OttLite CSJ2500C Manual

J
K
E
A
Lighted Magnifier Clip Lamp
CSJ2500C CSJ2500C-SHPR CSJ25G5W-SHPR OTTCSJ2508C
INS250826
H
B
D
C
F
G
ENGLISH
CONGRATULATIONS!
You've purchased the finest in natural lighting technology with your
new OttLite product.
®
PRODUCT REGISTRATION FORM
Please complete the enclosed Product Registration Form and return
it today by mail, or register online by going to: OttLite.com/warranty.
WARNING: To prevent electric shock, make sure the lamp is not
plugged in until all assembly steps are complete.
NOTE: THIS UNIT IS FULLY ASSEMBLED
1. Remove lamp from packing for use on a horizontal table.
2. To use on standard table, mount lamp body clip (A) on the
preferred edge of the table.
3. Grasp by flex-neck (B) and back of body clip, squeeze clip
mechanism and slide onto table edge. Clip must fully touch edge
of the table.
4. Verify the lamp is secure before using.
5. Connect power adapter input (F) into lamp cord connection (G)
located at the rear of clip (A).
6. Plug the power adapter (D) into a standard household 120V AC
outlet. Note: Only use with the supplied AC adapter to avoid
damage or fire.
7. Turn the lamp ON & OFF using power switch (C) located on the
top of clip (A). Power switch (C) is a "touch" switch that controls
ON/OFF power and the LED brightness settings of the lamp.
8. To power LED settings, slightly touch the switch to achieve the
following:
• turn lamp "ON" to lower-brightness; touch the switch "once";
• for medium-brightness; touch the switch "twice";
• for high-brightness; touch the switch "three-times";
• to turn lamp "OFF"; touch the switch "four-times".
9. To position the shade simply bend the flex-neck (B) as needed
to point the light. To avoid damaging the lamp, DO NOT force the
flex-neck into a sharp bend.
10. To use magnifier (J), open protective lid (H). When magnifier (J) is
not in use, close protective lid (H) for safe coverage.
CAUTION:
INDOOR USE ONLY. NEVER LEAVE THE MAGNIFIER LENS
UNATTENDED IN DIRECT SUNLIGHT OR WHERE LIGHT CAN SHINE THROUGH
IT AS THIS CAN POSE A RISK OF FIRE.
SAFETY WARNING:
TO REDUCE THE RISK OF FIRE, ELECTRIC
SHOCK, OR INJURY TO PERSONS
1. Turn off and WAIT UNTIL LAMP HEAD (K) and ADAPTER (D) ARE
COOL before handling.
2. The circular LED panel (E) might get hot after several hours of
continuous use, DO NOT place your hands directly on LED light panel.
3. Never use with an extension cord unless the plug can be fully
inserted into the receptacles in the extension cord.
4. Do not alter the plug.
PL-0375
Lighted Magnifier Clip Lamp
5. The lamp head included with this unit cannot be replaced by the
consumer.
6. INDOOR USE ONLY.
NOTE: The important safety instructions appearing in this instruction
sheet are not meant to cover all possible conditions and situations
that may occur. It must be understood that common sense, caution,
and care must be used with any electrical product.
CAUTION!
IF THE EXTERNAL FLEXIBLE CABLE OR CORD OF THIS
LUMINAIRE IS DAMAGED, IT SHALL BE EXCLUSIVELY REPLACED BY THE
MANUFACTURER OR ITS SERVICE AGENT OR A SIMILAR QUALIFIED PERSON IN
ORDER TO AVOID A HAZARD.
CAUTION!
THE LIGHT SOURCE OF THIS LUMINAIRE IS NOT REPLACEABLE;
WHEN THE LIGHT SOURCE REACHES ITS END OF LIFE THE WHOLE LUMINAIRE SHALL
BE REPLACED.
FCC PART 15
Note: This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the FCC rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that the interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on,
the user is encouraged to try to correct the interference by one or more
of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Changes or modifications not expressly approved by the party responsible
for compliance could void the user's authority to operate the equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject
to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including
interference that may cause undesired operation.
CAUTION: Any change or modification to product not expressly recognized
by OttLite voids OttLite's responsibility for proper function of product
CAN ICES-005 (B)/ NMB-005 (B)
AC/DC ADAPTER
Input: AC 100-240V, 50-60Hz, 0.2A
Output: 13V DC 0.4A with Male DC plug
REV040225
