quality and damage the phone, causing loss of performance and SAR levels exceeding the recommended limits as well as result in non-compliance with local regulatory requirements in your country. To assure optimal phone performance and ensure human exposure to RF energy is within the guidelines set forth in the relevant standards, always use your...
- Page 19 Safety and regulatory guide Device getting warm after prolonged use When using your device for prolonged periods of time, such as when you’re talking on the phone, charging the battery or browsing the Web, the device may become warm. In most cases, this condition is normal and therefore should not be interpreted as a problem with the device.
- Page 20 Safety and regulatory guide Avoid pushing objects into product Never push objects of any kind into cabinet slots or other openings in the product. Slots and openings are provided for ventilation. These openings must not be blocked or covered. ...
-
Page 21: Regulatory Agency Identifications
Safety and regulatory guide Regulatory agency identifications For regulatory identification purposes, your product is assigned a model number of PC40200. To ensure continued reliable and safe operation of your device, use only the accessories listed below with your PC40200. The Battery Pack has been assigned a model number of BB96100 or BTR6300B. Operating temperature range: 3°F to 104°F (0°C to 40°C) NOTE: This product is intended for use with a certified Class Limited Power Source, rated 5 Volts DC,... - Page 22 Safety and regulatory guide Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
- Page 23 Safety and regulatory guide M-Ratings: Phones rated M3 or M4 meet FCC requirements and are likely to generate less interference to hearing devices than phones that are not rated. M4 is the better/higher of the two ratings. PC4000 is rated M4. T-Ratings: Phones rated T3 or T4 meet FCC requirements and are likely to be more usable with a hearing aid’s telecoil than phones that are not rated.
- Page 24 FCC RF exposure guidelines when used with the HTC Corporation. Accessories supplied or designated for this product. Use of other accessories may not ensure compliance with the FCC RF exposure guidelines.
- Page 25 Safety and regulatory guide FCC RF Radiation Exposure Statement This Transmitter has been demonstrated co-location compliance requirements with Bluetooth and WLAN. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. Telecommunications &...
- Page 26 Safety and regulatory guide RoHS compliance This product is in compliance with Directive 00/95/EC of the European Parliament and of the Council of 7 January 003, on the restriction of the use of certain hazardous substances in electrical and electronic equipment (RoHS) and its amendments.
- Page 27 Safety and regulatory guide...
- Page 28 91H0xxxx-xxM Rev.A htc.com...
