n52te USER MANUAL
Software Installation
1. Insert the n52te Installation CD into your PC's drive.
2. The software should start automatically. If it does not, click the "Start"
button and choose "Run". Click "Browse" and choose your CD drive.
Select "setup.exe" and click "OK".
3. Follow the on-screen instructions to continue with the
software installation.
4. After the installation is complete, select "Finish" and reboot
when prompted.
5. After your PC boots up, connect the n52te to an available USB port
on your computer.
6. If you have Windows
XP and you are prompted to allow "Unsigned
XP and you are prompted to allow "Unsigned
®
®
®
Drivers", click "Yes" to proceed.
7. If you have Windows Vista
and you are prompted to verify the
and you are prompted to verify the
®
®
®
publisher of the driver, click "Install this driver anyway" to proceed.
8. Once the drive have been initialized, please check to see if the
installation was successful by proceeding to the next section of the
manual titled "Installation Verification".
Installation Verification
1. You will need to confirm that the installation was successful through
the Device Manager.
2. To get to Device Manager, right-click on "My Computer" and
left-click on "Properties". Then left-click on "Hardware" and then
on the "Device Manager" button.
3. Check to make sure that the Device Manager list includes:
a) A new entry under Human Interface Devices, "n52te".
b) A new entry under Human Interface Devices, "Virtual HID Device".
CONFIGURING n52te
n52te Editor
The n52te Editor is the tool used to customize and program custom
functions to your n52te. Some examples of programmable functions are:
Single Key – Make a button on the controller work like a keyboard key.
Macros – Record a sequence of keyboard keystrokes, and/or
mouse-button presses that can be saved and played back by the n52te
at a later time.
Keymap Selector – Switch between the three color Keymaps (Blue,
Green, Red) and effectively triple the number of functions you can
program in a single profile. The default Keymap is Blue.
Mouse – Program n52te to emulate mouse clicks or
scroll-wheel functions.
Polling Rate – Sets the polling rate to: 125Hz, 500Hz, or 1000Hz.
Note: You need to reduce the polling rate if your computer does not
support USB 2.0.
Razer Synapse™ – Store one of your profiles in the onboard memory to
take it with you! The profile stored with Razer Synapse will be available
on any PC, even without the software installed.
Page
1

Advertisement

loading

Related Manuals for Belkin F8GFPC200

Summary of Contents for Belkin F8GFPC200

  • Page 1 n52te USER MANUAL CONFIGURING n52te Software Installation n52te Editor 1. Insert the n52te Installation CD into your PC's drive. The n52te Editor is the tool used to customize and program custom functions to your n52te. Some examples of programmable functions are: 2.

  • Page 2: Creating A Profile

    Main Screen of the n52te Editor CREATING A PROFILE This figure shows the n52te Editor screen for the Nostromo n52 Tournament Edition. A profile is a set of remapped buttons and/or programmable functions for a specific application that can be saved and recalled at a later time.
  • Page 3 Macro Editor Insert Delay – Allows you to manually insert a time delay in the “Current Macros are recorded sequences of keyboard keystrokes and/or Macro Assignment” sequence list. Simply select an event, then choose mouse-button presses that can be saved and played back by the the desired duration and click on the “Insert Delay”...

  • Page 4: Creating And Assigning A Macro

    MACRO BEHAVIOR KEYMAPS These three settings determine how the macro will be played back The n52te Editor allows you to program three Keymaps: Blue, Red, and when triggered. Green. A Keymap allows you to add another layer of programming to each button. In order to switch between Keymaps during play, you 1.

  • Page 5: Profile Management

    PROFILE MANAGEMENT Profile Selection and Razer Synapse™ You can manage profiles by using the following buttons on the main Editor Window. The “Profile Selection” pane displays the entire library of custom profiles located on your PC. New – Creates a new profile with default name “Untitled Profile 0x”. Thereafter, you can specify a name for the profile.
  • Page 6 HELP ADJUSTMENTS Thumb-Stick If you have any problems using the n52te, simply click the “Help” tab to The n52te comes equipped with a removable thumb-stick for access the help file for any troubleshooting. customized control of the 8-way D-pad. Simply pull the thumb-stick up away from the D-pad to remove it if preferred.
  • Page 7 What is not covered by this warranty? All above warranties are null and void if the Belkin product is not provided to Belkin for inspection upon Belkin’s request at the sole expense of the purchaser, or if Belkin determines that the Belkin product has been improperly installed, altered in any way, or tampered with.
