• If the Product is exposed to over pressure or sudden physical shock (such as a drop), examine the Product for damage that can cause a safety concern. If necessary, return the Product to KPFM for evaluation. • Always apply thread seal tape or liquid seal tape to the threads of the transducers and other fittings as required.
Page 3
Battery • The battery door must be closed and secured before you using the Product. • Replace the batteries when the low battery indicator shows to prevent unwanted shutdowns. • To avoid leakage, remove the batteries if the unit is to be stored for extended periods of time or if stored in high temperature areas (over 50°C).
Component list 1. Receiver/Display Unit 2. Transmitter Units 3. Pressure Transducers 4. Extension Cables 1. Receiver/Display Unit • The Receiver/Display unit receives pressures from the transmitter and displays them on a colour LCD screen. • This unit also tracks the minimum, maximum, or will calculate the differential between the sets of readings (see button function section).
Page 5
2. Transmitters Unit • Each transmitter will read the pressures from 2 transducer at the same time and send the values to the receiver. • Readings are taken every half second, converted to psi, and transmitted. • The connecting cables are RF shielded and use a standard 4 pin M12 connector. •...
Operation Display Display Button Functions: • Power: Turns the unit power on or off. Hold for 2 seconds to power off. • Unit: Changes the unit that the values are displayed in. The standard available units are psi, kg/cm2, kPa, Mpa and bar.
Page 7
X4 Kit Receiver Display: • Battery level indicator for the receiver unit • Battery level indicator for the transmitter unit • Signal strength indicator • Current readings • Mode indicator area • Current unit display Transmitter: Transmitter LEDs: • The Power button is LED back lit and comes on about 1 second after the button is pressed.
Set up and use • When connecting and disconnecting components always depressurize the system first. • Connect the transducers to the desired test points on the machine. • Connect the transmitters to the matching transducer colour. Use the extension cables if required to reach the desired test points. Connectors on the cables and transducers are an M12 type.
• The frequency for re-calibration varies with the application and the user’s requirements. • KPFM’s preference is to have the gauges re-calibrated every three years. • NIST traceable testing and setup can be done on request for an additional charge.
Page 10
Transducers • ±0.25% Accuracy • -40°C to +125°C Operating temperature • Temperature compensated -20°C to +85°C • 17 - 4PH Stainless steel diaphragm and housing Size • Receiver 210 x 100 x 32mm • Transmitter 147 x 89 x 24mm Weight •...
Page 11
Contact KPFM at Kevin@kpfm.ca or 1-250-462-0042...
