- Page 1 LIFESOURCE PLATINUM RO OWNER INSTALLATION MANUAL Reverse Osmosis Undersink Water Filtration System with pH Balancer...
- Page 2 Platinum Seal Listing The LifeSource RO system is certified by IAPMO R&T according to NSF/ANSI 58 for the reduction of contaminants as noted on the Performance Data Sheet on page 20 for specific substances and reduction performances. The LifeSource RO with pH System is made with quality components that ensure pure, safer drinking water.
-
Page 3: Table Of Contents
TABLE OF CONTENTS Getting Started ..........................1 Before You Install .......................... 1 Parts List ............................1 Introduction ............................2 Installation ............................3 Location of RO Unit ............................3 Mounting the RO Filter Unit Under a Sink ..................3 Connecting the Feed Water Supply .......................5 Installation of non UPC Drain Connection ..................6 Installation of the Clean Water Faucet ....................7 Porcelain/Enamel Over Steel or Cast Iron Sinks ................7... - Page 4 TABLE OF CONTENTS Appendix: Theory of Operation ..................... 22 Pre Filters ................................. 22 The Reverse Osmosis Membrane ......................23 Auto Control................................24...
-
Page 5: Getting Started
GETTING STARTED Thank you for purchasing the LifeSource Platinum RO with pH Balancer Undersink Water Filtration System. The Platinum RO enhances the taste and quality of your water. This environmentally friendly water treatment system saves you money by reducing water waste. -
Page 6: Introduction
INTRODUCTION The LifeSource RO with pH Balancer is a 5-stage water cleansing system. Stage One is a sediment filter that removes particles 5-microns in size or larger including rust, sand and other debris in the water line. Stage Two and Three are granular activated carbon (GAC) filters that remove odors, chlorine and bad tastes. -
Page 7: Installation
INSTALLATION Before the installation, measure the water pressure under the sink. A pressure of 60-75 PSI is normal. If pressure is too low (less than 40 PSI): — Use a model with a booster pump. If pressure is too high (90 PSI): —... - Page 8 INSTALLATION Figure 1 Clean Water Faucet Discarded pH Balancer Membrane Clean Water Out Drinking Water Storage Tank Drain Feed Water Figure 2 Auto-Valve Feed Water Line (Orange Tubing from Pre Filters) Drain Water Line (Black Tubing to Drain) Pure Water Line (White Tubing) To PH Balancer...
-
Page 9: Connecting The Feed Water Supply
INSTALLATION Connecting the feed water supply (Figure 3) The feed water assembly consists of 1/2" brass slip joint adapter, a black washer, and a ¼" x ¼" ball valve. Locate these parts in the installation kit. 1. Turn off cold water shut off valve under the sink. 2. -
Page 10: Installation Of Non Upc Drain Connection
INSTALLATION Installation of Non-UPC Drain Connection (Figure 4) 1. Place the drain outlet saddle on the drain pipe. 2. Allow proper space for the drilling operation. 3. Tighten saddle bolts evenly on both sides. 4. Using the opening in the drain outlet saddle as a guide, drill a 1/4" hole in the drain pipe. -
Page 11: Installation Of The Clean Water Faucet
INSTALLATION Installation of the Clean Water Faucet Position the faucet for optimal aesthetics, function, and convenience. Allow for an ample flat area for the faucet base to be drawn down tightly. Ensure that the space under the sink where the faucet will be mounted is clear of obstructions. If you have any of the following, you don't need to drill a hole in the sink. - Page 12 INSTALLATION Figure 5 Step 1. Pilot Drill Step 2. Spring Loaded Porcelain Saw (Relton Cutter) Step 3. Finish Hole Saw...
-
Page 13: Install Faucet
INSTALLATION Install Faucet (Figure 6) Disassemble all the hardware from the threaded stud except for the top base plate and sealing gasket. Install the faucet into the sink hole. Assemble the mounting hardware from underneath the sink and tighten the nut using a deep socket. Figure 6... -
Page 14: Tubing Connections
INSTALLATION Tubing Connections The LifeSource Platinum RO has standard tubing connections that use a Quick Connect O-ring seal design. To make the connections, follow the instructions in Figure 8 and use the provided tubing. If you need to cut the tubing, cut an even square for proper sealing. - Page 15 INSTALLATION 3. Push Up to Tube Stop Push the tube into the fitting, to the tube stop. The collet (gripper) has stainless steel teeth which hold the tube firmly in position while the O-ring provides a permanent leak proof seal. 4.
-
Page 16: Drain Line
INSTALLATION Feed Water Line 1. Connect orange 1/4" inlet tubing to ball valve, or saddle valve installed in Step 2.3 above. 2. To reduce water hammer effect on this fitting, make a large loop in tubing before the connection on sediment filter. 3. -
Page 17: Air Gap Faucet Installation
INSTALLATION Air Gap Faucet Installation (Figure 8) Municipal codes sometimes require air gap faucets. These faucets allow wastewater from the membrane to flow by gravity to the drain saddle, preventing potential clogging issues. A drain saddle with 3/8" (instead of ¼") tubing is used, along with an extra section of 3/8"... - Page 18 INSTALLATION Figure 8...
-
Page 19: System Start Up
SYSTEM START-UP Air Purge Filters for stages I, 2, 3, and 5 are shipped dry and contain air in the pores. The air may collect in the system and should be purged for optimal efficiency. Refer to Section 3.2 for air purge and start-up procedure. Start-Up 1. -
Page 20: Recommended Filter Changes
Pre-Carbon GAC Element, Stage 2 TF-4115 12 Months Pre-Carbon Filter Element, Stage 3 MHA-4222 12 Months RO Membrane Assembly, Stage 4 TF-4115 12 Months Post Carbon Filter Element, Stage 5 TF-4114 12 Months These filter replacement kits are available through LifeSource Water Systems. -
Page 21: Filter Replacement Procedure
FILTER REPLACEMENT PROCEDURE The LifeSource Platinum RO uses Quick Connect O-ring seals. To make the connections, use the tubing and follow the instructions in Figure 8. 1. Ensure tubing is cut squarely to fit and seal correctly. 2. Before proceeding, turn off the feed water at feed water ball valve and turn storage tank ball valve to ‘off’... -
Page 22: Installation Troubleshooting
— Check valve not — Clean or replace check functioning properly. valve. — RO production good — High TDS and/or Iron — Consult LifeSource at first but falls off in and Manganese. Water Systems for a months or weeks. water analysis. -
Page 23: One-Year Limited Warranty
LifeSource within 5 days of buyer's discovery of such defect. If such goods are proven to be materially defective to LifeSource’s, and only LifeSource’s reasonable satisfaction, then such defective goods shall be repaired or replaced at LifeSource's sole option. -
Page 24: Performance Data Sheet
Reverse osmosis (RO) water treatment systems are effective at removing pentavalent arsenic, but not trivalent arsenic. The LifeSource RO with pH System is designed to remove pentavalent arsenic, but the RO component must be replaced... - Page 25 PERFORMANCE DATA SHEET Platinum Seal This system has been tested and certified by the IAPMO according to NSF/ANSI 58 for reduction of the substances listed below. The concentration of the indicated substances in water entering the system was reduced to a concentration less than or equal to the permissible limit for water leaving the system, as specified by NSF/ANSI 58.
-
Page 26: Appendix: Theory Of Operation
APPENDIX: THEORY OF OPERATION Figure A1 Clean Water Faucet Discarded pH Balancer Membrane Clean Water Out Drinking Water Storage Tank Drain Feed Water Pre Filters: The prefilters serve two purposes: to clean the water for consumption and prevent RO membrane fouling. The first stage filter removes sediment particles such as sand, rust, pipe scale, and dirt. -
Page 27: The Reverse Osmosis Membrane
APPENDIX: THEORY OF OPERATION The Reverse Osmosis Membrane: The membrane is the system's core and protector. Similar to the human stomach lining, the membrane allows water molecules to pass through while retaining dissolved molecules. How RO Works Reverse osmosis (RO) pushes water molecules through the membrane, rejecting approximately 93% of total dissolved solids. -
Page 28: Auto Control
APPENDIX: THEORY OF OPERATION Auto Control: As water is produced, pressure in the storage tank increases. The auto control valve stops water production when the storage tank is full, maintaining pressure at around 40 PSI (see Figure A-1). Average U.S. city pressure is 60 PSI. The purified water is stored in the tank, which has a 4.0-gallon volume and a bladder with air at 6 PSI. - Page 29 All work performed by licensed contractors. | CA Lic# 787179 – NV Lic# 059578 – AZ ROC 327043...
