Suzuki SX4 2021 Series Owner's Manual

Table Of Contents

Table of Contents

Advertisement

Quick Links

Download this manual

This owner's manual applies to the SX4 series.

83RM018

NOTE: The illustrated model is one of the SX4 series.

Copyright ©

2021 All Rights Reserved

No part of this document may be reproduced or transmitted in any form or by any means, electronic or

mechanical, for any purpose, without the express written permission of Magyar Suzuki Corporation Ltd.

Table of Contents

Advertisement

Table of Contents

Need help?

Need help?

Do you have a question about the SX4 2021 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Suzuki SX4 2021 Series

Page 1 NOTE: The illustrated model is one of the SX4 series. Copyright © 2021 All Rights Reserved No part of this document may be reproduced or transmitted in any form or by any means, electronic or mechanical, for any purpose, without the express written permission of Magyar Suzuki Corporation Ltd.
Page 2 Please read this manual carefully cial information, the symbol and the tion in this manual and your vehicle. before operating your new SUZUKI vehicle words WARNING, CAUTION, NOTICE MAGYAR SUZUKI CORPORATION and review the manual from time to time. It and NOTE have special meanings.
Page 3: Modification Warning
CB (Citizen’s Band) radios may cause electronic interfer- ence with your vehicle’s ignition sys- tem or any other electrical systems, resulting vehicle performance problems. Consult your SUZUKI dealer or qualified service technician for advice on installing such mobile communication equipment.
Page 4 INTRODUCTION Thank you for choosing SUZUKI product and welcome to our growing family. Your choice was a wise one; SUZUKI products have great value that will give you driving pleasure for years. This owner’s manual was prepared to give you a safe, enjoyable, and trouble-free experience with your SUZUKI vehicle. In this manual, you will learn about the vehicle’s operation, its safety features and maintenance requirements.
Page 5 A wide variety of non-genuine replacement parts and accessories for SUZUKI vehicles are currently available in the market. Using these parts and accessories can affect the vehicle performance and shorten its useful life. Therefore, installation of non-genuine SUZUKI parts and accessories is not covered under warranty.
Page 6: Vehicle Data Recordings
Vehicle Data Recordings There are certain components of your vehicle (the “Vehicle”) incorporating data storage modules or memories, which temporarily or per- manently store the technical data below listed. These data are exclusively technical and serve for (i) identifying and correcting faults occurred in the Vehicle and/or (ii) optimizing functions of the Vehicle.
Page 7 Conditions under which SUZUKI and the Parties can disclose or provide any of the Recorded Data to a third party SUZUKI and the Parties may disclose or provide any of the Recorded Data to a third party under any of the following conditions: •...
Page 8: Service Station Guide
SERVICE STATION GUIDE 1. Fuel (see section 1) 2. Engine hood (see section 5) 3. Tire changing tools (see section 8) 4. Engine oil dipstick <Yellow> (K14D engine) (see section 7) 5. Engine coolant (see section 7) (RHD) 6. Windshield washer fluid (see section 7) 7.
Page 9 MEMO...
Page 10: Table Of Contents
TABLE OF CONTENTS FUEL RECOMMENDATION BEFORE DRIVING OPERATING YOUR VEHICLE DRIVING TIPS OTHER CONTROLS AND EQUIPMENT VEHICLE LOADING AND TOWING INSPECTION AND MAINTENANCE EMERGENCY SERVICE APPEARANCE CARE GENERAL INFORMATION SPECIFICATIONS SUPPLEMENT INDEX...
Page 11: Illustrated Table Of Contents
ILLUSTRATED TABLE OF CONTENTS EXTERIOR, FRONT EXAMPLE 1. Engine Hood (P.5-2) 2. Windshield Wipers (P.2-109) 3. Sunroof (if equipped) (P.5-9) 4. Roof Rails (if equipped) (P.5-20) 5. Frame Hook (P.5-21) 6. Radar Sensor (if equipped) (P.3-99) 7. Parking Sensors (if equipped) (P.3-63) 8.
Page 12: Exterior, Rear
ILLUSTRATED TABLE OF CONTENTS EXTERIOR, REAR EXAMPLE 1. Radio Antenna (P.5-41) 2. High-mount Stop Light (P.7-52) 3. Rear Window Wiper (P.2-112) 4. Fuel Filler Cap (P.5-1) 5. Rear Combination Lights (P.7-49) 6. Reversing Lights (P.7-50) 7. Rearview Camera (if equipped) (P.3-70) 8.
Page 13 ILLUSTRATED TABLE OF CONTENTS INTERIOR, FRONT EXAMPLE 1. Electric Window Controls (P.2-17)/ Electric Mirror Control Switch (P.2-21)/ Outside Rearview Mirror Folding Switch (if equipped) (P.2-22) 2. Front Passenger’s Front Airbag (P.2-54) 3. Glove Box (P.5-12)/ Airbag Deactivation Switch (P.2-64) 4. Front Seats (P.2-22)/ Side Airbags (P.2-58) 5.
Page 14 ILLUSTRATED TABLE OF CONTENTS 1. Sun Visors (P.5-4) VIEW A EXAMPLE 2. Front Interior Light (P.5-5, 7-53) 3. Hands-free Microphone (if equipped) (P.5-68) 4. Inside Rearview Mirror (P.2-20) 5. Overhead Console (if equipped) (P.5-12) 6. Sunroof Switch (if equipped) (P.5-9) 7.
Page 15 ILLUSTRATED TABLE OF CONTENTS 1. Lighting Control Lever (P.2-101)/ VIEW B EXAMPLE Turn Signal Control Lever (P.2-107) 2. Remote Audio Controls (if equipped) (P.5-79) 3. Driver’s Front Airbag (P.2-54) 4. Engine Hood Release Handle (P.5-2) 5. Headlight Leveling Switch (if equipped) (P.2-106)/ Front Fog Light Switch (if equipped) (P.2-106)/ ®...
Page 16 ILLUSTRATED TABLE OF CONTENTS 1. Adaptive Cruise Control Switches VIEW C EXAMPLE (if equipped) (P.3-104)/ Cruise Control Switches (if equipped) (P.3-58)/ Speed Limiter Switches (if equipped) (P.3-61) 2. Instrument Cluster (P.2-66)/ Information Display (P.2-69) 3. Windshield Wiper and Washer Lever (P.2-109)/ Rear Window Wiper and Washer Switch (P.2-112) 4.
Page 17 ILLUSTRATED TABLE OF CONTENTS INTERIOR, REAR EXAMPLE 1. Seat Belts (P.2-30) 2. Center Interior Light (P.5-5, 7-53) 3. Assist Grips (P.5-11) 4. Lap-shoulder Belt with Detachable Connector (P.2-34) 5. Side Curtain Airbags (P.2-58) 6. Rear Seats (P.2-26) 7. Rear Armrest with Cup Holders (if equipped) (P.5-16) 61MM0A041...
Page 18: Luggage Compartment
ILLUSTRATED TABLE OF CONTENTS LUGGAGE EXAMPLE COMPARTMENT 3 4 5 1. Shopping Hook (P.5-18) 2. Luggage Compartment Cover (if equipped) (P.5-19) 3. Accessory Socket (if equipped) (P.5-8) 4. Luggage Compartment Light (if equipped) (P.5-7, 7-53) 5. Cargo Net Hooks (if equipped) (P.5-19) 6.
Page 19 ILLUSTRATED TABLE OF CONTENTS MEMO...
Page 20: Fuel Recommendation
FUEL RECOMMENDATION FUEL RECOMMENDATION Fuel Recommendation ............1-1 65D394...
Page 21 FUEL RECOMMENDATION Gasoline-ethanol blends Fuel Recommendation Blends of unleaded gasoline and ethanol NOTICE (grain alcohol), also known as gasohol, are The fuel tank has an air space to commercially available in certain areas. allow for fuel expansion in hot Blends of this type may be used in your weather.
Page 22: Before Driving
BEFORE DRIVING BEFORE DRIVING Front Seats ................2-22 Rear Seats ................2-26 Seat Belts and Child Restraint Systems ......2-30 Child Restraint System for Countries Applied for UN Regulation No.16 ............ 2-42 Supplemental Restraint System (airbags) ......2-52 Instrument Cluster .............. 2-66 Speedometer ...............
Page 23: Keys
“ON”. If you need to make NOTICE spare keys or remote controllers, see your SUZUKI dealer. The vehicle must be pro- Do not modify or remove the immobi- grammed with the correct identification 54G489 lizer system.
Page 24: Door Locks
Ask the ignition switch or the engine switch your SUZUKI dealer to have the system when using your SUZUKI vehicle, or the inspected. engine may not be started because they...
Page 25 BEFORE DRIVING To unlock a front door from the outside of NOTE: Central Door Locking System the vehicle, insert the key and turn the top You can switch the function that unlocks all of the key toward the front of the vehicle. doors from twice operations to once opera- tion, and vice versa, via the setting mode of the information display.
Page 26 BEFORE DRIVING NOTE: NOTE: • You can also lock or unlock all doors by • You can also activate the dead lock sys- operating the transmitter or remote con- tem by operating the transmitter or troller. Refer to “Keyless Push Start Sys- remote controller.
Page 27 BEFORE DRIVING Child-proof Locks (rear door) Tailgate 2 times EXAMPLE EXAMPLE Front Rear 83E107 To release this system: To unlock all doors (including the tailgate), 61MM0A046 61MM0A047 insert the key in the driver’s door lock and (1) LOCK (1) Tailgate unlatch switch turn the top of the key toward the front of (2) UNLOCK the vehicle twice.
Page 28: Keyless Push Start System Remote Controller/Keyless Entry System Transmitter
(Type A) or a keyless entry system trans- ing the unlatch switch (1), have the vehicle mitter (Type B). The remote controller has inspected by your SUZUKI dealer. a keyless entry system and a keyless push start system. The transmitter has only a CAUTION keyless entry system.
Page 29 “Information Display” in this section. antenna(s) disabled your SUZUKI dealer. The turn signal lights will flash once and the exterior buzzer will sound once when the doors are locked. Central door locking system with the...
Page 30 • If you lose one of the remote controllers, doors are unlocked: ask your SUZUKI dealer as soon as pos- With the remote controller inside the vehi- • To lock all doors, push one of the sible for a replacement. Be sure to have cle, if you push the “LOCK”...
Page 31 BEFORE DRIVING The turn signal lights will flash once and during this time, the light will start to fade When the remote controller is within the exterior buzzer will sound once when out immediately. approximately 80 cm (2 1/2 feet) from a the doors are locked, and then the turn sig- front door handle or the tailgate switch, you Be sure the doors are locked after you...
Page 32 • If you lose one of the remote controllers, The remote controller is a sensitive ask your SUZUKI dealer as soon as pos- electronic instrument. To avoid dam- sible for a replacement. Be sure to have aging the remote controller: your dealer program the new remote •...
Page 33 BEFORE DRIVING Press the request switch again after doing The indicator light will turn off within sev- Replacement of the battery the following: eral seconds after the remote controller is If the remote controller becomes unreli- With the ignition mode changed to “LOCK” returned to an area of the vehicle other able, replace the battery.
Page 34 The recy- cling of materials will help to conserve natural resources. For more detailed infor- mation about disposing or recycling of the used battery, consult your SUZUKI dealer. 2-12...
Page 35 BEFORE DRIVING Central door locking system NOTE: Keyless Entry System Transmitter • To lock all doors, push the “LOCK” but- You can switch the function that unlocks all (Type B) ton (1) once. doors from twice operations to once opera- •...
Page 36 CR1616 or equivalent • If you lose one of the transmitters, ask your SUZUKI dealer as soon as possible 3) Put the edge of a flat-bladed screw- for a replacement. Be sure to have your driver in the slot of the transmitter (2) dealer program the new transmitter code and pry it open.
Page 37: Theft Deterrent Alarm System (If Equipped)
– The key natural resources. For more detailed infor- – The lock knob on a door mation about disposing or recycling of the – The power door locking switch used battery, consult your SUZUKI dealer. 2-15...
Page 38 BEFORE DRIVING How to arm the theft deterrent alarm NOTE: NOTICE system (when enabled) • To prevent the alarm from being acci- Lock all doors (including the tailgate) using dentally triggered, avoid arming it while Do not modify or remove the theft the keyless push start system remote con- anyone remains inside the vehicle.
Page 39: Windows
BEFORE DRIVING How to stop the alarm Checking whether the alarm has been Windows Should the alarm be triggered accidentally, triggered during parking unlock the doors using the keyless push If the alarm was triggered due to an unau- start system remote controller, the request thorized entry into the vehicle and you then switch or the keyless entry system trans- press the engine switch to change the igni-...
Page 40 BEFORE DRIVING Passenger’s side Lock switch EXAMPLE EXAMPLE CLOSE OPEN 81A009 61MM0A052 61MM0A053 To open a window, push the top part of the The passenger’s door has a switch (5) to The driver’s door also has a lock switch for switch and to close the window lift up the operate the passenger’s window.
Page 41 BEFORE DRIVING Pinching Prevention Function WARNING CAUTION The driver’s window is equipped with the • You should always lock the pas- • The pinching prevention function pinching prevention function. The function senger’s window operation when does not act while you are holding detects a foreign object caught in the win- there are children in the vehicle.
Page 42: Mirrors
To adjust the mirror, set function. Have your vehicle inspected by the selector tab (1) to the day position, an authorized SUZUKI dealer. then move the mirror up, down or sideways by hand to obtain the best view.
Page 43: Outside Rear View Mirrors
BEFORE DRIVING • The auto dimming rearview mirror is Auto Dimming Rearview Mirror Outside Rearview Mirrors automatically deactivated while the gear- (if equipped) shift lever is in the “R” position. Adjust the outside rearview mirrors so you can just see the side of your vehicle in the mirrors.
Page 44: Front Seats
BEFORE DRIVING 1) Move the selector switch to the left or Outside Rearview Mirror Folding Front Seats right to select the mirror you wish to Switch (if equipped) adjust. 2) Press the outer part of the switch that corresponds to the direction in which Seat Adjustment EXAMPLE you wish to move the mirror.
Page 45 BEFORE DRIVING WARNING Do not place any object under the front seat. If an object becomes caught under the front seat, the fol- lowing may occur. • The seat will not be latched. • The lithium-ion battery or the DCDC converter, located under the front seat in a model equipped with SHVS, will be damaged.
Page 46 BEFORE DRIVING Seat position adjustment lever (1) Pull the lever up and slide the seat. EXAMPLE Seatback angle adjustment lever (2) Pull the lever up and move the seatback. Seat height adjustment lever (3) (if equipped) Pull the lever up to raise the seat. Push the lever down to lower the seat.
Page 47: Head Restraints
BEFORE DRIVING NOTE: Head Restraints Front Seat Heater (if equipped) It may be necessary to recline the seat- back to provide enough overhead clear- ance to remove the head restraint. Front EXAMPLE 80J001 61MM0A093 Head restraints are designed to help (1) Left seat heater switch reduce the risk of neck injuries in the case (2) Right seat heater switch...
Page 48: Rear Seats
BEFORE DRIVING • To select the low heat range, push the Rear Seats “LO” side (3) of the switch. the low side WARNING indicator light will illuminate when the Improperly using the seat heater can heater is on. be hazardous. An occupant can suf- •...
Page 49 BEFORE DRIVING Seatback angle adjustment lever (1) (if equipped) EXAMPLE Pull the lever up and move the seatback. After adjustment, try to move the seatback LOCK forward and rearward to ensure that it is securely latched. CAUTION After securing the rear seatback, make sure that it is locked securely.
Page 50: Folding Rear Seats
BEFORE DRIVING Rear Head Restraints Folding Rear Seats EXAMPLE Head restraints are designed to help The rear seats of your vehicle can be reduce the risk of neck injuries in the case folded forward to provide additional cargo of an accident. space.
Page 51 BEFORE DRIVING NOTICE NOTICE EXAMPLE After folding the rear seatback for- • When returning the rear seatback LOCK ward, do not allow any foreign mate- to the normal position, do not allow rial to enter the lock opening. This any foreign material to enter the may cause damage to the inside of lock opening.
Page 52: Seat Belts And Child Restraint Systems
BEFORE DRIVING Seat Belts and Child Restraint WARNING Systems An airbag supplements, or adds to, frontal collision protection offered by seat belts. The driver and all passengers must be properly restrained by wearing seat belts at all Above the pelvis times, whether or not an airbag is mounted at their seating position, to minimize the risk of severe injury or...
Page 53 BEFORE DRIVING as low as possible across the hips Across the pelvis 65D201 65D199 65D609 WARNING WARNING WARNING (Continued) (Continued) (Continued) • Seat belts should never be worn • Pregnant women should use seat • Do not hold a child on a passen- with the straps twisted and should belts, although specific recommen- ger's lap.
Page 54: Lap-Shoulder Belt
BEFORE DRIVING Lap-shoulder Belt WARNING WARNING (Continued) (Continued) Emergency locking retractor (ELR) • Periodically inspect seat belt • For child, if the seat belt irritates The seat belt has an emergency locking assemblies for excessive wear and the neck or face, use a child retractor (ELR), which is designed to lock damage.
Page 55 BEFORE DRIVING NOTE: The word “CENTER” is marked on the buckle for the rear center belt. The buckles Low on hips are designed so a latch plate cannot be inserted into the wrong buckle. 60A040 60A036 To reduce the risk of sliding under the belt To fasten the seat belt, sit up straight and during a collision, position the lap portion far back into the seat, pull the latch plate...
Page 56 BEFORE DRIVING Lap-shoulder Belt with Detachable Connector CENTER EXAMPLE 61MM0A060 61MM0A094 Fastening Unfastening Before fastening the rear center lap-shoul- To unfasten the seat belt, push the button der belt, make sure the detachable con- on the buckle (3) and retract the belt slowly 61MM0A059 nector (1) is securely latched and the while attaching a hand to the belt or/and...
Page 57 BEFORE DRIVING Unlatching and latching detachable Latching connector To latch the connector: 1) Pull the belt out from the holder. EXAMPLE 61MM0A062 61MM0A063 WARNING 61MM0A064 Unlatching To minimize risk of severe injury or To unlatch the connector: 2) Insert the connector latch plate (2) into death in the event of a collision, 1) Insert a key or a latch plate into the slot the connector (3) so as to align the tri-...
Page 58: Seat Belt Reminder
BEFORE DRIVING Stowing rear center lap-shoulder belt Seat Belt Reminder Stow the belt after it is retracted com- pletely. EXAMPLE 61MM0A065 To stow the belt, insert the latch plate into the slit (1). Then insert the connector latch plate (2) into the roof holder slot (3). (2)(3)(4) 83RM02100 2-36...
Page 59 BEFORE DRIVING (1) Driver’s seat belt reminder light / front NOTE: Front passenger’s seat belt reminder passenger’s seat belt reminder light The driver’s seat belt reminder light / front The front passenger’s seat belt reminder (2) Rear passenger’s seat belt reminder passenger’s seat belt reminder light is for will activate only when there is a passen- light (rear left)*...
Page 60: Shoulder Anchor Height Adjuster
The pretensioners and the load limiter only functions once. In case they did not activate, consult EXAMPLE with Suzuki dealer. 64J198 Adjust the shoulder anchor height so that the shoulder belt rides on the center of the outboard shoulder. To move upward, slide the anchor up.
Page 61: Seat Belt Pretensioner System
This section of the owner’s manual precautions general information low across the pelvis, not across the waist. describes your SUZUKI’s SEAT BELT including servicing the pretensioner sys- Please refer to the “Seat Adjustment” sec- PRETENSIONER SYSTEM. Please tem, refer to the “Supplemental Restraint...
Page 62: Child Restraint Systems
Do not touch pretensioner system compo- tensioner system serviced by an autho- nents or wiring. The wires are wrapped rized SUZUKI dealer as soon as possible. with yellow tape or yellow tubing, and the If the “AIRBAG” light on the instrument couplers are yellow.
Page 63 WARNING EXAMPLE When purchasing a child restraint and (Continued) install it to your SUZUKI vehicle, refer to • Children could be endangered in a the information about suitability for child collision if their child restraint sys- restraints shown in “Child Restraint Sys-...
Page 64: Child Restraint System For Countries Applied For Un Regulation No.16
BEFORE DRIVING Child Restraint System for Countries Applied for UN Regulation No.16 CAUTION Adjust the height of the head restraint or remove it for fitting the child restraint, as necessary. However, if a booster cush- ion not equipped with the head restraint is fitted, the rear seat head restraint should not be removed. If the rear head restraint is removed for fitting the child restraint, you need to install it again after removing the child restraint.
Page 65 BEFORE DRIVING NOTE: For the installation suitability of child restraint systems of Taiwan models, refer to “For Taiwan” in the “SUPPLEMENT” section. In case the front passenger airbag is deactivated Seating position (or other site) Mass Group Intermediate Intermediate Front Passenger Rear Outboard Rear Center Outboard...
Page 66 BEFORE DRIVING Table of vehicle handbook information on ISOFIX child restraint systems installation suitability for various ISOFIX positions Vehicle ISOFIX positions Size Mass Group Fixture Front Rear Rear Intermediate Intermediate Others class Passenger Outboard Center Outboard Center sites ISO/L1 N.A. N.A.
Page 67 SUZUKI recommends Duo Plus child seat. This restraint system is SUZUKI Genuine Accessory which complies with the UN R44 or R129, refer to the genuine accessories catalog. However, there is a case that this child restraint system is not sold because of nonconformity to the law of your country or other reason.
Page 68 BEFORE DRIVING Child restraint systems suitability #1: Front seat longitudinal adjustment for each seat position (for K14D should be rearmost position. engine models) Front seat height adjustment should (#2, #3) be upmost position if equipped. #2: When you install a forward-facing child restraint, if there is a gap or space between the child restraint and the seatback, adjust the seat-...
Page 69 BEFORE DRIVING Detailed information for child restraint system Seating position Seat position number Front Front Passenger Passenger airbag is airbag is activated deactivated Seating position suitable for universal belted (YES/NO) i-Size seating position (YES/NO) Seating position suitable for lateral fixture (L1/L2) Suitable rear-facing fixture R1, R2X,...
Page 70 BEFORE DRIVING NOTE: Approval mark to meet child Installation with Lap-shoulder Seat • UN R44 means the international regula- restraint system regulation for UN Belts tion for the child restraint system. R44 regulation “ECE” is shown on the mark in the illustra- tion for the child restraint system.
Page 71 80JC021 forward to make sure the connecting bars are securely latched to the anchorages. Whenever possible, SUZUKI recom- mends that child restraint systems be installed on the rear seat. According to EXAMPLE accident statistics, children are safer when properly restrained in rear seats than in the front passenger seat.
Page 72 BEFORE DRIVING tions provided by the child restraint system 2) Place the child restraint in the rear seat, manufacturer. inserting the connecting bars to the EXAMPLE anchorages between the seat cushion Here is a general instruction: and the seatback. 1) Raise the head restraint to the most upper position.
Page 73 BEFORE DRIVING 5) Grasp the front of the child restraint and cle depends on the vehicle specification. push the child restraint forcefully to Install the child restraint system as follows: Type 1 latch the connecting bars. Make sure 1) Remove the luggage compartment they are securely latched by trying to cover (if equipped).
Page 74: Supplemental Restraint System (Airbags)
EXAMPLE System (airbags) WARNING This section of the owner’s manual describes the protection provided by your SUZUKI’s SUPPLEMENTAL RESTRAINT SYSTEM (airbags). Please read and follow ALL these instructions carefully to minimize your risk of severe injury or death in the event of a collision.
Page 75 (or the seat belt preten- For the label of Taiwan models, refer to sioner system) may not work properly. “For Taiwan” in the “SUPPLEMENT” sec- Have the airbag system inspected by an tion. authorized SUZUKI dealer as soon as pos- sible. 2-53...
Page 76: Front Airbags
BEFORE DRIVING Front passenger’s front airbag Front Airbags WARNING EXAMPLE Therefore, an airbag is NOT a substi- EXAMPLE tute for seat belts. To maximize your protection, ALWAYS WEAR YOUR SEAT BELTS. Be aware that no sys- tem can prevent all possible injuries that may occur in an accident.
Page 77 Have your vehicle angles of about 30 degrees (1) or less inspected by an authorized SUZUKI from the front of your vehicle dealer. • If you smash the airbag stored...
Page 78 BEFORE DRIVING Front airbags may not inflate The front airbags may not inflate when a strong impact has not occurred since the crash object was easy to be deformed or moved, or the crashed portion of your vehi- cle was easy to be deformed. Also, front airbags may not inflate in many cases when the collision angle is greater than about 30 degrees at left and right...
Page 79 BEFORE DRIVING Front airbags do not inflate Front airbags do not inflate in rear impacts, side impacts or rollovers, etc. However, these might inflate in a strong impact. 80J105E 80J110 • Collision with a fixed wall or guardrail at • Vehicle rollover left and right angles of greater than about 30 degrees (1) from the front of your vehicle...
Page 80 Only the side air- lision. Have your vehicle inspected bag and side curtain airbag on the side of by an authorized SUZUKI dealer. the vehicle that is struck will inflate. How- 83RM02071 ever, in a frontal angle collision, the side...
Page 81 BEFORE DRIVING Conditions of side airbags and side cur- tain airbags deployment (inflation) 52RM20730 80J101 • Hitting a curb or bump • Landing hard or falling 80J119 • Impacts from the side at about a right angle by a general passenger car to your vehicle at more than about 30 km/h (20 mph) or in a greater impact Side airbags and side curtain airbags...
Page 82 BEFORE DRIVING Side airbags and side curtain airbags may not inflate 80J123 80J125 • Impact from the side at an oblique angle • Impact from the side by a motorcycle or 80J121 bicycle 80J122 80J124 80J126 • Impact from the side to the vehicle body •...
Page 83: How The System Works
BEFORE DRIVING Side airbags and side curtain airbags How the System Works do not inflate In a frontal collision, the crash sensors will detect rapid deceleration, and if the con- troller judges that the deceleration rep- resents a severe frontal collision, the controller will trigger the inflators.
Page 84 • When installing radio equipment, should not lean on or sleep against objects lean etc., consult a SUZUKI dealer or a the door. In these situations, the umbrella, as these objects could be qualified workshop. Radio waves, out-of-position occupant would be propelled by the airbag in the event etc., from a radio may adversely...
Page 85 90 seconds before performing any electri- Your vehicle is equipped with a diagnostic shop or scrap yard for help with cal service work on your SUZUKI. Do not module which records information about disposal. touch airbag system components or wires.
Page 86 BEFORE DRIVING When the front passenger’s airbag is acti- Front Passenger Airbag Deactiva- vated, both the “PASSENGER AIRBAG WARNING tion System ON” indicator (1) and “PASSENGER AIR- • Whenever a child restraint system BAG OFF” indicator (2) come on for a few has to be used in the front passen- seconds then go out.
Page 87 Whenever possible, SUZUKI recom- 1) Make sure the ignition switch is in the 1) Make sure the ignition switch is in the mends that child restraint systems be “LOCK”...
Page 88: Instrument Cluster
BEFORE DRIVING Instrument Cluster 1. Speedometer 2. Tachometer 3. Fuel gauge 4. Temperature gauge 5. Information display 6. Warning and indicator lights EXAMPLE 83RM02020 2-66...
Page 89: Speedometer
BEFORE DRIVING Refer to “Low Fuel Warning Light” in Speedometer Fuel Gauge “Warning and Indicator Lights” in this sec- tion for details. The speedometer indicates vehicle speed. The mark (2) indicates that the fuel filler door is located on the left side of the vehi- cle.
Page 90: Temperature Gauge
BEFORE DRIVING To reduce the brightness of the instrument Temperature Gauge Brightness Control panel lights, turn the indicator selector knob (1) counterclockwise. WARNING EXAMPLE EXAMPLE If you attempt to adjust the bright- ness of the instrument panel lights while driving, you could lose control of the vehicle.
Page 91: Information Display
BEFORE DRIVING Display (E) Information Display Selector position EXAMPLE (for automatic transaxle models) / The information display is shown when the Gear position ignition switch is in the “ON” position or the (for automatic transaxle models) / ignition mode is “ON”. Gearshift indicator Display (F) Trip meter (Type A)
Page 92 BEFORE DRIVING If the outside temperature nears freezing, Clock Fuel Consumption / Driving Range / the message shown in the above illustra- Average Speed / Total Idling Stop tion will appear on the display. The display (A) shows the time. Time (if equipped) / Total Idling Fuel To set the clock, follow the “Setting mode”...
Page 93 BEFORE DRIVING (a) Instantaneous fuel consumption (b) Average fuel consumption EXAMPLE (c) Driving range (d) Average speed (e) Total idling stop time (if equipped) (f) Total idling fuel saved (if equipped) (g) Energy flow indicator (if equipped) (h) No indication To switch the display indication, push the indicator selector knob (2) quickly.
Page 94 BEFORE DRIVING Instantaneous fuel consumption the ignition switch is turned to the “ON” NOTE: The display shows instantaneous fuel con- position or the engine switch is pressed to If you add only a small amount of fuel sumption with a bar graph only when the change the ignition mode to “ON”.
Page 95 BEFORE DRIVING • When you reconnect the negative (–) knob (2) for a while when the display Idling Stop Time (if equipped) terminal to the battery, the value of driv- shows the total idling stop time. ing range will be shown after driving for a NOTE: period of time.
Page 96 BEFORE DRIVING NOTE: The display shows the transaxle selector Eco-driving Display • You can change the setting so that the position (4) or the gear position (5). Eco-driving display will not be displayed. • When the manual mode is not in use, the When you turn the ignition switch to For details on the setting mode, refer to display shows the selector position.
Page 97 BEFORE DRIVING Trip Meter / Odometer (Type A) Trip Meter / Odometer (Type B) Setting Mode The display (G) shows the trip meter or When the ignition switch is in the “ON” Trip Meter odometer. position or the ignition mode is “ON” and The display (F) shows the trip meter.
Page 98 BEFORE DRIVING NOTE: Fuel reset (Average fuel consumption • To change the minute indication, turn the • If you push and hold the indicator selec- reset setting) indicator selector knob (2) left or right tor knob (2) to enter the setting mode You can change when the value of aver- repeatedly when the minute indication when the display (D) shows average fuel...
Page 99 BEFORE DRIVING return the turn signal control lever immedi- IS A/C (ENG A-STOP system setting) (Regen disp setting) ately after moving it. (if equipped) You can choose that the deceleration • When using the automatic heating and energy regenerating indicator light comes Oil change (Oil life monitoring system air conditioning system (if equipped), on or does not come on.
Page 100 BEFORE DRIVING • When you push and hold the indicator Warning and Indicator Messages selector knob (2) for about 2 seconds while a message is displayed, the mes- The display shows warning and indicator sage will disappear temporarily. If the messages to let you know about certain problem that caused the message is not vehicle problems.
Page 101 BEFORE DRIVING Warning and indicator messages All models Warning and Indicator Master Warning Sound Cause and Remedy Message Indicator Light Blinks Beep (one time from interior A door or tailgate is not properly closed. (only while vehicle buzzer; only while vehicle is Stop in a safe place and close the door or is in motion) in motion)
Page 102 (#1) 61MS409 Blinks Beep (one time from interior If this message is displayed, have your buzzer) vehicle inspected by an authorized SUZUKI dealer. 61MM0A180 Blinks Beep (one time from interior You should change the engine oil and oil fil- buzzer) ter immediately.
Page 103 Blinks Beep (one time from interior There may be a problem with the gasoline buzzer) particulate filter. Have your vehicle inspected by an autho- rized SUZUKI dealer. 83RM088 Blinks Beep (one time from interior You should regenerate the GPF. buzzer) Refer to “Gasoline Particulate Filter (GPF)”...
Page 104 BEFORE DRIVING Models with keyless push start system Warning and Indicator Master Warning Sound Cause and Remedy Message Indicator Light The brake pedal (for automatic transaxle models) or the clutch pedal (for manual transaxle models) is depressed. Press the engine switch to start the engine. 61MM0A164 This message is displayed when the “ACC”...
Page 105 BEFORE DRIVING Warning and Indicator Master Warning Sound Cause and Remedy Message Indicator Light Blinks Series of beeps under cer- The remote controller may be outside the tain conditions (for about 2 vehicle or its battery may have become dis- seconds from exterior and/or charged.
Page 106 Beep (one time from interior There is a problem with the immobilizer/ buzzer) keyless push start system. Have your vehicle inspected by an autho- rized SUZUKI dealer. 61MM0A169 Blinks Beep (one time from interior The steering lock is not disengaged. While...
Page 107 BEFORE DRIVING Warning and Indicator Master Warning Sound Cause and Remedy Message Indicator Light Manual Transaxle The engine switch is pressed without depressing the brake and clutch pedals. Try again as instructed by the message. 61MM0A166 Automatic Transaxle The engine switch is pressed with the gear- shift lever in a position other than “P”.
Page 108 BEFORE DRIVING Models with K14D engine Warning and Indicator Master Warning Sound Cause and Remedy Message Indicator Light Continuous beep (from inte- Temperature of the lithium-ion battery is rior buzzer) extremely low and the engine cannot be started. Refer to “Starting Engine in Cold Area”...
Page 109 Beep (one time from interior There may be a problem with the ESP buzzer) system. Have your vehicle inspected by an autho- rized SUZUKI dealer. 61MM0A178 Blinks Beep (one time from interior There may be a problem with the hill hold buzzer) control system.
Page 110: Warning And Indicator Lights
When the system detects a malfunction, while driving, have your vehicle this light will blink for about 75 seconds inspected by an authorized SUZUKI and then remain continuously illuminated. dealer. Even if the light turns off after This sequence will be repeated after the blinking, indicating that the monitor- ignition switch is turned to the “ON”...
Page 111 BEFORE DRIVING WARNING WARNING WARNING The load-carrying capacity of your Continuing to drive with the low tire (Continued) tires is reduced at lower inflation pressure warning light on can lead to • If your vehicle is equipped with a pressures. If your tires are even mod- an accident, resulting in severe injury flat tire repair kit instead of a spare erately under-inflated, the load on the...
Page 112: Brake System Warning Light
If any of the following conditions the vehicle’s brake system. If this happens, occur, you should immediately ask you should: your SUZUKI dealer to inspect the 1) Pull off the road and stop carefully. brake system. • If the brake system warning light...
Page 113: Antilock Brake System (Abs) Warning Light
ESP systems (other than If one of these happens, have the system ABS). You should have the system inspected by your SUZUKI dealer. inspected by an authorized SUZUKI If the ABS becomes inoperative, the brake dealer. system will function as an ordinary brake system that does not have this ABS sys- ®...
Page 114 If there is enough oil, the lubrication sys- dealer. For details of the ESP systems, refer to ® tem should be inspected by your SUZUKI “Electronic Stability Program (ESP )” in dealer before you drive the vehicle again. the “OPERATING YOUR VEHICLE” sec- tion.
Page 115: Seat Belt Reminder Light
“ON” position tem. or the engine switch is pressed to Bring the vehicle to your SUZUKI dealer to change the ignition mode to “ON”, have the damage fixed. stays on for more than 10 seconds,...
Page 116: Open Door Warning Light
This light comes on for several seconds right or left. If this light still stays on, ask when the ignition switch is turned to the your SUZUKI dealer to have the system “ON” position or the engine switch is inspected.
Page 117 When the power steering control system tem. Bring the vehicle to your SUZUKI cool down, the power steering system dealer to have the problem corrected. back to the original condition.
Page 118 “ON”, this light comes on briefly so you can check that the light is working. If this light comes on, there is a problem with the LED headlight. Park the vehicle in a safe place and consult your SUZUKI dealer to have the problem corrected. 2-96...
Page 119 BEFORE DRIVING and oil filter. When the engine oil and oil fil- 4WD Warning Light (if equipped) Oil Change Request Light ter are changed, and the oil life monitoring (if equipped) system is reset, this light will go out. Whenever the engine oil is changed, the light must be reset to monitor the next oil change timing properly.
Page 120 • For K14C engine models, refer to “ENG You should have the system inspected by A-STOP System (Engine Auto Stop Start an authorized SUZUKI dealer. System) (For K14C Engine Models)” in • For K14D engine model, refer to “ENG the “OPERATING YOUR VEHICLE” sec- A-STOP System (Engine Auto Stop Start tion.
Page 121 “ON”. tem will stop functioning when the ignition by an authorized SUZUKI dealer. • When there is a problem with the radar mode is “ON”. • When there is a problem with the ABS brake support system.
Page 122 BEFORE DRIVING For details of the GPF, refer to “Gasoline Master Warning Indicator Light Gasoline Particulate Filter (GPF) Particulate Filter (GPF)” in the “OPERAT- Warning Light (For K14C and K14D ING YOUR VEHICLE” section. Engine Models) NOTICE Be sure to regenerate the GPF when the GPF warning light comes on.
Page 123: Lighting Control Lever
BEFORE DRIVING Lighting Operation Lighting Control Lever EXAMPLE EXAMPLE 61MM0A073 With the headlights on, push the lever for- ward to switch to the high beams (main 61MM0A072 57L21128 beams) or pull the lever toward you to To turn the lights on or off, twist the knob switch to the low beams.
Page 124 BEFORE DRIVING Your vehicle’s lighting system is controlled by two main systems: the Lighting switch and Automatic Light Operation the Auto-On Headlight System (when the lighting switch is in the “AUTO” position). (if equipped) The two systems work together to operate your lights as shown in the following chart: ON: Lights ON EXAMPLE LIGHT: When it is light around the light sensor (5).
Page 125 BEFORE DRIVING To turn the lights on or off, twist the knob on the end of the lever. There are four CAUTION Front position lights, tail lights, license positions: plate light, instrument lights and headlights If the light sensor area of the wind- are on.
Page 126: Light Reminder Buzzer
Please contact an authorized condition: column, when the following three condi- SUZUKI dealer if you want the function The headlights and/or position lights are tions are all met. reprogrammed. on even after the ignition switch is turned...
Page 127 BEFORE DRIVING Daytime Running Light (D.R.L.) Rear Fog Light Switch Adjusting Headlight Pattern System Headlight pattern, left hand traffic When the engine is started, this system EXAMPLE turns on the daytime running lights. Conditions for D.R.L. system operation 1) The engine is running. 2) Headlights and front fog light (if equipped) are off.
Page 128: Front Fog Light Switch (If Equipped)
BEFORE DRIVING The headlight pattern must be adjusted to Front Fog Light Switch Headlight Leveling Switch avoid dazzling oncoming motorists and can be set for right or left hand traffic. (if equipped) (if equipped) However, your vehicle do not need to adjust the light pattern.
Page 129: Turn Signal Control Lever
BEFORE DRIVING Turn Signal Operation Turn Signal Control Lever Vehicle Load Switch Position Condition With the ignition switch in the “ON” position or the ignition mode “ON”, move the lever Driver only up or down to activate the right or left turn signals.
Page 130: Hazard Warning Switch
Hazard Warning Switch You can customize the setting for the num- ber of times of flashing of the turn signal and its indicator (1 to 4 times). Please ask an authorized SUZUKI dealer for the cus- EXAMPLE tomization. EXAMPLE 61MM0A077 Move the lever part-way in the direction to turn and hold it there.
Page 131: Windshield Wiper And Washer Lever
To turn off the wipers, move the there may be another problem. Ask your lever back to the “OFF” position. SUZUKI dealer to have the wipers inspected. Move the lever up and hold it to the “MIST” position, the windshield wipers will turn on continuously at low speed.
Page 132 BEFORE DRIVING Windshield Wipers with Rain Sens- EXAMPLE EXAMPLE ing Function (if equipped) EXAMPLE 61MM0A080 61MM0A082 If the lever is equipped with the “INT TIME” If the control lever has on “AUTO” position, control, turn the control forward or rear- you can change the system’s sensitivity to ward to adjust the intermittent wiper opera- rain/snow by turning the knob of the con-...
Page 133 – The rain sensor is hotter than 80°C switch in the “ON” mode. Other- (176°F) in the sun or lower than –10°C authorized SUZUKI dealer for this customi- wise, the wipers could unexpect- (14°F) in freezing weather. (The wip- zation.
Page 134: Windshield Washer
BEFORE DRIVING Windshield Washer Rear Window Wiper/Washer Switch NOTICE To help prevent damage to the wind- EXAMPLE EXAMPLE shield wiper and washer system components, you should take the fol- Washer lowing precautions: • Do not continue to hold in the lever Wiper when there...
Page 135: Tilt/Telescoping (If Equipped) Steering Lock Lever
BEFORE DRIVING Tilt/Telescoping (if equipped) NOTICE WARNING Steering Lock Lever Clear ice or snow from the rear win- Never attempt to adjust the steering dow and rear wiper blade before wheel while the vehicle is moving or using the rear wiper. Accumulated you could lose control of the vehicle.
Page 136: Horn
BEFORE DRIVING Type 2 Horn Heated Rear Window and EXAMPLE Heated Outside Rearview Mirror Switch (if equipped) EXAMPLE Type 1 EXAMPLE 61MM0A087 When the rear window is misted, push this switch (1) to clear the window. 68LM240 Press the horn button of the steering wheel EXAMPLE to sound the horn.
Page 137 BEFORE DRIVING switch (1), both the heated outside rear- view mirrors and the heated rear window will operate simultaneously. An indicator light will be lit when the defog- ger is on. The defogger will work only when the engine is running. To turn off the defogger, push the switch (1) again.
Page 138: Operating Your Vehicle
(Vehicle without Keyless Push Start System) ....3-3 (if equipped) ................ 3-79 Engine Switch SUZUKI SAFETY SUPPORT (if equipped) ......3-87 (Vehicle with Keyless Push Start System) ......3-5 Emergency Stop Signal (ESS) (if equipped) ....3-114 Keyless Push Start System (if equipped) ......3-7...
Page 139: Exhaust Gas Warning
OPERATING YOUR VEHICLE Exhaust Gas Warning Daily Inspection Checklist WARNING (Continued) • Do not park with the engine run- Before Driving ning for a long period of time, even in an open area. If it is necessary to sit for a short time in a parked vehi- cle with the engine running, make sure the air intake selector is set to “FRESH AIR”...
Page 140: Engine Oil Consumption
OPERATING YOUR VEHICLE NOTE: 5) Windshield washer fluid level Engine Oil Consumption It is normal for water to drip from the air 6) Hood latch operation conditioning system after use. Pull the hood release handle inside the It is normal for the engine to consume vehicle.
Page 141: Ignition Switch
OPERATING YOUR VEHICLE making it appear that the oil level has not Ignition Switch changed. EXAMPLE You should also be aware that the diluting (Vehicle without Keyless ingredients evaporate out when the vehicle Push Start System) is subsequently driven at high speeds, such as on an expressway, making it appear that oil is excessively consumed after high-speed driving.
Page 142 OPERATING YOUR VEHICLE Manual transaxle Accessories such as the radio can oper- Turn to “LOCK” ate, but the engine is off. This is the normal operating position. All electrical systems are on. Push START This is the position for starting the engine using the starter motor.
Page 143: Engine Switch
OPERATING YOUR VEHICLE IGNITION SWITCH POSITION. Refer to Engine Switch WARNING “Information Display” in the “BEFORE DRIVING” section for details. (Vehicle with Keyless Push (Continued) • Always return the ignition switch to Start System) “LOCK” position and remove the • With the engine off ignition key when leaving the vehi- You can use such electric equipment as cle even only for a short time.
Page 144 OPERATING YOUR VEHICLE START Unreleased Steering Lock Warning • Manual transaxle vehicles NOTICE Provided you have the keyless push start If the steering lock remains engaged when Do not leave the engine switch in system remote controller with you, the you press the engine switch to change the ACC or ON mode when the engine is engine automatically starts when you...
Page 145: Keyless Push Start System (If Equipped)
OPERATING YOUR VEHICLE • When the engine is off and the position Selection of Ignition Modes Keyless Push Start System lights are on. The illumination will go out when the position lights are turned off. (if equipped) Press the engine switch to select the •...
Page 146 OPERATING YOUR VEHICLE Every time you press the engine switch, NOTE: the ignition mode changes as follows. • Automatic transaxle – If the gearshift EXAMPLE lever is in any position other than “P”, or Automatic transaxle if the knob button is pushed when the gearshift lever is in “P”...
Page 147 Contact When either of the conditions described an authorized SUZUKI dealer for an below is met, the system issues a “remote inspection of the system. controller outside” warning by sounding the •...
Page 148: Parking Brake Lever
OPERATING YOUR VEHICLE (OFF) by pressing the engine switch and NOTE: Parking Brake Lever then perform the engine starting opera- • Even when the remote controller is in the tion. Refer to “Starting / Stopping “interior workable area”, if it is in any of Engine”...
Page 149 Automatic transaxle – shift into rized SUZUKI dealer. “P” (Park) and turn off the engine. 3) Get out of the vehicle and put chocks under the wheels. 4) Release the parking brake.
Page 150: Pedal
NOTE: Brake Pedal (2) Your vehicle is equipped with Brake Over- 80J2121 ride System. If you depress both the accel- Your SUZUKI vehicle is equipped with front Automatic transaxle erator pedal brake pedal and rear disc brakes. Depressing the...
Page 151: Starting / Stopping Engine (Vehicle Without Keyless Push Start System)
“LOCK” position and wait for more than 30 seconds before trying again. If the engine does not start after several attempts, consult a SUZUKI dealer or a qualified work- 83RM005 shop. If the engine starts, the 1) Check that the parking brake is set fully.
Page 152 OPERATING YOUR VEHICLE While driving, if temperature of the lithium- Starting Engine in Cold Area Stopping Engine ion battery becomes extremely low (about (For K14D Engine Model) -35°C (-31°F) or below), the situation is informed sounding buzzer in the cabin, WARNING blinking charging light and ENG A-STOP Except in cases of emergency, do not...
Page 153: Starting / Stopping Engine (Vehicle With Keyless Push Start System)
2) Turn off such loads as the headlights the starter motor will stop turning attempts, consult a SUZUKI dealer and air conditioning system to facilitate automatically after approximately 12 or a qualified workshop. starting of the engine.
Page 154 OPERATING YOUR VEHICLE NOTE: While driving, if temperature of the lithium- Starting Engine in Cold Area • You do not need to keep the engine ion battery becomes extremely low (about (For K14D Engine Model) switch pressed to start the engine. -35°C (-31°F) or below), the situation is •...
Page 155: Emergency Stop
OPERATING YOUR VEHICLE Stopping Engine Master Warning Indicator Light NOTICE Blinks and Engine cannot be • Depress the engine switch to stop the • Automatic transaxle vehicles: Started engine after the vehicle stopped com- If you stop the engine while the pletely.
Page 156 “LOCK” (OFF) position if the gearshift where, such as a low lead-acid battery. lever is in any other position than “P”. Consult a SUZUKI dealer or a qualified Certain problems like a fault in engine sys- workshop for inspection.
Page 157 (including completed. the tailgate) is opened or closed, the inte- rior buzzer will warn you of this condition with repeated short beeps. If this happens, have the vehicle inspected by an autho- rized SUZUKI dealer. 3-19...
Page 158: Using The Transaxle
OPERATING YOUR VEHICLE 6MT model Using the Transaxle NOTICE Be sure to regenerate the GPF when the GPF warning light comes on. Fail- WARNING ure to regenerate the GPF will cause Do not hang any items on the gear- a vehicle malfunction due to the shift lever and do not use the gear- clogged filter.
Page 159 OPERATING YOUR VEHICLE Downshifting maximum allowable *NOTE: speeds You may not accelerate to the maximum allowable speed because of the driving sit- For M16A engine model uation and/or the vehicle condition. Downshifting km/h (mph) NOTICE 2nd to 1st 25 (15) When downshifting to a lower gear, make sure not to downshift at the 3rd to 2nd...
Page 160: Speed Automatic Transaxle
OPERATING YOUR VEHICLE The gearshift lever has a lock mechanism 6-Speed Automatic Transaxle NOTICE to help prevent accidental shifting. To shift the gearshift lever: • To help avoid clutch damage, do Gearshift lever not use the clutch pedal as a foot- EXAMPLE rest while driving or use the clutch EXAMPLE...
Page 161 OPERATING YOUR VEHICLE NOTE: N (Neutral) • Always shift the gearshift lever without Use this position for starting the engine if CAUTION pushing in the knob button (1) except the engine stalls and you need to restart it For the vehicles with the keyless when you shift from “P”...
Page 162 OPERATING YOUR VEHICLE Manual mode NOTE: NOTICE The automatic transaxle can shift gears • The indicated gear position on the infor- automatically. When using the manual mation display when you shift from “D” to Be sure to take the following precau- mode, you can shift gears in the same “M”...
Page 163 OPERATING YOUR VEHICLE Using the shift paddle Canceling the manual mode To cancel the manual mode, shift the gear- shift lever from “M” to “D”. Temporary manual mode Pull the shift paddle toward you when driv- ing with the gearshift lever in the “D” posi- tion.
Page 164: If You Cannot Shift Automatic Transaxle Gearshift Lever Out Of "P" (Park)
OPERATING YOUR VEHICLE 1) Be sure the parking brake is firmly Right Hand Drive Vehicle If You Cannot Shift Automatic Tran- applied. saxle Gearshift Lever Out of “P” 2) If the engine is running, stop the (PARK) engine. 3) Make sure the key is in the “ON” or Left Hand Drive Vehicle “ACC”...
Page 165: Gearshift Indicator
OPERATING YOUR VEHICLE 1) Be sure the parking brake is firmly The electronic control system monitors Gearshift Indicator applied. driving condition (such as vehicle speed 2) If the engine is running, stop the and/or engine revolution), and it shows engine. which gear position is optimal for your driv- 3) Make sure the key is in the “ON”...
Page 166 OPERATING YOUR VEHICLE NOTE: WARNING • For manual transaxle, the gearshift indi- cator is not indicated when the gear The gearshift indicator is designed to position is in “N” (Neutral). indicate optimal gear position for • For manual transaxle, if you depress the your driving, however, a driver will clutch pedal while UP/DOWN arrow is not be relieved from the duty of care...
Page 167 OPERATING YOUR VEHICLE Example of the gearshift indicator Manual transaxle Indication Description Lower gear position is selected for the vehicle speed and/or engine revolution. Changing to a higher gear posi- tion is recommended. • In this case, shifting up is recommended. Higher gear position is selected for the vehicle speed and/or engine revolution.
Page 168: Four-Mode 4Wd System (If Equipped)
OPERATING YOUR VEHICLE SPORT Four-mode 4WD System This mode is optimized for sporty driving. EXAMPLE The system apportions torque to promote (if equipped) cornering performance. • In the vehicle with automatic transaxle, this mode optimizes the throttle/torque EXAMPLE characteristics with small and moderate throttle openings to keep the engine PUSH LOCK...
Page 169 4WD system. Have the sys- • When the ignition switch is turned to the tem inspected by an authorized “ON” position or the engine switch is SUZUKI dealer. pressed to change the ignition mode to “ON”, the AUTO mode is selected auto- NOTICE matically.
Page 170 Beep (one time from interior There may be a problem with the four- buzzer) mode 4WD system. Have your vehicle inspected by an autho- rized SUZUKI dealer. 61MM0A185 Blinks Beep (one time from interior Tires of different sizes may be fitted or tires buzzer) may be insufficiently inflated.
Page 171 Drive train components may be over- buzzer) heated. Stop in a safe place and allow the engine to idle. 61MM0A187 Blinks Beep (one time from interior If this message is displayed, have your buzzer) vehicle inspected by an authorized SUZUKI dealer. 61MM0A203 3-33...
Page 172 OPERATING YOUR VEHICLE Warning and Indicator Master Warning Sound Cause and Remedy Message Indicator Light Blinks Beep (one time from interior The “LOCK” part of the driving mode switch buzzer) is pushed when the vehicle speed is more than 60 km/h (37 mph). (#1) Refer to “Selecting LOCK mode”...
Page 173 Warning and Indicator Master Warning Sound Cause and Remedy Message Indicator Light Blinks Beep (one time from interior There may be a problem with the driving buzzer) mode switch. Have your vehicle inspected by an authorized SUZUKI dealer. 61MM0A189 3-35...
Page 174: Shvs (Smart Hybrid Vehicle By Suzuki) (For K14D Engine Model)
NOTE: The SHVS (Smart Hybrid Vehicle by When you restart the engine by pushing Suzuki) of this vehicle is a system that the engine switch, the ordinary starter uses generators with motor function (ISG) motor is used and you will hear a gear to operate the following functions accord- engagement noise.
Page 175 OPERATING YOUR VEHICLE • The starter motor function is functioning If all of the following conditions are met, Battery indicator when the engine has been automatically the motor assistance function is function- The segments in the battery indicator (1) stopped: ing.
Page 176: Eng A-Stop System (Engine Auto Stop Start System) (For K14D Engine Model)
OPERATING YOUR VEHICLE NOTE: Handling of the Integrated Starter ENG A-STOP System If your vehicle is equipped with the auto- Generator (ISG) matic heating and air conditioning system, (Engine Auto Stop Start you can change the automatic engine stop System) (For K14D Engine condition via the information display.
Page 177 • To replace or dispose of the lithium-ion – For automatic transaxle, if the battery, or to replace the DCDC con- driver’s seat belt is unfastened, verter, consult an authorized SUZUKI even if the brake pedal is pressed dealer. down, or the driver’s door is...
Page 178 During the automatic engine stop, do converter and difficult to remove, not shift the gearshift lever to a posi- consult authorized SUZUKI tion other than “N” without depress- dealer. ing the clutch pedal. If the gear shift lever is in a position other than “N”,...
Page 179 OPERATING YOUR VEHICLE NOTE: NOTE: • Engine auto stop function during decel- When the engine is restarted automati- eration will be ready once the vehicle cally, the following conditions may be runs at a speed exceeding 10 km/h (6 found as the hill hold control system is acti- mph) after restart of the engine.
Page 180 OPERATING YOUR VEHICLE to improve the cooling and heating per- formance. 2) When you remove your foot from the brake pedal, regardless of whether it is before or after stopping the vehicle, the engine is restarted and the ENG A- STOP indicator light (green) goes off.
Page 181 OPERATING YOUR VEHICLE Precautions of when the Engine is Stopped Automatically WARNING Do not perform any of the following operations while the engine has been stopped automatically. This may result in an acci- dent. Operation/Vehicle Condition Solution To restart the engine, follow the procedure below. 1) Set the parking brake firmly, and then place the gearshift lever Engine hood opened in the “N”...
Page 182 OPERATING YOUR VEHICLE Before driving, close the door and buckle the seat belt. In addition, before getting out of the vehicle, follow the procedure below. Driver’s seat belt unfastened, or driver’s door opened 1) Set the parking brake firmly, and then place the gearshift lever Automatic •...
Page 183 OPERATING YOUR VEHICLE Operating Conditions of ENG A-STOP System Standby conditions If all of the following conditions are met while driving, the automatic engine stop will be permitted. When the engine is started • The engine is started with the engine hood securely closed. •...
Page 184 OPERATING YOUR VEHICLE Conditions to stop the engine automatically If all of the following conditions are met while the standby conditions are met, the engine is stopped automatically when the vehicle is decelerating before stopping or when the vehicle is stopped. ®...
Page 185 OPERATING YOUR VEHICLE Conditions to restart the engine automatically If any of the following vehicle conditions occur or operations are performed while the engine is stopped automatically, the engine is restarted automatically and the ENG A-STOP indicator light (green) goes off. •...
Page 186 OPERATING YOUR VEHICLE *1: After the ENG A-STOP indicator light (green) blinks, it goes off. Also, the interior buzzer may sound at the same time. *2: Depending on the situations of malfunction, it is a normal restart or the restart as *1. *3: The engine may be restarted automatically when the brake pedal is depressed lightly.
Page 187 • To deactivate the system, press the ENG vated. If it blinks, have the vehicle ser- A-STOP OFF switch (1) to turn on ENG viced by an authorized SUZUKI dealer. A-STOP OFF light (2). – If the system is operating normally •...
Page 188 The ENG A-STOP system or the SHVS system does not actuate correctly while the indicator is blinking. Have the system inspected by an authorized SUZUKI dealer. – There may be something wrong with the ENG A-STOP system or the SHVS system.
Page 189: Information Message
OPERATING YOUR VEHICLE Information Message The information display shows the messages to let you know certain problems of the ENG A-STOP system. Information Message Cause and Remedy The ENG A-STOP system cannot stop the engine automatically because something of the actuation conditions is not met.
Page 190 OPERATING YOUR VEHICLE Information Message Cause and Remedy The engine restarted automatically because one of the following automatic engine restart con- ditions is met. • The defroster is turned on. • The driver’s seat belt is released. • The driver’s door is opened. •...
Page 191: Eng A-Stop System (Engine Auto Stop Start System) (For K14C Engine Model)
• When the vehicle will be stopped for a Only use the vehicle battery types long time or when you will leave the WARNING that have been approved by SUZUKI vehicle unattended, turn the ignition vehicle manufacture, otherwise you switch to the “LOCK” position or press •...
Page 192: Automatically Stopping The Engine
OPERATING YOUR VEHICLE For more details, refer to the explanation • The “ENG A-STOP OFF” light blinks. below. • Engine coolant temperature is either low or high. • Vehicle battery performance is low. Automatically Stopping the Engine • The temperature of the vehicle battery is either low or high.
Page 193 OPERATING YOUR VEHICLE Automatic transaxle models • When the engine is started with the hood 1) With the gearshift lever in “D” or “N”, NOTICE open. depress brake pedal and stop the vehi- • The vehicle has stopped on a steep hill. The brake booster becomes inoperative cle.
Page 194: Automatically Restarting The Engine
OPERATING YOUR VEHICLE • Blower speed selector is set to the “ON” Automatically Restarting the Engine NOTICE mode and the inside of the vehicle has not sufficiently cooled and warmed (for The ENG A-STOP system will not Manual transaxle models the vehicle with automatic air condition- operate and engine does not restart ing).
Page 195 OPERATING YOUR VEHICLE Automatic transaxle models NOTE: NOTE: Under the following conditions, the engine When the engine restarts, the sound of the will restart automatically even if the engine audio may be interrupted. was stopped by the ENG A-STOP system: This is normal and not the malfunction of the audio system.
Page 196: Cruise Control (If Equipped)
The should have the system inspected by an controls for operating the cruise control authorized SUZUKI dealer. For details, system are on the steering wheel. refer to “Warning and Indicator Lights” in the “BEFORE DRIVING” section.
Page 197 OPERATING YOUR VEHICLE When you push the “CRUISE” switch (1), To Set Cruising Speed the system is on and the cruise indicator (5) will come on. When the vehicle’s speed 1) Turn on the cruise control system by is controlled by the cruise control system, pushing the “CRUISE”...
Page 198 OPERATING YOUR VEHICLE To Change Speed Temporarily To Change Cruising Speed Cancellation of the Cruise Control When the cruising speed is maintained, Using the accelerator pedal The set indicator (6) will go off and the you can temporarily accelerate or deceler- To reset at a faster cruising speed, accel- cruise control will be canceled temporarily ate.
Page 199: Speed Limiter (If Equipped)
OPERATING YOUR VEHICLE Models with cruise control To Set Maximum Speed Speed Limiter (if equipped) 1) Turn on the speed limiter system by pushing the speed limiter switch (1). EXAMPLE When the limit indicator (5) comes on, you can set maximum speed. 2) Accelerate or decelerate to the desired speed.
Page 200 OPERATING YOUR VEHICLE To Override the Maximum Speed To Change Speed Setting Cancellation of the Speed Limiter You can exceed the maximum speed tem- • To cancel the speed limiter, push the Setting to the current speed porarily by quickly depressing the acceler- “CANCEL”...
Page 201: Parking Sensors (If Equipped)
OPERATING YOUR VEHICLE obstacle and return from it, from which it Sensor Locations Parking Sensors (if equipped) determines the obstacle’s position. • The parking sensor function can be used On the front bumper when you press the engine switch to change the ignition mode to “ON”, the EXAMPLE EXAMPLE...
Page 202 • If the bumper hits a hard object, the sensors on it may not work prop- erly. If this occurs, have the sen- sors inspected by an authorized SUZUKI dealer. 61MM0B009 (3) Rear center sensors (2 places) (4) Rear corner sensors (2 places)
Page 203 OPERATING YOUR VEHICLE Working sensors The sensors that work depends on the position of the gearshift lever as follows: Manual transaxle Automatic transaxle Gearshift lever position N, 1st – 5th or 6th N, D or M Center (with the parking brake lever released) Front sensors Corner...
Page 204 OPERATING YOUR VEHICLE Approximate areas where obstacles can be detected WARNING WARNING (Continued) (Continued) EXAMPLE – Sensors are wet from water – Sensors are at an angle to a splashes or heavy rain. highly reflective object such as – Sensors are covered by a hand, glass.
Page 205 OPERATING YOUR VEHICLE • When the ignition mode is “ON” and the indicator light in the parking sensor switch is How to Use the Parking Sensor on, indicating that the parking sensor is ready for operation under the following condi- tions: Parking sensor switch –...
Page 206 OPERATING YOUR VEHICLE Upon detecting an obstacle, the parking sensor causes an interior buzzer to sound and a Obstacle Indication by Parking Sen- symbol representing the obstacle appears on the information display in the instrument cluster. • A different symbol is displayed depending on the direction and distance of the obstacle. •...
Page 207 Have your vehicle inspected by Trailer mode an authorized SUZUKI dealer. The rear corner and rear center sensors are inhibited from operating. Use this mode when towing a trailer. NOTICE One blinking Series of...
Page 208: Rearview Camera (If Equipped)
OPERATING YOUR VEHICLE Rearview Camera Location Rearview Camera (if equipped) NOTICE If you use the rearview camera for a When the gearshift lever is shifted to the long time when the ignition switch is “R” position while the ignition switch is in in the “ON”...
Page 209 OPERATING YOUR VEHICLE Example of display range of rearview How to Use Rearview Camera NOTICE camera 1) Turn the ignition switch to the “ON” If water enters the rearview camera, it EXAMPLE position or press the engine switch to may cause a malfunction or catching change the ignition mode to “ON”.
Page 210 OPERATING YOUR VEHICLE NOTE: Uphill incline behind the Vehicle Downhill incline behind the vehicle • Images shown on the display from the rearview camera are reversed images EXAMPLE EXAMPLE (mirror images). • The colors of objects on the rearview camera may differ from the actual object colors.
Page 211: Braking
4 times greater than the pressing the brake pedal once and holding rized SUZUKI dealer as soon as possible. braking distance needed at 30 km/h (19 it down. The reserve power is partly used mph).
Page 212 OPERATING YOUR VEHICLE it senses that the wheels are locking up. WARNING You may feel the brake pedal moves a little WARNING while the ABS is operating. Even without reserve power in the (Continued) brake system, you can still stop the •...
Page 213: Electronic Stability Program (Esp ® )
ABS system. skidding situation, computer will Ask your SUZUKI dealer to inspect change braking pressure several times the ABS system immediately. If the each second to prevent the wheels from ® The Electronic Stability Program (ESP ABS system becomes inoperative, locking.
Page 214: Stability Control System
OPERATING YOUR VEHICLE ® The ESP has the following three sys- operate whenever it senses that wheels tems: are locking up. You may feel the brake WARNING pedal pulsate while the ABS is operating. ® • The ESP may not work properly if (For more information on ABS, see “Brak- Stability Control System engine related parts such as the...
Page 215 ® be a malfunction of the ESP sys- tems (other than ABS). You should have the systems inspected by an authorized SUZUKI dealer. 61MM429 ® (1) ESP OFF switch 3-77...
Page 216 • The hill hold control system is not there may be a problem with the ESP designed to stop the vehicle on a system. Have your vehicle inspected by an hill. authorized SUZUKI dealer. (Continued) NOTE: ® The ESP system will not activate while this message is displayed.
Page 217: Tire Pressure Monitoring System (Tpms) (If Equipped)
Have your vehicle tires indicates significant under-inflation, brakes will not work so steering inspected by an authorized SUZUKI the low tire pressure warning light shown and braking will be much harder dealer. below comes on. than usual which can result in an NOTE: accident or vehicle damage.
Page 218 SUZUKI the vehicle placard or tire inflation pressure an accident. dealer. Even if the light turns off after label.
Page 219 OPERATING YOUR VEHICLE WARNING WARNING WARNING The load-carrying capacity of your Continuing to drive with the low tire (Continued) tires is reduced at lower inflation pressure warning light on can lead to • If your vehicle is equipped with a pressures.
Page 220 TPMS. Have your have pressure below the specification vehicle inspected by an authorized when the vehicle is driven outside in very SUZUKI dealer. cold temperature. If you adjust the tire 61MM0A198 pressure in a garage that is warmer than...
Page 221: Tpms Malfunction Indicator
The TPMS malfunction indicator is com- have tires repaired or replaced by bined with the low tire pressure warning an authorized SUZUKI dealer. The light. When the system detects a malfunc- tire pressure sensors can be dam- tion, the low tire pressure warning light will...
Page 222 – Snow tires that are not installed genu- ine TPMS sensors or tire chains are used. • When you use non-genuine SUZUKI wheels or tires. • When the pressure of any tire is too high. • When there is a problem with the receiver of the TPMS controller.
Page 223 OPERATING YOUR VEHICLE NOTE: • If the low tire pressure warning light EXAMPLE EXAMPLE comes on, the information display will be switched to “Tyre Press” display and the corresponding tire pressure indication blinks to alert you which tire(s) is(are) low pressure. •...
Page 224 OPERATING YOUR VEHICLE To set the initial value of tire pressure EXAMPLE EXAMPLE EXAMPLE 83RM30170 61MM0A232 83RM042 2) Turn the indicator selector knob (1) left 3) Turn the indicator selector knob (1) left 1) When the ignition switch is in the “ON” or right to select the “TPMS”...
Page 225: Suzuki Safety Support (If Equipped)
Use of tires or wheels not recom- • Make sure all passengers wear mended by SUZUKI can result in fail- their seat belts when the vehicle is ure of the TPMS. being operated.
Page 226 OPERATING YOUR VEHICLE NOTE: WARNING • While the system is working, if a vehicle in front of you moves outside of the (Continued) radar’s detection field or the vehicle can • On the following surfaces, you may no longer be detected, the system may not be able to decelerate even with stop functioning.
Page 227: Forward Collision Warning
OPERATING YOUR VEHICLE Forward collision warning When there is a risk of a frontal collision, warning will be given through the information display and sound. EXAMPLE buzzer 61MM702 3-89...
Page 228 OPERATING YOUR VEHICLE Warning brake system If the driver cannot take or is insufficient to take evasive action such as brake operation and steering operation after frontal collision warning activates, the system applies brake lightly. EXAMPLE buzzer 83RM050 CAUTION In the following conditions, this warning brake system may not activate. •...
Page 229: Brake Assist System
OPERATING YOUR VEHICLE Brake assist system When there is high probability of a frontal collision, the brake assist system provides more powerful braking when you slam down on the brake pedal. EXAMPLE buzzer 61MM431 3-91...
Page 230 OPERATING YOUR VEHICLE Automatic brake system When a frontal collision is unavoidable at lower speeds, the brakes will powerfully brake automatically. (#1) EXAMPLE buzzer 61MM432 (#1) After the vehicle has been stopped by the automatic brake system, flashing of the radar brake support system warning light and forward collision warning will continue until the brake system is released.
Page 231 OPERATING YOUR VEHICLE It will not activate in the following It may not activate in the following situations situations EXAMPLE In the following situations, the system will In the following situations, the radar may not activate. not detect the vehicle in front of you and •...
Page 232 OPERATING YOUR VEHICLE In the following situations, it may also activate EXAMPLE EXAMPLE In the following objects, the radar may judge the following as a vehicle in front of you and the system may activate. EXAMPLE 54M3238 • Specially shaped vehicles such as car carriers 61MM402 •...
Page 233 OPERATING YOUR VEHICLE In situations such as the following, the radar may judge the following as a vehicle EXAMPLE EXAMPLE in front of you and the system may acti- vate. • When crossing narrow bridges • When operating on hills that have vary- ing slopes •...
Page 234 OPERATING YOUR VEHICLE Forward collision warning “FAR/NEAR setting” switch You can change the timing of when the for- When you are operating at a speed of EXAMPLE ward collision warning works, while the approximately 5 km/h (3 mph) or over system is functioning, by using the “FAR/ toward the moving vehicle or speeds between approximately 5 km/h to 80 km/h...
Page 235 OPERATING YOUR VEHICLE Warning brake system WARNING CAUTION When you are operating at a speed of approximately 30 km/h (19 mph) or over If you attempt to press the “FAR/ In the following conditions, this warn- toward the moving vehicle and if the driver NEAR setting”...
Page 236 OPERATING YOUR VEHICLE Brake assist system Automatic brake system “Radar Brake Support OFF” switch When you are operating at a speed of When a frontal collision is judged to be You can turn off the radar brake support approximately 5 km/h (3 mph) or over and unavoidable at a speed of approximately 5 system.
Page 237 OFF” switch (1) until the interior buzzer front bumper. SUZUKI dealer. buzzes and the radar brake support OFF – When there is a minor collision and indicator light (2) comes on the instru-...
Page 238 – Do not do any customizing, coat- ing light (comes on) ing or applying of non-genuine (5) “RADAR BRAKE SUPPORT: NOT SUZUKI parts to the radiator grill ACTIVE BY SENSOR.” message or front bumper. For repairs and (comes on) parts replacement, contact an (6) “RADAR BRAKE SUPPORT FCN...
Page 239 • If you clean the sensor and drive the and the radar brake support system will vehicle, but the message (5) appears turn back on. again, there might be another problem. Contact an authorized SUZUKI dealer for further assistance. 3-101...
Page 240 There may be malfunction of the adaptive rior buzzer) cruise control system. Contact your SUZUKI dealer for inspection. 54P000356 Blinks “Beep” (one time from inte- There may be a problem with the radar rior buzzer) brake support system. Have your vehicle inspected by an autho- rized SUZUKI dealer.
Page 241 If the message does not disappear for a while, have your vehicle inspected by an authorized SUZUKI dealer. 61MM436 Blinks “Beep” (one time from inte- The radar brake support system is disabled...
Page 242: Adaptive Cruise Control System (If Equipped)
OPERATING YOUR VEHICLE The adaptive cruise control system has the Adaptive Cruise Control System (if WARNING following four controls. equipped) • Deceleration control by the adap- (1) Constant-speed control tive cruise control system is lim- The adaptive cruise control system allows (There is no vehicle ahead) ited.
Page 243 OPERATING YOUR VEHICLE (2) Deceleration control NOTE: Situations where the radar will not (A vehicle ahead is within radar range • When your vehicle is getting close to the activate properly and going slower than the set speed) vehicle ahead while deceleration control or following control is functioning, a fron- WARNING tal collision warning is activated.
Page 244 OPERATING YOUR VEHICLE • When your vehicle is towing a trailer or Situations where the radar may not being towed activate properly EXAMPLE Under the following situations, the radar EXAMPLE may not detect a vehicle ahead correctly and frontal collision warning may not func- tion.
Page 245 OPERATING YOUR VEHICLE Situations where the radar may Setting cruising speed Information display unintentionally activate Adaptive cruise control switches Under the following situations, the radar EXAMPLE system detects a vehicle on the neighbor- EXAMPLE ing lane or roadside objects and frontal col- lision warning may function.
Page 246 OPERATING YOUR VEHICLE 3) Push “SET –” switch (5), “SET” indica- tor (8) and set speed indication (10) appear on the information display. If you take your foot off the accelerator pedal, the set speed will be maintained. At this time, vehicle ahead detecting indicator (9) will vary as follows, depending on the presence or absence of the vehicle ahead.
Page 247 OPERATING YOUR VEHICLE Changing following distance While adaptive cruise control indicator (7) is on, you can adjust a following distance between your vehicle and the vehicle ahead as fol- lows, by pressing following distance setting switch (1). Indication Description Short (“Dist: 1”) A following distance will be kept shorter, compared with Middle setting.
Page 248 OPERATING YOUR VEHICLE Changing speed temporarily NOTE: Canceling adaptive cruise control When the brake pedal is depressed, “SET” When the cruising speed is maintained, “SET” indicator (8) will disappear and the indicator (8) disappears until you reset the you can temporarily accelerate or deceler- adaptive cruise control system will be can- set speed.
Page 249 OPERATING YOUR VEHICLE To resume the previously set speed, push Frontal collision warning “RES +” switch (4) and turn on “SET” indi- WARNING cator (8). The vehicle speed must be • Do not use the adaptive cruise con- above about 40 km/h (25 mph) when the trol system in a heavy traffic area vehicle is not under the above conditions.
Page 250 Blinks Beep (one time from interior buzzer) There may be malfunction of the adap- tive cruise control system. Contact your SUZUKI dealer for inspection. 54P000356 Blinks Beep (one time from interior buzzer) The adaptive cruise control system and...
Page 251 Beep (one time from interior There may be a problem with the radar buzzer) brake support system. Have your vehicle inspected by an autho- rized SUZUKI dealer. 54P000357 Blinks Beep (one time from interior That is the temporarily disabled state about...
Page 252: Emergency Stop Signal (Ess) (If Equipped)
OPERATING YOUR VEHICLE Emergency Stop Signal (ESS) (if equipped) WARNING Although the ESS is designed to ESS stands for Emergency Stop Signal. reduce the number of rear-end colli- sions that occur from sudden brak- ESS is a feature that gives warning to a following vehicle by flashing all turn signal lights ing, by warning a following vehicle, it faster than usual if all the following conditions are met.
Page 253 OPERATING YOUR VEHICLE MEMO 3-115...
Page 254: Driving Tips
DRIVING TIPS DRIVING TIPS Running-in ................4-2 Catalytic Converter ............. 4-2 Improving Fuel Economy ........... 4-3 Highway Driving ..............4-4 Driving on Hills ..............4-4 Driving on Slippery Roads ..........4-5 Off-road Driving ..............4-7 When Encountering a Flooded Area ......... 4-7 60G409...
Page 255 52D078S parts that affect their functions are sult with a SUZUKI dealer or a qual- adjusted or arranged. In the follow- ified workshop. WARNING ing cases, these systems will be –...
Page 256: Running-In
DRIVING TIPS to the catalyst and other vehicle compo- Running-in Catalytic Converter nents. NOTICE NOTICE To minimize the possibility of catalyst The future performance and reliabil- or other vehicle damage: ity of the engine depends on the care • Maintain the engine in the proper and restraint exercised during its operating condition.
Page 257: Improving Fuel Economy
DRIVING TIPS Keep the air cleaner clean Improving Fuel Economy EXAMPLE The following instructions will help you improve fuel economy. Avoid excessive idling If you are to wait for more than a minute while you are parked, stop the engine and start it again later.
Page 258: Highway Driving
DRIVING TIPS • When climbing steep hills, the vehicle Highway Driving Driving on Hills may begin to slow down and show a lack of power. If this happens, you should When driving at highway speeds, pay Manual transaxle shift to a lower gear so that the engine attention to the following: will again be operating in its normal •...
Page 259: Driving On Slippery Roads
SUZUKI dealer or a wheel caps can be damaged by the Four-mode 4WD Models roadside assistance service. If a towing chain bands.
Page 260 • Do not use tires other than those and do not spin the wheels faster specified by SUZUKI. Never use dif- than an indicated 40 km/h (25 mph) ferent sizes or types of tires on the on the speedometer.
Page 261: Off-Road Driving
Grown Grass checking the brake effectiveness. Then, ask a SUZUKI dealer or a qualified work- If you drive in the field covered with grass, shop to check the following inspection it may cause accident or vehicle damage items.
Page 262: Other Controls And Equipment
OTHER CONTROLS AND EQUIPMENT OTHER CONTROLS AND EQUIPMENT Fuel Filler Cap ..............5-1 Engine Hood ................ 5-2 Sun Visor ................5-4 Interior Light ................ 5-5 Accessory Socket ............... 5-8 Sunroof (if equipped) ............5-9 Assist Grips (if equipped) ..........5-11 Glove Box ................
Page 263: Fuel Filler Cap
OTHER CONTROLS AND EQUIPMENT The fuel filler cap is located on the left rear Fuel Filler Cap side of the vehicle. The fuel filler door can EXAMPLE be unlocked by pulling up the opener lever located on the outboard side of the driver’s seat and locked by simply closing the door.
Page 264: Engine Hood
Engine Hood WARNING EXAMPLE If you need to replace the fuel cap, use a genuine SUZUKI cap. Use of an EXAMPLE improper cap can result in a malfunc- tion of the fuel system or emission control system. It may also result in fuel leakage in the event of an acci- dent.
Page 265 OTHER CONTROLS AND EQUIPMENT To close the engine hood: 1) Lift the hood up slightly and remove the CAUTION EXAMPLE prop rod from the hole. Put the prop rod To avoid injury, be sure no part of the back to the holding clip. occupant’s body such as hands or head is in the path of the hood when EXAMPLE...
Page 266: Sun Visor
OTHER CONTROLS AND EQUIPMENT Card holder (if equipped) Vanity mirror (if equipped) Sun Visor EXAMPLE EXAMPLE 80JM152 61MM0B018 (1) Mirror cover (3) Vanity mirror (2) Card holder (4) Vanity mirror light (if equipped) 79J161 The sun visors can be pulled down to block You can put a card in the card holder (2) To use the vanity mirror (3) on the back of glare coming through the windshield, or...
Page 267: Interior Light
OTHER CONTROLS AND EQUIPMENT Interior Light NOTICE EXAMPLE If the vanity mirror has the light, do not leave the mirror cover open for a EXAMPLE long time, or the battery will dis- charge. (4) / (5) 61MM0B019 (1) Glove box light (if equipped) (2) Footwell lights (if equipped) (3) Instrument panel pocket light (if equipped)
Page 268 OTHER CONTROLS AND EQUIPMENT Glove Box Light (if equipped) (1) Front (without overhead console) (4) Front (with overhead console) (5) Refer to “Glove Box” in this section. EXAMPLE Footwell Lights (if equipped) (2) A footwell light is provided in the leg space in front of each front seat.
Page 269 OTHER CONTROLS AND EQUIPMENT key, or press the engine switch to Center (with sunroof) (7) Luggage Compartment change the ignition mode to “ACC” or (if equipped) (8) “ON” during this time, the light will start to fade out immediately. After removing the key from the ignition switch, or after pressing the engine switch to change the ignition mode to “LOCK”...
Page 270: Accessory Socket
OTHER CONTROLS AND EQUIPMENT The accessory socket will work when the Accessory Socket NOTICE ignition switch is in the “ACC” or “ON” posi- tion, or the ignition mode is “ACC” or “ON”. Do not leave the tailgate open with Center console Each socket can be used to provide 12 luggage compartment...
Page 271: Sunroof (If Equipped)
If the roof around the sunroof such as by problem persists, ask an autho- sitting on it. rized SUZUKI dealer to have the • Remove water drops, snow, ice or system inspected. sand from the sunroof before open- ing.
Page 272 OTHER CONTROLS AND EQUIPMENT To tilt the sunroof To open the sunroof To close the sunroof You can close the sunroof manually by pushing the sunroof switch to “CLOSE” position (4). The sunroof will close, and then the sun shade will close. When you push the sunroof switch to “FULL CLOSE”...
Page 273: Assist Grips (If Equipped)
OTHER CONTROLS AND EQUIPMENT There is a system to prevent being Coat Hooks (if equipped) Assist Grips (if equipped) pinched by the sunroof. When the system senses that something is pinched when the sunroof is sliding for- ward or tilting down, the sunroof will auto- matically reverse direction and slide rearward or tilt up.
Page 274: Glove Box
OTHER CONTROLS AND EQUIPMENT Glove Box Overhead Console WARNING (if equipped) Do not leave cigarette lighters or spray cans in the glove box. If a cigarette EXAMPLE lighter or spray can is in a place such as the glove box, it may light acciden- tally when luggage is loaded, causing a fire.
Page 275: Cup Holder And Storage Area
OTHER CONTROLS AND EQUIPMENT Cup Holder and Storage Area WARNING • Do not drive with the overhead con- sole lid open, or the articles stowed EXAMPLE inside could fall down during brak- ing, acceleration or in the event of a collision. Always close the lid after putting something into or tak- (7) (8) ing something out of the console.
Page 276 ENG A- tally, have your vehicle inspected STOP system or SHVS may cause a by an authorized SUZUKI dealer. fire or electric shock or damage to the battery and DCDC converter. In addition, if liquid spills out on...
Page 277 OTHER CONTROLS AND EQUIPMENT Console box Universal serial bus (USB) socket Front Bottle Holder (3) / Use this stowage for keeping small items. (if equipped) Rear Bottle Holder (6) Open the compartment by raising the top EXAMPLE lid while keeping the lever (1) up. You should hold a bottle with a cap in the holder.
Page 278 OTHER CONTROLS AND EQUIPMENT Front Seat Back Pocket Rear Armrest with Cup Holders WARNING (if equipped) (5) (if equipped) (7) • If the seat belt is obstructed by any part of the armrest when fastened, EXAMPLE it cannot provide the intended pro- tection.
Page 279: Footrest
OTHER CONTROLS AND EQUIPMENT Luggage Compartment Pocket (8) Footrest Floor Mats (if equipped) EXAMPLE EXAMPLE EXAMPLE 61MM0B034 68LM543 83RM50010 To open the lid, slide the lever (1) and pull Use the footrest (1) as a support for your (1) UNLOCK the lid.
Page 280: Luggage Compartment Hooks
WARNING weather floor mats, we highly recommend Failure to take the following precau- using genuine SUZUKI floor mats for tions may result in the driver’s side proper fitting. Shopping Hook floor mat interfering with the pedals and causing a loss of vehicle control or an accident.
Page 281: Luggage Compartment Cover (If Equipped)
OTHER CONTROLS AND EQUIPMENT Cargo Net hooks (if equipped) Luggage Compartment Cover Luggage Compartment Board (if equipped) (if equipped) EXAMPLE EXAMPLE 83RM064 EXAMPLE You can hook an optional net to these hooks. 61MM0B109 61MM0B035 These hooks are not designed for large or Luggage or other cargo placed in the lug- Your vehicle is equipped with the luggage heavy items.
Page 282: Roof Rails Or Roof Rack Anchors (If Equipped)
OTHER CONTROLS AND EQUIPMENT Roof Rails or Roof Rack WARNING Anchors (if equipped) • Objects that extend higher than the luggage compartment cover (if equipped) can obstruct the driver’s Roof rails rear view, which can cause an acci- dent. These objects also become damaged or can damage...
Page 283: Frame Hooks
Frame Hooks anchors to attach the optional roof rack hang over the bumpers or the sides of which is available at your SUZUKI dealer. the vehicle, or block your view. Your SUZUKI does not recommend you If you use a roof rack, observe the instruc- •...
Page 284 OTHER CONTROLS AND EQUIPMENT To install the hook (1), follow the proce- Front dure below. EXAMPLE EXAMPLE EXAMPLE 83RM028 2) Remove the cover (C) by using a jack 61MM0B039 handle (A) covered with a soft cloth as 83RM027 1) Pick up the towing hook (1), jack handle shown in the illustration.
Page 285 OTHER CONTROLS AND EQUIPMENT Rear EXAMPLE EXAMPLE EXAMPLE 83RM029 83RM030 3) Install the towing hook (1) by hand. 4) To tighten the towing hook (1), turn it clockwise by using a wheel wrench (B) 61MM0B043 NOTE: until the hook (1) is securely installed. The frame hook (2) is provided on the rear We recommend that fasten the cover with of the vehicle for use in emergency situa-...
Page 286 OTHER CONTROLS AND EQUIPMENT Other Hooks EXAMPLE 61MM0A112 The hooks (3) (if equipped) and frame holes (5) are provided for trailer/train ship- ping purposes only. The hooks (4) are pro- vided for sea shipping purpose only. WARNING Do not use the hooks (3), (4) and the frame holes (5) for towing purpose.
Page 287: Heating And Air Conditioning System
OTHER CONTROLS AND EQUIPMENT Air Outlet Heating and Air Conditioning System There are three types of heating and air conditioning systems as follows: • Heating System • Manual Heating and Air Conditioning System • Automatic Heating and Air Conditioning System (Climate Control) EXAMPLE 61MM0B045 1.
Page 288 OTHER CONTROLS AND EQUIPMENT Side outlet Center outlet OPEN CLOSE 61MM0B046 61MM0B047 Move the knob (1) vertically or horizontally, Move the knob (1) vertically or horizontally to adjust the direction of airflow as desired. to adjust the direction of airflow as desired. CAUTION Move the dial (2) to open or close the out- let.
Page 289: Heating System
OTHER CONTROLS AND EQUIPMENT Air flow selector (3) Bi-level (b) Heating System Description of Controls 61MM0B050 Temperature-controlled air comes out of the floor outlets and cooler air comes out of the center and side outlets. When the temperature selector (1) is in the fully COLD position or fully HOT position, how- ever, the air from the floor outlets and the 61MM0A019...
Page 290 OTHER CONTROLS AND EQUIPMENT Heat & defrost (d) Air intake selector (4) （A） 61MM0B052 61MM0A020 Temperature-controlled air comes out of This selector is used to select the following the floor outlets, the windshield defroster modes. outlets, the side defroster outlets and the side outlets.
Page 291 OTHER CONTROLS AND EQUIPMENT Head cooled/Feet warmed heating System Operating Instructions Select “BI-LEVEL” and “FRESH AIR”, the EXAMPLE temperature selector to the desired tem- Natural ventilation perature position, and the blower speed Select “VENTILATION” and “FRESH AIR”, selector to the desired blower speed posi- the temperature selector to the desired tion.
Page 292: Manual Heating And Air Conditioning System
OTHER CONTROLS AND EQUIPMENT Air flow selector (3) Bi-level (b) Manual Heating and Air Conditioning System Description of Controls 61MM0B050 Temperature-controlled air comes out of the floor outlets and cooler air comes out of the center and side outlets. When the temperature selector (1) is in the fully COLD position or fully HOT position, how- ever, the air from the floor outlets and the...
Page 293 OTHER CONTROLS AND EQUIPMENT Heat & defrost (d) Air intake selector (4) （A） 61MM0B052 61MM0A020 Temperature-controlled air comes out of This selector is used to select the following the floor outlets, the windshield defroster modes. outlets, the side defroster outlets and the side outlets.
Page 294 OTHER CONTROLS AND EQUIPMENT Air conditioning switch (5) Head cooled/Feet warmed heating System Operating Instructions To turn on the air conditioning system, set Select “BI-LEVEL” and “FRESH AIR”, the the blower speed selector to a position temperature selector to the desired tem- Natural ventilation other than “OFF”...
Page 295: Maintenance
1234yf should be used in your vehicle. (For the country of Singapore) • For repair and parts replacement, have your vehicle repaired or replaced parts by an authorized SUZUKI dealer that has the mechanic qualified with SAE J2845 for air conditioner of R-1234yf. 5-33...
Page 296 OTHER CONTROLS AND EQUIPMENT NOTICE Using the wrong refrigerant may damage your air conditioning sys- tem. Use R-1234yf only. Do not mix or replace the R-1234yf with other refrig- erants. NOTE: For the air conditioning refrigerant of Rus- sia models, refer to “For Russia” in the “SUPPLEMENT”...
Page 297: Automatic Heating And Air Conditioning System (Climate Control)
OTHER CONTROLS AND EQUIPMENT (1) Left hand drive vehicle: Automatic Heating and Air Conditioning System Driver’s temperature selector Right hand drive vehicle: (Climate Control) Passenger’s temperature selector (2) Left hand drive vehicle: Passenger’s temperature selector Description of Controls Right hand drive vehicle: Driver’s temperature selector (3) “DUAL”...
Page 298 OTHER CONTROLS AND EQUIPMENT Temperature selector (1) / (2) “DUAL” switch (3) Blower speed selector (4) Every time you press the “DUAL” switch (3), the temperature control mode switches between the following: (1) / (2) Individual control mode (indicator ON): The driver and passenger can make temperature adjustments...
Page 299 OTHER CONTROLS AND EQUIPMENT Air intake selector (5) FRESH AIR (b) Ventilation (c) When this mode is selected, outside air is introduced. NOTE: If you select “RECIRCULATED AIR” for an extended period of time, the air in the vehi- cle can become contaminated. Therefore, you should occasionally select “FRESH 61MM0B049 AIR”.
Page 300 OTHER CONTROLS AND EQUIPMENT Heat (e) Defrost switch (7) NOTE: When you push the defrost switch (7), the “FRESH AIR” mode will be automatically selected and the air conditioning switch will automatically turn on (“A/C” will appear on the display). In cold weather, air flows out of the defroster outlets but the air condi- tioning does not turn on even though the A/ 61MM0B051...
Page 301 You should have the EXAMPLE (13) system inspected authorized (10) SUZUKI dealer. NOTE: • To find the temperature at which you are 61MM0A028 most comfortable, start with the 22°C You can let the climate control system (72°F) setting, for example.
Page 302 • set the blower speed selector to HIGH, your vehicle repaired or replaced parts • adjust the temperature selector to the by an authorized SUZUKI dealer that “HI” indication on the display, and has the mechanic qualified with SAE • adjust the side outlets so the air blows J2845 for air conditioner of R-1234yf.
Page 303: Radio Antenna
Consult your SUZUKI • Remove the antenna when the dealer or qualified service technician antenna hits anything such as a for advice on installing such mobile low ceiling in a parking garage or communication equipment.
Page 304: Audio System (If Equipped)
OTHER CONTROLS AND EQUIPMENT Audio system (if equipped) NOTE: For Taiwan models, refer to “For Taiwan” in the “SUPPLEMENT” section. EXAMPLE 83RM051 FM/LW/MW CD PLAYER 5-42...
Page 305: Safety Information
• Set the sound volume to a level unit, or lubricate the rotating parts. that will allow you to continue to be aware of road and traffic condi- Please bring the unit to an authorized tions while driving. SUZUKI dealer. 5-43...
Page 306 OTHER CONTROLS AND EQUIPMENT Removing the disc Proper way to hold the compact disc 52D347 52D348 To remove fingermarks and dust, use a Never stick labels on the surface of the soft cloth, and wipe in a straight line from compact disc or write on the surface with a the center of the compact disc to the cir- pencil or pen.
Page 307 OTHER CONTROLS AND EQUIPMENT 52D350 52D351 Do not use compact discs that have large Do not expose compact discs to direct sun- scratches, are misshaped, or cracked, etc. light or any heat source. Use of such discs will cause damage or prevent the system from operating prop- NOTE: erly.
Page 308 OTHER CONTROLS AND EQUIPMENT WARNING ® The Bluetooth word mark and logo are This is a class I laser product. Use registered trademarks and are owned by The latest “DECLARATION of CONFOR- of controls or adjustments or perfor- the Bluetooth SIG, Ink. MITY”...
Page 309 OTHER CONTROLS AND EQUIPMENT Information on Disposal for Users of Waste Electrical & Electronic Equip- ment (private households) This symbol on the products and/or accompanying documents means that used electrical and electronic products should not be mixed with general household waste. For proper treatment, recovery and recycling, please take these products to designated collection points, where they will be accepted on a free of charge basis.
Page 310: Basic Operations
OTHER CONTROLS AND EQUIPMENT Turning on/off power Basic operations Press “VOL PUSH PWR” knob (1) to turn on the power. The unit starts to operate in the previous setting that the power was EXAMPLE turned off. Adjusting the volume Turn “VOL PUSH PWR” knob (1). Turning it clockwise increases the volume;...
Page 311 OTHER CONTROLS AND EQUIPMENT Adjusting bass/treble/balance/fader Adjusting the AVC (Auto volume con- Preset-EQ 1) Press “TUNE/FLD PUSH SOUND” trol) Preset-EQ calls up various sound types in knob (2). The Auto Volume Control (AVC) function accordance with the listening music type. Each time the knob is pressed, sound automatically adjusts...
Page 312 OTHER CONTROLS AND EQUIPMENT Listening to the radio Display NOTE: For Taiwan models, refer to “For Taiwan” in the “SUPPLEMENT” section. EXAMPLE 68LM561 (1) “RADIO” button (2) UP button (3) DOWN button (4) “TUNE/FLD PUSH SOUND” knob (5) PRESET buttons ([1] to [6]) (6) “AS”...
Page 313 OTHER CONTROLS AND EQUIPMENT Selecting the reception band Preset memory Auto store mode on/off Press the “RADIO” button (1). 1) Select the desired station. Press “AS” button (6). Each time the button is pressed, the recep- 2) Hold down a desired button ([1] to [6]) Each time the button is pressed, the mode tion band will change as follows: of PRESET buttons (5) to which you...
Page 314 OTHER CONTROLS AND EQUIPMENT Using the RDS Functions (if equipped) Display EXAMPLE 68LM562 (1) TA button (2) RDM/PTY button (3) RPT/AF button (4) Up button (5) Down button (6) DISP button (A) Band (B) Channel number (C) Programme service (PS) name 83RM052 5-52...
Page 315 OTHER CONTROLS AND EQUIPMENT TA (Traffic Announcement) on/off PTY (Program Type) search AF (Alternative Frequency) on/off Press the TA button (1). 1) Press the RDM/PTY button (2) to Press the RPT/AF button (3). Each time it is pressed, TA adjustment is select PTY mode.
Page 316 OTHER CONTROLS AND EQUIPMENT TA Standby At the moment traffic information is received while the source is set to CD, ® USB, iPod, or Bluetooth audio with TA activated, the source is automatically changed to radio. After reception of traffic information, the source immediately before radio resumes.
Page 317 OTHER CONTROLS AND EQUIPMENT Listening to a CD Display NOTE: For Taiwan models, refer to “For Taiwan” in the “SUPPLEMENT” section. EXAMPLE (1) Insertion slot (2) EJECT button (3) “CD” button (4) UP button (5) DOWN button (6) “RPT” button (7) “RDM”...
Page 318 OTHER CONTROLS AND EQUIPMENT NOTICE NOTICE • Never insert your finger or hand If you forcefully try to push an into the CD insertion slot. Never ejected CD inside the unit before auto insert foreign objects. reloading, the disc surface might be •...
Page 319 OTHER CONTROLS AND EQUIPMENT Random playback Display change Press “RDM” button (7). Press “DISP” button (8). Each time the button is pressed, the mode Each time the button is pressed, display will change as follows: will change as follows: Play time TRACK RANDOM Disc title Track title...
Page 320 OTHER CONTROLS AND EQUIPMENT Listening to an MP3/WMA/AAC disc Display EXAMPLE (1) “TUNE/FLD PUSH SOUND” knob (2) UP button (3) DOWN button (4) “RPT” button (5) “RDM” button (6) “DISP” button (A) Folder number (B) Track number (C) Play time (D) Disc type 61MM712 5-58...
Page 321 OTHER CONTROLS AND EQUIPMENT Selecting a folder Random playback Repeat playback Turn “TUNE/FLD PUSH SOUND” knob (1) Press “RDM” button (5). Press “RPT” button (4). to select a folder. Each time the button is pressed, the mode Each time the button is pressed, the mode will change as follows: will change as follows: Selecting a track...
Page 322 OTHER CONTROLS AND EQUIPMENT Display change Points to remember when making MP3/ Notes on MP3/WMA/AAC Press “DISP” button (6). WMA/AAC files Each time the button is pressed, display Common What is MP3? will change as follows: • High bit rate and high sampling fre- •...
Page 323 OTHER CONTROLS AND EQUIPMENT Recording MP3/WMA/AAC files on a CD Compression formats media • It is recommended not to write both CD- • Bit rate: DA files and MP3/WMA/AAC files on a MPEG1 Audio Layer III: 32 k - 320 kbps disc.
Page 324 OTHER CONTROLS AND EQUIPMENT Listening to Files Stored in a USB Device Display EXAMPLE (1) “USB” button (2) “TUNE/FLD PUSH SOUND” knob (3) UP button (4) DOWN button (5) “RPT” button (6) “RDM” button (7) “DISP” button (A) Folder number (B) Track number (C) Play time (D) File type...
Page 325 OTHER CONTROLS AND EQUIPMENT Selecting a USB device mode Random playback • FOLDER REPEAT Press “USB” button (1). Press “RDM” button (6). The repeat indicator “F.RPT” will light. Each time the button is pressed, the mode Each time the button is pressed, the mode All the tracks in the folder currently will change as follows: will change as follows:...
Page 326 OTHER CONTROLS AND EQUIPMENT USB device connection Compression formats Notes on USB device • When connecting a USB device, check that the connector is pushed all the way • Bit rate: Compatible USB devices into the port. MPEG1 Audio Layer III: 32 k - 320 kbps •...
Page 327: Listening To An Ipod
OTHER CONTROLS AND EQUIPMENT Listening to an iPod Display EXAMPLE (1) “USB” button (2) “TUNE/FLD PUSH SOUND” knob (3) UP button (4) DOWN button (5) “RPT” button (6) “RDM” button (7) “DISP” button (8) PRESET buttons ([1] to [6]) (A) Track title (B) Track number (C) Play time 61MM714...
Page 328 OTHER CONTROLS AND EQUIPMENT Selecting an iPod mode Random playback Display change Press “USB” button (1). Press “RDM” button (6). Press “DISP” button (7). Each time the button is pressed, the mode Each time the button is pressed, the mode Each time the button is pressed, display will change as follows: will change as follows:...
Page 329 OTHER CONTROLS AND EQUIPMENT Playing mode selection iPod Notes on iPod 1) Press the button numbered [6] of PRE- SET buttons (8) for 1 second or longer. Made for iPod 2) Turn “TUNE/FLD PUSH SOUND” knob • iPod touch (5th generation) (2).
Page 330 OTHER CONTROLS AND EQUIPMENT ® Bluetooth Hands-free (if equipped) Steering switch EXAMPLE ® (4) Bluetooth setup button (5) OFF HOOK button 61MM715 (6) ON HOOK button (1) “TUNE/FLD PUSH SOUND” knob (7) “VOL” switch (2) “VOL PUSH PWR” knob (3) PRESET buttons 5-68...
Page 331 OTHER CONTROLS AND EQUIPMENT Phone registration NOTE: Adjusting the ring volume • When selecting “Go Back”, the previous • Turn “VOL PUSH PWR” knob (2) while a To use the hands-free function with this menu will be displayed. call is coming in. unit, it is required to register the phone •...
Page 332 OTHER CONTROLS AND EQUIPMENT NOTE: Dialing using missed/incoming/ NOTE: When selecting “Go Back”, the previous outgoing calls • When selecting “Go Back”, the previous menu will be displayed. Follow the instructions below to dial to the menu will be displayed. previously dialed number again.
Page 333 OTHER CONTROLS AND EQUIPMENT 7) Turn “TUNE/FLD PUSH SOUND” knob 7) Transfer contacts from the phone. NOTE: (1) to select “Confirm”, and press the When the registration is completed, the When selecting “Go Back”, the previous knob (1) to complete the deletion. “Setup Phonebook”...
Page 334 OTHER CONTROLS AND EQUIPMENT Deletion of registered data (Delete Registration in speed dial When the assignment is completed, the Entry) Follow the instructions below to assign a “Setup Phonebook” will be displayed. Follow the instructions below to delete a number to one of PRESET buttons (3) to NOTE: number registered in phonebook.
Page 335 OTHER CONTROLS AND EQUIPMENT Deletion of speed dial (Del Speed Dial) Display of device data (Device Name) Reset to the factory defaults Follow the instructions below to delete the Follow the instructions below to display the Follow the instructions below to reset all ®...
Page 336 OTHER CONTROLS AND EQUIPMENT Selection of phone (Select Phone) List of phones (List Phones) 4) Turn “TUNE/FLD PUSH SOUND” knob Follow the instructions below to select a Follow the instructions below to display the (1) to select “New Passkey”, and press phone to be paired with from the registered names of the registered phones in the knob (1) to determine the selection.
Page 337 OTHER CONTROLS AND EQUIPMENT Deletion of phone information (Delete BT function on/off (BT Power) Phone) Follow the instructions below to turn on/off ® Follow the instructions below to delete the the Bluetooth function. ® registered phone information. 1) Press the Bluetooth setup button (4).
Page 338 OTHER CONTROLS AND EQUIPMENT ® Bluetooth audio (if equipped) Steering switch EXAMPLE Display (1) “USB” button (2) “TUNE/FLD PUSH SOUND” knob (3) UP button (4) DOWN button (5) “DISP” button ® 61MM720 (6) Bluetooth setup button (A) Track number (B) Play time 5-76...
Page 339 OTHER CONTROLS AND EQUIPMENT Registration of audio devices NOTE: Fast forwarding/rewinding a track • When selecting “Go Back”, the previous • Hold down UP button (3) to fast forward menu will be displayed. the track. ® To use Bluetooth ready audio devices •...
Page 340 OTHER CONTROLS AND EQUIPMENT Selection of audio device (Select Audio) List of audio devices (List Audio) 4) Turn “TUNE/FLD PUSH SOUND” knob Follow the instructions below to select an Follow the instructions below to display the (2) to select “New Passkey”, and press audio device to be paired with from the names of the registered audio devices in the knob (2) to determine the selection.
Page 341 OTHER CONTROLS AND EQUIPMENT Deletion of audio device information ® Disclaimer for Bluetooth function Remote audio controls (if equipped) (Delete Audio) Follow the instructions below to delete the • Depending on compatibility of mobile Controlling basic functions of the audio ®...
Page 342 OTHER CONTROLS AND EQUIPMENT Adjusting the volume Selecting the radio station (FM1, FM2, • To increase the volume, hold down “+” of AM mode) “VOL” switch (1). The volume will con- • To select the next preset station, press tinue to increase until the switch is “...
Page 343: Anti-Theft Feature
OTHER CONTROLS AND EQUIPMENT The anti-theft function is intended to dis- Anti-theft feature courage thefts. For example, when the audio system is installed in another vehi- EXAMPLE cle, it will become unable to operate. This function works by entering a Personal Identification Number (PIN).
Page 344 OTHER CONTROLS AND EQUIPMENT Setting the anti-theft function Canceling the anti-theft feature Confirming the Personal Identification 1) Press “VOL PUSH PWR” knob (1) to To cancel the anti-theft function, delete the Number (PIN) power off. registered PIN. When the main power source is discon- 2) Hold down the buttons numbered [1] 1) Press “VOL PUSH PWR”...
Page 345: Troubleshooting
OTHER CONTROLS AND EQUIPMENT Troubleshooting When encountering a problem, check and follow the instructions below. If the described suggestions do not solve the problem, it is recommended to take the unit to your authorized SUZUKI dealer. Problem Possible cause Possible solution Common When “SECURITY”...
Page 346 OTHER CONTROLS AND EQUIPMENT Problem Possible cause Possible solution MP3/WMA/AAC The disc contains unsupported formatted No playback Check the file format. data. Sound skipping may occur when playing Sound skips or noise produced It is not recommended to play VBR files. VBR (Variable Bit Rate) files.
Page 347 OTHER CONTROLS AND EQUIPMENT Error display messages Display Possible cause Possible solution Insert the disc with its label side up. Check the disc if it is not warped or is free of flaws. “ERROR 1” The disc cannot be read. When “ERROR 1”...
Page 348 OTHER CONTROLS AND EQUIPMENT Display Possible cause Possible solution ® Bluetooth ® Disconnect the Bluetooth ready device and connect it The player developed an error of an again. “ERROR 1” unidentified cause. When “ERROR 1” does not disappear, contact your dealer.
Page 349 OTHER CONTROLS AND EQUIPMENT MEMO 5-87...
Page 350: Vehicle Loading And Towing
VEHICLE LOADING AND TOWING VEHICLE LOADING AND TOWING Vehicle Loading (vehicle equipped with genuine trailer hitch) ....6-1 Trailer Towing ..............6-1 54G215...
Page 351: Trailer Towing
VEHICLE LOADING AND TOWING Vehicle Loading (vehicle Trailer Towing WARNING equipped with genuine trailer Never overload your vehicle. The gross vehicle weight (sum of the hitch) weights of the vehicle, all the occu- pants, accessories, cargo plus trailer Your vehicle was designed for specific nose weight if towing a trailer) must weight capacities.
Page 352 We recommend that you use a genuine for attaching safety chains. Always leave do not use adaptive cruise control SUZUKI tow bar (available as options), or just enough slack to permit full turning. system. If not, accidents related to equivalent.
Page 353 VEHICLE LOADING AND TOWING Trailer Lights Brakes Mirrors Make sure your trailer is equipped with Check to see if your vehicle’s mirrors meet WARNING lights which meet local requirements. local requirements for mirrors used on tow- Always check for the proper operation of ing vehicles.
Page 354 VEHICLE LOADING AND TOWING Additional Trailer Towing Warnings WARNING WARNING Improper weight distribution of your Your vehicle will handle differently WARNING trailer may result in poor vehicle han- when towing a trailer. For your safety dling and swaying of the trailer. and the safety of others, you should Connect trailer lights and hook up Always make sure that trailer nose...
Page 355 VEHICLE LOADING AND TOWING WARNING WARNING (Continued) (Continued) • If the trailer has over-run brakes, • Avoid “riding” the brakes. This apply the brakes gradually to avoid could cause the brakes to over- snatching caused by the trailer heat resulting in reduced braking wheels locking.
Page 356 VEHICLE LOADING AND TOWING Trailer hitch installation points WARNING (Continued) When starting out after parking: 1) Depress the clutch and start the engine. 2) Shift into gear, release the parking brake, and slowly pull away from the chocks. “a” 3) Stop, apply the brakes firmly and hold them.
Page 357 VEHICLE LOADING AND TOWING MEMO...
Page 358: Inspection And Maintenance
INSPECTION AND MAINTENANCE INSPECTION AND MAINTENANCE Maintenance Schedule ............7-2 Periodic Maintenance Schedule (except for Russia and Taiwan) ........7-3 Maintenance Recommended under Severe Driving Conditions (except for Russia and Taiwan) ........7-8 Drive Belt ................7-13 Engine Oil and Filter ............7-14 Engine Coolant ..............
Page 359 SUZUKI. Do not touch airbag system hoses. components, seat belt pretensioner • Do not allow smoking, sparks, or system components or wires. flames around fuel or the battery.
Page 360: Maintenance Schedule
SUZUKI recommends that mainte- nance on items marked with an aster- performed your authorized SUZUKI dealer or a quali- fied service technician. If you are qualified, you may perform mainte- nance on the unmarked items by referring to the instructions in this section.
Page 361: Periodic Maintenance Schedule (Except For Russia And Taiwan)
INSPECTION AND MAINTENANCE Periodic Maintenance Schedule (except for Russia and Taiwan) “R” : Replace or Change “I” : Inspect, clean, adjust, lubricate or replace as necessary NOTE: • Class 1: K14C engine • Class 2: K14D engine NOTE: This table shows the service schedule up to 240000 km (150000 miles). Beyond 240000 km (150000 miles), perform the same services at the same intervals shown in the chart.
Page 362 #2: Be sure to perform the engine coolant level check under the daily inspection in “OPERATING YOUR VEHICLE” section. If you use the engine coolant other than the SUZUKI LLC: Super (Blue) for replacement, follow the schedule of SUZUKI LLC: Stan-...
Page 363 #2: Be sure to perform the engine coolant level check under the daily inspection in “OPERATING YOUR VEHICLE” section. If you use the engine coolant other than the SUZUKI LLC: Super (Blue) for replacement, follow the schedule of SUZUKI LLC: Stan-...
Page 364 *6-7. Steering system – – – *6-8. Manual transaxle oil Genuine “SUZUKI GEAR OIL 75W” Inspect every 40000 km (25000 miles) or 24 months. Other than “SUZUKI GEAR OIL 75W” – – – *6-9. Automatic transaxle Fluid leak check –...
Page 365 *6-7. Steering system – – – *6-8. Manual transaxle oil Genuine “SUZUKI GEAR OIL 75W” Inspect every 40000 km (25000 miles) or 24 months. Other than “SUZUKI GEAR OIL 75W” – – – *6-9. Automatic transaxle Fluid leak check –...
Page 366: Maintenance Recommended Under Severe Driving Conditions (Except For Russia And Taiwan)
INSPECTION AND MAINTENANCE Maintenance Recommended under Severe Driving Conditions (except for Russia and Taiwan) Follow this schedule if your vehicle is mainly operated under one or more of the following conditions: • When most trips are less than 6 km (4 miles). •...
Page 367 #2: Be sure to perform the engine coolant level check under the daily inspection in “OPERATING YOUR VEHICLE” section. If you use the engine coolant other than the SUZUKI LLC: Super (Blue) for replacement, follow the schedule of SUZUKI LLC: Stan-...
Page 368 #2: Be sure to perform the engine coolant level check under the daily inspection in “OPERATING YOUR VEHICLE” section. If you use the engine coolant other than the SUZUKI LLC: Super (Blue) for replacement, follow the schedule of SUZUKI LLC: Stan- dard (Green).
Page 369 – *6-9. Manual transaxle oil Genuine “SUZUKI GEAR OIL 75W” Inspect every 20000 km (12500 miles) or 12 months. Replace every 80000 km (50000 miles) or 48 months. Other than “SUZUKI GEAR OIL 75W” – – – *6-10. Automatic transaxle Fluid leak check –...
Page 370 – *6-9. Manual transaxle oil Genuine “SUZUKI GEAR OIL 75W” Inspect every 20000 km (12500 miles) or 12 months. Replace every 80000 km (50000 miles) or 48 months. Other than “SUZUKI GEAR OIL 75W” – – – *6-10. Automatic transaxle Fluid leak check –...
Page 371: Drive Belt
(6) Idler pulley If you need to replace or adjust the belt Drive belt deflection (100 N (10 kg, 22 Drive belt deflection (100 N (10 kg, 22 have it done by your SUZUKI dealer. lbs) press) lbs) press) (a) New: (a) New: 5.7 - 6.4 mm (0.22 - 0.25 in.)
Page 372: Engine Oil And Filter
Since special procedures, materials and • The replacement timing varies with the tools are required, it is recommended that type of engine oil that you choose. Refer you trust this job to an authorized SUZUKI to “Maintenance schedule” in this sec- dealer. Specified Oil tion for corresponding maintenance schedule.
Page 373: Oil Level Check
SAE 0W-20 (1) is the best choice for good tion for corresponding maintenance fuel economy and good starting in cold schedule. weather. • SUZUKI highly recommends the use of ECSTAR brand engine oil. ECSTAR has NOTE: been specially formulated for your • The replacement timing varies with the SUZUKI product and contributes to the type of engine oil that you choose.
Page 374 To reset the oil life monitoring Pull out the oil dipstick, wipe oil off with a system, consult your SUZUKI dealer. clean cloth, insert the dipstick all the way 3) When the engine oil level exceeds the into the engine, then remove it again.
Page 375: Changing Engine Oil And Filter
INSPECTION AND MAINTENANCE Changing Engine Oil and Filter EXAMPLE EXAMPLE Drain the engine oil while the engine is still warm. Open Close EXAMPLE 56KN054 60G306 2) Remove the oil filler cap. Tightening torque for drain plug 3) Place a drain pan under the drain plug. 35 Nm (3.6 kg-m, 25.8 lb-ft) 4) Using a wrench, remove the drain plug WARNING...
Page 376: Replacing The Oil Filter
To reset the oil change request light, consult your SUZUKI dealer. If you reset it by yourself, refer to “Setting Mode” in “Information Display”...
Page 377 (1) Oil filter • When replacing the oil filter, it is (2) 3/4 turn recommended that you use a genu- ine SUZUKI replacement filter. If NOTICE you use an aftermarket filter, make To tighten the oil filter properly, it is...
Page 378: Engine Coolant
Failure to use the proper coolant can dam- Coolant Level Check Engine Coolant age your cooling system. Your authorized SUZUKI dealer can help you select the Check the coolant level at the reservoir proper coolant. tank, not at the radiator. With the engine...
Page 379 Remove the reservoir tank cap and add SUZUKI LLC: Super (Blue) coolant; coolant until the reservoir tank level SUZUKI LLC: Super (Blue) coolant is reaches the “FULL” mark. Never fill the already diluted to the proper percent- reservoir tank above the “FULL” mark.
Page 380: Coolant Replacement
(degassing tank cap) will be greater intake resistance, resulting SUZUKI dealer for coolant replacement. when the water temperature is high, in decreased power output and increased because scalding fluid and steam fuel consumption.
Page 381 INSPECTION AND MAINTENANCE For K14C engine model 61MM0B064 83RM032 3) Unclamp the side clamps, and remove 1) Lift the engine cover directly above. the element from the air cleaner case. If 54P020702 it appears to be dirty, replace it with a 2) Unclamp the side clamps and remove new one.
Page 382: Spark Plugs
For K14D engine models Since special procedures, materials and tools are required, it is recommended that you trust this job to your authorized SUZUKI dealer. 83RM70030 83RM70040 1) Loosen the bolt (1) and pull the duct 2) Unclamp the side clamps (3) and (2).
Page 383 INSPECTION AND MAINTENANCE For M16A and K14C engine models To access the spark plug: EXAMPLE EXAMPLE 1) Lift the air cleaner case up. • For M16A engine, refer to “Air Cleaner” in this section. Correct Wrong 83RM017 78K179 2) If necessary, disconnect the coupler (6) while pushing the release lever.
Page 384: Gear Oil
(4WD)/Rear Differential Oil (4WD) When adding gear oil, use gear oil with the appropriate viscosity and grade as shown in the chart below. We highly recommend you use: “SUZUKI GEAR OIL 75W” for manual tran- saxle gear oil. 60G160 54G106 Manual transaxle oil Spark plug gap “a”...
Page 385 INSPECTION AND MAINTENANCE We highly recommend you use: Transfer (4WD) Gear Oil Level Check “SUZUKI GEAR OIL 75W-85” for transfer oil (4WD) and rear differential oil (4WD). 5-speed manual transaxle Transfer oil (4WD) EXAMPLE Rear differential oil (4WD) 75W-85 EXAMPLE...
Page 386: Clutch
If the play is more or less than the above, or clutch dragging is felt with the Transfer (3) / Rear differential (4): pedal fully depressed, have the clutch 23 Nm (2.3 kg-m, 17.0 lb-ft) inspected by an authorized SUZUKI dealer. 7-28...
Page 387: Clutch Fluid
Have your vehicle inspected immedi- ately by a SUZUKI dealer or a quali- fied workshop. 61MM0B067 Check the clutch fluid level by looking at the reservoir in the engine compartment.
Page 388 In this case, – Do not use any fluid other than ask a SUZUKI dealer or a qualified SAE J1704 or DOT4 brake fluid. workshop to inspect the brake sys- Do not use reclaimed fluid or tem.
Page 389: Brake Pedal
If not, have the brake sys- ness, squealing noise sounds during Since your vehicle’s brake system is self- tem inspected by your SUZUKI dealer. If braking. adjusting, there is no need for pedal you doubt the brake pedal for the regular If you hear this noise, have the vehi- adjustment.
Page 390: Steering
SUZUKI dealer. by your SUZUKI dealer. 7-32...
Page 391: Tires
INSPECTION AND MAINTENANCE appear to be at the specified pressure Tire Inspection Tires when checked after driving, when the tires are warm, could have pressure below the Inspect your vehicle’s tires at least once a specification when the tires cool down. month by performing the following checks: Also, tires that are inflated to the specified 1) Measure the air pressure with a tire...
Page 392 For 4WD models, replacing a tire with one of a different size, or using differ- 54G136 • Your SUZUKI is equipped with tires ent brands among the four tires can (1) Tread wear indicator which are all the same type and result in damage to the drive train.
Page 393: Tire Rotation
INSPECTION AND MAINTENANCE Note that two or more compact spare tires Tire Rotation Compact Spare Tire (if equipped) should not be used on one vehicle simulta- neously. 4-tire rotation WARNING The compact spare tire and wheel are intended for temporary emergency use only.
Page 394: Battery
INSPECTION AND MAINTENANCE • The lead-acid battery and lithium-ion Battery WARNING battery discharge gradually. In order to avoid a flat battery, drive the vehicle (Continued) This vehicle is equipped with the following once a month for at least 30 minutes to •...
Page 395 INSPECTION AND MAINTENANCE Replacement of the battery NOTICE EXAMPLE EXAMPLE If your vehicle is equipped with the ENG A-STOP system, it uses a lead- acid battery specifically for the high- efficiency A-STOP system, observe the following precautions. Failure to observe these precautions may result in a malfunction of the system or a shortened battery life.
Page 396 SUZUKI dealer. “LOCK” (OFF). If the battery termi- could otherwise be caused by inappropri- ate trash handling of the battery. The recy- nal is disconnected within 3 min-...
Page 397: Fuses
INSPECTION AND MAINTENANCE mation about disposing or recycling of the Fuses in the Engine Compartment Fuses used battery, consult your SUZUKI dealer. Your vehicle has three types of fuses, as Lithium-ion Battery (if equipped) described below: Main fuse This battery is installed only in models...
Page 398 INSPECTION AND MAINTENANCE *1, *2, *3 25 A Headlight (31) – Blank MAIN FUSE / PRIMARY FUSE (14) *1, *2 20 A Headlight (32) 15 A Transaxle 5 50 A (15) 30 A Back up (33) 7.5 A Starting signal 50 A *1, *2 *1, *2, *3...
Page 399: Fuses Under The Dash Board
When replacing the main fuse, a primary fuse or an individual fuse, use a genuine SUZUKI replacement. To remove a fuse, use the fuse puller pro- vided in the fuse box. The amperage of each...
Page 400 15 A Radio problem. Have your vehicle 15 A Accessory socket 2 inspected immediately your (31) 10 A Tail lamp SUZUKI dealer. (10) 30 A Power window (32) 20 A (11) 10 A Hazard (33) 7.5 A Cruise control 7-42...
Page 401: Headlight Aiming
CAUTION occur by driving on a rainy day or washing SUZUKI dealer for headlight alignment. the vehicle. This is a temporary phenome- • Light bulbs can be hot enough to non caused by temperature difference...
Page 402 Since special procedures are required, we Replace the target assembly if any bulb is recommend you take your vehicle to your defective. If you need to replace the SUZUKI dealer for bulb replacement. assembly, ask your SUZUKI dealer. • Headlight (LED type) Halogen headlights •...
Page 403: Side Turn Signal Light (If Equipped)
INSPECTION AND MAINTENANCE High beam Side Turn Signal Light (if equipped) 83RM080 83RM079 3) Push the retaining spring (4) forward For the high beam; and unhook it. Then remove the bulb 64J195 2) Turn the bulb holder (3) counterclock- (5). As the bulb is built-in type, the light assem- wise and remove it.
Page 404 INSPECTION AND MAINTENANCE Front Turn Signal Light (1) EXAMPLE Front Position Light (2) (Vehicle with the halogen headlights) 83RM081 61MM0B078 1) Open the engine hood. To remove the (3) Removal bulb holder of the front turn signal light (4) Install (1) or the front position light (2) from the 2) To remove the bulb of the front turn sig- light housing, turn the holder counter-...
Page 405: Front Fog Light (If Equipped)
INSPECTION AND MAINTENANCE (Vehicle with the LED headlights) Front Fog Light (if equipped) EXAMPLE 1) Start the engine. Turn the steering wheel to the opposite side of the replac- ing fog light to replace the bulb easily. Then turn off the engine. 83RM035 83RM068 3) Remove the clips (2) by prying it off with...
Page 406: Daytime Running Light (If Equipped)
INSPECTION AND MAINTENANCE 1) To approach the daytime running light, Daytime Running Light open the end of the cover inside the EXAMPLE (if equipped) front fender. Refer to the procedure for the bulb replacement of the “Front Fog Models without front fog light Light”...
Page 407: Rear Combination Light
INSPECTION AND MAINTENANCE Rear Combination Light EXAMPLE EXAMPLE EXAMPLE (3) / (4) 61MM0B083 61MM0B084 2) To remove the bulb holder of the rear (5) Removal turn signal light (3) or the bulb type tail/ (6) Install 61MM0B082 brake light (4) (if equipped) from the 1) Remove the bolts (1) and pull the light 3) To remove the bulb of the rear turn sig- light housing, turn the holder counter-...
Page 408: Reversing Light
INSPECTION AND MAINTENANCE 2) Disconnect the coupler (3) by pushing Reversing Light the lock release. Turn the bulb holder of EXAMPLE the reversing light (4) counterclockwise and remove it. EXAMPLE 61MM0B085 NOTE: When reinstalling the light housing, make 61MM0B088 sure the clips are properly attached. 1) Open the tailgate.
Page 409: License Plate Light
1) Turn the cover (1) counterclockwise to license plate light (2), simply pull out or remove it. push in the bulb. 83RM70070 Since special procedures are required, it is recommended that you take your vehicle to an authorized SUZUKI dealer for bulb replacement. 7-51...
Page 410: High-Mount Stop Light
INSPECTION AND MAINTENANCE High-mount Stop Light EXAMPLE EXAMPLE 63J127 80JM076 EXAMPLE 2) Close the tailgate. Remove the high- 3) Pushing the unguiform prongs (3) mount stop light housing (2) from the inward and remove the bulb holder (4). 80J100 tailgate. 1) Open the tailgate, and remove the nuts (1) as shown in the illustration.
Page 411: Rear Fog Light
Rear Fog Light EXAMPLE Since special procedures are required, we recommend you take your vehicle to your SUZUKI dealer for bulb replacement. Interior Light Remove the lens by using a flat-bladed screwdriver covered with a soft cloth as shown. To install it, simply push it back in.
Page 412 INSPECTION AND MAINTENANCE Center (with sunroof) Glove Box Light (if equipped) Since special procedures are required, we recommend you take your vehicle to your SUZUKI dealer for bulb replacement. EXAMPLE 61MM0B096 61MM0A130 2) Push the damper (1) leftward to remove Luggage compartment (if equipped) the grove box.
Page 413: Wiper Blades
INSPECTION AND MAINTENANCE NOTE: Wiper Blades Some wiper blades may be different from the ones described here depending on vehicle specifications. If so, consult your SUZUKI dealer for proper replacement method. For windshield wipers: EXAMPLE EXAMPLE 61MM0A210 2) Open the lock (1), slide the wiper frame...
Page 414 INSPECTION AND MAINTENANCE 3) Pull the locked end of the wiper blade firmly to unlock the blade and slide the EXAMPLE EXAMPLE blade out as shown. EXAMPLE 61MM0B098 61MM0A212 (A) Up (B) Down 71LMT0708 NOTE: (3) Retainer When you install the metal retainers (3), make sure the direction of metal retainers 4) If the new blade is provided without the as shown in the above illustrations.
Page 415 INSPECTION AND MAINTENANCE For rear wipers: EXAMPLE EXAMPLE EXAMPLE 61MM0A213 65D151 (4) Locked end NOTE: Do not flex the wiper blade frame end more 5) Install the new blade in the reverse than necessary. If you do, it can break off. order of removal, with the locked end (4) positioned toward the wiper arm.
Page 416: Windshield Washer Fluid
INSPECTION AND MAINTENANCE Check that there is washer fluid in the tank Windshield Washer Fluid by looking at the washer fluid level gauge EXAMPLE which is attached to the cap of the washer fluid tank. If the fluid level is near empty, refill it.
Page 417: Air Conditioning System
SUZUKI dealer for the air conditioner filter start using it again. To help maintain opti- replacement. mum performance and durability of your air conditioner, it needs to be run periodically.
Page 418: Emergency Service
EMERGENCY SERVICE EMERGENCY SERVICE Tire Changing Tool ............. 8-1 Jacking Instructions ............8-1 Flat Tire Repair Kit (if equipped) ........8-5 Jump Starting Instructions ..........8-8 Towing .................. 8-10 If the Starter Does Not Operate .......... 8-11 If the Engine is Flooded ............8-11 If the Engine Overheats ............
Page 419: Tire Changing Tool
EMERGENCY SERVICE Tire Changing Tool Jacking Instructions WARNING After using the tire changing tools, be sure to stow them securely or they EXAMPLE can cause injury if an accident occurs. CAUTION The jack should be used only to change wheels. It is important to read the jacking instructions in this sec- tion before attempting to use the jack.
Page 420 EMERGENCY SERVICE 3) Turn on the hazard warning flasher if 7) Continue to raise the jack slowly and your vehicle is near traffic. smoothly until the tire clears the 4) Block the front and rear of the wheel ground. Do not raise the vehicle more diagonally opposite of the wheel being than necessary.
Page 421 (commercially available) at the points indicated below. NOTE: For more details, please contact an autho- Front jacking point for garage jack (1) rized SUZUKI dealer. EXAMPLE Changing Wheels To change a wheel, use the following pro- 61MM0B043 cedure:...
Page 422 6) Install the new wheel and replace the torque checked by an authorized wheel bolts with their cone shaped end SUZUKI dealer. facing the wheel. Tighten each bolt snugly by hand until the wheel is securely seated on the hub.
Page 423: Flat Tire Repair Kit (If Equipped)
EMERGENCY SERVICE Full Wheel Cover (if equipped) Flat Tire Repair Kit EXAMPLE (if equipped) EXAMPLE The flat tire repair kit is stowed in the lug- gage compartment. Refer to “Luggage Compartment” in the “ILLUSTRATED TABLE OF CONTENTS” section. WARNING Failure to follow the instructions in this section for using the flat tire 52RM603 repair kit can result in an increased...
Page 424 The Flat Tire Repair Kit cannot be used WARNING in the following cases. Consult a Flat tire repair kit sealant is harmful if SUZUKI Dealer or a Roadside Assis- swallowed, or it comes in contact tance Service. with skin or eyes. If swallowed, do •...
Page 425 EMERGENCY SERVICE sult a SUZUKI Dealer or a Roadside Assis- How to Perform an Emergency tance Service. 10 min. Max. Repair NOTE: 1) Place the vehicle on level, hard ground. required If over inflated, deflate air by loosening the Set the parking brake firmly and shift air pressure screw of the filler hose.
Page 426: Jump Starting Instructions
10 minutes. It can cause are not touching each other. After using the sealant bottle, replace overheating of the compressor. • If your battery discharges repeat- it with a new bottle from your SUZUKI edly, for no apparent reason, have dealer. your vehicle inspected authorized SUZUKI dealer.
Page 427 EMERGENCY SERVICE NOTICE WARNING Your vehicle should not be started by Never connect the jump lead directly pushing or towing. This starting to the negative (–) terminal of the dis- method could result in permanent charged battery, or an explosion may damage to the catalytic converter.
Page 428: Towing
EMERGENCY SERVICE 2-Wheel Drive (2WD) Automatic 2-Wheel Drive (2WD) Manual Tran- Towing Transaxle saxle If you need to have your vehicle towed, Automatic transaxle vehicles may be Manual transaxle vehicles may be towed contact a professional service. Your dealer towed using either of the following meth- using either of the following methods.
Page 429: If The Starter Does Not Operate
SUZUKI dealer. engine. • Do not operate the starter motor for more than 12 seconds. NOTE: If the engine refuses to start, the starter motor automatically stops after a certain period of time.
Page 430: If The Engine Overheats
If your engine overheats and you are pressure. The cap should only be can no longer be seen or heard, open unsure what to do, contact your SUZUKI taken off when the coolant tem- the hood to see if the coolant is still dealer.
Page 431 EMERGENCY SERVICE MEMO 8-13...
Page 432: Appearance Care
APPEARANCE CARE APPEARANCE CARE Corrosion Prevention ............9-1 Vehicle Cleaning ..............9-2 60G412...
Page 433: Corrosion Prevention
APPEARANCE CARE 4) High temperatures will cause an accel- Remove foreign material deposits Corrosion Prevention erated rate of corrosion to parts of the Foreign material such as salts, chemicals, vehicle which are not well ventilated to road oil or tar, tree sap, bird droppings and It is important to take good care of your permit quick drying.
Page 434: Vehicle Cleaning
APPEARANCE CARE spill or leak does occur, clean and dry the Vehicle Cleaning area immediately. WARNING On models equipped with SHVS, Store your vehicle in a dry, well-venti- there are a lithium-ion battery under lated area the front right side seat and a DCDC Do not park your vehicle in a damp, poorly converter the front left side seat.
Page 435 APPEARANCE CARE Leather upholstery Seat belts Remove loose dirt with a vacuum cleaner. Clean seat belts with a mild soap and WARNING Using a mild soap or saddle soap solution, water. Do not use bleach or dye on the Do not spray the interior with water wipe dirt off with a clean damp soft cloth.
Page 436 APPEARANCE CARE Washing by hand Cleaning the Exterior Washing NOTICE WARNING It is important that your vehicle be • Never attempt to wash and wax kept clean and free from dirt. Failure your vehicle with the engine run- to keep your vehicle clean may result ning.
Page 437 APPEARANCE CARE 2) Rinse the body to loosen the dirt. 6) Check carefully for damage to painted Washing by an automatic car wash Remove dirt and mud from the body surfaces. If there is any damage, exterior with running water. You may “touch-up”...
Page 438 APPEARANCE CARE Waxing 60B211S After washing the vehicle, waxing and pol- ishing are recommended to further protect and beautify the paint. • Only use waxes and polishes of good quality. • When using waxes polishes, observe the precautions specified by the manufacturers.
Page 439 APPEARANCE CARE MEMO...
Page 440: General Information
GENERAL INFORMATION GENERAL INFORMATION Vehicle Identification ............10-1 84MM01001...
Page 441: Vehicle Identification
Whenever you have occasion tion. 63J104 to consult your SUZUKI dealer, remember to identify your vehicle with this number. Should you find the number difficult to read, you will also find it on the identifica- tion plate.
Page 442: Specifications
SPECIFICATIONS SPECIFICATIONS NOTE: Specifications are subject to change without notice. M/T: Manual transaxle 2WD: 2-wheel drive A/T: Automatic transaxle 4WD: 4-wheel drive ITEM: Dimensions UNIT: mm (in.) Overall length 4300 (169.3) Overall width 1785 (70.3) Overall height 1580 – 1585 (62.2 – 62.4) Wheelbase 2600 (102.4) Track...
Page 443 SPECIFICATIONS ITEM: Mass (weight) UNIT: kg (lbs) M16A K14C K14D engine K14D engine engine model engine model M/T model A/T model Curb mass (weight) 1085 – 1155 1150 – 1175 1180 – 1215 – (2392 – 2546) (2535 – 2590) (2601 –...
Page 444 (for K14D engine model) Lithium-ion battery with SHVS Maintenance free* Fuses See “INSPECTION AND MAINTENANCE” section. *1 If the lithium-ion battery is completely discharged, the battery cannot be recharged. When replacing or disposing the lithium-ion bat- tery, consult an authorized SUZUKI dealer. 11-3...
Page 445 P21W • If you need to replace the following bulbs indicated in the above table, consult your SUZUKI dealer. *1 Since the lights are non-disassemble type, you cannot replace a bulb. Replace the target assembly if any bulb is defective.
Page 446 – • If you need to replace the following bulbs indicated in the above table, consult your SUZUKI dealer. *1 Since the lights are non-disassemble type, you cannot replace a bulb. Replace the target assembly if any bulb is defective.
Page 447 •Make sure they are tires of the same size, structure and load capacity as the originally installed tires. •Mount the snow tires on all four wheels. •Please understand that the maximum permissible speed of snow tires is generally less than the originally installed tires. Consult your SUZUKI dealer or supplier for further information. 11-6...
Page 448 6.2 L (10.9 Imp pt) (including reservoir tank) 5.5 L (9.7 Imp pt) (including reservoir tank) K14C engine SUZUKI LLC: Super (Blue) Coolant model 5.7 L (10.0 Imp pt) (including reservoir tank) 6.7 L (11.8 Imp pt) (including reservoir tank)
Page 449 ITEM: Recommended Fuel/Lubricants and Capacities (approx.) Manual transaxle oil M16A engine model 2.5 L (4.4 Imp pt) K14C engine model “SUZUKI GEAR OIL 75W” 2.5 L (4.4 Imp pt) K14D engine model 2.5 L (4.4 Imp pt) Automatic transaxle oil M16A engine model 5.8 L (10.2 Imp pt)
Page 450: Supplement
SUPPLEMENT SUPPLEMENT For Israel, Russia and Taiwan ........... 12-1 For Russia and Other Countries Adopting ERA-GLONASS ..........12-1 For Russia ................12-11 For Taiwan ................12-31...
Page 451: For Israel, Russia And Taiwan
SUPPLEMENT For Israel, Russia and Taiwan For Russia and Other Countries Adopting ERA-GLONASS Emergency road assistance - global navigation satellite system (ERA-GLONASS) is Theft Deterrent Light equipped according to the model of the vehicle. This system is equipped if “SOS” button and ERA-GLONASS microphone are equipped with the vehicle.
Page 452 EMERCOM center (112 ser- properly. Have function (4) Red indicator vice) of accident conditions. checked by an authorized SUZUKI (5) Cover (4) Emergency vehicle is dispatched. dealer. • For normal operating condition of The ERA-GLONASS (Emergency road the ERA-GLONASS, use SUZUKI assistance - global navigation satellite sys- genuine audio system.
Page 453 SUPPLEMENT Automatic operation mode Manual operation mode NOTE: (For both automatic and manual operation The ERA-GLONASS system is operated Open the cover (5) for manual operation. modes) when the ignition switch is turned to “ON” When the ignition switch is turned to “ON” •...
Page 454 Have your vehicle inspected by an authorized SUZUKI dealer soon. When the built-in battery is in the undercharged condition, replace the battery as soon as possible even though the remaining battery...
Page 455 If an accident occurs in the above condition, the indicator light goes out and the ERA-GLONASS system starts the automatic operation. #2 You can customize the system to stop blinking of the green indicator. Ask an authorized SUZUKI dealer for details.
Page 456 There may be malfunction of the ERA-GLONASS. (#1) buzzer) Have your vehicle inspected by an authorized SUZUKI dealer. 83RM12020 (#1) When Master warning indicator blinks, the red indicator light (4) in “SOS” button will also blink (approximately every 1 second).
Page 457 SUPPLEMENT 4) Release the parking brake and set the Cancellation of ERA-GLONASS How to Use Test Mode parking brake. Repeat this operation 3 times in total (the parking brake is set The operation can be canceled only when Using the test mode, the ERA-GLONASS finally).
Page 458 SUPPLEMENT Test call 7) The test call communication begins Normal function of the ERA-GLONASS automatically. The green indicator (3) system can be checked using the micro- will change the blinking interval to phone, speaker and the call center for test approximately every 1 second and the as follows.
Page 459 SUPPLEMENT Indicator light (in test mode) In the test mode, the indicator light in “SOS” button operates as follows according to the ERA-GLONASS operation state and communi- cation state. Green indicator Red indicator State Blinks Normal operation (Test mode). (approximately every 3 seconds) You speak over the microphone.
Page 460 SUPPLEMENT Triggering of Seat Belt Pretensioner Triggering of Side Curtain Airbags System in Case of Vehicle Rollover in Case of Vehicle Rollover The pretensioners are triggered in almost The side curtain airbags are triggered in all rollover situations in addition to severe almost all rollover situations in addition to side collision and frontal collision enough severe side collision.
Page 461: For Russia
SUPPLEMENT Periodic Maintenance Schedule For Russia (for Russia) - For M16A Engine Model Air Conditioning System “R” : Replace or Change NOTE: “I” : Inspect, clean, adjust, lubricate Your vehicle uses the air conditioning or replace as necessary refrigerant HFC-134a, commonly called “R-134a”.
Page 462 #1: Be sure to perform the engine coolant level check under the daily inspection in “OPERATING YOUR VEHICLE” section. If you use the engine coolant other than the SUZUKI LLC: Super (Blue) for replacement, follow the schedule of SUZUKI LLC: Stan- dard (Green).
Page 463 #1: Be sure to perform the engine coolant level check under the daily inspection in “OPERATING YOUR VEHICLE” section. If you use the engine coolant other than the SUZUKI LLC: Super (Blue) for replacement, follow the schedule of SUZUKI LLC: Stan- dard (Green).
Page 464 – – *6-8. Manual transaxle oil Genuine “SUZUKI GEAR OIL 75W” Inspect every 30000 km (18000 miles) or 24 months. Other than “SUZUKI GEAR OIL 75W” (I: 1st 15000 km only) – – – *6-9. Automatic transaxle Fluid leak check –...
Page 465 – – – *6-8. Manual transaxle oil Genuine “SUZUKI GEAR OIL 75W” Inspect every 30000 km (18000 miles) or 24 months. Other than “SUZUKI GEAR OIL 75W” (I: 1st 15000 km only) – – – – *6-9. Automatic transaxle Fluid leak check –...
Page 466 SUPPLEMENT Maintenance Recommended under Severe Driving Conditions (for Russia) - For M16A Engine Model Follow this schedule if your vehicle is mainly operated under one or more of the following conditions: • When most trips are less than 6 km (4 miles). •...
Page 467 #1: Be sure to perform the engine coolant level check under the daily inspection in “OPERATING YOUR VEHICLE” section. If you use the engine coolant other than the SUZUKI LLC: Super (Blue) for replacement, follow the schedule of SUZUKI LLC: Stan- dard (Green).
Page 468 #1: Be sure to perform the engine coolant level check under the daily inspection in “OPERATING YOUR VEHICLE” section. If you use the engine coolant other than the SUZUKI LLC: Super (Blue) for replacement, follow the schedule of SUZUKI LLC: Stan- dard (Green).
Page 469 – – *6-8. Manual transaxle oil Genuine “SUZUKI GEAR OIL 75W” Inspect every 30000 km (18000 miles) or 24 months. Replace every 60000 km (36000 miles) or 48 months. Other than “SUZUKI GEAR OIL 75W” – – – – –...
Page 470 – *6-8. Manual transaxle oil Genuine “SUZUKI GEAR OIL 75W” Inspect every 30000 km (18000 miles) or 24 months. Replace every 60000 km (36000 miles) or 48 months. Other than “SUZUKI GEAR OIL 75W” – – – – *6-9. Automatic transaxle Fluid leak check –...
Page 471 SUPPLEMENT Periodic Maintenance Schedule (for Russia) - For K14C Engine Model “R” : Replace or Change “I” : Inspect, clean, adjust, lubricate or replace as necessary NOTE: This table shows the service schedule up to 120000 km (72000 miles). Beyond 120000 km (72000 miles), perform the same services at the same intervals shown in the chart.
Page 472 #1: Be sure to perform the engine coolant level check under the daily inspection in “OPERATING YOUR VEHICLE” section. If you use the engine coolant other than the SUZUKI LLC: Super (Blue) for replacement, follow the schedule of SUZUKI LLC: Stan- dard (Green).
Page 473 #1: Be sure to perform the engine coolant level check under the daily inspection in “OPERATING YOUR VEHICLE” section. If you use the engine coolant other than the SUZUKI LLC: Super (Blue) for replacement, follow the schedule of SUZUKI LLC: Stan- dard (Green).
Page 474 Genuine “SUZUKI GEAR OIL 75W” Inspect every 30000 km (18000 miles) or 24 months. Other than “SUZUKI GEAR OIL 75W” First time only: Inspect at 10000 km (6000 miles) or 12 months. Replace every 40000 km (24000 miles) or 36 months.
Page 475 Genuine “SUZUKI GEAR OIL 75W” Inspect every 30000 km (18000 miles) or 24 months. Other than “SUZUKI GEAR OIL 75W” First time only: Inspect at 10000 km (6000 miles) or 12 months. Replace every 40000 km (24000 miles) or 36 months.
Page 476 SUPPLEMENT Maintenance Recommended under Severe Driving Conditions (for Russia) - For K14C Engine Model Follow this schedule if your vehicle is mainly operated under one or more of the following conditions: • When most trips are less than 6 km (4 miles). •...
Page 477 #1: Be sure to perform the engine coolant level check under the daily inspection in “OPERATING YOUR VEHICLE” section. If you use the engine coolant other than the SUZUKI LLC: Super (Blue) for replacement, follow the schedule of SUZUKI LLC: Stan- dard (Green).
Page 478 #1: Be sure to perform the engine coolant level check under the daily inspection in “OPERATING YOUR VEHICLE” section. If you use the engine coolant other than the SUZUKI LLC: Super (Blue) for replacement, follow the schedule of SUZUKI LLC: Stan- dard (Green).
Page 479 Genuine “SUZUKI GEAR OIL 75W” Inspect every 30000 km (18000 miles) or 24 months. Replace every 60000 km (36000 miles) or 48 months. Other than “SUZUKI GEAR OIL 75W” Replace every 30000 km (18000 miles) or 24 months. *6-9. Automatic transaxle Fluid leak check Inspect every 30000 km (18000 miles) or 24 months.
Page 480 Genuine “SUZUKI GEAR OIL 75W” Inspect every 30000 km (18000 miles) or 24 months. Replace every 60000 km (36000 miles) or 48 months. Other than “SUZUKI GEAR OIL 75W” Replace every 30000 km (18000 miles) or 24 months. *6-9. Automatic transaxle Fluid leak check Inspect every 30000 km (18000 miles) or 24 months.
Page 481: For Taiwan
SUPPLEMENT Gasoline-ethanol blends For Taiwan Blends of unleaded gasoline and ethanol NOTICE (grain alcohol), also known as gasohol, are The fuel tank has an air space to commercially available in some areas. Fuel Recommendation allow for fuel expansion in hot Blends of this type may be used in your weather.
Page 482: Child Restraint System
SUPPLEMENT Warning Label for Front Passen- Child Restraint System Child Restraint ger's Front Airbag The suitability of each passenger’s seat CAUTION position for carriage of children and fitting of child restraint system is shown in the Adjust height head table below. restraint or remove it for fitting the child restraint, as necessary.
Page 483 SUPPLEMENT (#1) (#1) It is suitable for universal cate- gory of child restraint system fixed with the vehicle seat belt. It is suitable for ISOFIX child restraint system. This seat is equipped with Top tether anchorage point. It is not suitable for child restraint system.
Page 484 SUPPLEMENT Detailed information for child restraint system Seating position Seat position number Seating position suitable for universal belted (YES/NO) i-Size seating position (YES/NO) Seating position suitable for lateral fixture (L1/L2) Suitable rear-facing fixture R1,R2,R3 R1,R2,R3 (R1/R2/R3) Suitable front-facing fixture F2X,F2,F3 F2X,F2,F3 (F2X/F2/F3) Key of letters to be inserted in the above table...
Page 485 SUPPLEMENT If your child restraint system has no size class (or if you cannot find information in the following table), refer to the child restraint system suitability information for the vehicle or ask the retailer of your child seat. Mass group Size class Fixture Description...
Page 486 SUPPLEMENT Audio System (if equipped) EXAMPLE 61MM0A140 AM/FM CD PLAYER 12-36...
Page 487 • Set the sound volume to a level unit, or lubricate the rotating parts. that will allow you to continue to be aware of road and traffic condi- Please bring the unit to an authorized tions while driving. SUZUKI dealer. 12-37...
Page 488 SUPPLEMENT Proper way to hold Removing the disc the compact disc 52D347 52D348 To remove fingermarks and dust, use a Never stick labels on the surface of the soft cloth, and wipe in a straight line from compact disc or write on the surface with a the center of the compact disc to the cir- pencil or pen.
Page 489 SUPPLEMENT 52D350 52D351 Do not use compact discs that have large Do not expose compact discs to direct sun- scratches, are misshaped, or cracked, etc. light or any heat source. Use of such discs will cause damage or prevent the system from operating prop- NOTE: erly.
Page 490 SUPPLEMENT Part 15 of the FCC Rules FCC ID: FCC Warning: ® The Bluetooth word mark and logo are ACJ932YEP0PTA606 Any unauthorized changes or modifica- registered trademarks and are owned by tions to this equipment would void the the Bluetooth SIG, Ink. user’s authority to operate this device.
Page 491 SUPPLEMENT This equipment has been tested and found • Reorient or relocate the receiving anten- to comply with the limits for a Class B digi- tal device, pursuant to part 15 of the FCC • Increase the separation between the Rules.
Page 492: Listening To The Radio
SUPPLEMENT Listening to the Radio Display EXAMPLE 68LM561 (1) “FM” button (2) “AM” butto (3) UP button (4) DOWN button (5) “TUNE/FLD PUSH SOUND” knob (6) PRESET buttons ([1] to [6]) (7) “AS” button (A) Band (B) Frequency 61MM0A142 12-42...
Page 493 SUPPLEMENT Selecting the reception band Auto store Auto store mode on/off Press the “FM” button (1). Hold down “AS” button (7) for 2 seconds or Press “AS” button (7). Each time the button is pressed, the recep- longer. Each time the button is pressed, the mode tion band will change as follows: 6 stations in good reception will automati- is switched as follows:...
Page 494 SUPPLEMENT Display Listening to a CD EXAMPLE (1) Insertion slot (2) EJECT button (3) “CD” button (4) UP button (5) DOWN button (6) “RPT” button (7) “RDM” button (8) “DISP” button (A) Track number (B) Play time NOTE: This product does not support 8 cm CD (sometimes called as “mini single CD”, “3- inch CD”, “CD3”, etc.).
Page 495 SUPPLEMENT NOTICE NOTICE • Never insert your finger or hand If you forcefully try to push an into the CD insertion slot. Never ejected CD inside the unit before auto insert foreign objects. reloading, the disc surface might be • Never insert a CD with glue coming scratched.
Page 496 SUPPLEMENT Random playback Display change Press “RDM” button (7). Press “DISP” button (8). Each time the button is pressed, the mode Each time the button is pressed, display will change as follows: will change as follows: Play time TRACK RANDOM Disc title Track title •...
Page 497 SUPPLEMENT Periodic Maintenance Schedule (for Taiwan) - For K14C Engine Model “R”: Replace or Change “I”: Inspect, clean, adjust, lubricate or replace as necessary NOTE: This table shows the service schedule up to 120000 km (72000 miles). Beyond 120000 km (72000 miles), perform the same services at the same intervals shown in the chart.
Page 498 #1: Be sure to perform the engine coolant level check under the daily inspection in “OPERATING YOUR VEHICLE” section. If you use the engine coolant other than the SUZUKI LLC: Super (Blue) for replacement, follow the schedule of SUZUKI LLC: Stan- dard (Green).
Page 499 #1: Be sure to perform the engine coolant level check under the daily inspection in “OPERATING YOUR VEHICLE” section. If you use the engine coolant other than the SUZUKI LLC: Super (Blue) for replacement, follow the schedule of SUZUKI LLC: Stan- dard (Green).
Page 500 SUPPLEMENT Interval: This interval should be judged by km (x1000) odometer reading or months, whichever miles (x1000) comes first. months BRAKE *5-1. Brake discs and pads Brake drums and shoes (if equipped) Inspect every 30000 km (18000 miles) or 24 months. *5-2.
Page 501 SUPPLEMENT Interval: This interval should be judged by km (x1000) odometer reading or months, whichever miles (x1000) comes first. months BRAKE *5-1. Brake discs and pads Brake drums and shoes (if equipped) Inspect every 30000 km (18000 miles) or 24 months. *5-2.
Page 502 SUPPLEMENT Maintenance Recommended under Severe Driving Conditions (for Taiwan) - For K14C Engine Model Follow this schedule if your vehicle is mainly operated under one or more of the following conditions: • When most trips are less than 6 km (4 miles). •...
Page 503 #1: Be sure to perform the engine coolant level check under the daily inspection in “OPERATING YOUR VEHICLE” section. If you use the engine coolant other than the SUZUKI LLC: Super (Blue) for replacement, follow the schedule of SUZUKI LLC: Stan- dard (Green).
Page 504 #1: Be sure to perform the engine coolant level check under the daily inspection in “OPERATING YOUR VEHICLE” section. If you use the engine coolant other than the SUZUKI LLC: Super (Blue) for replace- ment, follow the schedule of SUZUKI LLC: Standard (Green).
Page 505 SUPPLEMENT Interval: This interval should be judged by km (x1000) odometer reading or months, whichever miles (x1000) comes first. months BRAKE *5-1. Brake discs and pads – – – Brake drums and shoes (if equipped) Inspect every 30000 km (18000 miles) or 24 months. *5-2.
Page 506 SUPPLEMENT Interval: This interval should be judged by km (x1000) odometer reading or months, whichever miles (x1000) comes first. months BRAKE *5-1. Brake discs and pads – – – Brake drums and shoes (if equipped) Inspect every 30000 km (18000 miles) or 24 months. *5-2.
Page 507 SUPPLEMENT MEMO 12-57...
Page 508: Index
INDEX INDEX Average Speed ..............2-70 Symbols Battery...................7-36 “AIRBAG” Light ............2-53, 2-93 ® Bluetooth audio..............5-76 “ENG A-STOP OFF” Light........... 2-98 ® Bluetooth hands-free ............5-68 “ENG A-STOP” Indicator Light........... 2-98 Brake Assist System........... 3-74, 3-98 “FAR/NEAR setting” switch..........3-96 Brake Fluid................7-29 “Radar Brake Support OFF”...
Page 509 INDEX Coolant Level Check ............7-20 Engine Hood ................5-2 Coolant Replacement ............7-22 Engine Oil and Filter ............7-14 Corrosion Prevention ............9-1 Engine Oil Consumption ............3-2 Cruise Control..............3-58 Engine Serial Number............10-1 Cup Holder and Storage Area..........5-13 Engine Switch.................
Page 510 INDEX Front Position Light............. 7-46 Heating and Air Conditioning System........5-25 Front Seat Back Pocket............5-16 Heating System ..............5-27 Front Seat Heater..............2-25 High-mount Stop Light ............7-52 Front Seats ................2-22 Highway Driving ..............4-4 Front Turn Signal Light ............7-46 Hill Hold Control System .............3-78 Fuel Filler Cap ................
Page 511 INDEX Maintenance Recommended under Severe Driving Conditions (except for Russia and Taiwan) ....... 7-8 Jacking Instructions.............. 8-1 Maintenance Recommended under Severe Driving Jump Starting Instructions ........... 8-8 Conditions (for Russia) - For K14C engine model ..12-26 Maintenance Recommended under Severe Driving Keyless Entry System Transmitter ......
Page 512 INDEX Periodic Maintenance Schedule Roof Rails or Roof Rack Anchors ........5-20 (except for Russia and Taiwan)........... 7-3 Running-in ................4-2 Periodic Maintenance Schedule (for Russia) - For K14C engine model ......12-21 Seat Adjustment............2-22, 2-26 Periodic Maintenance Schedule Seat Belt Inspection.............2-38 (for Russia) - For M16A engine model ......
Page 513 Sun Visor ................5-4 Universal serial bus (USB) socket........5-15 Sunroof ................... 5-9 Using the Transaxle .............3-20 Supplemental Restraint System (airbags)......2-52 SUZUKI SAFTY SUPPORT ..........3-87 Vehicle Cleaning ..............9-2 Vehicle Identification ............10-1 Tachometer ................2-67 Vehicle Loading..............6-1 Tailgate ...................
Page 514 When you intend to use RF transmitting equipment in your vehicle, we strongly recommend that you select the equipment which con- forms to applicable rules or regulations in your country, and consult a SUZUKI dealer or qualified service technician for advice.
Page 515 Specific conditions for installation NOTE: 1) Antenna cable shall be routed as far as possible from the vehicle electrical and electronic systems and wiring in the vehicle. 2) Power cable of transmitter shall be properly connected to lead-acid battery in the vehicle. NOTICE Before using your vehicle, check if there is no interference to all electrical devices on your vehicle for both Standby mode and Transmitting mode of the RF transmitting equipment.
Page 519 ț...
Page 526: Technical Data
Robert Bosch GmbH Addendum Chassis Systems Control PO Box 1661 71226, Leonberg Tel +49 711/811-0 www.bosch.co.jp Technical data Product model name: MRRevo14F Frequency Band: 76-77 GHz Maximum Transmit Power: 32 dBm Nominal radiated power e.i.r.p. (peak detector): Maximum Transmit Power: 27 dBm Nominal radiated power e.i.r.p.
Page 532 Robert Bosch GmbH Addendum Chassis Systems Control PO Box 1661 71226, Leonberg Tel +49 711/811-0 Technical data Product model name: Frequency Band: 76-77 GHz Maximum Transmit Power: Nominal radiated power e.i.r.p. (peak detector): Maximum Transmit Power: Nominal radiated power e.i.r.p. (RMS detector):...
Page 534 MODEL NAME : S57L0 S180052024 MODEL NAME : R57L1 MODEL NAME : TWK1A001 TIS-15 MODEL NAME : I61M0 MODEL NAME : T61M0 40398036...
Page 538 S180052024 AGREE PAR L’ANRT MAROC Numéro d’agrément : MR 17719 ANRT 2018 Date d’agrément : 16/10/2018 TIS-15 AGREE PAR L’ANRT MAROC Numéro d’agrément : MR 17386 ANRT 2018 Date d’agrément : 30/08/2018 40398036 AGREE PAR L’ANRT MAROC Numéro d’agrément : MR 5837 ANRT 2010 Date d’agrément : 08/10/2010...
Page 540 ä ä ä ä ü b é é 'éq é à é é b à ' é ó U á ó ящ ч ъ ъж ъ я я я ъ ж я Με την παρούσα ο η δηλώνει ότι ο ραδιοεξοπλισμός πληροί...
Page 542 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC CAUTION Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
Page 543 Microsoft WMT License This product is protected by certain intellectual property rights of Microsoft Corporation and third parties. Use or distribution of such technology outside of this product is prohibited without a license from Microsoft or an authorized Microsoft subsidiary and third parties. Windows Media is either a registered trademark or trademark of Microsoft Corporation in the United States and/or other countries.
Page 544 CZ36E1AE CZ36E1AE...
Page 546 Інтернешнл 04073 м.Київ, пр -кт.Степана Бандери, 22-А U Panasonicu 266, Staré Čívice 53006 Pardubice Crech Republic Bluetooth радіочастот, в якій працює радіообладнання; 2402-2480MHz потужність випромінювання в смузі радіочастот, в якій працює радіообладнання; 2.5mW cправжнім Panasonic Corporation заявляє, що тип радіообладнання [ CQ- JZ04F0AE,CQ-CZ36E1A ] відповідає...
Page 556 MEMO...
Page 557 MEMO...
Page 558 BATTERY LABEL SYMBOL MEANINGS No smoking, no naked flames, no sparks Battery acid Shield eyes Note operating instructions Keep away from children Explosive gas Prepared by July, 2021 Part No. 99011-83RB4-01E Printed in Hungary TP556...
